- Page 1 No.DOC1067620 NN65788001 PRODUCT NAME Electric Gripper for Collaborative Robots MODEL / Series / Product Number LEHR Series ―CRX Plug-in Software－...
-
Page 2: Table Of Contents
Contents How to Download the Software ......2 １ Install CRX Plug-in Software ........2 ２ ２.１ Robot control device software version..........2 ２.２ Install ....................... 2 Basic settings for electric grippers ...... 3 ３ Dedicated Instruction ........... 4 ４ ４.１... -
Page 3: １ How To Download The Software
How to Download the Software １ Please download the software (CRX Plug-in Software) from the SMC website (URL: https://www.smcworld.com) and save it in a USB memory device. Install CRX Plug-in Software ２ ２.１ Robot control device software version If the software for the robot control device is V9.40P / 37 version or earlier, update to the latest version V9.40P / 38 version or later before installing the plug-in software. -
Page 4: ３ Basic Settings For Electric Grippers
Basic settings for electric grippers ３ Here, communication connections for electric grippers and the status signal output settings are made. 1. Select the menu icon and select [SMC LEHR] under [PLUGINS]. (1) (2) 2. Grip failure setting. (3) ☑: In the event of a grasping failure, an alarm is generated and the program is stopped. □: The program continues even if the grip fails. -
Page 5: ４ Dedicated Instruction
Dedicated Instruction ４ The CRX Plug-in Software has two dedicated instruction （LEHR Activate , LEHR Motion). ⚫ LEHR Activate "LEHR start" is a dedicated instruction required when starting the electric gripper. ⚫ LEHR Motion "LEHR actuation" is a dedicated instruction that instructs the operation of the electric gripper. How to add a dedicated instruction ４.１... -
Page 6: Lehr Activate
LEHR Activate ４.２ "LEHR Activate" is a dedicated instruction required when starting the electric gripper. After installing the LEHR, execute this command only once at the beginning. 1. After adding the icon, press the "Details" button to display the details screen. (1) (2) 2. -
Page 7: Lehr Motion
LEHR Motion ４.３ "LEHR activation" is a dedicated instruction that instructs the operation of the electric gripper. On the detail screen, set the driving selection (positioning or grasping) and the motion settings (position, speed, force). 1. Select operation selection. (1), (2) Positioning: It is mainly used for the release of workpieces. -
Page 8: ５ Alarm Detection
Alarm detection ５ The occurrence of warnings and alarms can be confirmed by the LED on the electric gripper main unit or on the plug-in software screen. For the LED display pattern of the electric gripper body, refer to the instruction manual of "Electric gripper body for collaborative robot"... - Page 9 Revision history February 2024: Frist edition March 2025: Revision for Software version 1.4.0 URL https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
