  • Page 1 PCI-Based Serial Communication Cards Recycled Paper...
  • Page 2 Trademarks C514, C518, C485, C584, C588, C888, C960, C990, C990D, F641, F642, C584XB and C588XB are trademarks of ADLINK Technology Inc., MS-DOS, Windows 95, Windows NT are registered trademark of Microsoft Corporation.
  • Page 3 Getting service from ADLINK Customer Satisfaction is always the most important thing for ADLINK Tech Inc. If you need any help or service, please contact us and get it. ADLINK Technology Inc. Web Site http://www.adlink.com.tw Sales and service@adlink.com.tw Service Technical NuDAQ nudaq@adlink.com.tw...
  • Page 4 ADLINK PCI Multiport Card Comparison Chart C960/990/ C485 C514 C518 C584 C588 C888 990D 4~32 8~64 8~16 8~16 8~128 Serial port Serial 16C550 16C550 16C550 16C550 16C554 CD1865 16C554 communicati on controller 104 /240 MAX System 115.2K*4 115.2K*4 115.2K*8 115.2K*4 115.2K*8...
  • Page 5 Overview of C485............14 1.6.1 What is C485? ..............14 1.6.2 Feature of C485..............14 1.6.3 Specification of C485 ............14 1.6.4 Connector Pin Assignment of C485 .......16 Overview of C888............17 1.7.1 What is C888? ..............17 1.7.2 Feature of C888..............17 1.7.3 Specification of C888 ............17 1.7.4...
  • Page 6 Unpacking ..............25 Installation Procedure ..........26 Hardware Configuration..........27 Software Installation ............ 28 2.5.1 Windows NT Installation ...........28 2.5.2 Windows 95/98 Installation ..........30 2.5.3 UNIX/XENIX Installation...........31 Chapter 3 Expansion/Isolation Box User Guide ..38 Introduction..............38 Pin Definition / DIP Switch Setting ........ 41 Product Warranty/Service..........43 ii •...
  • Page 7 Introduction About the Serial Communication Cards • The serial communication cards are intelligent serial input/output multi-port controller cards which are suitable to PC AT with PCI bus machine. The cards can reduce the interval for serial communication controller to interrupt main CPU on the mainboard to improve the whole system performance.
  • Page 8 Overview of C514 1.2.1 What is C514? The C514 is an enhanced four ports serial communication card used for PC with PCI bus. It includes a PGA to support the serial communication controller and a 37-pin connector to connect external I/O port. The expansion cable has four standard DB25 connectors and one DB37 connector to connect to C514 interface card.
  • Page 9 ♦ Flow control • Xon/Xoff control • RTS/CTS control ♦ Port Capability: • 3 independent RS-232C compatible ports • 1 isolated RS-422/485 port with 500Vdc isolation voltage • Max. port per system: 32 (8 cards) ♦ Operation System Compatibility: Windows 95/98/NT •...
  • Page 10 1.2.4 Connector Pin Assignment of C514 DB37 female connector pin assignment for C514. DB37 Pin No. Signal Name DB37 Pin No. Signal Name RXD1(IN) TXD1(OUT) CTS1(IN) RTS1(OUT) DSR1(IN) DTR1(OUT) DCD1(IN) RI1(IN) RXD2(IN) TXD2(OUT) CTS2(IN) RTS2(OUT) DSR2(IN) DTR2(OUT) DCD2(IN) RI2(IN) RI3(IN) DCD3(IN) DTR3(OUT) DSR3(IN)
  • Page 11 Overview of C584 1.3.1 What is C584? The C584 is an enhanced four ports serial communication card used for PC with PCI bus. It includes a PGA to support the serial communication controller and a 37-pin connector to connect external I/O port. The expansion cable has four standard DB25 connectors and one DB37 connector to connect to C584 interface card.
  • Page 12 ♦ System IO mapping: • Assigned by PCI BIOS • Shared IRQ ♦ Flow control • Xon/Xoff control • RTS/CTS control ♦ Port Capability: • 4 independent RS-232C compatible ports • Optional external C584XB box for extending to 4 isolated RS-232/422/485 port •...
  • Page 13 1.3.4 Connector Pin Assignment of C584 DB37 female connector pin assignment for C584. DB37 Pin No. Signal Name DB37 Pin No. Signal Name RXD1(IN) TXD1(OUT) CTS1(IN) RTS1(OUT) DSR1(IN) DTR1(OUT) DCD1(IN) RI1(IN) RXD2(IN) TXD2(OUT) CTS2(IN) RTS2(OUT) DSR2(IN) DTR2(OUT) DCD2(IN) RI2(IN) RI3(IN) DCD3(IN) DTR3(OUT) DSR3(IN)
  • Page 14 Overview of C518 1.4.1 What is C518? The C518 is an enhanced eight ports serial communication card used for PC with PCI bus. It includes a PGA to support the serial communication controller and a 62-pin connector to connect external I/O port. The expansion cable has eight standard DB25 connectors and one DB62 connector to connect to C518 interface card.
  • Page 15 • Shared IRQ ♦ Flow control • Xon/Xoff control • RTS/CTS control ♦ Port Capability: • 7 independent RS-232C compatible ports • 1 isolated RS-422/485 port with 500Vdc isolation voltage • Max. port per system: 64 (8 cards) ♦ Operation System Compatibility: Windows 95/98/NT ♦...
  • Page 16 1.4.4 Connector Pin Assignment of C518 DB62 female connector pin assignment for C518. DB62 Pin Signal Name DB62 Pin Signal Name DB62 Pin Signal Name TXD1(OUT) TXD2(OUT) TXD3(OUT) RXD1(IN) RXD2(IN) RXD3(IN) RTS1(OUT) RTS2(OUT) RTS3(OUT) CTS1(IN) CTS2(IN) CTS3(IN) DSR1(IN) DSR2(IN) DSR3(IN) DTR1(OUT) DTR2(OUT) DTR3(OUT)
  • Page 17 Overview of C588 1.5.1 What is C588? The C588 is an enhanced eight ports serial communication card used for PC with PCI bus. It includes a PGA to support the serial communication controller and a 62-pin connector to connect external I/O port. The expansion cable has eight standard DB25 connectors and one DB62 connector to connect to C588 interface card.
  • Page 18 ♦ System IO mapping: § Assigned by PCI BIOS § Shared IRQ ♦ Flow control § Xon/Xoff control § RTS/CTS control ♦ Port Capability: • 8 independent RS-232C compatible ports • Optional external C588XB box for extending to 8 isolated RS-232/422/485 port •...
  • Page 19 1.5.4 Connector Pin Assignment of C588 DB62 female connector pin assignment for C588. DB62 Pin DB62 Pin DB62 Pin Signal Name Signal Name Signal Name TXD1(OUT) TXD2(OUT) RXD1(IN) RXD2(IN) RTS1(OUT) RTS2(OUT) CTS1(IN) CTS2(IN) TXD4(OUT) DSR1(IN) DSR2(IN) RXD4(IN) DTR1(OUT) DTR2(OUT) RTS4(OUT) DCD1(IN) DCD2(IN) CTS4(IN)
  • Page 20 Overview of C485 1.6.1 What is C485? The C485 is an enhanced four ports serial communication card used for PC with PCI bus. It includes a PGA to support the serial communication controller and a 37-pin connector to connect external I/O port.
  • Page 21 • RTS/CTS control ♦ Port Capability: • 4 isolated RS-422/485 port with 500Vdc isolation voltage • Max. port per system: 8 (2 card) ♦ Baud rate: Each port can be configured to 50~115,200 bps ♦ Operation System Compatibility: Windows 95/98/NT ♦...
  • Page 22 1.6.4 Connector Pin Assignment of C485 DB37 female connector pin assignment for C485. DB37 Pin No. Signal Name DB37 Pin No. Signal Name RXDA+(IN) TXDA+(OUT) RXDA-(IN) TXDA-(OUT) GND.A RXDB+(IN) TXDB+(OUT) RXDB-(IN) TXDB-(OUT) GND.B GND.C TXDC-(OUT) RXDC-(IN) TXDC+(OUT) RXDC+(IN) GND.D TXDD-(OUT)
  • Page 23 Overview of C888 1.7.1 What is C888? The C888 is intelligent eight ports serial communication card used for PC with PCI bus. It includes a local high performance processor to manage the data flow between main CPU and external interface. It also includes dual port RAM, through the dual port RAM, the local processor can communicate with main CPU.
  • Page 24 • 29.4912 MHz ♦ System IO mapping: • Assigned by PCI BIOS • Shared IRQ ♦ Flow control • Xon/Xoff control • RTS/CTS control ♦ Port Capability: • 8 independent RS-232C compatible ports • Optional external C588XB box for extending to 8 isolated RS-232/422/485 port •...
  • Page 25 1.7.4 Connector Pin Assignment of C888 DB62 female connector pin assignment for C888. DB62 Pin DB62 Pin DB62 Pin Signal Name Signal Name Signal Name TXD1(OUT) TXD2(OUT) RXD1(IN) RXD2(IN) RTS1(OUT) RTS2(OUT) CTS1(IN) CTS2(IN) TXD4(OUT) DSR1(IN) DSR2(IN) RXD4(IN) DTR1(OUT) DTR2(OUT) RTS4(OUT) DCD1(IN) DCD2(IN) CTS4(IN)
  • Page 26 Overview of C960/C990/C990D 1.8.1 What is C960/C990/C990D? The C960/C990/C990D is an intelligent serial port controller card used for PC with PCI bus. It includes a local high performance processor to manage the data flow between main CPU and external interface. It also includes dual port RAM, through the dual port RAM, the local processor can communicate with main CPU.
  • Page 27 ♦ 128K byte dual port RAM ♦ A system includes one controller board and at least one expansion box ♦ At most 8 expansion boxes in one system ♦ System IO mapping: • Assigned by PCI BIOS • Shared IRQ ♦...
  • Page 28 1.8.4 Connector Pin Assignment of C960/C990/C990D DB37 male connector pin assignment for C960/C990/C990D. DB37 Pin No. Signal Name DB37 Pin No. Signal Name BOXD0 BOXIRQ0 BOXD1 BOXIRQ1 BOXD2 BOXIRQ2 BOXD3 BOXIRQ3 BOXD4 VCC +5V BOXD5 V- -12V BOXD6 BOXD7 V+ +12V BOXA1 BOXA2 VCC +5V...
  • Page 29 Installation This chapter describes the configurations of the serial communication cards. At first, the contents in the package and unpacking information that you should care about are described. The serial communication cards are plug-and-play and very easy to install into any PC system with PCI slots. Installation •...
  • Page 30 What You Have In addition to this User's Manual, the package includes the following items: For C514/C584/C518/C588/C485/C888: • C514/C584/C518/C588/C485/C888 Serial Communication Interface Card • Expansion Cable • Software Utility CD or Disks For C960/C990/C990D: • C960/C990/C990D Serial Communication Controller Card •...
  • Page 31 Unpacking Your serial communication card contains sensitive electronic components that can be easily damaged by static electricity. The card should be done on a grounded anti-static mat. The operator should be wearing an anti-static wristband, grounded at the same point as the anti-static mat.
  • Page 32 Installation Procedure Turn off your computer Turn off all accessories (printer, modem, monitor, etc.) connected to computer. Remove the cover from your computer. Select a 32-bit PCI expansion slot. Caution! Don‘t put PCI card into ISA or EISA slot. Before handling the serial communication card, discharge any static buildup on your body by touching the metal case of the computer.
  • Page 33 Hardware Configuration The serial communication card has plug and play component, the card can requests memory usage (I/O port locations) of the card which is assigned by system BIOS. The address assignment is done on a board-by-board basis for all serial communication cards in the system. The jumper JP1 for the serial communication card is used for the system to recognize the first or second card of the same model in the system if there are two cards of the same on board.
  • Page 34 For C584, we may specify as follow: X:\NuCOM\C584588\P584\NT4 For C518, we may specify as follow: X:\NuCOM\C514518\P518\NT4 For C588, we may specify as follow: X:\NuCOM\C584588\P588\NT4 For C485, we may specify as follow: X:\NuCOM\C584588\P584\NT4 For C888/C960/C990/C990D, we may specify as follow: X:\NuCOM\C9x0888\Nt4 28 • Installation...
  • Page 35 Now, you can follow the configuration dialog boxes to install the driver. In the default condition, the TTY port is given name from “COM3”. User can specify the start “COM” port number in installation procedure. We can install up to two same type serial communication cards in one NT system.
  • Page 36 2.5.2 Windows 95/98 Installation Once Windows 95/98 system has been started, the plug & play function in 95/98 system will find the new serial communication card. If this is the first time to install serial communication card in your Windows 95/98 system, you will be informed to install the driver.
  • Page 37 If you install two same type serial communication cards with jumper ON or OFF simultaneously, we can not confirm that both cards will active properly. If you install multiple cards in one 95/98 system simultaneously, please confirm that the COM port number assigned do not overlap for different card.
  • Page 38 /etc/PCIIOP/OBJ/P960F.O (For different card, replace P960F to relative name) /etc/PCIIOP/DRIVER/Driver.x /etc/PCIIOP/DRIVER/Driver.u /etc/PCIIOP/DRIVER/Driver.u1 /etc/PCIIOP/DRIVER/Driver.s /etc/PCIIOP/DRIVER/Driver.e 10. /etc/PCIIOP/DRIVER/Driver.e2 11. /etc/PCIIOP/DRIVER/Driver.e6 12. /etc/PCIIOP/etty 13. /etc/PCIIOP/om (This is the utility file for interface card operation condition monitor.) What may be happened while installing: Link kit packages have not been installed completely. (Install like kit completely.) Can not boot the system due to low voltage.
  • Page 39 Please strike the numeric key 1 to 2 to continue the installation procedure. Updating system configuration. Making terminal device 100%. Editing terminal definitions 100%. Installing serial communication card driver. You must create a new kernel to effect the driver change to your specified.
  • Page 40 Login as a super user. Login: root Password: # cd/ Extract all the files on the diskette by “tar” command. tar xvf /dev/fd0135ds18 # cd /etc/PCIIOP # ./build System will display following main menu on the screen: Global View Intelligent Input/Output Processor Installation: Install PCIIOP Driver Remove PCIIOP Driver...
  • Page 41 From this procedure, the screen message and installation procedure will be different for XENIX and UNIX system. In XENIX system: Re-linking the kernel. Kernel with driver modifications is in /usr/sys/conf/xenix Do you want this kernel to reboot by default? (y/n) y The new kernel is installed in /xenix.
  • Page 42 “map =” denotes the mapping address and memory space of dual port RAM, should be assigned by PCI bus. “dram =” denotes the PCIIOP interface card’s built-in memory space. “ports =” denotes the number of ports, which should be octal of the number of expansion boxes.
  • Page 43 Definitions of serial port device: Card No. Device Name tty6?? tty7?? Card number 1 is the card with JP1 jumper on. F641/F642 Box No. Device Name tty?1? tty?2? tty?3? tty?4? tty?5? tty?6? tty?7? tty?8? Device Name (non Device Name Port No. Modem) (Modem) tty??a...
  • Page 44 Expansion/Isolation Box User Guide Introduction An APU is the kernel of a serial communication controller system. It can manage up to 8 pieces of F641/F642 box. The APU communicates with the MPU via dual port RAM and processes the data transfer between MPU and I/O devices.
  • Page 45 Each port has two bit DIP switch to set for RS-232, RS-422 or RS-485 interface. In RS-485 mode, we had auto data direction function to maintain no local echo condition, but user may still need to maintain just only one port to output data, so RS-485 mode must be used in half-duplex transmission environment.
  • Page 46 Because RS-485 interface do not use RTS/CTS/DTR/DSR/DCD signal, user may not use RTS/CTS or DTR/DSR handshake and DCD signal checking function in its application, these signals are in inactive condition for RS-422 interface. 40 • Expansion/Isolation Box User Guide...
  • Page 47 Pin Definition / DIP Switch Setting The pin definition for F641 box DB25 male connector. Pin No. Signal Name Frame Ground Transmit Data Out Receive Data In RTS Out CTS In DSR In Signal Ground DCD In DTR Out The pin definition for F642 box DB25 male connector. Pin No.
  • Page 48 The pin definition for RS-422/485 DB25 male connector. Pin No. RS-422/485 Mode Signal Name TXD+ (Out) RXD+ (In) RTS+ (Out) CTS+ (In) RTS- (Out) TXD- (Out) RXD- (In) CTS- (In) RS-485 mode may let pin 2 and pin 3, pin 14 and pin 16 short together to connect with other device.
  • Page 49 Product Warranty/Service ADLINK warrants that equipment furnished will be free from defects in material and workmanship for a period of one year from the date of shipment. During the warranty period, we shall, at our option, either repair or replace any product that proves to be defective under normal operation. This warranty shall not apply to equipment that has been previously repaired or altered outside our plant in any way as to, in the judgment of the manufacturer, affect its reliability.
