OttLite Good Housekeeping OTTCL4QTPNGH Manual

powered by
A
F
Table Lamp with Wireless Charging
OTTCL4QTPNGH
INS240816
K
E
H
J
ENGLISH
CONGRATULATIONS!
You've purchased the finest in natural lighting technology with your new OttLite
product.
PRODUCT REGISTRATION FORM
Please complete the enclosed Product Registration Form and return it today by mail,
or register online by going to: OttLite.com/warranty
C
This lamp includes an OttLite ClearSun® LED Bulb.
1. Remove lamp from packing, placing lamp base (A) flat on a steady surface.
2. Fit shade (B) over socket (C) then thread socket ring (D) onto socket. Turn
socket ring (D) clockwise to tighten until finger tight and the shade (B) is held
B
securely.
3. Refer to BULB INSERTION/REMOVAL to install bulb (E) in lamp.
4. Plug the cord (F) into a standard 120V AC outlet.
5. Turn the lamp ON & OFF using power switch (G).
6. To adjust the shade position, rotate the turnkey (K) counterclockwise to loosen,
move the shade up or down to the desired position, then rotate the turnkey (K)
clockwise to tighten and secure.
BULB INSERTION/REMOVAL
1. Make sure that the lamp is not plugged into an electrical socket.
2. If the lamp has been in use, allow it to cool approximately 5 minutes before
proceeding.
3. To install included bulb (E) in the socket (C), thread the base of the bulb into the
socket turning clockwise until snug. CAUTION: DO NOT overtighten the bulb.
Overtightening the bulb may make removal difficult or damage the lamp or bulb.
D
4. To remove a bulb (E) already installed in the lamp, unthread the bulb from the
socket (C) turning counterclockwise to loosen.
NOTE: For bulb replacement, use only an E26 TYPE "A" bulb with a maximum of
40W (120V/60Hz), an E26 listed SBCFL up to 13W, or an E26 listed SBLED up to
9W.
WIRELESS CHARGING INSTRUCTIONS:
To wirelessly charge a device, perform the following:
• Place the device, which supports wireless charging, face up on the middle of
the wireless charging icon (H).
• When the device is centered on the wireless charging icon (H) a white light (J)
will come on noting charging mode active. Your device should show charging is
taking place.
G
• Refer to the LED indicator (J) for charging status:
∙ Rapid Blinking LED: Device is not charging. Adjust the device's position.
∙ Slow Blinking LED: Device is charging. Your device should show charging is
taking place.
∙ Solid LED: Device is fully charged.
CAUTION! Device may become warm during charging. This is normal and part of
the process. Charging times vary by device.
SAFETY WARNING:
SHOCK, OR INJURY TO PERSONS
1. Turn lamp off and WAIT UNTIL BULB IS COOL before handling.
2. Bulb gets hot quickly! Touch only switch or plug when turning ON or OFF.
3. Never use with an extension cord unless the plug can be fully inserted into the
receptacles in the extension cord.
4. Do not alter the plug.
5. INDOOR USE ONLY.
NOTE: The important safety instructions appearing in this instruction sheet are not
meant to cover all possible conditions and situations that may occur. It must be
understood that common sense, caution, and care must be used with any electrical
product.
TM1561
CAUTION! IMPORTANT SAFETY INSTRUCTIONS:
®
THIS PORTABLE LAMP HAS A POLARIZED PLUG (ONE BLADE IS WIDER THAN THE
OTHER) AS A FEATURE TO REDUCE THE RISK OF ELECTRIC SHOCK. THIS PLUG WILL
FIT IN A POLARIZED OUTLET ONLY ONE WAY. IF THE PLUG DOES NOT FIT FULLY IN
THE OUTLET, REVERSE THE PLUG. IF IT STILL DOES NOT FIT, CONTACT A QUALIFIED
ELECTRICIAN. NEVER USE WITH AN EXTENSION CORD UNLESS PLUG CAN BE FULLY
INSERTED. DO NOT ALTER THE PLUG.
CAUTION!
WIDE SLOT, FULLY INSERT.
CAUTION!
IS DAMAGED, IT SHALL BE EXCLUSIVELY REPLACED BY THE MANUFACTURER OR ITS
SERVICE AGENT OR A SIMILAR QUALIFIED PERSON IN ORDER TO AVOID A HAZARD.
INDOOR USE ONLY.
CAUTION: Any change or modification to product not expressly recognized by
OttLite voids OttLite's responsibility for proper function of product.
FCC PART 15
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC/IC RF RADIATION EXPOSURE STATEMENT CAUTION:
To maintain compliance with the FCC's RF exposure guidelines, place the product at least
20cm from nearby persons.
TO REDUCE THE RISK OF FIRE, ELECTRIC
WIRELESS CHARGER SPECIFICATION:
Output: 9V, 1.12A or 10 watts
Table Lamp with Wireless Charging
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO
IF THE EXTERNAL FLEXIBLE CABLE OR CORD OF THIS LUMINAIRE
REV120524
