- Page 1 User Manual SKY-MXM-A2000 ® MXM 3.1 Type-A NVIDIA ® Quadro Embedded A2000 with DP 1.4A...
- Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
- Page 3 Product Warranty (2 years) Advantech warrants the original purchaser that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel authorized by Advantech, or products that have been subject to misuse, abuse, accident, or improper installation.
- Page 4 It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the SKY-MXM-A2000, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.
-
Page 5: Table Of Contents
Table 2.2: DisplayPort Multiplexed Signal Definitions ....13 Figure 2.5 Dual-Mode DisplayPort Implementation ....13 Mechanical and Environmental Specifications........14 Table 2.3: DVI-I DDC Mapping..........14 GPU Thermal Policy................15 Table 2.4: GPU Thermal Policy ..........15 System BIOS Requirements ..............15 SKY-MXM-A2000 User Manual... - Page 6 SKY-MXM-A2000 User Manual...
-
Page 7: Chapter 1 Hardware Configuration
Chapter Hardware Configuration... -
Page 8: Introduction
Introduction As an NVIDIA Elite Partner, Advantech offers MXM GPU cards powered by NVIDIA’s embedded GPUs. They are perfect for image processing and Edge AI acceleration in manufacturing, medical, and gaming industries. Built on NVIDIA's latest architec- tures, Advantech MXM GPUs deliver state-of-the-art technologies to provide high-... -
Page 9: Display Support And Options
® DirectX OpenGL 4.5 Vulcan 1.0 1.3.6 Graphics Options The SKY-MXM-A2000 supports 4 x DP 1.4, with display ports as shown below. MXM Port DP_A DP_B DP_C DP_D Advantech Link A Link B Link C Link E... -
Page 10: Block Diagram
PCI Express X8 IFPA DP_A: Display Port NVIDIA IFPB DP_B: Display Port Quadro A2000 IFPC DP_C: Display Port IFPE DP_D: Display Port Board Dimensions Unit:mm 82.00 46.00 9.00 17.55 12.00 3.50 3.50 3.50 29.00 2.20 3.00 17.50 20.19 39.00 SKY-MXM-A2000 User Manual... -
Page 11: Mxm 3.1 Connector Pin Definitions
DP_C_L0# RSVD PEX_RX14 DP_C_L0 RSVD PEX_TX13# PEX_RX13# PEX_TX13 DP_C_L1# DP_D_L0# PEX_RX13 DP_C_L1 DP_D_L0 PEX_TX12# PEX_RX12# PEX_TX12 DP_C_L2# DP_D_L1# PEX_RX12 DP_C_L2 DP_D_L1 PEX_TX11# PEX_RX11# PEX_TX11 DP_C_L3# DP_D_L2# PEX_RX11 DP_C_L3 DP_D_L2 PEX_TX10# PEX_RX10# PEX_TX10 DP_C_AUX# DP_D_L3# PEX_RX10 DP_C_AUX DP_D_L3 SKY-MXM-A2000 User Manual... - Page 12 PEX_TX3# DP_B_L3# 121 PEX_RX3# PEX_TX3 DP_A_L2# DP_B_L3 123 PEX_RX3 DP_A_L2 125 GND DP_B_AUX# 127 KEY DP_A_L3# DP_B_AUX 129 KEY DP_A_L3 DP_B_HPD 131 KEY DP_A_HPD 133 GND DP_A_AUX# 135 PEX_RX2# PEX_TX2# DP_A_AUX 137 PEX_RX2 PEX_TX2 PRSNT_L# 139 GND SKY-MXM-A2000 User Manual...
-
Page 13: Safety Precautions
MXM GPU card. Modern electronic devices are very sensitive to static- electric discharges. As a safety precaution, use a grounding wrist strap at all times. Place all electronic components on a static-dissipative sur- face or in a static-shielded bag when they are not in the chassis. SKY-MXM-A2000 User Manual... - Page 14 SKY-MXM-A2000 User Manual...
-
Page 15: Chapter 2 System Requirements
Chapter System Requirements... -
Page 16: Power Sequencing
Input voltage to the GPU must strictly follow the ranges listed in the below table (with reference to GND). Operating outside the required voltage range will cause permanent damage to the Power Rail Min. Typ. Max. PWR_SRC 6.5V 7-20V 4.7V 5.3V 3.1V 3.3V 3.5V SKY-MXM-A2000 User Manual... -
Page 17: Module Power Down And Power Up
Figure 2.3 Reset Sequencing Note! In order to reduce boot time, a system that monitors the PWR_GOOD signal is allowed to violate the TPVPERL specification as long as the TPERST-PG timing is still met. SKY-MXM-A2000 User Manual... -
Page 18: Displayport Interface
In addition the MXM imple- mentation of Dual-mode DisplayPort requires the circuit in Figure 2.4 on the AUX lines for proper dongle detection. The HPD signal conditioning must also be placed on the system board. Figure 2.4 Dual-Mode DisplayPort Implementation SKY-MXM-A2000 User Manual... -
Page 19: Dvi/Hdmi On Dp Interface
HDMI/DVI connector. For the optional dual-link DVI support refer to Table 2.3. Table 2.2: DisplayPort Multiplexed Signal Definitions Pin Name DVI/HDMI DP_x_L0 TX_x_D2 DP_x_L0# TX_x_D2# DP_x_L1 TX_x_D1 DP_x_L1# TX_x_D1# DP_x_L2 TX_x_D0 DP_x_L2# TX_x_D0# DP_x_L3 TX_x_CLK DP_x_L3# TX_x_CLK# DP_x_AUX DDC_x_CLK DP_x_AUX# DDC_x_DAT Figure 2.5 Dual-Mode DisplayPort Implementation SKY-MXM-A2000 User Manual... -
Page 20: Mechanical And Environmental Specifications
PCB strain of 500 μstrains or below. iii. The strain rate is too high (.5000 μstrains/second) during PCB operation. c. For a PCB thickness of less than 1.0 mm, the max. allowable strain shall follow IPC 9704. SKY-MXM-A2000 User Manual... -
Page 21: Gpu Thermal Policy
(Base Clock) under the total board power level. System BIOS Requirements Before you install the MXM module, please make sure your system BIOS is config- ured with the following settings: CSM Support [Disabled] Above 4G Decoding [Enabled] SKY-MXM-A2000 User Manual... - Page 22 Note! Option names may vary depending on system architecture. SKY-MXM-A2000 User Manual...
- Page 23 SKY-MXM-A2000 User Manual...
- Page 24 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2023...
