- Page 1 OPERATING INSTRUCTIONS Translation of the Original CNR 36X Capacitive gauge...
-
Page 2: Dear Customer
Dear Customer, Thank you for choosing a Pfeiffer Vacuum product. Your new gauge is designed to support you in your individual application with maximum performance and without malfunctions. The name Pfeiffer Vacuum stands for high-quality vacuum technology, a comprehensive and complete range of top-quality products and first-class service. -
Page 3: Table Of Contents
Foreseeable improper use Responsibilities and warranty Operator requirements Personnel qualification 2.9.1 Ensuring personnel qualification 2.9.2 Personnel qualification for maintenance and repair 2.9.3 Advanced training with Pfeiffer Vacuum 2.10 Operator requirements Product description Function Button and status display Switching functions Identifying the product... - Page 4 Table of contents Shipping Recycling and disposal 10.1 General disposal information 10.2 Dispose of gauges Service solutions by Pfeiffer Vacuum Accessories 12.1 Accessory information 12.2 Ordering accessories Technical data and dimensions 13.1 General 13.2 Technical data 13.3 Dimensions ETL certification...
-
Page 5: List Of Tables
List of tables List of tables Tbl. 1: Applicable documents Tbl. 2: CNR 36x variants with P-control filter Tbl. 3: Abbreviations used Tbl. 4: Permissible ambient conditions Tbl. 5: Illuminating diodes Tbl. 6: Constants for converting measuring signal and pressure Tbl. -
Page 6: List Of Figures
List of figures List of figures Fig. 1: Button and LED Fig. 2: Relay contacts dependent upon the switch-points Fig. 3: Establishing vacuum connection Fig. 4: Connection diagram Fig. 5: D-sub cable socket Fig. 6: Measurement cable Fig. 7: Relation between measuring signal and pressure Fig. -
Page 7: About This Manual
CNR 36x variants with P-control filter You can find the part number on the rating plate of the product. Pfeiffer Vacuum reserves the right to make technical changes without prior notification. Information that relates to only one of the products is indicated accordingly. -
Page 8: Conventions
About this manual ● Transportation ● Setup (Installation) ● Usage and operation ● Decommissioning ● Maintenance and cleaning ● Storage or disposal The work described in this document is only permitted to be performed by persons with the appropriate technical qualifications (expert personnel) or who have received the relevant training from Pfeiffer Vac- uum. -
Page 9: Abbreviations
About this manual Rating plate The rating plate is locat- ed on the side of the unit. Mod. CNR 36x 2000123456 PT T20 136 22x DExxxxxxxxxxx 3103457 Input 14 ... 30 V DC 1 W LPS Range xxxx Torr Made in Liechtenstein 2024/12 Mod. -
Page 10: Safety
Safety instructions according to product life stages All safety instructions in this document are based on the results of a risk assessment. Pfeiffer Vacuum has taken into account all the relevant life stages of the product. Risks during installation DANGER Danger to life due to dangerous contact voltage Voltages above 30 V (AC) or 60 V (DC) are considered dangerous in accordance with EN 61010. - Page 11 Safety DANGER Risk to life due to electric shock An improperly earthed product is potentially fatal in the event of a fault. ► Connect the product galvanically with the earthed vacuum chamber. ► Ensure that the connection complies with the requirements of a protective bonding according to EN 61010.
- Page 12 ► Only operate the unit in a dry environment. ► Operate the unit away from fluids and sources of moisture. ► Do not switch on the unit if fluid has entered it. Instead contact Pfeiffer Vacuum Service. ► Always disconnect the power supply before cleaning the unit.
-
Page 13: Safety Precautions
Safety Risks during disposal WARNING Health hazard through poisoning from toxic contaminated components or devices Toxic process media result in contamination of devices or parts of them. During maintenance work, there is a risk to health from contact with these poisonous substances. Illegal disposal of toxic sub- stances causes environmental damage. -
Page 14: Proper Use
The gauge is used for vacuum measurement of gases within its defined measuring range. Use the product according to its intended purpose ► Operate the gauge with a Pfeiffer Vacuum total pressure measuring and control unit or with an evaluation unit provided by the customer. -
Page 15: Personnel Qualification
─ Customer with Pfeiffer Vacuum service training ─ Pfeiffer Vacuum service technician 2.9.3 Advanced training with Pfeiffer Vacuum For optimal and trouble-free use of this product, Pfeiffer Vacuum offers a comprehensive range of courses and technical trainings. For more information, please contact Pfeiffer Vacuum technical training. -
Page 16: Operator Requirements
4. Comply with the limits of use. 5. Observe the technical data. 6. Please contact the Pfeiffer Vacuum Service Center if your questions on operation or maintenance of the product are not answered in these operating instructions. – You can find information in the Pfeiffer Vacuum service area. -
Page 17: Product Description
Product description 3 Product description 3.1 Function The gauge has a capacitive measuring element with a ceramic diaphragm. The pressure deflects the ceramic diaphragm. The gauge detects the deflection of the diaphragm as a change in the capacitance. The electronics convert the capacitance change to an output signal (DC). The output signal is linear with the pressure to be measured. -
Page 18: Identifying The Product
You will need all the data from the rating plate to safely identify the product when communicating with Pfeiffer Vacuum. ► To ensure clear identification of the product when communicating with Pfeiffer Vacuum, always keep all of the information on the rating plate to hand. -
Page 19: Transport And Storage
Transport and storage 4 Transport and storage 4.1 Transporting product NOTICE Damage caused by incorrect transport Transport in unsuitable packaging or failure to install all transport locks can result in damage to the product. ► Comply with the instructions for safe transport. Packing We recommend keeping the transport packaging and original protective cover. -
Page 20: Installation
Installation 5 Installation 5.1 Establishing vacuum connection DANGER Risk to life due to electric shock An improperly earthed product is potentially fatal in the event of a fault. ► Connect the product galvanically with the earthed vacuum chamber. ► Ensure that the connection complies with the requirements of a protective bonding according to EN 61010. -
Page 21: Establishing Electric Connection
► Only connect the product to devices which meet the following criteria: ● Requirements of the earthed protective extra-low voltage (PELV) ● Limited power source (LPS) Class 2 ► Secure the line to the product. – Pfeiffer Vacuum measuring and control equipment complies with this requirement. 21/44... - Page 22 Required tools ● Torque wrench (≤ 0.4 Nm) Required materials ● Measurement cable for a Pfeiffer Vacuum total pressure measuring and control unit from the Cen- terLine accessories range ● Self-fabricated measurement cable for an evaluation unit provided by the customer ●...
- Page 23 2. Tighten the locking screw on the D-sub cable socket. – Tightening torque: ≤ 0.4 Nm 3. Connect the gauge to a Pfeiffer Vacuum total pressure measuring and control unit or an evalua- tion unit provided by the customer. 23/44...
-
Page 24: Operation
Operation 6 Operation After switching on the supply voltage, the gauge is ready for operation. The measuring signal is inde- pendent of the gas type. Recommendations ► On initial operation, perform zero point adjustment. ► Allow a start-up time of at least 15 minutes for general pressure measurements within the specifi- cations. -
Page 25: Setting Threshold Values
Operation Measuring signal (U) Pressure (p) Constant (c) [Torr] 1.00 [hPa] 1013.25/760 = 1.3332 [mbar] [Pa] 101325/760 = 133.3224 Tbl. 6: Constants for converting measuring signal and pressure Converting measuring signal and pressure ► Observe the constants for converting the measuring signal and pressure. ►... - Page 26 Operation max. ø1.1 mm Fig. 9: Use the "zero" button to set the threshold value Setting threshold value SP1 1. Using a stylus, press and hold down the "SP" button. – The gauge changes to switching function mode and displays the current threshold value for 10 seconds at the measuring signal output.
-
Page 27: Dismantling
Dismantling 7 Dismantling DANGER Risk to life due to electric shock An improperly earthed product is potentially fatal in the event of a fault. ► Connect the product galvanically with the earthed vacuum chamber. ► Ensure that the connection complies with the requirements of a protective bonding according to EN 61010. - Page 28 Dismantling Disassembling the gauge 1. Disconnect the measurement cable from the gauge. 2. Disassemble the gauge from the vacuum system. 3. Fit the protective cap onto the connection flange. 28/44...
-
Page 29: Maintenance
► Only operate the unit in a dry environment. ► Operate the unit away from fluids and sources of moisture. ► Do not switch on the unit if fluid has entered it. Instead contact Pfeiffer Vacuum Service. ► Always disconnect the power supply before cleaning the unit. -
Page 30: Calibrating Gauge
► Operate the unit away from fluids and sources of moisture. ► Take special precautions if there is a risk of dripping water. ► Do not switch on the unit if fluid has penetrated into it, instead contact the Pfeiffer Vacuum Serv- ice Center. -
Page 31: Carrying Out Zero Point Calibration With "Zero" Button
Maintenance Recommended final pressure 10 Torr < 5 × 10 torr 5 Torr < 2.5 × 10 torr 2 Torr < 1 × 10 torr 1 Torr < 5 × 10 torr 0.5 Torr < 2.5 × 10 torr 0.25 Torr <... -
Page 32: Carrying Out Zero Point Calibration With "Zero" Button And Ramp Func
Maintenance 8.2.2 Carrying out zero point calibration with "zero" button and ramp function You can use the ramp function to: ● adjust the zero point in case of a known reference pressure that lies within the gauge's measuring range ● set a characteristic offset to compensate for a measurement system offset or to create a slightly positive zero point for a 0 to 10 V AD converter. - Page 33 Maintenance max. ø1.1 mm Fig. 12: Use the "zero" button to load the factory settings Procedure 1. Decommission the gauge. 2. Commission the gauge and at same time hold down the "zero" button with a stylus for longer than 5 seconds. –...
-
Page 34: Shipping
► Comply with the notices for safe shipment. Decontamination subject to charge Pfeiffer Vacuum decontaminates products not clearly declared "Free of contamination" at your expense. Safe shipping of the product ► Do not ship microbiological, explosive or radioactively contaminated products. -
Page 35: Recycling And Disposal
● Help to reduce the wastage of natural resources. ● Prevent contamination. 10.1 General disposal information Pfeiffer Vacuum products contain materials that you must recycle. ► Dispose of our products according to the following: – Iron – Aluminium –... -
Page 36: Service Solutions By Pfeiffer Vacuum
We are always focused on perfecting our core competence – servicing of vacuum components. Once you have purchased a product from Pfeiffer Vacuum, our service is far from over. This is often exactly where service begins. Obviously, in proven Pfeiffer Vacuum quality. - Page 37 Service solutions by Pfeiffer Vacuum 5. Prepare the product for transport in accordance with the provisions in the contamination declaration. a) Neutralize the product with nitrogen or dry air. b) Seal all openings with blind flanges, so that they are airtight.
-
Page 38: Accessories
Accessories 12 Accessories View the range of accessories for CenterLine on our website. 12.1 Accessory information Seals with centering ring and filter Filter available in different pore sizes to protect the measuring system against contamination in the event of potential contaminating applications 12.2 Ordering accessories Description Order number... -
Page 39: Technical Data And Dimensions
Technical data and dimensions 13 Technical data and dimensions 13.1 General mbar Torr | mm Hg mbar 1 · 10 0.75 1000 1000 1 · 10 0.01 0.01 1 · 10 1 · 10 7.5 · 10 0.75 1 · 10 0.01 1000 Torr | mm Hg 1.33... -
Page 40: Dimensions
Technical data and dimensions FS [Torr] 0.25 1000 Switch-point (voltage 30 V DC Switch-point (current 0.5 A Protection degree IP30 Volume 3.6 cm Materials in contact Ceramic (Al = 99.5%), stainless steel (AISI 316L) with media Material (flange) Stainless steel (AISI 316L) Weight DN 16 ISO-KF = 330 g DN 16 CF-R = 350 g... -
Page 41: Etl Certification
ETL LISTED The products CNR 36x/37x/38x/39x/30x - conform to the UL standard UL 61010-1. - are certified to the CAN/CSA standard CAN/CSA C22.2 No. 61010-1. 3103457... -
Page 42: Ec Declaration Of Conformity
Harmonized standards and applied national standards and specifications: DIN EN IEC 61000-6-2:2019 DIN EN IEC 61000-6-3:2022 DIN EN 61010-1:2020 DIN EN IEC 61326-1:2022 DIN EN IEC 63000:2019 Signature: Pfeiffer Vacuum GmbH Berliner Straße 43 35614 Asslar Germany (Daniel Sälzer) Asslar, 2024-12-02 Managing Director... -
Page 43: Declaration Of Conformity
EN IEC 61326-1:2021 EN IEC 63000:2018 The manufacturer's authorized representative in the United Kingdom and the authorized agent for compiling the technical documentation is Pfeiffer Vacuum Ltd, 16 Plover Close, In- terchange Park, MK169PS Newport Pagnell. Signature: Pfeiffer Vacuum GmbH Berliner Straße 43...
