Note:
For firmware updates on the P100B
please use the latest C100 BLE Firmware.
Before starting, please ensure that all components listed below are supplied with the
ordered product either P100B-100 or the P100B-200:
Aperio P100B Padlock
AU Part Number
P100B-100
P100B-100
Aperio P100B Padlock with Chain
AU Part Number
P100B-200
P100B-200
P100B-200
P100B-200
ASSA ABLOY Australia Pty Limited, 235 Huntingdale Rd, Oakleigh, VIC 3166 ABN 90 086 451 907 ©2024
Experience a safer and more open world
INSTALLATION GUIDE AND USER MANUAL
INCLUDED PARTS & ACCESSORIES (SUPPLIED)
Qty Per
Description
Pack
1
Aperio P100B Padlock
1
Battery change tool
Qty Per
Description
Pack
1
Aperio P100B Padlock
1
Battery change tool
1
Chain
1
Clamp
P100B APERIO PADLOCK
IP66*
*Only when
locked and in upright
position
SCAN FOR DETAILED
PRODUCT INFORMATION
P100B-121 (1)
Advertisement
Table of Contents
Related Manuals for Assa Abloy aperio P100B
Summary of Contents for Assa Abloy aperio P100B
- Page 1 Qty Per Description Pack P100B-200 Aperio P100B Padlock P100B-200 Battery change tool P100B-200 Chain P100B-200 Clamp ASSA ABLOY Australia Pty Limited, 235 Huntingdale Rd, Oakleigh, VIC 3166 ABN 90 086 451 907 ©2024 Experience a safer and more open world...
-
Page 2: Important Safety Instructions And Warnings
OTHER PARTS & ACCESSORIES (NOT SUPPLIED) Additional accessories are available for optional mounting & spare parts (not supplied): AU Part Number Qty Per Pack Description AH30-3-0 Accessories - Aperio Hub 1:16 RS485 Hub Accessories - AH40 Aperio 1:64/16 IP (Ethernet) Hub AH40-4-0 IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS Read and follow all instructions prior to installing and using this product. -
Page 3: Battery Safety Information
BATTERY SAFETY INFORMATION Only the following type of batteries should be used: CR2 (Lithium). Do not mix old and new batteries. Do not use any other type of battery. Adhere to battery information and warnings. Remove batteries before storing the product for extended periods of time. Do not dispose of old batteries in a fire as they may explode. -
Page 4: Setup Instructions
SETUP INSTRUCTIONS SLIDE PADLOCK OUT OF JACKET REMOVE BATTERY TAB CLICK PUSH IN TAB TO RELEASE BASE SETUP FUNCTION ATTENTION: ALWAYS KEEP PADLOCK UPRIGHT DURING USE WAIT 2-3 SECONDS... WHEN IN USE, ALLOW SHACKLE CLEARANCE OF AT LEAST 20mm FOR BATTERY CHANGE ACCESS SLIDE DOWN ALLOW 20mm... -
Page 5: Ingress Protection
INGRESS PROTECTION SEAL MUST NOT BE DISTORTED OR TORN WHICH COMPROMISES INGRESS PROTECTION GENTLY PULL SHACKLE UNTIL SEAL IS CORRECTLY LOCATED SEAL MUST NOT BE ENSURE SEALS ARE PUSHED UNDER THE CORRECTLY SEATED AND COVER WHICH NOT DISTORTED COMPROMISES INGRESS PROTECTION BATTERY REPLACEMENT - REMOVING FLAT BATTERY... - Page 6 BATTERY REPLACEMENT - REPLENISH BATTERY ENSURE ALIGNMENT OF THE FLAT EDGE OF THE LOCKING PLATE (a), BATTERY (b), AND DIMPLE (c). TWIST KNOB TO TIGHTEN THE COVER PROPERLY POSITION SEAL AROUND COVER TO PREVENT WATER FROM ENTERING THE KNOB GENTLY PULL SHACKLE UNTIL SEAL IS CORRECTLY LOCATED...
-
Page 7: Mechanical Specifications
Clean the external surfaces with a dry cloth only, do not use chemicals. Replace battery when required following the instructions and warnings. A special tool is required to change the battery: Battery change tool is supplied with the Aperio P100B. FAULTS, REPAIRS & RETURNS This product contains no user serviceable parts. -
Page 8: Country Of Origin
Strojnická 633 West Midlands, WV13 3PW 516 01 Rychnov nad Kněžnou United Kingdom Czech Republic www.assaabloy.com/uk/en www.assaabloy.com/cz/cs ASSA ABLOY Australia Pty Limited, 235 Huntingdale Rd, Oakleigh, VIC 3166 ABN 90 086 451 907 ©2024 Experience a safer and more open world...
