- Page 1 ELVA Series USER MANUAL V. 25.01...
- Page 2 Lynx Pro Audio S.L. shall not be liable to the purchaser of this product or to third parties for any damages, losses, costs, or expenses incurred by the purchaser as a result of an accident, issue, or abuse of this product, nor for any modifications, repairs, or alterations to it, or for failing to strictly adhere to the operating and maintenance instructions of Lynx Pro Audio S.L.
-
Page 3: Table Of Contents
CONTENTS IMPORTANT SAFETY INSTRUCTIONS ..........................5 1. INTRODUCTION......................................6 INSTALLATION GUIDE...............................7 USER GUIDE..................................8 3. TECHNICAL DATA ................................9 4. RAINBOW (Acoustic Prediction software) .......................12 GUARANTEE ..................................13... - Page 4 We hope that as a user you will be completely satisfied. We are sure that the ELVA speaker will meet your expectations and make it easier for you to get the most out of your system. ELVA Series | User Manual...
-
Page 5: Important Safety Instructions
Before unpacking your new speaker, verify that the box does not show any damage or deformation. If this happens, please claim the damage to your fordwarder. Once unpacked and verified its correct operation, keep the original box in case you need to ship it back to your provider. ELVA Series | User Manual... -
Page 6: Introduction
The ELVA series also excels in houses of worship, where intelligibility and even sound distribution are paramount. For broadcast and multimedia spaces, these speakers deliver accurate and detailed sound reproduction, ensuring that every nuance of the audio is captured and delivered with clarity. -
Page 7: Installation Guide
Refer to the speaker’s manual for safe overhead installation instructions, which likely recommend two people. • Avoid extrem weather conditions Do not install the speaker in direct sunlight, rain, or any other liquids. The speaker is not waterproof. If installed outdoors, protect it from the elements. ELVA Series | User Manual... -
Page 8: User Guide
To ensure safe operation, avoid placing liquids or objects near the appliance. If a spill happens, unplug it quickly and contact after-sales service. • Before a thunderstorm or lightning storm, unplug the appliance from the power outlet for safety. ELVA Series | User Manual... -
Page 9: Technical Data
Dimensions 160 x 221 x 128 (mm) Weight 2,5 Kg Fittings 1 x M4 safety, 2 x M4 wall bracket Wall bracket included Accessories Other info IP66 rating when used with accesory terminal cover. • Dimmensions: ELVA Series | User Manual... - Page 10 209 x 294 x 185 (mm) Weight 3 Kg Fittings 1 x M4 safety, 2 x M4 wall bracket Accessories Wall bracket included Wall bracket include IP66 rating when used with accesory Other info terminal cover. • Dimmensions: ELVA Series | User Manual...
- Page 11 Dimensions 241 x 339 x 195 (mm) Weight 5 Kg Fittings 1 x M4 safety, 2 x M4 wall bracket Accessories Wall bracket included Other info IP66 rating when used with accesory terminal cover • Dimmensions: ELVA Series | User Manual...
-
Page 12: Rainbow (Acoustic Prediction Software)
• Multiple listening zones The program can simulate all Lynx Pro Audio’s acoustic enclosures located in a 3D space, including the classic side, top and front views. It can also define multiple listening zones and allows offset positioning and symmetry. Blueprint images, textures and PNG format pictures can be imported. -
Page 13: Guarantee
Lynx Pro Audio S.L. In the case that the product could not be returned to the factory for checking and repairing, Lynx Pro Audio S.L. -
Page 14: Declaration Of Conformity
DECLARATION OF CONFORMITY Lynx Pro Audio S.L. Calle 1 - Pol. Ind. Picassent 46220 Picassent (Valencia) SPAIN - EU Tel.: (+34) 961 10 96 01 www.lynxproaudio.com Lynx Pro Audio S.L. declares that ELVA series are in conformity with the following EC directives: Low Voltage Directive 2014/35/UE Electromagnetic Compatibility EMC 2014/30/UE RoHS Directive 2011/65/UE RAEE (WEEE) - Page 15 LYNX Pro Audio S.L. Calle 1. Pol. Ind. Picassent, Picassent, Valencia 46220 España +34 961 109 601 info@lynxproaudio.com www.lynxproaudio.com...
