Phoenix Model EXTRA NG GP Instruction Manual

SPECIFICATION
- Wingspan: 2680mm (105.5 in)
- Length: 2551mm (100.4 in)
- Flying weight: 12550 - 12800 gr
- Wing area: 122 dm2
- Wing loading: 102.8 g/dm2
- Gear type: Carbon fiber for main gear (included)
- Spinner size: 115mm (included)
- Radio: 6 channel minimum (not included)
- Servo: 9 standard hitorque servo (up 25kg):
4 aileron; 2 elevator; 2 rudder; 1 throttle
(not included)
- Propeller: suit with your engine
- Engine: 120CC Gas engine (not included)
- Gravity CG: 200 mm (7.8 in) Back from
the leading edge of the wing, at the fuselage
EXTRA NG
2.68m 105.5" 120CC ARF CARBON
- Ailerons:
Low rate: 18-20 degrees, 30-40% exponential
High rate: 40-45 degrees, 50-60% exponential
- Elevators:
Low rate: 10-12 degrees, 18-20% exponential
High rate: 45-60 degrees, 50-60% exponential
- Rudder:
Low rate: 20 degrees, 50-60% exponential
High rate: 45-55 degrees, 60-80% exponential
- Experience level: Intermediate
- Plane type: Aerobatic
UNDER SAFETY PRECAUTIONS
This radio control model is not a toy!
It is highly recommended that first-time builders seek advice of
experienced modelers before beginning assembly.
Assemble this kit only in places out of children's reach!
Take enough safety precautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
Always keep this instruction manual ready at hand for quick
reference, even after completing the assembly.
GP
version
