- Page 1 OSM-IMX8MM Open Standard Module User’s Manual Ed – 26 August 2024 Copyright Notice Copyright © 2024 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2047OM8M00R...
-
Page 2: Document Amendment History
OSM-IMX8MM User’s Manual Document Amendment History Revision Date Comment August 2024 Avalue Initial Release 2 OSM-IMX8MM User’s Manual... -
Page 3: Declaration Of Conformity
For detailed information, please always refer to the electronic user's manual. Copyright Notice © 2024 by Avalue Technology Inc. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Avalue Technology Inc. - Page 4 ㆍDescription of your software (operating system, version, application software, etc.) ㆍA complete description of the problem ㆍThe exact wording of any error messages To receive the latest version of the user’s manual; please visit our Web site at: www.avalue.com 4 OSM-IMX8MM User’s Manual...
- Page 5 On the other hand, if the new product defect is resulting from incorrect configuration or erroneous use by the user instead of any problem of the hardware itself, the customer will also be requested to pay for relevant handling fees. OSM-IMX8MM User’s Manual...
- Page 6 Lacking detailed statement of fault steps also makes the problem hard to be identified, sometimes resulting in second-time repairs. 6 OSM-IMX8MM User’s Manual...
- Page 7 • Product has been altered or its label of the serial number has been torn off. • Product functionality issues resulting from improper use by the user, unauthorized dismantle or alteration, unfit operation environment, improper maintenance, accident OSM-IMX8MM User’s Manual...
- Page 8 If the customer demands an additional maintenance analysis report, a service fee of various level will be charged depending on the warranty status. In case the analysis result shows that the defect attributes to Avalue’s faulty design or process, the analysis fee will be exempted. 8 OSM-IMX8MM User’s Manual...
- Page 9 9. Position the power cord so that people cannot step on it. Do not place anything over the power cord. 10. All cautions and warnings on the equipment should be noted. 11. If the equipment is not used for a long time, disconnect it from the power source to OSM-IMX8MM User’s Manual...
- Page 10 The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. 15. Equipment intended only for use in a RESTRICTED ACCESS AREA. 10 OSM-IMX8MM User’s Manual...
- Page 11 A NOTE provides additional information intended to avoid Note inconveniences during operation. Direct current. Alternating current Stand-by, Power on FCC Certification CE Certification Follow the national requirements for disposal of equipment. Stacking layer limit This side up OSM-IMX8MM User’s Manual 11...
- Page 12 OSM-IMX8MM User’s Manual Fragile Packaging Beware of water damage, moisture-proof Carton recyclable Handle with care Follow operating instructions of consult instructions for use. 12 OSM-IMX8MM User’s Manual...
- Page 13 EXPLOSION ou une fuite de liquide ou de gaz inflammable. - UNE BATTERIE soumise à une pression d'air extrêmement basse pouvant entraî ner une EXPLOSION ou une fuite de liquide ou de gaz inflammable. OSM-IMX8MM User’s Manual 13...
-
Page 14: Table Of Contents
4. Carrier Board ........................ 27 System Specifications ..................... 28 Architecture Overview—Block Diagram ..............30 Product Oveview ..................... 31 Product Overview ....................32 Jumper and Connector List ..................33 OSM-IMX8MM Setting Connectors ................. 34 4.6.1 SPEAKER(J3) ..........................34 4.6.2 MIC(MIC1) ............................34 4.6.3 USB 2.0 Slot (J4) .......................... -
Page 15: Getting Started
1.2 Packing List Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty OSM-IMX8MM OSM-IMX8MM User’s Manual 15... -
Page 16: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up OSM-IMX8MM or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 17: System Specifications
Size (L x W) 45*45mm(Size-L) OS Information Yocto 4.0 Note: Specifications are subject to change without notice. User condition suggestion: User should consider overall power consumption including CPU and devices add-on, to choose suitable power adapter. OSM-IMX8MM User’s Manual 17... -
Page 18: Architecture Overview-Block Diagram
OSM-IMX8MM User’s Manual 1.5 Architecture Overview—Block Diagram 18 OSM-IMX8MM User’s Manual... -
Page 19: Hardware Configuration
User’s Manual 2. Hardware Configuration OSM-IMX8MM User’s Manual 19... -
Page 20: Product Overview
OSM-IMX8MM User’s Manual 2.1 Product Overview 20 OSM-IMX8MM User’s Manual... -
Page 21: Function & Pin Define
I2C4_SDA AA21 JTAG_nTRST ENET_TD0 POR_B ENET_TD1 UART1_RXD ENET_TD2 UART1_TXD ENET_TD3 UART1_RTS ENET_TX_CTL UART1_CTS ENET ENET_TXC UART UART3_RXD ENET_RD0 UART3_TXD ENET_RD1 UART3_RTS ENET_RD2 UART3_RTS ENET_RD3 UART2_RXD ENET_RX_CTL UART UART2_TXD ENET_RXC UART4_RXD ENET ENET_MDIO UART Console UART4_TXD ENET_MDC OSM-IMX8MM User’s Manual 21... - Page 22 CSI_DN1 DSI_DP1 CSI_DP1 DSI_DN2 CSI_DN2 MIPI-DSI DSI_DP2 CSI_DP2 DSI_DN3 CSI_DN3 MIPI-CSI DSI_DP3 CSI_DP3 DSI_CKN CSI_CKN DSI_CKP CSI_CKP PCIE_RXP GPIO1_IO01 PCIE_RXN I2C3_SDA PCIE PCIE_TXP I2C3_SCL PCIE_TXN CSI0_PWDN PCIE_CLKP MIPI-CSI CSI0_nRST PCIE PCIE_CLKN GPIO1_IO05 GPIO Vendor SAI1_RXD2 GPIO1_IO00 22 OSM-IMX8MM User’s Manual...
- Page 23 SYS_nRST AJ4, AK4, Y8, Y9, Y10, Y11 VDD_1V8 Y3,C5 D18, E15, E21, F16, F20, J16, J20, L18, M16, M20, P18, R16, R20, V16, Ground V20, Y18, AA14, AA17, AA19, AA22, AB15, AB21，A4, A7, A10, B2, B5, OSM-IMX8MM User’s Manual 23...
- Page 24 AH2, AH34, AJ35, AK3, AL2, AL34, AM13, AM16, AM19, AM22, AM35, AN3, AN6, AN9, AN11, AN15, AN18, AN21, AN33, AP2, AP5, AP8, AP13, AP16, AP19, AP22, AP25, AP28, AP31, AP34, AR14, AR17, AR20, AR26, AR29, AR32 24 OSM-IMX8MM User’s Manual...
-
Page 25: Mechanical Drawing
User’s Manual 3. Mechanical Drawing OSM-IMX8MM User’s Manual 25... - Page 26 OSM-IMX8MM User’s Manual Unit: mm 26 OSM-IMX8MM User’s Manual...
-
Page 27: Carrier Board
User’s Manual 4. Carrier Board OSM-IMX8MM User’s Manual 27... -
Page 28: System Specifications
FPC Slot 3 x FPC Slot PoE PD 1 x PoE PD 12V Out IR Receiver 1 x IR Receiver Expand Connector 1 x Expand Connector Button 1 x Button for Recovery key Mechanical & Environmental Specification 28 OSM-IMX8MM User’s Manual... - Page 29 Size (L x W) 125*120mm OS Information Yocto 4.0 Note: Specifications are subject to change without notice. User condition suggestion: User should consider overall power consumption including CPU and devices add-on, to choose suitable power adapter. OSM-IMX8MM User’s Manual 29...
-
Page 30: Architecture Overview-Block Diagram
OSM-IMX8MM User’s Manual Architecture Overview—Block Diagram 30 OSM-IMX8MM User’s Manual... -
Page 31: Product Oveview
User’s Manual Product Oveview OSM-IMX8MM User’s Manual 31... -
Page 32: Product Overview
OSM-IMX8MM User’s Manual Product Overview 32 OSM-IMX8MM User’s Manual... -
Page 33: Jumper And Connector List
30 Pin 0.5mm for MIPI CSI PoE PD 12V Out 5 Pin 2.0mm PH2.0 IR Receiver *1 Infrared remote control reception Button *1 Recovery Key Expand For Keypad/LED 10 Pin 2.0mm Connector TF-CARD 1*TF-CARD SIM-CARD 1* SIM-CARD OSM-IMX8MM User’s Manual 33... -
Page 34: Osm-Imx8Mm Setting Connectors
OSM-IMX8MM User’s Manual OSM-IMX8MM Setting Connectors 4.6.1 SPEAKER(J3) Signal 4.6.2 MIC(MIC1) Signal MIC_P MIC_N 34 OSM-IMX8MM User’s Manual... -
Page 35: Usb 2.0 Slot (J4)
User’s Manual 4.6.3 USB 2.0 Slot (J4) Signal Data- Data+ 4.6.4 CAN Bus(J5(CAN2)/J6(CAN1)) Signal CAN_L CAN_H OSM-IMX8MM User’s Manual 35... -
Page 36: Expand Slot(J8)
OSM-IMX8MM User’s Manual 4.6.5 Expand slot(J8) Signal PIN PIN Signal SPI_A_SCK_3V3 24 PWM3/GPIO_C2 SPI_A_CS0#_3V3 22 PWM2/GPIO_C1 SPI_A_D3/HOLD_3V3 17 UART0_RTS SPI_A_D2/WP_3V3 UART0_RX SPI_A_D1_3V3 UART0_TX SPI_A_D0_3V3 UART0_CTS +3.3V +3.3V 4.6.6 Debug(J12) Signal 36 OSM-IMX8MM User’s Manual... -
Page 37: Rtc Battery Interface(Jbat1)
User’s Manual 4.6.7 RTC Battery interface(JBAT1) Signal VDD_RTC 4.6.8 I2C for TP(J21) Signal RESET OSM-IMX8MM User’s Manual 37... -
Page 38: Mipi Dsi(J24)
OSM-IMX8MM User’s Manual 4.6.9 MIPI DSI(J24) Signal CLKN CLKP PWM_OUT Signal LED- LED- +3.3V +1.8V RESET LED+ LED+ 38 OSM-IMX8MM User’s Manual... -
Page 39: Csi(J23)
User’s Manual 4.6.10 CSI(J23) Signal +2.8V +1.2V +1.8V +2.8V RESET +1.8V MCLK CLKP CLKN OSM-IMX8MM User’s Manual 39... -
Page 40: Keypad(J22)
Update Key Note: To Use the IR receiver function, in Power_LED+ addition to connecting pin9 and pin10, please Power LED Power_LED- make sure to also connect a GND pin to +3.3V complete the circuit. IR receiver IR_IN 40 OSM-IMX8MM User’s Manual... -
Page 41: Mechanical Drawing
User’s Manual Mechanical Drawing Unit: mm OSM-IMX8MM User’s Manual 41...
