OttLite BY2G5B Manual

E
K
J
A
90°
LED Desk Lamp with Color Changing Base
BY2G5B BY200B BY2G59 BY2G59-FFP
INS150164
F
H
G
B
D
C
30° 30°
45°
BY200B-FFP
EnGlish
CONGRATULATIONS!
You've purchased the finest in natural lighting technology with
your new OttLite ® product.
PRODUCT REGISTRATION FORM
Please complete the enclosed Product Registration Form and
return it today by mail, or register online by going to:
OttLite.com/warranty
NOTE: THIS UNIT IS FULLY ASSEMBLED
1. Remove lamp from packing placing lamp body base (A) flat on
a steady surface.
2. Connect the AC Adapter input (G) into connector (H) in the
rear-bottom of the lamp.
3. Plug the A/C adapter (F) into a standard household 120V AC
outlet. Note: Only use with the supplied AC adapter to
avoid damage or fire.
4. Turn the lamp ON & OFF using power switch (B) located in the
front-upper side of base (A). Power switch (B) is a "touch" switch
that controls the dimmer function for 3 levels of brightness.
5. To power LED settings, slightly touch the switch (B) to achieve
the following:
• turn lamp "ON" to first lower-brightness; touch the
switch "once";
• for medium-brightness; touch the switch "twice";
• for high-brightness; touch the switch "three-times";
• to turn lamp "OFF"; touch the switch "four-times".
6. This lamp features a Color Changing Base on both sides of lamp
body base (A).
7. The Color Changing Base can be turned ON & OFF by using
power switch (C) located on bottom of the light changing bar
or wheel (D). For operation, turn the Color Changing Base light
bar to "ON" status. To engage function for different colors,
• Touch desired color represented within color wheel;
• Slide finger along color wheel in either direction;
• Or touch the Color Changing Base light power switch (C)
for "three seconds" and watch light color change
automatically.
8. To position the shade simply bend the flex-neck (J) as needed
to point the light. Please hold the lamp base (A) while adjusting
the lamp. Take care not to overextend the lamp to avoid
unbalancing it and damage. Please refer to diagrams for lamp
maximum adjustment range.
SAFETY WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS
1. Turn lamp off and WAIT UNTIL LAMP HEAD (E) AND
ADAPTER (F) ARE COOL before handling.
2. The LED panel (K) might get hot after several hours of
continuous use, DO NOT place your hands directly on LED
light panel.
3. Never use with an extension cord unless the plug can be fully
inserted into the receptacles in the extension cord.
4. Do not alter the plug.
5. The lamp head included with this unit cannot be replaced by
45°
the consumer.
T3
LED Desk Lamp with Color Changing Base
NOTE: The important safety instructions appearing in this
instruction sheet are not meant to cover all possible conditions
and situations that may occur. It must be understood that
common sense, caution, and care must be used with any
electrical product.
CAUTION!
IF THE ExTERNaL FLExIbLE CabLE OR CORD OF THIS LUmINaIRE
IS DamagED, IT SHaLL bE ExCLUSIvELY REPLaCED bY THE maNUFaCTURER OR ITS
SERvICE agENT OR a SImILaR qUaLIFIED PERSON IN ORDER TO avOID a HazaRD.
INDOOR USE ONLY.
FCC PART 15
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that the interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that of
the receiver.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B)/NMB-3 (B)
CAUTION:
Any change or modification to product not
expressly recognized by OttLite Technologies voids OttLite's
responsibility for proper function of product.
AC/DC ADAPTER
Input: AC 100-240V, 50/60 Hz, 0.3A
Output: 5V DC, 1.0A with a Male DC Plug
REV033115
