Kimball National Waveworks Assembly Instruction

Using a knife, open counterweight box and remove compo-
1
nents shown in Figure A. NOTE: Do Note Open box with
DO NOT OPEN sticker.
Remove drawers from freestanding unit. Refer to their respective
2
AI's for removal of each drawer.
Place the counterweight card-
3
board box with sticker and plastic
straps inside the freestanding unit
vertical on the back frame leaning
up against the back panel. Note:
the longest side lays down. See
Figure B.
Front View
If lateral file model, use step 5. All other models use a set-in-place counterweight.
4
Skip to step 6.
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
If you have any questions concerning these instructions, please call National Customer Service
Counterweight
Lat Files
Fold tabs up
Assembly Instruction
Figure A
.
800.482.1717
Waveworks
Package Contents
Components...................... Qty
Metal Storage Cabinet 1
Counterweight Box 1
Z-Bracket w/tape 4
Tools Required
Box Cutter/Utility Knife
Pliers
Telephone 800.482.1717
Fax 812.482.8800
www.NationalOfficeFurniture.com
Part # 3637780
Rev, A
Printed in U.S.A
