- Page 1 HPE Aruba Networking 503 Series Campus Access Points Installation Guide...
- Page 2 Hewlett Packard Enterprise Company. To obtain such source code, please check if the code is available in the HPE Software Center at https://myenterpriselicense.hpe.com/cwp-ui/software but, if not, send a written request for specific software version and product for which you want the open source code.
- Page 3 Verifying Post-Installation Connectivity Electrical and Environmental Specifications Electrical Environmental Regulatory Information Brazil Safety and Regulatory Compliance Industry Canada EU & UK Regulatory Conformity Japan Korea México Нормативные требования Евhразийского Экономического Союза Ukraine Taiwan United States HPE Aruba Networking 503 Series Campus Access Points...
- Page 4 About This Guide About This Guide This document describes the hardware features of the HPE Aruba Networking 503 Series Campus Access Points. It provides a detailed overview of the physical and performance characteristics of each access point model and explains how to install the access point.
- Page 5 Hardware Overview Hardware Overview The HPE Aruba Networking 503 Series Campus Access Points are high-performance, dual-radio wireless devices that can be deployed in either controllerbased (AOS) or controller-less (Instant) modes. The 503 Series Campus Access Points support the full 802.11ax (Wi-Fi 6) featureset with dual 2x2 MIMO radios and provide a wired network interface.
- Page 6 Figure 2 503 Series: Access Point Bottom View Radio status LED indicator Wi-Fi status LED indicator Figure 3 503 Series: Access Point Side View Kensington Lock slot HPE Aruba Networking 503 Series Campus Access Points |...
- Page 7 Figure 5 503 Series: Access Point Rear View Console E0 Ethernet port LED indicators The 503 Series access points have two LED indicators located at the bottom, front edge: one being system status and the other being radio status. HPE Aruba Networking 503 Series Campus Access Points...
- Page 8 The console port is a Micro-B connector is located on the back of this device. Use the proprietary AP- CBL-SERU cable or AP-MOD-SERU module (sold separately) for direct management of this device when connected to a serial terminal or laptop. For pin-out details, refer to Figure HPE Aruba Networking 503 Series Campus Access Points |...
- Page 9 The USB 2.0 interface located on the top of the is 503 Series compatible with selected cellular modems and other peripherals. When active, this port can supply up to 5W/1A to a connected device. Figure 8 503 Series USB HPE Aruba Networking 503 Series Campus Access Points...
- Page 10 When the AP is powered by the E0 port, the AP can be configured by management software to source PoE power. Power sources are sold separately; see the 503 Series Ordering Guide for details. HPE Aruba Networking 503 Series Campus Access Points |...
- Page 11 DNS server with an “A” record DHCP Server with vendor specific options HPE Aruba Networking, in compliance with governmental requirements, has designed the 503 Series access points so that only authorized network administrators can change configuration settings. For more information about AP...
- Page 12 Additional ceiling or wall mount kits are sold separately as accessories. All HPE Aruba Networking access points should be installed by a professional. The installer is responsible for ensuring that grounding is available and meets applicable national and electrical codes. Failure to properly install this product may result in physical injury and/or damage to property.
- Page 13 5. Pushing toward the ceiling tile, rotate the access point clockwise until the device clicks into place on the ceiling tile rail. Figure 10 Mounting the access point to a 7/16" rail Figure 11 Mounting the access point to a 15/16" rail HPE Aruba Networking 503 Series Campus Access Points...
- Page 14 AP Software Quick Start Guide. HPE Aruba Networking access points are classified as radio transmission devices, and are subject to government regulations of the host country. The network administrator(s) is/are responsible for ensuring that configuration and operation of this equipment is in compliance with their country’s regulations. For a complete list of approved channels in your country, refer to the HPE Aruba Networking Downloadable Regulatory Table at...
- Page 15 AP-503 RMN: APIN0503 HPE ArubaNetworking provides a multi-language document that contains country-specific restrictions and additional safety and regulatory information for all HPE Aruba Networking access points. This document can be viewed or downloaded at www.arubanetworks.com. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.
- Page 16 Select the document that corresponds to your device’s model number as it is indicated on the product label. Compliance is only assured if the HPE Aruba Networking approved accessories as listed in the ordering guide are used. To order accessories, visit: https://www.arubanetworks.com/assets/og/OG_...
- Page 17 125171, г. Москва, Ленинградское шоссе, 16А, стр.3, Телефон: +7 499 403 4248 Факс: +7 499 403 4677 'HPE Kazakhstan': TOO «Хьюлетт-Паккард (К)», Республика Казахстан, 050040, г. Алматы, Бостандыкский район, проспект Аль-Фараби, 77/7, Телефон/факс: + 7 HPE Aruba Networking 503 Series Campus Access Points...
- Page 18 Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. HPE Aruba Networking 503 Series Campus Access Points |...
- Page 19 The operation of this device is prohibited on oil platforms, cars, trains, boths, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet. Operation in the 5.9725-7.125GHz band is prohibited for control or communication with unnamed aircraft systems. HPE Aruba Networking 503 Series Campus Access Points...
