- Page 1 SL201-DXXR(E) Rack Server User Manual Document Version: 01 Release Date: 2022/10/16 Shenzhen Gooxi Information Security Co., Ltd.
-
Page 2: Copyright Statement
Gooxi does not provide guarantees for the results obtained from the use of this manual or the accuracy or reliability of any information obtained through this manual. - Page 3 Foreword This manual is the product technical manual of Gooxi Purley platform 2U server, which mainly describes the appearance, structure, hardware installation and basic configuration of this product. This manual is for reference and research by professional technicians. This product should only be installed and maintained by experienced technicians.
-
Page 4: Modification Record
Modification record Manual version Release date Remarks V1.1 2022-10-30 Modification and improvement... -
Page 5: Table Of Contents
Contents 1 Product Description ..............................6 1.1 Product description ............................6 1.2 Product structure ............................7 1.3 Logical structure ............................7 1.4 Product specification ............................9 2 Hardware Description ............................11 2.1 Front panel ..............................11 2.1.1 Appearance ..............................11 2.1.2 LEDs and buttons ............................12 2.1.3 Interface .............................. -
Page 6: Product Description
SL201 Purley 2U dual-socket rack server is a new generation of 2U dual-socket rack server with a wide range of uses launched by Gooxi for the needs of the Internet, IDC (Internet Data Center), cloud computing, enterprise market, and telecom applications. -
Page 7: Product Structure
Rear view 1-2 Product structure SL201 Purley 2U dual-socket server varies depending on the requirements, and the configuration maybe vary. Taking the 8-bay model as an example, the components of the server are described, as shown in the following figure: Structure diagram 1-3 Name Name... - Page 8 Motherboard logic block diagram 1-4 The CPU adopts the first and second generation Intel Xeon scalable processors, ® ® LGA3647 socket, TDP 205W; Each CPU supports 12 channels of DDR4, and each channel supports 2 memory sticks, RDIMM/LRDIMM. Two CPUs support a maximum capacity of 9 TB (including Optane memory);...
-
Page 9: Product Specification
Product specification SL201-D12R SL201-D08R Product series SL201-D12RE SL201-D25RE SL201-D08R-NV SL201-D12R-NV Product type 2U 8-bay 2U 12-bay 2U 25-bay Size 748*433.4*87.6mm (D*W*H) Support one or two 1st or 2nd Generation Intel ® Xeon ® Scalable series Processor processors 24 DDR4 memory slots, support DDR4 LRDIMM/RDIMM 2400/2666/2933 Memory MHz;... - Page 10 humidity Long-term storage (>72H): temperature 20℃～28℃/humidity 30%～70%RH non-condensing (including packaging) Table 1-2...
-
Page 11: Hardware Description
Hardware Description Front panel 2.1.1 Appearance 8x3.5 inch hard drive configuration Figure 2-1 Name Name DVD drive USB3.0 interface VGA interface 3.5 inch hard drive table 2-1 12x3.5 inch hard drive configuration Figure 2-2 Name Name 3.5 inch hard drive USB3.0 interface VGA interface Table 2-2... -
Page 12: Leds And Buttons
2.1.2 LED and button Figure 2-4 LED/button LED/button Power switch button/LED System alarm LED UID button/LED Network port 1 connection status LED Reset restart server Network port 2 connection button status LED HDD LED LED status description Logo LED/button Status description Description of the power LED: Green on: Indicates that the device has been powered on normally. -
Page 13: Interface
Reset restart Press to restart the server server button Green flashing: The hard disk is operating HDD LED normally System warning LED. Including system System alarms, fan alarms, power supply alarms, Alarm LED etc., which can be viewed through the IPMI management software Corresponds to the Ethernet port LED of the network card. -
Page 14: Rear Panel
interface as a monitor or KVM USB 3.0 For accessing USB devices interface Table 2-6 Rear panel 2.2.1 Appearance Appearance of the rear panel Figure 2-6 Name Name Riser1 module Riser2 module Riser3 module Riser4 module OCP network card Power module 1 (optional) Power module 2... -
Page 15: Interface
When configuring 1 processor, it needs to be installed in the CPU 0 position; Processors configured on the same server must have the same model; For specific optional system options, please consult Gooxi sales rep. The location of the processor is shown in the figure below: ... -
Page 16: Memory
Figure 2-9 Memory 2.4.1 Memory slot location The motherboard supports 12 DDR4 channels, each channel supports 2 DIMMs, and 2 CPUs support 24 DDR4 slots (when only one memory is inserted, the slot in the red box in the picture below is preferred, and the plastic color of the slot on the motherboard is blue color). -
Page 17: Storage
DDR4 memories of different types (RDIMM, LRDIMM) and specifications (capacity, bit width, rank, height, etc.) do not support mixed use. Different models of Intel Xeon Scalable processors (Sky Lake, Cascade ® ® Lake) support different maximum memory capacities. –... -
Page 18: Hard Drive Serial Number
Riser2 module (2x3.5 or 2.5)* 2 -Only support SAS/SATA hard SAS hard drives 12x3.5 inch Front hard drive (12x3.5 drives need to be or 2.5)* 12 Riser3 module (2x2.5)* 2 supported by Pass-through – Slot0 to slot11 only -Support NVMe/SAS/SATA hard optional SAS configuration support SAS/SATA hard... -
Page 19: Hdd Status Led
Figure 2-12 25x2.5 inch hard drive configuration Figure 2-13 2.5.3 HDD status LED Figure 2-14 Hard Disk Status LED Description Function Act LED Fault LED Status LED Hard disk in-position Hard disk activity Hard disk Flashing positioning 4Hz/sec Hard disk fault Flashing... -
Page 20: Power Supply
For power modules configured on the same server, the power module models must be the same; For specific optional system options, please consult Gooxi sales rep; The location of the power supply is shown in the figure below: ... -
Page 21: I/O Expansion
Figure 2-16 I/O expansion 2.8.1 PCIe slot location Figure 2-17 The slots provided by the Riser1 module are Slot 0, Slot 1, and Slot 2. When using PCIE expansion module with 2 slots, Slot 1 is unavailable; The slots provided by the Riser2 module are Slot 3, Slot 4, and Slot 5. When ... -
Page 22: Pcie Expansion Module
PCIE expansion module with 2 slots: X16 Full height, Slot 5 CPU0 PCIe 3.0 3 slots PCIE expansion module: full length Half height, Slot 6 CPU1 PCIe 3.0 half length PCIE expansion module with 1 slot: X16 Half height, Slot 7 CPU1 PCIe 3.0 PCIE expansion module with 2... - Page 23 Figure 2-19 PCIE expansion module 3 Riser card for x16 to x8 (x16 slot)+x8 – Installed at Riser3 and provides PCIe slots as Slot 6 and Slot 7 . Figure 2-20 PCIE expansion module 4 – Installed at Riser4 and provides PCIe slots as Slot 6 and Slot 7 . Figure 2-21 3.5 inch hard disk module ...
-
Page 24: Pcba
Figure 2-23 PCBA 2.9.1 Motherboard Motherboard Figure 2-21... -
Page 25: Hard Disk Backplane
Name 4U chassis fan control 4pin interface Memory slot (corresponding to CPU0) Memory slot (corresponding to CPU1) CPU0 CPU1 GPU Power 2*4pin interfaces BP Power 2*4pin interfaces SFF8643 SATA interface USB3.0 interface BP I2C interface PCIE4.0 X8 PCIE4.0 X16 I350 PCIE4.0 X16 IPMI RJ45 1Gb LAN RJ45 1Gb*2... - Page 26 SAS0~7 SAS/SATA hard disk 2. Maximum 6Gb/s SATA hard disk; connector 3. Support SAS/SATA hard disk hot swap. Table 2-14 Bottom surface Figure 2-23 Description Function Backplane power transmission connector, 1, 2 ATX power input used for 12V power transmission Temperature-controlled fan 3, 4, 5, 6 For 4pin fan interface...
- Page 27 Figure 2-25 Description Function Temperature-controlled fan 1, 2, 3, 4 For 4pin fan interface socket MINI SAS HD high-speed Used for 12Gb/s SAS or 6Gb/s connector SATA signal transmission Backplane power transmission Power connector connector, used for 12V power transmission PM8043 SXP 24Sx12G Expander chip 24-port 12G SAS Expander...
- Page 28 backplane bracket Expander chip PM8043 SXP 24Sx12G Table 2-19 2×2.5 rear hard disk backplane-1 TOP surface Figure 2-28 Description Function SAS/SATA hard disk 1. Maximum support for 12Gb/s connector SAS hard disk; 2. Maximum support for 6Gb/s SATA hard disk. Table 2-20 Bottom surface Figure 2-29...
-
Page 29: Installation Notes
Installation Notes Chassis upper cover installation Step 1: Lift the card slot at the opening position, and push it up in the direction shown in the figure; Figure 3-1 Mounting accessories Install the CPU 3.2.1 Step 1: Install the clamping piece, tilt the CPU angle as shown in the figure, ... -
Page 30: Install Heat-Sink
Figure 3-3 3.2.2 Install heat-sink Step 1: Remove the processor idle bezel (as shown in the figure below) Figure 3-4 Step 2: Align the heat-sink with the heat-sink fixing studs on the CPU base, and tighten the heat-sink fixing screws sequentially according to the instructions. -
Page 31: Install Memory
3.2.3 Install memory The 8 memory slots controlled by CPU 1 of the motherboard are: DIMMA1, A2, DIMMB1, B2, DIMM C1, C2 and DIMM D1, D2; the 8 memory slots controlled by CPU 2 are: DIMME1, E2, DIMMF1, F2, DIMMG1, G2 and DIMMH1, H2, pay attention that the notch of the memory is consistent with the notch of the DIMM slot, and snap each DIMM module vertically in place to prevent incorrect installation. - Page 32 2 pieces of memory: CPU0_A1 / CPU0_B1 3 pieces of memory: CPU0_A1 / CPU0_B1 / CPU0_C1 4 pieces of memory: CPU0_A1 / CPU0_B1 / CPU0_D1 / CPU0_E1 5 pieces of memory: this configuration is not recommended 6 pieces of memory: CPU0_A1, B1 / CPU0_C1, D1 / CPU0_E1, F1 7 pieces of memory: this configuration is not recommended 8 pieces of memory: CPU0_A1, A2 / CPU0_B1, B2 / CPU0_D1, D2/CPU0_E1, E2...
-
Page 33: Install The Server Rails
16 pieces of memory: CPU0_A1/A2, CPU0_B1/B2, CPU0_D1/D2, CPU0_E1/E2, CPU1_A1/A2, CPU1_B1/B2, CPU1_D1/D2, CPU1_E1/E2 18/20/22 pieces of memory: asymmetrical, this configuration is not recommended 24 pieces of memory: all inserted in. Note: In the same Channel, memory with a large capacity must be inserted into the first one (such as A1/B1/C1/D1/E1/F1): blue Mixed use of RDIMM and LRDIMM is not allowed;... - Page 34 Figure 3-10 Note: When installing the guide rail, it is necessary to align with the U mark, and when it is installed in place with a snap, secure it with M5 screws. Step 4: Align the chassis with the inner rails installed on the outer rails for installation Figure 3-11 Note: When you push the chassis forward, you will hear a snapping sound.
- Page 35 speed to avoid damage to the equipment.
-
Page 36: Configuration Instructions
Configuration Instructions Initial configuration Power on 4.1.1 Before powering on, it is necessary to ensure that all configurations of the server are installed in accordance with the corresponding specifications and standards, and keep the server turned off but not unplugged from the power supply. - Page 37 Figure 4-1 PCH state after G3 PCH state setting after G3, the menu options are: S0: Power on and start up directly S5: You need to press the Power button to turn on the power Leave power state unchanged Default: S0 ...
-
Page 38: Initial Data
Figure 4-2 For detailed usage of BMC and BIOS, please refer to the corresponding user manual. Initial data 4.1.2 BMC default account: admin BMC default password: admin BMC default address: 192.168.x.x BIOS Default Password: None Configure BIOS 4.1.3 Press the <DEL>... -
Page 39: Configure Bmc
Figure 4-3 The Main interface contains the basic information of the BIOS system, such as the BIOS version number, CPU model, memory capacity, and the system time can be set. For detailed instructions, please refer to the "BIOS User Manual". ... - Page 40 process when starting the server. In the lower left corner of the logo screen, the IP address is displayed. After the server is powered on, turn it on, pay attention to the POST process, press the keyboard <DEL> or <ESC> key, ready to enter the BIOS Setup interface, switch to the following interface: Figure 4-4 Configure IPV4 support:...
- Page 41 the network parameter information (IPV4) of the system shared network port, the current IP configuration mode, BMC IP, subnet mask, MAC address, routing IP, routing MAC; BMC Dedicated Management Channel Configuration Address source Configure the BMC IP address allocation mode, the menu options are: ...
- Page 42 Figure 4-5 Enter the account password to enter the home page, and you can set the BMC IP address on the management interface. On the left side of the interface, switch to "Settings Page"-> "Network Settings"-> "Network IP Settings". As shown below:...
-
Page 43: Appendix
If the above operation does not solve the fault problem, it is recommended to replace the known correct monitor to confirm whether the original monitor is faulty If there are no problems, please contact Gooxi technical team to solve the problem Warning light on the front panel ... - Page 44 The system alarm LED warning, please check the external environment first Other LED alarming, please contact Gooxi technical end to solve the problem Hard disk LED is abnormal -Make sure the hard drive is installed properly. -Please confirm the specific alarm information of the alarm LED...
