Bennett 3000 Series Installation Manual

Hide thumbs Also See for 3000 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
PARTS
Installation Manual
3700 Commercial, 3800 Retail, Remote and
Self-Contained Dispensers
153871 Rev C 03/17/2025
Specification 300, Specification 400 (New
hydraulic layout effective 02/2024)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Bennett 3000 Series

Summary of Contents for Bennett 3000 Series

  • Page 1 PARTS Installation Manual 3700 Commercial, 3800 Retail, Remote and Self-Contained Dispensers 153871 Rev C 03/17/2025 Specification 300, Specification 400 (New hydraulic layout effective 02/2024)
  • Page 2 Before signing off on a shipment open each package and visually inspect. Inspect shipped materials for damage or missing equipment. Bennett Pump Company is not liable for the hazards of transportation. Please address damage claims directly to the delivery company.

  • Page 3: Table Of Contents

    Aboveground Storage Tanks..15 12.1 ........44 IRING IAGRAMS 6.1.2 Underground Storage Tanks ..15 12.2 ........ 46 OOTPRINT RAWINGS ......16 LUMBING EQUIREMENTS 12.2.1 Specification 300 ......46 6.2.1 Containment Sump ......16 12.2.2 Specification 400 ......48 3000 Series Installation Manual...

  • Page 4: Safety Instructions

    6. DANGER: PLACE A PROTECTIVE PHYSICAL BARRIER AROUND THE INSTALLATION ACTIVITY AREA BEFORE BEGINNING. 7. DANGER: GASOLINE AND FUEL ETHANOL ARE FLAMMABLE. NO SMOKING OR OPEN FLAME. 8. DANGER: FUEL (INCLUDING ETHANOL) IS POISONOUS AND SHOULD NOT BE INGESTED. 3000 Series Installation Manual...
  • Page 5 3. WARNING: Failure to properly ground the equipment can cause injury or damage to the equipment and will void the Bennett Limited Warranty. 4. WARNING: Do not use conduit as a ground. Do not use wire nuts on ground wires. Use only compression connectors on ground wires.
  • Page 6 Consult with the piping manufacturer to determine that the piping material, fittings, and connectors are compatible with alcohol-blended fuel. NOTICE: All installations of Bennett products and accessories (i.e., nozzles, hoses, and breakaways) must be performed by a trained and licensed technician following all codes, standards, and regulations.

  • Page 7: Introduction

    Institute of Standards and Technology. Compliance with these standards protects the operator and the consumer from personal injury. • Bennett Pump Company will not assume responsibility or liability for any consequential injury or damage caused by the unauthorized alteration of its products. 2.1 HAZARDOUS LOCATIONS Classified areas are hazardous locations.

  • Page 8: Materials

    Physical barriers to secure the work area. Pipe Joint Sealing Compound - UL Classified • • Potting compound – NFPA 70 approved Rigid metal conduit • • Schedule 40 steel inlet pipe Static Grounding Strap • 3000 Series Installation Manual Back to TOC...

  • Page 9: Related Documents

    Parts Manual 147828-Simply Secure Payment - Conexxus Protocol Programming, Service & Parts 147828 Manual Accessories 105022 515 Installation & Service Manual 141938 515XP Installation & Service Manual 139127 Bennett 3K 719 Configuration Visual Aid 3000 Series Installation Manual Back to TOC...

  • Page 10: Features

    OUTLET Low Hose: 1-1/4” (4.4 cm) dia NPT High Hose: 1” (2.54 cm) dia NPT PROTOCOL Bennett Current Loop, Generic Current Loop, RS485, Pulse Output 60 gpm / 230 lpm (Remote) FLOW RATE* 40 gpm / 150 lpm (Suction) *3K Big Fueler Remote and Suction flow rates are approximate and represent one hose active with Master and Satellite in simultaneous flow with a 1-1/2”...

  • Page 11: Specifications

    When installed, the dispenser’s field wiring connections are in an explosion-proof junction box located in the lower hydraulics area of the dispenser. Field wiring connections are terminated on the terminal strip and pulled into the electronic enclosure. 3000 Series Installation Manual Back to TOC...

  • Page 12: External +12 Vdc Battery

    Push the button to disconnect the dispenser battery power during service or when necessary, see Figure 3.1. • Only works during a power outage when the display shows AC OFF. Press and hold until the display is blank. • 3000 Series Installation Manual Back to TOC...

  • Page 13: The 719 Control Board

    2. 120 VAC Neutral or 220 VAC Line 7. Manager’s Keypad Terminal 3. 120 VAC Hot or 220 VAC Line 8. Personality Board 4. ON/OFF Switch 9. Intrinsically Safe Barrier 5. Calibration Switch 10. I/O Board Terminal 3000 Series Installation Manual Back to TOC...

  • Page 14: Layout

    Debit Pin Pad Alpha Numeric 719 Control Board Keypad Two w/ Active 4 units. Payment Control Board Lower cabinet components: Meters Suction Pump Figure 3.2. Cabinet Components - Installed components vary depending on order. 3000 Series Installation Manual Back to TOC...

  • Page 15: Pump Motor Controlr

    Suction 2-Horsepower 3-Phase ..............380 VAC 50/600 Hz CAUTION: Areas that frequently experience low AC line voltage or brownouts, must install thermal motor protectors between the Bennett power board and pump motor. Refer to the table below for motor protector sizing.

  • Page 16: Americans With Disabilities Act Compliance

    Chapter 3 Building Blocks, Section 308 Reach Ranges, and Section 309 Operable Parts. For more information on ADA regulations, see 2010 ADA Standards for Accessible Design at https://www.ada.gov/law-and-regs/design-standards/2010-stds/ The 3000 series meets and complies with Sections 308 Reach Ranges and 309 Operable Parts within the ADA Standards for Accessible Design. 48”...

  • Page 17: Receive, Lift & Transport The Dispenser

    When lifting with straps, do not allow the straps to go under any of the hydraulic castings such as the meter outlet, copper tubes, or valves. The straps should only lift the front and rear chassis. To avoid damage, follow the recommended lifting methods. 3000 Series Installation Manual Back to TOC...

  • Page 18: Lift The Dispenser - Low Hose

    WARNING: Lift only to the height required to set the dispenser on the island. Keep hands and feet clear of the dispenser while it is suspended in the air. 3000 Series Installation Manual Back to TOC...

  • Page 19: Lift The Dispenser - High Hose

    Figure 4.3. Cover Six (6) Screws. Figure 4.4. Lifting Brackets. 2. Place the dispenser gently on the island, carefully line up the base anchor bolt holes with the anchor bolts embedded in the concrete island. 3000 Series Installation Manual Back to TOC...

  • Page 20: Underground And Tanks

    Site Preparation 6 SITE PREPARATION Bennett Pump is not responsible for any damage to the dispenser or for improper operation due to accidents, abuse, or faulty installation. Installation specifications will vary by location; however, this manual assumes certain basic preparations have been met before installing the dispenser.

  • Page 21: Aboveground Storage Tanks

    Underground Storage Tanks (USTs) Laws and Regulations. Bennett Pump is not responsible for any damage to the dispenser or for improper operation due to accidents, abuse, or faulty installation. We highly recommend installing new wires in the underground metal conduits to validate the equipment warranty.

  • Page 22: Plumbing Requirements

    Appendix, compare the measurements of the dispenser • sump, and adjust if necessary. • If no containment sump is used, follow all piping backfill and compaction instructions observed by national, state, NFPA, and local codes. 3000 Series Installation Manual Back to TOC...

  • Page 23: Piping

    Flex pipe also aids proper alignment of the product union or coupling. • Refer to the Footprint Drawings in Appendix B for plumbing connection specifications. Use flex pipe here Figure 5.1. Underground Tank, Piping, and Dispenser. 3000 Series Installation Manual Back to TOC...

  • Page 24: Supply Pipes

    CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPA). Do not use a line check valve between the dispenser and tank unless provided with a relief valve. 3000 Series Installation Manual Back to TOC...

  • Page 25: Shear Valve Installation

    “prime” of the suction line so that liquid product does not drain back into the tank. Follow all instructions contained in the vertical check valve’s installation manual and observe all • local codes. 3000 Series Installation Manual Back to TOC...

  • Page 26: Wiring Requirements

    4. CAUTION: Use only UL listed rigid metal conduit and UL listed sealing fittings with conductor seals. The following wiring requirements must be met to comply with Bennett’s Limited Warranty: All dispensers and electrical connection boxes must be grounded per NFPA 70 (National •...
  • Page 27 Therefore, the electronic power for all dispensers activating that pump must be on the same phase. • After all wires have been pulled through the conduit, Bennett recommends verifying the integrity of the site’s wire insulation with a megohmmeter following the device manufacturer’s instructions. •...

  • Page 28: Earth Ground Wire

    1. CAUTION: LIFT STRAPS MUST BE EQUAL IN LENGTH AND PARALLEL TO EACH OTHER TO PREVENT DAMAGE TO THE CABINET TOWERS (SEE FIGURE 4). 2. CAUTION: Transport the dispenser on the shipping pallet as close as possible to the final destination. 3000 Series Installation Manual Back to TOC...
  • Page 29 Installing the Dispenser NOTICE: All installations of Bennett products and accessories (i.e., nozzles, hoses, and breakaways) must be performed by a trained and licensed technician following all codes, standards, and regulations. NOTICE: Verify the correct position of the product supply pipes and inlets before mounting and anchoring the dispenser to the island.

  • Page 30: Wire Routing

    Communication Diagram Current Loop, Generic Current Loop, and RS-485 for additional information. • The 3000 Series dispenser can be equipped with one, two, or four hoses per unit. The number of 719 Control Boards varies per dispenser: • o One, two, or four hose units have one 719 Control Board, o Active 4 units contain two 719 Control Boards.

  • Page 31: Ac Power Connection

    8. For 120 VAC circuits only (not applicable to 240 VAC circuits) neutral and ground must have less than 1 ohm of resistance: a) Verify the screws on the plug are tight and no stray wire strands are present. 3000 Series Installation Manual Back to TOC...

  • Page 32: Communication Wiring

    All wiring inside the dispenser's electrical enclosure must be securely fastened using appropriate wire clips and fasteners. For all two (2) wire communication, Bennett strongly recommends twisting the associated wires together no less than 3 turns per foot to reduce the effects of electrical noise on the communication circuit.

  • Page 33: Fuel - Current Loop

    Qty. Board Connector Description Size Orange Current TS1, PIN 1 (+positive) Loop Personality Yellow TS2, PIN 2 Module (-negative) Bennett Shared Loop 2 Current Wires Shunts removed from JP1 & JP2 (2-sided dispenser) 3000 Series Installation Manual Back to TOC...

  • Page 34: Fuel - Generic Loop

    TS1, PIN 1 (+positive) Field TS1, PIN 2 Current Jumper to TS2 PIN 1 Loop Yellow Personality TS2, PIN2 (-negative) Module Top 2 Pins Shunts of JP1 and Shunts installed on JP1 & JP2 3000 Series Installation Manual Back to TOC...

  • Page 35: Fuel - Rs-485

    Field wiring connections are between the Bennett Pulse Output Board on the 719 Control Board (or optional junction box) and a third-party interface system. One Pulse Output Board can handle up to two hoses (products).
  • Page 36 (Tank Gauge) Pulse Out (+ positive) Brown (Tank Gauge) Pulse Out (- negative) Pink (Source) In-Use Product 1 Orange (Signal) In-Use Product 1 Yellow Authorize Signal Product 1 Black Authorize Neutral Product 1 White 3000 Series Installation Manual Back to TOC...
  • Page 37 (Source) In-Use Product 1 Orange (Signal) In-Use Product 1 Yellow (Source) In-Use Product 2 Black (Signal) In-Use Product 2 White Authorize Signal Product 1 Black Authorize Signal Product 2 Gray Authorize Neutral Product 2 White 3000 Series Installation Manual Back to TOC...

  • Page 38: Payment - Ethernet & Emv

    Payment - Conexxus Protocol Programming, Service & Parts Manual 7.4.6 PAYMENT – RS-485 For all RS-485 communication, Bennett strongly recommends the use of three (3) wires twisted together no less than 3 turns per foot to reduce the effects of electrical noise on the communication circuit. Do not connect the common wire if one is present.

  • Page 39: Connecting To Submerged Pump C Relays

    P1 to P3 Brown Jumper P2 to P4 Figure 6.2. Center photo: Blue and brown jumper wires send power to the submersible pump. Left and right photos enlarge the areas the arrows point to. 3000 Series Installation Manual Back to TOC...

  • Page 40: Suction Pump Motor Connection

    Standard Single Phase (120/240AC) Motor B Relay Connection Junction Box Non-Junction Box Wire to From Circuit QT Y Product B Breaker 3 To Connector Motor Control 14 AWG Red 719 CPU TS2, PIN 1 14 AWG White Neutral Motor B 3000 Series Installation Manual Back to TOC...
  • Page 41 Junction Box Wire to From Circuit To Motor QT Y To Connector Product B Breaker 2 Relay Motor Control 14 AWG Brown TS2, L1 14 AWG Orange TS2, L2 14 AWG Yellow TS2, L3 3000 Series Installation Manual Back to TOC...

  • Page 42: Installing The Wire Separator

    Verify that the negative terminal is connected to the battery. • Verify the battery wires terminate from the battery to the J17 connector on the 719 Control Board. 12 VDC Battery Figure 6.4. Illustrated plan view of battery connections. 3000 Series Installation Manual Back to TOC...

  • Page 43: Activate The Dispenser

    2. Switch the ON/OFF switch on the 719 Control Board to the ON position. 3. Close and lock the dispenser doors. Refer to the 3000 Series Operation Manual for more information regarding dispenser start-up. 8.2 PURGE AIR FROM THE HYDRAULIC LINES After completing all electrical connections, it is essential to purge the dispenser fuel product lines of any trapped air to verify proper operation and accurate fuel measurement.

  • Page 44: Suction Pumps

    The Air Eliminator Vent is a brass fitting with a copper tube attached that purges air down toward the sump. Only fuel should pass through the meter. • • The meter will not turn until fuel enters the pump and pressurizes the system. 3000 Series Installation Manual Back to TOC...
  • Page 45 This will allow trapped air to escape, preventing meter overspeeding. 6. Once the pump has dispensed 50 gallons of fuel, the SB100 meter should be tested for calibration. Please see the 3000 Operation Manual for calibration instructions. 3000 Series Installation Manual Back to TOC...

  • Page 46: Final Installation Checklist

    Note: Perform this operation with the dispenser ☐ power off. All dispenser product meters have been calibrated. Refer to 3000 Series ☐ Operators Manual. Verify the correct brand panels, nozzles, and hoses are installed for each ☐...

  • Page 47: Abbreviations And Acronyms

    Petroleum Equipment Institute Polyvinyl Chloride Submersible Turbine Pump THHN Thermoplastic High Heat-resistant Nylon-coated Telecommunications Industry Association/Electronic TIA/EIA Industries Alliance Underwriters Laboratories, Inc. Underground Storage Tank Voltage Alternating Current Voltage Direct Current Volt-Ohm meter 3000 Series Installation Manual Back to TOC...

  • Page 48: Din

    The first seven alphanumeric are the model numbers. The model number and DIN are located on the serial label on side 1 of the dispenser, on the vapor deck. The following DIN(s) define what you will find on the 3000 Series. 3000 Series Installation Manual...
  • Page 49 Uses 2 position on a POS device. M:\Data\Engineering Document Control\Din sheets for dispensers> 3. Din 3K 3000 Series Electronic Rev H 01 13 20 M:\Data\Engineering Document Control\Din sheets for dispensers> 3. Din 3K 3000 Series Electronic (C.c.) Rev J 04 23 21...

  • Page 50: Model Number And

    M=Master, S=Satellite, C=Combo, D=Combo with Sat. in use light; L=Master with in use light Self-containerd Pumps M=master, L=Master with in use light M:\Data\Engineering Document Control\Din sheets for dispensers> 6. Din 3K 3000 Series Truck (C.c.) Rev K 03 07 23...

  • Page 51: Wiring Diagrams

    12.1 WIRING DIAGRAMS The following wiring diagrams are provided on the following pages. Page Part Number Drawing 135043 Bennett Current Loop 719 Wiring Diagram 135044 Generic Current Loop 719 Wiring Diagram 135048 RS485 719 Wiring Diagram 135305 RS232 Port Board 719 Wiring Diagram (Mexico Only)

  • Page 52: Specification 300

    Generic Current Loop COMMUNICATION VAC - HOT NOT USED 7. Bennett recommends that the RS485 wires for optional VAC - NEUTRAL NOT USED Card Readers are twisted at least 3 times per foot from the RS-485 + PAYMENT RS-485 COM.
  • Page 53 Generic Current Loop 7" OR 10" PAYMENT P6378s6 COMMUNICATION 7. Bennett recommends that the RS485 wires for optional VAC - HOT NOT USED Card Readers are twisted at least 3 times per foot from the VAC - NEUTRAL...

  • Page 54: Specification 400

    (18 GA.) Damage to the control console may Optional result. 7" OR 10" PAYMENT P6378s7 COMMUNICATION 6. Bennett recommends that the RS485 wires for VAC - HOT NOT USED VAC - NEUTRAL optional Card Readers are twisted at least 3 times per NOT USED ...
  • Page 55 Applies for all 3000 series Electronics and Truck pumps, and all DEF Appendix C Dispensers. WIRING AND INSTALLATION Notes For Wiring Diagram: 719 CPU - 1. Field Connection = CURRENT LOOP w/ RS-232 Port Board 2. All wiring must be installed and used in accordance...
  • Page 56 10. Authorization Signal is 120vac/240vac provided by the controller. The controller turns the signal on when it wants to turn on the dispenser. 3/4” Conduit Bennett Pump Company (electronic enclosure) Toll Free: 800-235-7618 Telephone: 231-798-1310 Optional Factory www.bennettpump.com...
  • Page 57 图号 DRAWING NUMBER 产权和保密 等级 不依比例决定 SIZE THIS PRINT IS THE PROPERTY OF BENNETT PUMP CO. AND LOANED SUBJECT TO DIMENSIONS IN MILLIMETERS [INCHES] CLASS P6091s2 DO NOT SCALE 此图是美国贝纳特公司的财产。借阅者要在我们要求归还时交回图纸。未经许可不得复制。 RETURN ON DEMAND. MAY NOT BE REPRODUCED WITHOUT OUR CONSENT.
  • Page 58 1 ohm resistance to earth ground potential. This GROUND must be verified to the ground rod. Do not use wire nuts on ground circuits, use only compression type connectors. This is required to initiate Bennett's Limited 3/4" CONDUIT (Electrical Enclosure) TO INTERCOM Warranty.
  • Page 59 Do not use wire nuts on ground circuits, use SYSTEM FACTORY WIRE only compression type connectors. This is required to initiate Bennett's Limited Warranty. 3/4" CONDUIT (Electrical Enclosure) 6. Use 15 Amp neutral breaking circuit breakers which are supplied by the customer.
  • Page 60 3/4" CONDUIT (Electrical Enclosure) the ground rod. Do not use wire nuts on ground circuits, use only compression type connectors. This is required to initiate Bennett's Limited Warranty. 6. Use 15 Amp neutral breaking circuit breakers which are supplied by the customer.
  • Page 61 Do not use wire nuts on ground circuits, use only compression type 3/4" CONDUIT (Electrical Enclosure) connectors. This is required to initiate Bennett's Limited Warranty. 6. Use 15 Amp neutral breaking circuit breakers which are supplied by the customer. If dispenser included optional DEF Heater, no more than 1 Dispenser per Breaker.
  • Page 62 Remote | Master | High Hose | High Flow Big Fueler 137786 P5553 Remote | Satellite | High Hose | High Flow Big Fueler 137787 P5554 Remote | Combo | High Hose | High Flow Big Fueler 3000 Series Installation Manual Back to TOC...
  • Page 63 Appendix Footprint for: 3700, 3800, 3900 Models | High Hose and Low Hose | Remote | Standard Flow Rates CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser inlet. All joints Spring Lake, MI. 49456  to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Impact Safety Valves are to be installed with shear section in line with surface of island within + or ‐ 3/4".  www.bennettpump.com  d. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals. Part Number: 137778 e. Field connections are done in upper electrical enclosure. Wire must extend 72" above base of dispenser to make electrical connections Drawing Number: P5545...
  • Page 64 Appendix Footprint for: 3700, 3800, 3900 Models | High Hose and Low Hose | Suction | Standard Flow Rates CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Recomended inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser Spring Lake, MI. 49456  inlet. All joints to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals. www.bennettpump.com  d. Field connections are done in upper electrical enclosure. Wire must extend 72" above base of dispenser to make electrical connections Part Number: 137779 (24" if optional junction box installed).
  • Page 65 Appendix Footprint for: 3700, 3800, 3900 Models | High Hose | Remote | Quad or Active 4 | Standard Flow Rates CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser inlet. All joints Spring Lake, MI. 49456  to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Impact Safety Valves are to be installed with shear section in line with surface of island within + or ‐ 3/4".  www.bennettpump.com  d. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals.
  • Page 66 Appendix Footprint for: 3700, 3800, 3900 Models | High Hose | Suction | Quad | Standard Flow Rates CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser inlet. All joints Spring Lake, MI. 49456  to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Impact Safety Valves are to be installed with shear section in line with surface of island within + or ‐ 3/4".  www.bennettpump.com  d. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals. Part Number: 137781 e. Field connections are done in upper electrical enclosure. Wire must extend 72" above base of dispenser to make electrical connections Drawing Number: P5548 (24" if optional junction box installed).
  • Page 67 Appendix Footprint for: 3700, 3800, 3900 Models | Low Hose | Remote | Master / Combo | High Flow Big Fueler CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser inlet. All joints Spring Lake, MI. 49456  to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Impact Safety Valves are to be installed with shear section in line with surface of island within + or ‐ 3/4". www.bennettpump.com  d. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals.
  • Page 68 Appendix Footprint for: 3700, 3800, 3900 Models | Low Hose | Remote | Satellite | High Flow Big Fueler CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser inlet. All joints Spring Lake, MI. 49456  to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Impact Safety Valves are to be installed with shear section in line with surface of island within + or ‐ 3/4". www.bennettpump.com  d. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals. Part Number: 137783 e. Field connections are done in upper electrical enclosure. Wire must extend 72" above base of dispenser to make electrical connections Drawing Number: P5550...
  • Page 69 Appendix Footprint for: 3700, 3800, 3900 Models | High Hose and Low Hose | Suction | High Flow Big Fueler CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser inlet. All joints Spring Lake, MI. 49456  to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals. www.bennettpump.com  d. Field connections are done in upper electrical enclosure. Wire must extend 72" above base of dispenser to make electrical connections Part Number: 137784 (24" if optional junction box installed).
  • Page 70 Appendix Footprint for: 3700, 3800, 3900 Models | High Hose | Remote | Master | High Flow Big Fueler CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser inlet. All joints Spring Lake, MI. 49456  to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Impact Safety Valves are to be installed with shear section in line with surface of island within + or ‐ 3/4". www.bennettpump.com  d. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals. Part Number: 137785 e. Field connections are done in upper electrical enclosure. Wire must extend 72" above base of dispenser to make electrical connections Drawing Number: P5552...
  • Page 71 Appendix Footprint for: 3700, 3800, 3900 Models | High Hose | Remote | Satellite | High Flow Big Fueler CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser inlet. All joints Spring Lake, MI. 49456  to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Impact Safety Valves are to be installed with shear section in line with surface of island within + or ‐ 3/4". www.bennettpump.com  d. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals. Part Number: 137786 e. Field connections are done in upper electrical enclosure. Wire must extend 72" above base of dispenser to make electrical connections Drawing Number: P5553...
  • Page 72 Appendix Footprint for: 3700, 3800, 3900 Models | High Hose | Remote | Combo | High Flow Big Fueler CAUTION: Dispensers must be installed with provisions for expansion relief, which will relieve at pressures not to exceed 50 psi (345 mPa).  Do not use line check valve between dispenser and tank unless provided with relief valve. BENNETT PUMP COMPANY INSTALLATION NOTES:  1218 E. Pontaluna Road  a. Inlet piping shall be minimum Schedule 40 steel pipe with UL Listed union installed prior to installation into the dispenser inlet. All joints Spring Lake, MI. 49456  to be made using the appropriate pipe joint sealing compound classified for the type of fuel used. Toll Free: 800‐235‐7618  b. Installation must be in accordance with National Electric Code (NFPA 70), the Automotive and Marine Service Code (NFPA 30A) and all Telephone: 231‐798‐1310  State and Local Codes. Fax: 231‐799‐6202  c. Impact Safety Valves are to be installed with shear section in line with surface of island within + or ‐ 3/4". www.bennettpump.com  d. Use only Underwriters Listed threaded rigid metal conduit and listed sealing fittings for conductor seals. Part Number: 137787 e. Field connections are done in upper electrical enclosure. Wire must extend 72" above base of dispenser to make electrical connections Drawing Number: P5554...
  • Page 73 Remote | Master | High Hose | High Flow Big Fueler 155189 P7512 Remote | Satellite | High Hose | High Flow Big Fueler 155191 P7513 Remote | Combo | High Hose | High Flow Big Fueler 3000 Series Installation Manual Back to TOC...
  • Page 74 Hose units must be secured with a minimum of 2 bolts through the base frame. Spec 400 g. Shims(metal only) should only be used under bolts to ensure dispenser is level. Improper shimming that results in misaligned frame is NOT covered under the Bennett Limited Warranty. NOTES: Print and/or Product subject to change...
  • Page 75 Hose units must be secured with a minimum of 2 bolts through the base frame. SPEC 400 g. Shims(metal only) should only be used under bolts to ensure dispenser is level. Improper shimming that results in misaligned frame is NOT covered under the Bennett Limited Warranty. NOTES: P2:IN ①...
  • Page 76 Hose units must be secured with a minimum of 2 bolts through the base frame. g. Shims(metal only) should only be used under bolts to ensure dispenser is level. Improper shimming that results in misaligned frame is NOT covered under the Bennett Limited Warranty. HO:P2...
  • Page 77 Hose units must be secured with a minimum of 2 bolts through the base frame. g. Shims(metal only) should only be used under bolts to ensure dispenser is level. Improper shimming that results in misaligned frame is NOT covered under the Bennett Limited Warranty. HO:P2...
  • Page 78 Hose units must be secured with a minimum of 2 bolts through the base frame. g. Shims(metal only) should only be used under bolts to ensure dispenser is level. Improper shimming that results in misaligned frame is NOT covered under the Bennett Limited Warranty. HO:P2...
  • Page 79 3000 Series Installation Manual Back to TOC...
