High Precision Type / Electric Slide Table
D Type
●Standard
/LESYH D Series
#This manual describes the dedicated terms for "LESYH-X171 series".
Refer to the manual of LES series about other details.
#Refer to the manual relevant to the controller being used for full operating instructions.
PRODUCT NAME
MODEL / Series / Product Number
LESYH-X171 Series
Applicable models: LESYH (16,25)
Doc. no. LES-OMX0007-A
R/L Type
●Standard
/LESYH R/L Series
コントローラ
ＪＸＣ□1 Series
Advertisement
Table of Contents
Related Manuals for SMC Networks LESYH-X171 Series
Summary of Contents for SMC Networks LESYH-X171 Series
- Page 1 /LESYH R/L Series /LESYH D Series コントローラ ＪＸＣ□1 Series #This manual describes the dedicated terms for “LESYH-X171 series”. Refer to the manual of LES series about other details. #Refer to the manual relevant to the controller being used for full operating instructions.
-
Page 2: Table Of Contents
Contents Safety Instructions ................2 1. Specifications ................. 4 2. How to Order .................. 5 3. Electric slide table / Ball screw drive／Common Precautions ... 6 3.1 Handling ................... 6 3.2 Specific product precautions ..........6... -
Page 3: Safety Instructions
LESYH-X171 Series /Electric Slide Table Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Limited Warranty And Disclaimer/Compliance Requirements
LESYH-X171 Series /Electric Slide Table Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. -
Page 5: Specifications
1. Specifications LESYH*(D/R/L)E*-X171(Ball Screw Drive) LESYH LESYH LESYH LESYH Model 16*EB 16*EA 25*EB 25*EA Stroke[mm] 50,100 50,100,150 Horizontal Work load[kg] Vertical Pushing force[N] 35 to 70% 174 to 348 91 to 182 210 to 420 109 to 218 Speed[mm/s] 10 to 200 20 to 400 10 to 200 20 to 400... -
Page 6: How To Order
2. How to Order LESYH 16 D E A - 50 C - R 1 C D 1 7 T - X171 (1) (2) (3) (4) (5) (6) (1) Size (5) Stroke[mm] Size ● ● ● ● (2) Motor mounting position In-line ●... -
Page 7: Electric Slide Table / Ball Screw Drive／Common Precautions
3. Electric slide table / Ball screw drive／Common Precautions 3.1 Handling Caution When mounting the product, use screws with adequate length and tighten them to the maximum torque or less. Tightening with higher torque than the specified range may cause malfunction while the tightening with lower torque can cause the displacement of position or dropping a work piece. - Page 8 Revision history Jan / 2020 1st printing Edition A Jun / 2020 Revision * Added LESYH25-X171 *Changed the acceleration/deceleration 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
