DRPC-130-AL Embedded System
MODEL:
DRPC-130-AL
Fanless Embedded System with Intel® Atom™ x5-E3930 CPU,
Dual GbE, Digital IO, Serial Ports, Isolated CAN Bus,
USB 3.2 Gen 1, Dual HDMI, 12V~24V DC Power Input,
DIN Rail Mounting Support, RoHS Compliant
User Manual
Page i
Rev. 1.12 – December 17, 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DRPC-130-AL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology DRPC-130-AL

Summary of Contents for IEI Technology DRPC-130-AL

  • Page 1 DRPC-130-AL Embedded System MODEL: DRPC-130-AL Fanless Embedded System with Intel® Atom™ x5-E3930 CPU, Dual GbE, Digital IO, Serial Ports, Isolated CAN Bus, USB 3.2 Gen 1, Dual HDMI, 12V~24V DC Power Input, DIN Rail Mounting Support, RoHS Compliant User Manual Page i Rev.
  • Page 2 DRPC-130-AL Embedded System Revision Date Version Changes December 17, 2019 1.12 Modified Section 3.7: CAN Bus Connection November 5, 2019 1.11 Added Section 3.5.1: mSATA/PCIe Mode Selection August 22, 2018 1.10 Updated for R11 version – changing mounting method June 5, 2018 1.00...

  • Page 3: Copyright Notice

    DRPC-130-AL Embedded System Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Manual Conventions

    DRPC-130-AL Embedded System Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    DRPC-130-AL Embedded System Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 M ....................3 ODEL ARIATIONS 1.3 F ........................3 EATURES 1.4 F ......................4 RONT ANEL 1.5 T ......................... 5 ANEL 1.6 T ..................6...
  • Page 6 DRPC-130-AL Embedded System 3.10 LAN C ....................31 ONNECTION 3.11 AT/ATX M ..................32 ELECTION 3.12 DIN R .................... 33 OUNTING 3.13 P ..................35 OWER ROCEDURE 3.13.1 Installation Checklist ..................35 3.13.2 Terminal Block Pinouts .................. 35 3.13.3 Power-on Procedure ..................36 3.13.4 PS-ON, 2-pin Terminal Block ................
  • Page 7 DRPC-130-AL Embedded System 5.3.5 USB Configuration ................... 58 5.3.6 CPU Configuration ..................59 5.3.7 RTC Wake Settings ................... 61 5.3.8 Power Saving Configuration ................62 5.3.9 Serial Port Console Redirection ..............63 5.3.9.1 Legacy Console Redirection Settings ............65 5.3.10 IEI Feature ..................... 66 5.4 C...
  • Page 8 DRPC-130-AL Embedded System B.1.2 Anti-static Precautions ..................96 B.1.3 Explanation of Graphical Symbols ..............96 B.1.4 Product Disposal ..................... 97 B.2 M ............98 AINTENANCE AND LEANING RECAUTIONS B.2.1 Maintenance and Cleaning ................98 B.2.2 Cleaning Tools ....................98 C DIGITAL I/O INTERFACE ..................99 D WATCHDOG TIMER ....................
  • Page 9 DRPC-130-AL Embedded System List of Figures Figure 1-1: DRPC-130-AL Series ....................2 Figure 1-2: DRPC-130-AL Front Panel ..................4 Figure 1-3: DRPC-130-AL Top Panel ..................... 5 Figure 1-4: Physical Dimensions (millimeters) ................8 Figure 3-1: Internal Access Panel Retention Screws ..............15 Figure 3-2: SO-DIMM Slot Location ....................
  • Page 10 DRPC-130-AL Embedded System Figure 3-27: Attach the Mounting Bracket to the DIN Rail ............34 Figure 3-28: Mounting the System ....................34 Figure 3-29: Power-on ........................36 Figure 3-30: IEI Resource Download Center ................37 Figure 4-1: Clear CMOS Button Location ................... 43 Figure 4-2: TXE Override Jumper Location ................
  • Page 11 DRPC-130-AL Embedded System List of Tables Table 1-1: DRPC-130-AL Model Variations .................. 3 Table 1-2: Technical Specifications ....................7 Table 3-1: mSATA and PCIe Mode Select Switch Settings ............19 Table 3-2: PCIe Mini Card Slot – Full Size (MPCIE1) Pinouts ........... 25 Table 3-3: PCIe Mini Card Slot –...

  • Page 13: Introduction

    DRPC-130-AL Embedded System Chapter Introduction Page 1...

  • Page 14: Overview

    It is designed for harsh environment applications, and supports DIN rail mounting method. The DRPC-130-AL accepts a wide range of DC power input (12 V ~ 24 V), allowing it to be powered anywhere. Four USB 3.2 Gen 1 (5Gb/s), two GbE, four RS-232/422/485, one 8-bit digital I/O, two HDMI and isolated CAN bus provide rich I/O options for various applications.

  • Page 15: Model Variations

    DRPC-130-AL Embedded System 1.2 Model Variations The model variations of the DRPC-130-AL are listed below. Model No. Pre-installed Memory DRPC-130-AL-E1 4 GB DDR3L SO-DIMM DRPC-130-AL-E1/4GB Table 1-1: DRPC-130-AL Model Variations 1.3 Features The DRPC-130-AL features are listed below: Fanless design ...

  • Page 16: Front Panel

    DRPC-130-AL Embedded System 1.4 Front Panel The DRPC-130-AL front panel contains: 1 x DB-9 supporting 2-port isolated CAN bus  1 x 8-bit digital I/O  2 x RJ-45 Gigabit LAN ports  4 x RS-232/422/485 serial ports  4 x USB 3.2 Gen 1 (5Gb/s) ports ...

  • Page 17: Top Panel

    DRPC-130-AL Embedded System 1.5 Top Panel The DRPC-130-AL top panel contains: 1 x 12 V ~ 24 V DC power terminal block  1 x Earth ground connector  1 x PS-ON connector  2 x HDMI connector  1 x Power button ...

  • Page 18: Technical Specifications

    DRPC-130-AL Embedded System 1.6 Technical Specifications The DRPC-130-AL technical specifications are listed in Table 1-2. System ® ® CPU (SoC) Intel Atom x5-E3930 processor 1.3GHz (up to 1.8 GHz, dual-core, TDP=6.5W) Memory One 204-pin DDR3L SO-DIMM slot (system max. 8 GB)

  • Page 19: Table 1-2: Technical Specifications

    DRPC-130-AL Embedded System Interior Expansion 1 x PCIe Mini full-size/half-size card slot (supports mSATA module or WWAN module) 1 x PCIe Mini half-size card slot (reserved for optional Wi-Fi module) LED Indicators 1 x HDD LED (yellow) 1 x Power LED (green)

  • Page 20: Dimensions

    DRPC-130-AL Embedded System 1.7 Dimensions The physical dimensions are shown below: Figure 1-4: Physical Dimensions (millimeters) Page 8...

  • Page 21: Unpacking

    DRPC-130-AL Embedded System Chapter Unpacking Page 9...

  • Page 22: Anti-Static Precautions

    DRPC-130-AL and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the DRPC-130-AL. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the DRPC-130-AL or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 23: Packing List

    If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the DRPC-130-AL from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@ieiworld.com.

  • Page 24: Optional Items

    Power cable, DC jack to 3-pin terminal block, 200 mm (P/N: 32102-026500-100-RS) Wireless kit (P/N: EMB-WIFI-KIT01-R20) 20-pin Infineon TPM 2.0 module, software management tool, firmware v5.5 (P/N: TPM-IN02-R20) ® OS Image with Windows 10 IoT Enterprise Entry 64-bit for DRPC-130-AL Series, with DVD-ROM, RoHS (P/N: DRPC-130-W10E64-E-R10) Page 12...

  • Page 25: Installation

    DRPC-130-AL Embedded System Chapter Installation Page 13...

  • Page 26: Installation Precautions

    DRPC-130-AL. The DRPC-130-AL’s cooling vents must not be obstructed by any objects. Blocking the vents can cause overheating of the DRPC-130-AL. Leave at least 5 cm of clearance around the DRPC-130-AL to prevent overheating. Grounding: The DRPC-130-AL should be properly grounded. The voltage ...

  • Page 27: Internal Access Panel Removal

    3.2 Internal Access Panel Removal Before installing or maintaining the internal components, the internal access panel must be removed from the DRPC-130-AL. Follow the steps below to complete the task. Step 1: Remove the six retention screws indicated in Figure 3-1.

  • Page 28: So-Dimm Installation (Optional)

    3.3 SO-DIMM Installation (Optional) To install the SO-DIMM module, please follow the steps below. Step 1: Remove the internal access panel from the DRPC-130-AL. Please follow the instruction described in Section 3.2. Step 2: Locate the SO-DIMM slot on the motherboard.

  • Page 29: Hdd Installation

    It is recommended to use 2.5" HDD/SSD as the main system drive. The DRPC-130-AL allows installation of one 2.5” HDD/SSD. To install a HDD into the system, please follow the steps below.

  • Page 30: Pcie Mini Card Installation (Msata Or Wwan)

    Replace and secure the internal access panel to the system. 3.5 PCIe Mini Card Installation (mSATA or WWAN) The DRPC-130-AL has one full-size/half-size PCIe Mini slot (MPCIE1) on the motherboard for mSATA SSD or WWAN module installation. Refer to the instructions described in the following sections for how to set the mode and how to install a PCIe Mini card in the slot.

  • Page 31: Msata/Pcie Mode Selection

    Figure 3-6: mSATA and PCIe Mode Select Switch Location This switch is located on the rear side of the motherboard. To access the switch, please follow the instruction below to remove the motherboard from the DRPC-130-AL. Step 1: Remove the internal access panel from the DRPC-130-AL. See Section 3.2.

  • Page 32: Figure 3-7: D-Sub Hex Screws And Front Panel Bracket Screws

    DRPC-130-AL Embedded System Figure 3-7: D-sub Hex Screws and Front Panel Bracket Screws Step 3: Remove the top panel bracket. Loosen the screws (circled in red) to remove the two terminal block covers. Remove the three retention screws circled in yellow.

  • Page 33: Full-Size Pcie Mini Card Installation

    3.5.2 Full-size PCIe Mini Card Installation To install a full-size PCIe Mini module, follow the instructions below. Step 1: Remove the internal access panel from the DRPC-130-AL. See Section 3.2. Step 2: Locate the PCIe Mini slot on the motherboard (Figure 3-10).

  • Page 34: Figure 3-11: Removing The Standoff For Half-Size Pcie Mini Card

    DRPC-130-AL Embedded System Figure 3-11: Removing the Standoff for Half-size PCIe Mini Card Step 4: Remove the retention screw as shown in Figure 3-12. Figure 3-12: Removing the Retention Screw Step 5: Line up the notch on the card with the notch on the slot. Slide the PCIe Mini card into the socket at an angle of about 20º...

  • Page 35: Half-Size Pcie Mini Card Installation

    DRPC-130-AL Embedded System Figure 3-14: Securing the Full-size PCIe Mini Card 3.5.3 Half-size PCIe Mini Card Installation The PCIe Mini slot (MPCIE1) also allows installation of a half-size PCIe Mini card. To install a half-size PCIe Mini card, please follow the steps below.

  • Page 36: Figure 3-16: Inserting The Half-Size Pcie Mini Card Into The Slot At An Angle

    DRPC-130-AL Embedded System Figure 3-16: Inserting the Half-size PCIe Mini Card into the Slot at an Angle Step 3: Secure the half-size PCIe Mini card with the retention screw previously removed (Figure 3-17). Figure 3-17: Securing the Half-size PCIe Mini Card...

  • Page 37: Pcie Mini Card Slot Pinouts - Full/Half Size (Mpcie1)

    DRPC-130-AL Embedded System 3.5.4 PCIe Mini Card Slot Pinouts – Full/Half Size (MPCIE1) The MPCIE1 slot supports USB and PCIe signal for installing mSATA or WWAN modules. PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_WAKE# VCC3 VCC1.5 CLKREQ# REFCLK0- REFCLK0+ PERST#...

  • Page 38: Wireless Lan Module Installation (Optional)

    Section 3.2. Step 2: Remove the two knockout holes for antenna installation. The two knockout holes are located on the top panel of the DRPC-130-AL as shown below. Figure 3-18: Knockout Holes for Wireless Antenna Step 3: Locate the half-size PCIe Mini slot (Figure 3-19).

  • Page 39: Figure 3-20: Removing The Retention Screw

    DRPC-130-AL Embedded System Step 4: Remove the retention screw for half-size card installation as shown below. Figure 3-20: Removing the Retention Screw Step 5: Line up the notch on the WLAN module with the notch on the slot. Slide the WLAN module into the slot at an angle of about 20º...

  • Page 40: Figure 3-22: Securing Wlan Module And Connecting Rf Cables

    DRPC-130-AL Embedded System Figure 3-22: Securing WLAN Module and Connecting RF Cables Step 8: Remove the nut and washer from the SMA connector at the other end of the RF cable. Step 9: Insert the SMA connector to the antenna connector holes on the rear panel.

  • Page 41: Pcie Mini Card Slot Pinouts - Half Size (Mpcie2)

    DRPC-130-AL Embedded System 3.6.1 PCIe Mini Card Slot Pinouts – Half Size (MPCIE2) The MPCIE2 slot supports USB and PCIe signal and is reserved for WLAN module installation. PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_WAKE# VCC3 RESERVED RESERVED VCC1.5 CLKREQ#...

  • Page 42: Can Bus Connection

    DRPC-130-AL Embedded System 3.7 CAN Bus Connection The DRPC-130-AL has one CAN bus connector that supports two CAN bus connections. The pinouts for the CAN bus connector are listed in the table below. Description Description CAN1_GND CAN0_L CAN1_H CAN0_GND CAN1_L...

  • Page 43: Lan Connection

    DRPC-130-AL Embedded System PIN NO. RS-232 RS-422 RS-485 Table 3-6: RS-232/422/485 Connector Pinouts 3.10 LAN Connection The LAN connectors allow connection to an external network. Description Description TRD1P0 TRD1P2 TRD1N0 TRD1N2 TRD1P1 TRD1P3 TRD1N1 TRD1N3 Table 3-7: LAN1 Pinouts Description...

  • Page 44: At/Atx Mode Selection

    Table 3-9: RJ-45 Ethernet Connector LEDs 3.11 AT/ATX Mode Selection AT and ATX power modes can both be used on the DRPC-130-AL. The selection is made through an AT/ATX switch on the top panel as shown below (Figure 3-25). Figure 3-25: AT/ATX Switch Location...

  • Page 45: Din Rail Mounting

    DRPC-130-AL Embedded System 3.12 DIN Rail Mounting To mount the DRPC-130-AL embedded system onto a DIN rail, please follow the steps below. Step 1: Attach the supplied DIN rail mounting bracket to the rear panel of the embedded system. Secure the bracket to the embedded system with three retention screws (Figure 3-26).

  • Page 46: Figure 3-27: Attach The Mounting Bracket To The Din Rail

    DRPC-130-AL Embedded System Step 2: Attach the upper edge of the mounting bracket to the DIN rail as shown in Figure 3-27. Figure 3-27: Attach the Mounting Bracket to the DIN Rail Step 3: Push the system toward the DIN rail until the mounting bracket clips into place firmly (Figure 3-28).

  • Page 47: Power -O N Procedure

     3.13.2 Terminal Block Pinouts The DRPC-130-AL model has a 12 V–24 V power input terminal block. The terminal block pinouts are shown below. Make sure that the power and ground wires are attached to the correct sockets of the connector.

  • Page 48: Power-On Procedure

    DRPC-130-AL Embedded System 3.13.3 Power-on Procedure To power-on the DRPC-130-AL please follow the steps below: Step 1: Connect the power source to the power input terminal block. Step 2: Connect the grounding cable to the grounding connector on the top panel of the DRPC-130-AL.

  • Page 49: Ps-On, 2-Pin Terminal Block

    The pinouts of the PS-ON connector are listed below. 3.14 Available Drivers All the drivers for the DRPC-130-AL are available on IEI Resource Download Center (https://download.ieiworld.com). Type DRPC-130-AL and press Enter to find all the relevant software, utilities, and documentation.

  • Page 50: Driver Download

    3.14.1 Driver Download To download drivers from IEI Resource Download Center, follow the steps below. Step 1: Go to https://download.ieiworld.com. Type DRPC-130-AL and press Enter. Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result.
  • Page 51 DRPC-130-AL Embedded System Page 39...

  • Page 52: Troubleshooting And Maintenance

    DRPC-130-AL Embedded System Chapter Troubleshooting and Maintenance Page 40...

  • Page 53: System Maintenance Overview

    Failure to follow these instructions may lead to personal injury and system damage. To preserve the working integrity of the DRPC-130-AL embedded system, the system must be properly maintained. If embedded system components need replacement, the proper maintenance procedures must be followed to ensure the system can continue to operate normally.

  • Page 54: The System Doesn't Boot Up

    If all troubleshooting measures have been taken and the system still fails to start, contact the IEI reseller or vendor you purchased the DRPC-130-AL from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@ieiworld.com.

  • Page 55: Clear Cmos

    Step 0: 4.3.1 Clear CMOS If the DRPC-130-AL fails to boot due to improper BIOS settings, the clear CMOS button clears the CMOS data and resets the system BIOS information. To do this, push the clear CMOS button for a few seconds.

  • Page 56: Txe Override Jumper

    DRPC-130-AL Embedded System 4.3.2 TXE Override Jumper The TXE Override jumper (J_TXE1) allows users to enable or disable the TXE firmware update. Refer to Figure 4-2 and Table 4-1 for the jumper location and settings. Setting Description Open Disabled (default)

  • Page 57: Bios

    DRPC-130-AL Embedded System Chapter BIOS Page 45...

  • Page 58: Introduction

    DRPC-130-AL Embedded System 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 59: Getting Help

    DRPC-130-AL Embedded System Function Decrease the numeric value or make changes Esc key Main Menu – Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu...

  • Page 60: Main

    DRPC-130-AL Embedded System The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.

  • Page 61: Advanced

    DRPC-130-AL Embedded System System Date [xx/xx/xx]  Use the System Date option to set the system date. Manually enter the day, month and year. System Time [xx:xx:xx]  Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 62: Trusted Computing

    DRPC-130-AL Embedded System 5.3.1 Trusted Computing Use the Trusted Computing menu (BIOS Menu 3) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced Configuration...

  • Page 63: Acpi Settings

    DRPC-130-AL Embedded System 5.3.2 ACPI Settings The ACPI Settings menu (BIOS Menu 4) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced ACPI Settings Select the highest ACPI sleep state the system...

  • Page 64: F81866 Super Io Configuration

    DRPC-130-AL Embedded System 5.3.3 F81866 Super IO Configuration Use the F81866 Super IO Configuration menu (BIOS Menu 5) to set or change the configurations for the serial ports. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced F81866 Super IO Configuration...

  • Page 65: Serial Port 1 Configuration

    DRPC-130-AL Embedded System 5.3.3.1.1 Serial Port 1 Configuration Serial Port [Enabled]  Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enabled Enable the serial port EFAULT Change Settings [IO=3F8h; IRQ=4] ...

  • Page 66: Serial Port 2 Configuration

    DRPC-130-AL Embedded System 5.3.3.1.2 Serial Port 2 Configuration Serial Port [Enabled]  Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enabled Enable the serial port EFAULT Change Settings [IO=2F8h; IRQ=3] ...

  • Page 67: Serial Port 3 Configuration

    DRPC-130-AL Embedded System 5.3.3.1.3 Serial Port 3 Configuration Serial Port [Enabled]  Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enabled Enable the serial port EFAULT Change Settings [IO=3F8h; IRQ=10] ...

  • Page 68: Serial Port 4 Configuration

    DRPC-130-AL Embedded System 5.3.3.1.4 Serial Port 4 Configuration Serial Port [Enabled]  Use the Serial Port option to enable or disable the serial port.  Disabled Disable the serial port  Enabled Enable the serial port EFAULT Change Settings [IO=2E8h; IRQ=10] ...

  • Page 69: Iwdd H/W Monitor

    DRPC-130-AL Embedded System 5.3.4 iWDD H/W Monitor The iWDD H/W Monitor menu (BIOS Menu 7) contains the fan configuration submenus and displays operating temperature and system voltages. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced PC Health Status...

  • Page 70: Usb Configuration

    DRPC-130-AL Embedded System 5.3.5 USB Configuration Use the USB Configuration menu (BIOS Menu 8) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support.

  • Page 71: Cpu Configuration

    DRPC-130-AL Embedded System  Disabled Legacy USB support disabled  Auto Legacy USB support disabled if no USB devices are connected 5.3.6 CPU Configuration Use the CPU Configuration BIOS menu (BIOS Menu 9) to view detailed CPU specifications and configure the CPU.
  • Page 72 DRPC-130-AL Embedded System Intel VT-x Technology: Indicates if Intel VT-x Technology is supported by the  CPU. L1 Data Cache: Lists the amount of data storage space on the L1 cache.  L1 Code Cache: Lists the amount of code storage space on the L1 cache.

  • Page 73: Rtc Wake Settings

    DRPC-130-AL Embedded System VT-d [Disabled]  Use the VT-d option to enable or disable VT-d capability.  Disabled Disables VT-d capability. EFAULT  Enabled Enables VT-d capability. 5.3.7 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 10) configures RTC wake event.

  • Page 74: Power Saving Configuration

    DRPC-130-AL Embedded System  Enabled If selected, the following appears with values that can be selected: *Wake up every day *Wake up date *Wake up hour *Wake up minute *Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off.

  • Page 75: Serial Port Console Redirection

    DRPC-130-AL Embedded System  Disabled Power saving function is disabled. EFAULT  Enabled Power saving function is enabled. It will reduce power consumption when the system is off. 5.3.9 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 12) allows the console redirection options to be configured.
  • Page 76 DRPC-130-AL Embedded System The following options are available in the Console Redirection Settings submenu when the Console Redirection option is enabled. Terminal Type [ANSI]  Use the Terminal Type option to specify the remote terminal type.  VT100 The target terminal type is VT100 ...

  • Page 77: Legacy Console Redirection Settings

    DRPC-130-AL Embedded System  Even The parity bit is 0 if the number of ones in the data bits is even.  The parity bit is 0 if the number of ones in the data bits is odd.  Mark The parity bit is always 1.

  • Page 78: Iei Feature

    DRPC-130-AL Embedded System Legacy Serial Redirection Port [COM1]  Use the Legacy Serial Redirection Port option to select a COM port to display redirection of legacy OS and legacy OPROM messages. Configuration options are listed below. COM1 Default  COM2 ...

  • Page 79: Chipset

    DRPC-130-AL Embedded System  Disabled Auto recovery function disabled EFAULT  Enabled Auto recovery function enabled 5.4 Chipset Use the Chipset menu (BIOS Menu 15) to access the North Bridge and South Bridge subsystem configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 80: North Bridge

    DRPC-130-AL Embedded System 5.4.1 North Bridge Use the North Bridge menu (BIOS Menu 16) to configure the north bridge parameters. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset > Intel IGD Configuration Intel IGD Configuration > LCD Control...

  • Page 81: Intel Igd Configuration

    DRPC-130-AL Embedded System 5.4.1.1 Intel IGD Configuration Use the Intel IGD Configuration submenu (BIOS Menu 17) to configure the graphics settings. Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc. Chipset IGD Configuration Enable: Enable Integrated Graphics Integrated Graphics Device...
  • Page 82 DRPC-130-AL Embedded System DVMT Pre-Allocated [256M]  Use the DVMT Pre-Allocated option to specify the amount of system memory that can be used by the internal graphics device.  64 MB of memory used by internal graphics device  128M...

  • Page 83: Lcd Control

    DRPC-130-AL Embedded System 5.4.1.2 LCD Control Use the LCD Control submenu (BIOS Menu 18) to select a display device which will be activated during POST. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset LCD Control Select the Video Device...

  • Page 84: South Bridge

    DRPC-130-AL Embedded System 5.4.2 South Bridge Use the South Bridge menu (BIOS Menu 19) to configure the south bridge parameters. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset Auto Power Button Status [Disabled (ATX)] Select AC power state >...

  • Page 85: Hd-Audio Configuration

    DRPC-130-AL Embedded System BIOS Options Configured USB Ports LAN1_USB1 (external USB 3.2 Gen 1 ports) USB Power SW1 LAN2_USB1 (external USB 3.2 Gen 1 ports) USB Power SW2 USB2-2 (internal USB 2.0 port) Table 5-2: BIOS Options and Configured USB Ports 5.4.2.1 HD-Audio Configuration...

  • Page 86: Pci Express Configuration

    DRPC-130-AL Embedded System 5.4.2.2 PCI Express Configuration Use the PCI Express Configuration submenu (BIOS Menu 21) to configure the PCI Express slots. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset PCI Express Configuration Control the PCI Express >...
  • Page 87 DRPC-130-AL Embedded System 5.4.2.2.1 Onboard LAN1/LAN2 Use the Onboard LAN1/LAN2 menu (BIOS Menu 22) to configure the LAN 1 or LAN 2 port. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset PCIe Speed [Auto] Control the PCI Express Root Port.
  • Page 88 DRPC-130-AL Embedded System 5.4.2.2.2 MPCIE1/MPCIE2 Use the MPCIE1/MPCIE2 menu (BIOS Menu 23) to configure the PCIe Mini slots. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset PCIe Speed [Auto] Configure PCIe Speed --------------------- : Select Screen ↑ ↓: Select Item...

  • Page 89: Sata Configuration

    DRPC-130-AL Embedded System 5.4.2.3 SATA Configuration Use the SATA Configuration menu (BIOS Menu 24) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Chipset SATA Configuration...

  • Page 90: Security

    DRPC-130-AL Embedded System 5.5 Security Use the Security menu (BIOS Menu 25) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Password Description Set Administrator Password If ONLY the Administrator’s password is set,...

  • Page 91: Boot

    DRPC-130-AL Embedded System 5.6 Boot Use the Boot menu (BIOS Menu 26) to configure system boot options. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Boot Configuration Select the keyboard...
  • Page 92 DRPC-130-AL Embedded System Quiet Boot [Enabled]  Use the Quiet Boot BIOS option to select the screen display when the system boots.  Disabled Normal POST messages displayed  Enabled OEM Logo displayed instead of POST messages EFAULT Launch PXE OpROM [Disabled] ...

  • Page 93: Save & Exit

    DRPC-130-AL Embedded System 5.7 Save & Exit Use the Exit menu (BIOS Menu 27) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc. Main Advanced Chipset...
  • Page 94 DRPC-130-AL Embedded System Save as User Defaults  Use the Save as User Defaults option to save the changes done so far as user defaults. Restore User Defaults  Use the Restore User Defaults option to restore the user defaults to all the setup options.

  • Page 95: Interface Connectors

    DRPC-130-AL Embedded System Chapter Interface Connectors Page 83...

  • Page 96: Peripheral Interface Connectors

    DRPC-130-AL Embedded System 6.1 Peripheral Interface Connectors The DRPC-130-AL embedded system motherboard comes with a number of peripheral interface connectors and configuration jumpers. The connector locations are shown in Table 6-1 and Figure 6-2. The Pin 1 locations of the on-board connectors are also indicated in the diagrams.

  • Page 97: Internal Peripheral Connectors

    DRPC-130-AL Embedded System Figure 6-2: Main Board Layout Diagram (Solder Side) 6.2 Internal Peripheral Connectors Internal peripheral connectors on the motherboard and are only accessible when the motherboard is outside of the chassis. The table below shows a list of the connectors on the motherboard.

  • Page 98: Battery Connector (Bt1)

    DRPC-130-AL Embedded System Connector Type Label SPI flash connector (EC) 6-pin wafer J_SPI2 USB 2.0 connector 4-pin wafer USB2-2 TPM connector 20-pin header TPM1 Table 6-1: Peripheral Interface Connectors 6.2.1 Battery Connector (BT1) PIN NO. DESCRIPTION Table 6-2: Battery Connector (BT1) Pinouts 6.2.2 CPU Fan Connector (CPU_FAN1)

  • Page 99: Sata Connector (Sata1)

    DRPC-130-AL Embedded System 6.2.4 SATA Connector (SATA1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +V5S SATA_RXP0 SATA_RXN0 +V5S +V5S SATA_TXN0 +V5S SATA_TXP0 +V5S Table 6-5: SATA 3Gb/s Connector (SATA1) Pinouts 6.2.5 USB 2.0 Connector (USB2-2) PIN NO. DESCRIPTION +5VSUS -DATA4 +DATA4 Table 6-6: USB 2.0 Connector (USB2-2) Pinouts...

  • Page 100: Spi Flash Connector - Ec (J_Spi2)

    DRPC-130-AL Embedded System 6.2.7 SPI Flash Connector - EC (J_SPI2) PIN NO. DESCRIPTION +V3.3 SPI_CS#0_CN_EC SPI_SO_SW_EC SPI_CLK_SW_EC SPI_SI_SW_EC Table 6-8: SPI Flash Connector - EC (J_SPI2) Pinouts 6.2.8 TPM Connector (TPM1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION LPC_TPM LPC_FRAME_N BUF_PLTRST#...

  • Page 101: Regulatory Compliance

    DRPC-130-AL Embedded System Appendix Regulatory Compliance Page 89...

  • Page 102: Declaration Of Conformity

    DRPC-130-AL Embedded System DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive 2004/30/EU  Low-Voltage Directive 2014/35/EU  RoHS II Directive 2015/863/EU  If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
  • Page 103 DRPC-130-AL Embedded System Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ...
  • Page 104 DRPC-130-AL Embedded System Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 1999/5/CE. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.
  • Page 105 DRPC-130-AL Embedded System FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and  This device must accept any interference received, including interference that ...

  • Page 106: Safety Precautions

    DRPC-130-AL Embedded System Appendix Safety Precautions Page 94...

  • Page 107: Safety Precautions

    DRPC-130-AL Embedded System B.1 Safety Precautions WARNING: The precautions outlined in this appendix should be strictly followed. Failure to follow these precautions may result in permanent damage to the DRPC-130-AL. Please follow the safety precautions outlined in the sections that follow: B.1.1 General Safety Precautions...

  • Page 108: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the DRPC-130-AL. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the DRPC-130-AL is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.

  • Page 109: Product Disposal

    DRPC-130-AL Embedded System B.1.4 Product Disposal CAUTION: Risk of explosion if the battery is replaced by an incorrect type; Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types);...

  • Page 110: Maintenance And Cleaning Precautions

    When maintaining or cleaning the DRPC-130-AL, please follow the guidelines below. B.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the DRPC-130-AL, please read the details below. The interior of the DRPC-130-AL does not require cleaning. Keep fluids away ...

  • Page 111: Digital I/O Interface

    DRPC-130-AL Embedded System Appendix Digital I/O Interface Page 99...

  • Page 112: Sub-Function

    DRPC-130-AL Embedded System The DIO connector on the DRPC-130-AL is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 8-bit digital inputs and 8-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.
  • Page 113 DRPC-130-AL Embedded System AH – 6FH Sub-function: AL – 9 :Set the digital port as OUTPUT :Digital I/O output value Assembly Language Sample 2 AX, 6F09H ;setting the digital port as output BL, 09H ;digital value is 09H Digital Output is 1001b...

  • Page 114: Watchdog Timer

    DRPC-130-AL Embedded System Appendix Watchdog Timer Page 102...
  • Page 115 DRPC-130-AL Embedded System NOTE: The following discussion applies to DOS. Contact IEI support or visit the IEI website for drivers for other operating systems. The Watchdog Timer is a hardware-based timer that attempts to restart the system when it stops working. The system may stop working because of external EMI or software bugs.

  • Page 116: Example Program

    DRPC-130-AL Embedded System NOTE: The Watchdog Timer is activated through software. The software application that activates the Watchdog Timer must also deactivate it when closed. If the Watchdog Timer is not deactivated, the system will automatically restart after the Timer has finished its countdown.

  • Page 117: E Error Beep Code

    DRPC-130-AL Embedded System Appendix Error Beep Code Page 105...

  • Page 118: Pei Beep Codes

    DRPC-130-AL Embedded System E.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed...

  • Page 119: F Hazardous Materials Disclosure

    DRPC-130-AL Embedded System Appendix Hazardous Materials Disclosure Page 107...
  • Page 120 DRPC-130-AL Embedded System The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 121 DRPC-130-AL Embedded System 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 (Pb) (Hg) (Cd) (CR(VI)) (PBB) 醚 (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...

Table of Contents
