OttLite Twist CSNWC51W Quick Start Manual

B
E
Twist LED Desk Lamp with Wireless Charging
CSNWC51W
INS240813
D
C
J
K
A
H
G F
ENGLISH
CONGRATULATIONS!
You've purchased the finest in natural lighting technology with your new OttLite
product.
PRODUCT REGISTRATION FORM
Please complete the enclosed Product Registration Form and return it today by
mail, or register online by going to: OttLite.com/warranty
WARNING: To prevent electric shock, make sure the lamp is not plugged in until
all steps are complete.
NOTE: THIS UNIT IS FULLY ASSEMBLED
1. Remove lamp from packing, placing lamp body base (A) flat on a steady surface.
2. Connect power adapter input (F) into connector (G) in the rear-bottom of the lamp.
3. Plug the power adapter (H) into a standard household 120V AC outlet.
NOTE: Only use with the supplied power adapter to avoid damage or fire.
4. Turn the lamp ON & OFF using power switch (B) located on the top of the lamp
head. Power switch (B) is a "touch" switch that controls the dimmer function
for 3 levels of brightness.
5. To power LED settings, slightly touch the switch to achieve the following:
• turn lamp "ON" to low brightness; touch the switch "once";
• for medium brightness; touch the switch "twice";
• for high brightness level; touch the switch "three-times";
• to turn lamp "OFF"; touch the switch "four-times".
6. This lamp provides three color modes. To adjust lighting color mode slightly
"press and hold" switch (B) for two seconds to switch light color temperature
mode; 5000K, 2700K, 3500K.
7. Wireless charger (J) is located in the center of base (A). See Wireless Charging
Instructions section for details.
8. To position the shade simply bend the flex-neck (C) as needed to point the light.
Please hold the lamp base (A) while adjusting the lamp.
WIRELESS CHARGING INSTRUCTIONS
To wirelessly charge a device, perform the following:
• Place the device, which supports wireless charging, face up on the middle of
the wireless charging icon (J).
• When the device is centered on the wireless charging icon (J) a solid BLUE
light (K) will come on noting charging mode active. Your device should show
charging is taking place.
• Check the charge level on your device periodically to determine when device is
fully charged.
CAUTION! Device may become warm during charging. This is normal and part of
the process. Charging times vary by device.
SAFETY WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS
1. Turn lamp off and WAIT UNTIL LAMP HEAD (E) IS COOL before handling.
2. The LED panel (D) might get hot after several hours of continuous use DO NOT place
your hands directly on LED light panel.
3. Never use with an extension cord unless the plug can be fully inserted into the
receptacles in the extension cord.
4. Do not alter the plug.
5. The lamp head included with this unit cannot be replaced by the consumer.
6. INDOOR USE ONLY.
NOTE: The important safety instructions appearing in this instruction sheet are not
meant to cover all possible conditions and situations that may occur. It must be
understood that common sense, caution, and care must be used with any electrical
product.
PL-0370Q
Twist LED Desk Lamp with Wireless Charging
CAUTION!
IF THE EXTERNAL FLEXIBLE CABLE OR CORD OF THIS LUMINAIRE
®
IS DAMAGED, IT SHALL BE EXCLUSIVELY REPLACED BY THE MANUFACTURER OR ITS
SERVICE AGENT OR A SIMILAR QUALIFIED PERSON IN ORDER TO AVOID A HAZARD.
INDOOR USE ONLY.
CAUTION!
THE LIGHT SOURCE OF THIS LUMINAIRE IS NOT REPLACEABLE;
WHEN THE LIGHT SOURCE REACHES ITS END OF LIFE THE WHOLE LUMINAIRE SHALL
BE REPLACED.
CAUTION: Any change or modification to product not expressly recognized by
OttLite voids OttLite's responsibility for proper function of product.
FCC PART 15
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC RF RADIATION EXPOSURE STATEMENT CAUTION:
The FCC certification of this devic refers to RF exposure testing performed in typical
operating conditions,where a person is no closer than 20 centimeters from the device
surface at all times, except for non-repetitive patterns with transiennt time intercals in
the order of a second. Only in the stated connditions,the device is shown to fully comply
with the FCC RF Exposure requirements of KDB 447498.
POWER ADAPTER SPECIFICATION:
Input: AC 100-240V, 50/60 Hz, 0.6A
Output: 13V DC, 1.2A with a Male DC Plug
WIRELESS CHARGER SPECIFICATION: Output: 5V, 1A or 5 watts
REV082824
