User Manual
SPC-618WE-PUD
Touch Panel Computer with
Intel® 13
th
Gen. Core™ i CPU and
IECEx/ATEX Explosion-Protected
Certification
製造商: 研華股份有限公司
地址:
台北市內湖區陽光街365巷33號
電話:
02-27927818

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPC-618WE-PUD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech SPC-618WE-PUD

Summary of Contents for Advantech SPC-618WE-PUD

  • Page 1 User Manual SPC-618WE-PUD Touch Panel Computer with Intel® 13 Gen. Core™ i CPU and IECEx/ATEX Explosion-Protected Certification 製造商: 研華股份有限公司 地址: 台北市內湖區陽光街365巷33號 電話: 02-27927818...
  • Page 2 The documentation and the software included with this product are copyrighted 2023 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.

  • Page 3: Product Warranty (2 Years)

    Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.

  • Page 4: Technical Support And Assistance

    警告使用者 警告：為避免電磁干擾，本產品不應安裝或使用於住宅環境。 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service cen- ter for technical support if you need additional assistance. Please have the following information ready before you call: –...

  • Page 5: Warnings, Cautions, And Notes

    – The equipment shall be mounted in an enclosure that provides a degree of protection not less than IP6X in accordance with EN / IEC 60079-31 for category 3D Zone 22, EPL – Subject equipment must be installed in a low risk of mechanical danger location. –...
  • Page 6 Keep this User Manual for later reference. Conservez ce manuel d'utilisation pour référence ultérieure. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. Débranchez cet équipement de toute prise secteur avant de le nettoyer. Utilisez un chiffon humide.
  • Page 7 AVIS DE NON-RESPONSABILITÉ : Ces instructions sont fournies conformément à la norme CEI 704-1. Advantech décline toute responsabilité quant à l'exactitude des déclarations contenues dans le présent document. 24. This product is not intended for use by children (this product is not a toy).
  • Page 8 請妥善保存此用戶手冊供日後參考。 用濕抹布清洗設備前，請從插座拔下電源線。請不要使用液體或去汙噴霧劑清洗設 備。 對於使用電源線的設備，設備周圍必須有容易接觸到的電源插座。 請不要在潮濕環境中使用設備。 請在安裝前確保設備放置在可靠的平面上，意外跌落可能會導致設備損壞。 設備外殼的開口是用於空氣對流，從而防止設備過熱。請不要覆蓋這些開口。 當您連接設備到電源插座上前，請確認電源插座的電壓是否符合要求。 請將電源線佈置在人們不易絆到的位置，並不要在電源線上覆蓋任何雜物。 10. 請注意設備上的所有警告和注意標示。 11. 如果長時間不使用設備，請將其同電源插座斷開，避免設備被超標的電壓波動損壞。 12. 請不要讓任何液體流入通風口，以免引起火災或者短路。 13. 請不要自行打開設備。為了確保您的安全，請由經過認證的工程師來打開設備。 14. 如遇下列情況，請由專業人員來維修： ◼ 電源線或者插頭損壞； ◼ 設備內部有液體流入； ◼ 設備曾暴露在過於潮濕的環境中使用； ◼ 設備無法正常工作，或您無法通過用戶手冊來使其正常工作； ◼ 設備跌落或者損壞； ◼ 設備有明顯的外觀破損。 15. 請不要把設備保存在超出我們建議的溫度範圍的環境，即不要低於 -30°C （-22°F） 或高於 70°C （158°F） ，否則可能會損壞設備。 16. 注意：如果電池放置不正確，將有爆炸的危險。因此，只可以使用製造商推薦的同一 種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池。...

  • Page 9: Table Of Contents

    Content Chapter 1..........1 Introduction ....................2 Specifications ..................2 1.2.1 General ..................2 1.2.2 System Hardware ..............2 1.2.3 Certification and Environment ..........3 1.2.4 Power ..................3 External I/O ....................3 LCD & Touch Specification ..............4 Table 1.1: Specifications ............4 Dimensions ....................
  • Page 10 Table A.4: 5G Module Mode Select ........40 Table A.5:Remote Button Connector (REMOTE1) ....41 Table A.6: Internal USB Connector (USB2H1) ...... 41 Table A.7: SATA Power Connector (SATAPWR1) ....42 Table A.8: iDoor Power Connector (DCOUT1) ...... 42 Table A.9: RTC Battery Connector (BAT1) ......43 Table A.10: Internal COM Port Connector (COM2) ....

  • Page 11: Chapter 1

    Chapter General Information SPC-618WE User Manual...

  • Page 12: Introduction

    Introduction The SPC-618WE series is a touch panel computer equipped with 13th Generation Intel Core processor and certified with ATEX explosion protection. ◼ Powered by 13th Gen. Intel® Core™ i7-1365URE deca-core processor Single DDR5 slot built-in with 32GB memory ◼ LAN, PoE, and isolated serial port ◼...

  • Page 13: Certification And Environment

    1.2.3 Certification and Environment Certification ◼ BSMI ◼ ◼ ◼ FCC Class A ◼ CB/UL ◼ IECEx/ATEX explosion-protected certification ◼ Class 1 Division 2 explosion-protected certification ◼ IP66-rated front panel Environment ◼ Operating Temperature: -20~60 °C (-4~140 °F) ◼ Storage Temperature: -30~70 °C (-22~158 °F) ◼...

  • Page 14: Lcd & Touch Specification

    LCD & Touch Specification Table 1.1: Specifications Display Size 18.5" Display Type FHD TFT LED LCD Aspect Ratio 16:9 Max. Resolution 1920 x 1080 LCD Panel Max. Color 16.7M Luminance 350 cd/m² Viewing Angle (H/V) 178°/178° Backlight Life 50,000 hr Contrast Ratio 1000:1 Type...

  • Page 15: Dimensions

    Dimensions SPC-618WE touch panel computer ◼ Dimensions (W x H x D): 488 x 309 x 80 mm (19.21 x 12.16 x 3.15 inch) SPC-618WE User Manual...
  • Page 16 Computing Unit: Display Module: SPC-618WE User Manual...

  • Page 17: Led Indicators

    LED Indicators Indicator Default Status (ErP Enable) Status 2 (ErP Disable) Green Normal Powered-On State Normal Powered-On State Orange Sleep (S3) / Hibernate (S4) Sleep (S3) / Hibernate (S4) / Shutdown(S5) No Light Shutdown(S5)/Power Off Power Off SPC-618WE User Manual...

  • Page 18: Chapter 2

    Chapter System Setup SPC-618WE User Manual...

  • Page 19: Transport And Unpacking

    Transport and Unpacking 2.1.1 Transport When accepting a delivery, please check the packaging for visible transport dam- age and check the delivery for completeness by comparing it with your order. If you notice any shipping damage or inconsistencies between the contents and your order, please inform the responsible delivery service immediately.

  • Page 20: Driver Installation

    With administrator-level privileges, run the installer for the Advantech watchdog driver. Below is an example of the Advantech watchdog driver setup. To stop the setup process at any time, click the “Cancel” button on the pop-up screen. The setup program will stop the procedure automatically.
  • Page 21 Wait until the Advantech Watchdog Driver Setup Wizard has completed the instal- lation. Click the Install button to continue the installation of the Advantech watchdog driver software. SPC-618WE User Manual...

  • Page 22: Cabinet Installation And Earth Grounding Setup

    Click the Restart or Close button on the Advantech Watchdog Driver Setup Wiz- ard pop-up screen to complete the setup. Cabinet Installation and Earth Grounding Setup Follow these steps to set up the SPC-618WE system, ensuring that the Ground pin of the SPC-618WE system is properly connected to the earth ground. This...

  • Page 23: System Wiring

    2.3.2 System Wiring Ground the cabinet to earth. Ensure proper grounding for all cabinets. Connect the power supply ground to the cabinet. Connect the SPC-618WE system's ground pin to the cabinet. If necessary, connect I/O to the controller. Connect the power supply's V+ and V- to the SPC-618WE system. Proceed step by step through steps 1 to 6, then power on the SPC-618WE system.

  • Page 24: Panel Mounting

    The SPC is an industrial grade product, designed to prevent external interference and the possibility of electric shock. To complete the isolation design, we need to consider the following: The Ethernet is isolated, a LAN connection will not impact the isolation de- sign.
  • Page 25 Figure 2.5 Panel Mounting (1) Retrieve the clamps and long screws from the accessory pack. Hook the clamp into the holes around the four sides of the bezel. Figure 2.6 Panel Mounting (2) Fasten the screws with a torque of 2 kgf-cm. These screws will push the mounting panel, ensuring a secure and stable unit.0.

  • Page 26: Chapter 3

    Chapter BIOS Setup SPC-618WE User Manual...

  • Page 27: Bios Setup

    BIOS supports your CPU. If there is no num- ber assigned to the patch code, contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that the CPU status is valid.

  • Page 28: Main Setup

    3.2.1 Main Setup Upon entering the BIOS Setup Utility, users will be on the Main setup screen. At any point during the configuration, users can return to the Main setup screen by selecting the Main tab. There are two Main setup options, which are described in this section.

  • Page 29: Advanced Bios Features Setup

    3.2.2 Advanced BIOS Features Setup Select the Advanced tab from theSPC-618WE setup screen to enter the Ad- vanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as ACPI Settings and hit <enter> to go to the sub menu for that item.
  • Page 30 3.2.2.1 CPU Configuration SPC-618WE User Manual...
  • Page 31 3.2.2.2 PCH-FW Configuration ◼ ME State When this item is disabled, ME will be put into ME Temporarily Disabled Mode. ◼ Manageability Features State This item allows users to enable/disable Intel® Manageability features. Note: This option disables/enables Manageability Features in FW. To disa- ble, the supported platform must be in an un-provisioned state first.
  • Page 32 3.2.2.3 Trusted Computing ◼ TPM Device Selection This item allows users to select TPM device: fTPM or dTPM. fTPM: Enables fTPM. dTPM: Disables fTPM and enable dTPM. Warning! fTPM/dTPM will be disabled and all data saved on it will be lost. ◼...
  • Page 33 ◼ Physical Presence Spec Version This item allows users to enable support for PPI spec version 1.2 or 1.3. Note: Some HCK tests may not support version 1.3. ◼ Device Select TPM 1.2: select this to restrict support to TPM 1.2 devices. TPM 2.0: select this to restrict support to TPM 2.0 devices Auto: select this to support both;...
  • Page 34 3.2.2.5 NCT6126D Super I/O Configuration ◼ Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA). ◼ Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB). SPC-618WE User Manual...
  • Page 35 3.2.2.6 Hardware Monitor Configuration SPC-618WE User Manual...
  • Page 36 3.2.2.7 S5 RTC Wake Settings ◼ Wake System from S5 This item allows users to enable or disable system wake on alarm event. Select FixedTime, the system will wake on the hr:min:sec specified. Select DynamicTime, the system will wake on the current time + increased mi- nute(s).
  • Page 37 3.2.2.8 Intel TXT Information SPC-618WE User Manual...
  • Page 38 3.2.2.9 USB Configuration ◼ Legacy USB Support Enables Legacy USB support. The AUTO option disables legacy support if no USB devices are connected. The DISABLE option will keep USB devices available only for EFI applications. ◼ XHCI Hand-off This is a workaround of 0 Secs without XHCI hand-off support. The XHCI ownership change should be claimed by XHCI driver.
  • Page 39 3.2.2.10 Network Stack Configuration ◼ Network Stack This item allows users to enable or disable the UEFI network stack. SPC-618WE User Manual...
  • Page 40 3.2.2.11 NVMe Configuration SPC-618WE User Manual...

  • Page 41: Chipset Configuration

    3.2.3 Chipset Configuration 3.2.3.1 System Agent (SA) Configuration ◼ Memory Configuration This submenu allows users to view the memory parameters. ◼ Graphics Configuration This submenu allows users to set graphics configuration parameters ◼ VMD Setup Menu This submenu allows users to set VMD configuration parameters ◼...
  • Page 42 3.2.3.2 PCH-IO Configuration ◼ PCI Express Configuration This submenu allows users to set the PCI Express settings. ◼ SATA Configuration This submenu allows users to set the SATA device settings. ◼ USB Configuration This submenu allows users to set the USB settings. ◼...

  • Page 43: Security

    ◼ SPD Write Disable This item allows users to enable or disable the setting of SPD Write Disable. For security recommendations, SPD write disable bit must be set. 3.2.4 Security ◼ Administrator Password Set Administrator Password Secure Boot ◼ This item allows users to access a submenu to configure secure boot set- tings.

  • Page 44: Boot

    3.2.5 Boot ◼ Setup Prompt Timeout This item allows users to set the number of seconds to wait for setup activa- tion key. 65535 (oxFFFF) means indefinite waiting. ◼ Bootup NumLock State This item allows users to select the keyboard NumLock state. Quiet Boot ◼...

  • Page 45: Save & Exit

    3.2.6 Save & Exit ◼ Save Charges and Exit This item allows you to exit system setup after saving the changes. ◼ Discard Changes and Exit This item allows you to exit system setup without saving any changes. ◼ Save Changes and Reset This item allows you to reset the system after saving the changes.

  • Page 46: Mebx

    3.2.7 MEBx ◼ Intel(R) ME Password This item allows you to login MEBx by entering a password. SPC-618WE User Manual...
  • Page 47 Appendix Connectors SPC-618WE User Manual...

  • Page 48: Jumper And Connector Location

    Jumper and Connector Location A.1.1 Board Layout Figure A.1 Board Layout - Top View Figure A.2 Board Layout - Bottom View Table A.1: Board Placement Place Function JCMOS1 Clear CMOS jumper PSON1 AT/ATX jumper P68, P22, P20, P38 5G module jumper REMOTE1 Remote button connector SPC-618WE User Manual...
  • Page 49 USB2H1 Internal USB connector SATAPWR1 SATA power connector DCOUT1 iDoor power connector BAT1 RTC battery connector COM1 COM1 RS-232/422/485 connector COM2 Internal COM2 RS-232/422/485 connector SPK1 Speaker connector DCIN1 Power input connector USB2C1 USB 2.0 connector USB3C1 USB 3.0 connector LAN12 LAN RJ45 connectors TYPEC1...
  • Page 50 A.2.1 AT/ATX Select (PSON1) Table A.3: AT/ATX Select Description This jumper is used to select power on mode Default (1-2) (1-2) AT (Default) (2-3) (1-2) AT power (2-3) ATX power A.2.2 5G Module Mode Select (P68, P22, P20, P38) Table A.4: 5G Module Mode Select Description This switch is used to select 5G module mode Default...

  • Page 51: Connector Pin Definition

    Connector Pin Definition A.3.1 Remote Button Connector (REMOTE1) Table A.5:Remote Button Connector (REMOTE1) Signal ATX_PWRBTN# A.3.2 Internal USB Connector (USB2H1) Table A.6: Internal USB Connector (USB2H1) Signal SPC-618WE User Manual...
  • Page 52 A.3.3 SATA Power Connector (SATAPWR1) Table A.7: SATA Power Connector (SATAPWR1) Signal +V12 A.3.4 iDoor Power Connector (DCOUT1) Table A.8: iDoor Power Connector (DCOUT1) Signal DCIN DCIN SPC-618WE User Manual...

  • Page 53: Rtc Battery Connector (Bat1)

    A.3.5 RTC Battery Connector (BAT1) Table A.9: RTC Battery Connector (BAT1) Signal +VBAT A.3.6 Internal RS-232/422/485 Connector (COM2) Table A.10: Internal COM Port Connector (COM2) Signal DCD# DTR# RTS# CTS# SPC-618WE User Manual...

  • Page 54: Speaker Connector (Spk1)

    A.3.7 COM1 RS-232/422/485 Connector (COM1) Table A.11: COM1 RS-232/422/485 Connector (COM1) RS232 RS422 RS485 Data- Data+ A.3.8 Speaker Connector (SPK1) Table A.12: Speaker Connector (SPK1) Signal SPC-618WE User Manual...
  • Page 55 A.3.9 Power Input Connector (DCIN1) Table A.13: Power Input Connector (DCIN1) Signal Power In V+ Power In V- (GND) GND_EARTH A.3.10 M.2 M-Key Connector (M2M1) Table A.14: M.2 M-Key Connector (M2M1) Signal Signal 3.3V 3.3V 3.3V SUSCLK PEDET(NC-PCIe/GND-SATA) PEWAKE0# REFCLKp CLKREQ0# REFCLKn PERST0#...
  • Page 56 PETn2 3.3V PERp2 3.3V PERn2 3.3V 3.3V PETp3 PETn3 PERp3 3.3V PERn3 3.3V A.3.11 M.2 E-Key Connector (M2E1) Table A.15: M.2 E-Key Connector (M2E1) Signal Signal 3.3V 3.3V W_DISABLE1# W_DISABLE2# PEWAKE0# PERST0# CLKREQ0# SUSCLK REFCLKn REFCLKp PERn0 SPC-618WE User Manual...
  • Page 57 PERp0 PETn0 PETp0 3.3V USB_D- 3.3V USB_D+ A.3.12 M.2 B-Key Connector (M2B1) Table A.16: M.2 B-Key Connector (M2B1) Signal Signal 3.3V CONFIG_2 3.3V 3.3V CONFIG_1 RESET# PEWAKE0# REFCLKp SPC-618WE User Manual...
  • Page 58 CLKREQ0# REFCLKn PERST0# PETp0 PETn0 PERp0 PERn0 UIM_PWR USB3.1-Tx+ UIM_DATA USB3.1-Tx- UIM_CLK UIM_RESET USB3.1-Rx+ USB3.1-Rx- CONFIG_0 3.3V W_DISABLE1# USB_D- USB_D+ FULL_CARD_POW-ER_OFF# 3.3V 3.3V CONFIG_3 A.3.13 M.2 B-Key Connector (M2B2) Table A.17: M.2 B-Key Connector (M2B2) Signal Signal 3.3V 3.3V 3.3V RESET# SPC-618WE User Manual...
  • Page 59 PEWAKE0# REFCLKp CLKREQ0# REFCLKn PERST0# PETp0 PETn0 PERp0 PERn0 PETp1 PETn1 PERp1 PERn1 3.3V USB_D- FULL_CARD_POW-ER_OFF# USB_D+ 3.3V 3.3V SPC-618WE User Manual...
  • Page 60 Appendix Driver Installation SPC-618WE User Manual...

  • Page 61: Intel Chipset Device Software Installation

    Intel Chipset Device Software Installation Follow the steps below to install the Intel Chipset Device Software: Launch <Driver Root Path>\1. Chipset Driver-10.1.19199.8340-Public-MUP Install SetupChipset.exe Click Next. SPC-618WE User Manual...
  • Page 62 Click Accept. Click Install. Click Finish. SPC-618WE User Manual...

  • Page 63: Intel Management Engine Components Installation

    Intel Management Engine Components Installa- tion Follow the steps below to install the Intel Management Engine Components: Launch <Driver Root Path>\2. ME Driver_2239.3.33.0 Install SetupMe.exe Click Next. SPC-618WE User Manual...
  • Page 64 Check “I accept the terms in the License Agreement”. Click Next. Click Next. Click Finish. SPC-618WE User Manual...

  • Page 65: Intel Graphics Driver Installation

    Intel Graphics Driver Installation Follow the steps below to install the Intel Graphics Driver: Launch <Driver Root Path>\ 3. Graphic Driver Install Installer.exe Click Begin Installation. SPC-618WE User Manual...
  • Page 66 Click I agree. Click Start. Click Finish. SPC-618WE User Manual...

  • Page 67: Intel Serial Io Driver Installation

    Intel Serial IO Driver Installation Follow the steps below to install the Intel Serial IO driver: Launch <Driver Root Path>\ 4. SerialIO Driver_30.100.2237.26_v2_RPL_ADL- PCH_22H2 Install SetupSerialIO.exe Click Next. SPC-618WE User Manual...
  • Page 68 Check “I accept the terms in the License Agreement”. Click Next. Click Next. Click Finish. SPC-618WE User Manual...

  • Page 69: Intel Lan Driver Installation

    Intel LAN Driver Installation Follow the steps below to install the Intel LAN driver: Launch <Driver Root Path>\ 5. Lan Driver_68910-I225-I226-NDIS-Win-x64- 1.1.4.42 Select and right click e2f.inf. Click Install from the menu. After installation, the following screen appears. Click OK. SPC-618WE User Manual...
  • Page 70 Intel GNA Driver Installation Follow the steps below to install the Intel GNA driver: Launch <Driver Root Path>\ 6. gna-03.00.00.1457-win-3_0_sv2_resign- 20220819 Select and right click gna.inf. Click Install from the menu. After installation, the following screen appears. Click OK. SPC-618WE User Manual...
  • Page 71 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2024 SPC-618WE User Manual...
