Floor Lamp with Wireless Charging Table
OTTCL5QF4KGH
INS240817
Q
G
B
D
E
P
H
J
A
ENGLISH
CONGRATULATIONS!
You've purchased the finest in natural lighting technology with your new OttLite
product.
PRODUCT REGISTRATION FORM
Please complete the enclosed Product Registration Form and return it today by mail, or
register online by going to: OttLite.com/warranty
WARNING: To prevent electric shock, make sure the lamp is not plugged in until
all assembly steps are complete.
This lamp includes an OttLite ClearSun® LED Bulb.
LAMP ASSEMBLY
1. Unpack all lamp parts and lay out on the floor. Remove the parts from the plastic
bag, which include 3 screws, 1 screwdriver, 1 wrench, and 1 Allen wrench.
2. Place the wooden wireless charger table (P) onto the extended section of pole (L),
align the screw holes, insert the three provided screws, and securely tighten them
clockwise using the provided screwdriver.
3. Insert the threaded end of pole (K) into the base (A), place the washer over the
threads, hand-tighten the nut by turning it clockwise, and then use the provided
wrench to fully secure it.
4. Thread pole (L) into pole (K), then thread pole (M) into pole (L), and finally thread
pole (N) into pole (M), turning clockwise to tighten each connection by hand. Note:
Pull excess cord from bottom of base (A) as needed.
5. The top of pole (N) can be adjusted left or right by loosening the two set screws
with the provided Allen wrench, rotating it to the desired position, and then
tightening the screws securely.
6. Fit shade (B) over socket (C) then thread socket ring (D) onto socket. Turn socket
ring (D) clockwise to tighten until finger tight and the shade (B) is held securely.
7. Refer to BULB INSERTION/REMOVAL to install bulb (E) in lamp.
8. Plug the cord (F) into a standard 120V AC outlet.
9. Turn the lamp ON & OFF rotating the knob (G) clockwise.
10. To adjust the shade position, rotate the turnkey (Q) counterclockwise to loosen, move
the shade up or down to the desired position, then rotate the turnkey (Q) clockwise to
tighten and secure.
BULB INSERTION/REMOVAL
1. Make sure that the lamp is not plugged into an electrical socket.
2. If the lamp has been in use, allow it to cool approximately 5 minutes before
proceeding.
3. To install included bulb (E) in the socket (C), thread the base of the bulb into the
socket turning clockwise until snug. CAUTION: DO NOT overtighten the bulb.
Overtightening the bulb may make removal difficult or damage the lamp or bulb.
4. To remove a bulb (E) already installed in the lamp, unthread the bulb from the
socket (C) turning counterclockwise to loosen.
NOTE: For bulb replacement, use only an E26 TYPE "A" bulb with a maximum of 40W
(120V/60Hz), an E26 listed SBCFL up to 13W, or an E26 listed SBLED up to 9W.
WIRELESS CHARGING INSTRUCTIONS:
To wirelessly charge a device, perform the following:
• Place the device, which supports wireless charging, face up on the middle of
the wireless charging icon (H).
• When the device is centered on the wireless charging icon (H) a white light (J)
will come on noting charging charging is taking place.
• Refer to the LED indicator (J) for charging status:
∙ Rapid Blinking LED: Device is not charging. Adjust the device's position.
∙ Slow Blinking LED: Device is charging. Your device should show charging is
taking place.
∙ Solid LED: Device is fully charged.
CAUTION! Device may become warm during charging. This is normal and part of the
process. Charging times vary by device.
SAFETY WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY TO PERSONS
1. Turn lamp off and WAIT UNTIL BULB IS COOL before handling.
2. Bulb gets hot quickly! Touch only switch or plug when turning ON or OFF.
TF1560B
Floor Lamp with Wireless Charging Table
3. Never use with an extension cord unless the plug can be fully inserted into the
® receptacles in the extension cord.
4. Do not alter the plug.
5. INDOOR USE ONLY.
NOTE: The important safety instructions appearing in this instruction sheet are not
meant to cover all possible conditions and situations that may occur. It must be
understood that common sense, caution, and care must be used with any electrical
product.
CAUTION! IMPORTANT SAFETY INSTRUCTIONS:
THIS PORTABLE LAMP HAS A POLARIZED PLUG (ONE BLADE IS WIDER THAN THE
OTHER) AS A FEATURE TO REDUCE THE RISK OF ELECTRIC SHOCK. THIS PLUG WILL
FIT IN A POLARIZED OUTLET ONLY ONE WAY. IF THE PLUG DOES NOT FIT FULLY IN
THE OUTLET, REVERSE THE PLUG. IF IT STILL DOES NOT FIT, CONTACT A QUALIFIED
ELECTRICIAN. NEVER USE WITH AN EXTENSION CORD UNLESS PLUG CAN BE FULLY
INSERTED. DO NOT ALTER THE PLUG.
CAUTION!
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT.
CAUTION!
IF THE EXTERNAL FLEXIBLE CABLE OR CORD OF THIS LUMINAIRE
IS DAMAGED, IT SHALL BE EXCLUSIVELY REPLACED BY THE MANUFACTURER OR ITS
SERVICE AGENT OR A SIMILAR QUALIFIED PERSON IN ORDER TO AVOID A HAZARD.
INDOOR USE ONLY.
CAUTION: Any change or modification to product not expressly recognized by OttLite
voids OttLite's responsibility for proper function of product.
FCC PART 15
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that the interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC/IC RF RADIATION EXPOSURE STATEMENT CAUTION:
To maintain compliance with the FCC's RF exposure guidelines, place the product at least
20cm from nearby persons.
WIRELESS CHARGER SPECIFICATION:
Output: 9V, 1.12A or 10 watts
ACCESSORIES:
Wrench, Screwdriver, Allen Wrench
