No.LEY*-OMZ0010
PRODUCT NAME
Electric Actuator / Rod Type
Dust-tight / Water-jet-proof
(IP65 Equivalent / IP67 Equivalent)
MODEL / Series / Product Number
LEY Series
Applicable models： LEY□E-X8
※This manual describes the dedicated terms for "LEY□E-X8"
Refer to the manual of LEY series about other details. (No.LEY-OM00212)
※Refer to the manual relevant to the controller being used for full operating instructions.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SMC Networks LEY Series
Summary of Contents for SMC Networks LEY Series
- Page 1 MODEL / Series / Product Number LEY Series Applicable models： LEY□E-X8 ※This manual describes the dedicated terms for “LEY□E-X8” Refer to the manual of LEY series about other details. (No.LEY-OM00212) ※Refer to the manual relevant to the controller being used for full operating instructions.
- Page 2 Contents Safety Instructions 1．Rod type / LEY Series 1.1 Specification 1.2 How to Order 2．Specific product precautions No.LEY*-OMZ0010...
- Page 3 LEY/LEYG Series/Electric Actuator Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of "Caution", "Warning" or "Danger". They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
- Page 4 LEY/LEYG Series/Electric Actuator Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
- Page 5 1．Rod type / LEY Series 1.1 Specification Model LEY 25□E-X8 LEY 32□E-X8 LEY 40□E-X8 (3000 [mm/s Work load Horizontal (2000 [mm/s Note1) [kg] (3000 [mm/s Vertical Note2) Note 3) Note 4) Pushing force [N] 63 to 122 126 to 238 232 to 452...
- Page 6 1.2 How to Order Refor to the catalog for Controller. ➓ Controller Refor to the catalog for Controller. Caution Electric actuator and controller are sold as a set. When purchasing without controller, make sure that the combination of electric actuator and controller is correct. <Be sure to check the following before use.>...
- Page 7 2．Specific product precautions About precautions for installation of electric actuator, refer to [Specific precautions for Battery-less absolute encoder] that is described in the manual of used controller. Precautions for use 1. Please install the tube. (Outside diameter of applicable tube: Φ4) Please set up the tube end in the place where water doesn´t splash.
- Page 8 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2021 SMC Corporation All Rights Reserved No.LEY*-OMZ0010...
