P113-fitting instructions_Layout 1 03/02/2012 10:14 am Page 1
P113 Window Toggle lock
Fitting Instructions

Tools Required

Drill
3mm
Drill Bit
Fitting Instructions
1. Ensuring the window is closed, position the striking plate against the edge of
the fixed frame at the desired height. Fix using two of the screws provided.
Note: Ensure that the screws will not touch the glass.
2. With the window still closed, position the lock body on the opening
window frame so that it fits over the striking plate. Mark the screw holes and
fix.
3. To secure, swing the lock body over the striking plate and lock with the
key supplied.
The world's favourite lock since
School Street, Willenhall, West Midlands WV13 3PW
www.yale.co.uk
Pencil
Posidrive
Bradawl
Screwdriver
Tel: +44 (0) 1902 364647 E-mail: info@yale.co.uk
1843
Issue No: 01-2012
