Page 1 Washer-Extractors Micro Control Refer to Page 9 for Model Identification Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No. D1591ENR9 www.alliancelaundry.com October 2022...
Page 3: Table Of Contents
Programming the Motor On and Off Times for Reversing..............42 © Copyright 2024, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.
Page 4 The Static Drain Sequence.........................82 The Reversing Drain Sequence......................83 Operation Menu Operation Menu ..................................................84 84 Starting Up ............................84 Switching On the Power........................84 Load the Washing Machine........................84 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 5 Wash Program 12: Super Eco Color Wash 104°F 40°C ..............103 Wash Program 13: Super Eco Bright Color Wash 86°F 30°C ............103 Wash Program 14: Extraction - Low Speed..................105 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 6 Failure 37: Drain Failure at the Spray Sequence ................127 Failure 38: No Recycle Water......................127 Failure 39: Empty Soap Supply Box ....................127 Failure 40: Fill Failure Empty Water Recycling Tank ..............128 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 7 Failure 300-353: Mitsubishi Inverter Alarm Message..............138 Failure 300-301-302: OC Errors (OVERCURRENT) ..............141 Failure 303-304-305: OV Errors (OVERVOLTAGE) ..............141 Failure 306: THT-Error (INVERTER OVERLOAD) ..............141 Failure 307: THM-Error (MOTOR OVERLOAD) ..............141 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 8 ........................147 Maintenance ............................147 Information for Service ........................147 Programmer Circuit Board ........................147 Instructions for Replacing the Electronic Board and Keypad.............148 Instructions for Installing New Software ....................148 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 9: Safety Information Safety Information
• MB : Medical Barrier machines. • The machine must not be exposed to high humidity or ex- treme high and low temperatures. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 10: Introduction
IBC700W M180_GRAPHITRONIC SBU900W IBC900W M26_GRAPHITRONIC SBX11XW IBG0265W M33_GRAPHITRONIC SBX14XW IBG0332W M44_GRAPHITRONIC SBX18XW IBG0442W M70_GRAPHITRONIC SBX265W IBG0663W M90_GRAPHITRONIC SBX332W IBG0700W MB110_GRAPHITRONIC SBX442W IBG0900W MB140_GRAPHITRONIC SBX663W continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 11 IBU332W PBH14XW UBC663W IBU442W PBH18XW UBC700W IBU663W PBH265W UBC900W IBU700W PBH332W UBG0265W IBU900W PBH442W UBG0332W IBX11XW PBH663W UBG0442W IBX14XW PBH700W UBG0663W IBX18XW PBH900W UBG0700W continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 12 LBC14XW PBX900W UBU265W LBC18XW PBY265W UBU332W LBC265W PBY332W UBU442W LBC332W PBY442W UBU663W LBC442W PBY663W UBU700W LBC663W SB1100_MICRO UBU900W LBC700W SB1400_MICRO UBX11XW LBC900W SB1800_MICRO UBX14XW continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 13 SBG1100W UY90_MICRO LBX332W SBG1400W UYN090W LBX442W SBG1800W UYN125W LBX663W SBH11XW UYN180W LBX700W SBH14XW UYN230W LBX900W SBH18XW UYN275W LBY265W SBH265W UYU400W LBY332W SBH332W LBY442W SBH442W continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 14: Machine Type In Configuration Menu
16 kg / 35 lbs MB16 26 kg / 60 lbs / 265 L MB26 33 kg / 80 lbs / 332 L MB33 continues... Table 1 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 15 110 kg / 245 lbs / 1100 L MB110 140 kg / 310 lbs / 1400 L MB140 180 kg / 400 lbs / 1800 L MB180 continues... Table 1 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 16: Control Identification
ARROW UP (Selecting the previous menu item) CHM1640R ARROW DOWN (Selecting the next menu item) CHM1641R ARROW LEFT (Selecting the previous element of a menu item list) CHM1635R continues... Table 2 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 17 On the labels you can find Instructions for the Washing machine Operation and Information about the Wash Programs. Emergency stop switch This emergency stop switch is used by non-coin washer-extrac- tors. continues... Table 2 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 18: Main Menu
Control Identification Main Menu Figure 1 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 19: Basic Description Of Controls Basic Description Of Controls
• Programming the Maximum Level overfill value. • Inserting and deleting steps in the wash program. • Copying a wash program. The SERVICE Menu is Designated for: © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 20: How To Get Into The Setup Mode
Press the Status Button on the keypad. Then you will re- turn to "Run Mode" and "SELECT CYCLE" is shown. Press the Status Button on the keypad. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 21: 99 Wash Programs - 99 Steps
Step 99 Wash Wash Sequence Sequence Drain/ Drain/ Extraction Extraction Sequence Sequence Tumble Tumble Tumble . . . Tumble Sequence Sequence Sequence Sequence CHM1624R Figure 6 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 22: Available Wash Sequences
Chapter Step 4: Program- ming the Wash Part, Step 5: Programming the Drain • RINSE Step. • FINAL RINSE • FLUSH • SOAK © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 23: The Tumble Sequence
• Inlet Valve 4 corresponds with Soap Box B (Wash). • Inlet Valve 3 is a direct inlet Valve and speeds up the water fill process. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 24: Programming The Water Level
(3) 4.23 gal (3) 5.81 gal 6.60 gal [25 6.60 gal [25 9.77 gal [37 (1) 12.94 gal [15 l] [16 l] [22 l] [49 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 25 24.04 gal 36.19 gal 33.55 gal 41.48 gal [47 l] [55 l] [68 l] [79 l] [91 l] [137 l] [127 l] [157 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 26 52.31 gal [198 l] 53.63 gal [203 l] 54.95 gal [208 l] 56.53 gal [214 l] 58.12 gal [220 l] 59.44 gal [225 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 27: Cabinet Freestanding 6-23 Kg / 15-50 Lb
(4) 5.28 gal (4) 6.60 gal 7.13 gal [27 l] 8.19 gal [31 l] 9.77 gal [37 l] [18 l] [20 l] [25 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 28: Water Level
20.61 gal [78 23.25 gal [88 21.93 gal [83 29.32 gal [111 21.40 gal [81 24.04 gal [91 (4) 22.98 gal 30.38 gal [115 [87 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 29 39.63 gal [150 46.49 gal [176 40.95 gal [155 42.27 gal [160 43.59 gal [165 44.91 gal [170 46.23 gal [175 (1) Economic Low Level continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 30: Cabinet Freestanding 33-120 Kg / 80-265 Lb / 335-1200 L
14.53 gal [55 l] 18.49 gal [70 l] 20.10 gal [76 l] 64.72 gal [245 l] 65.78 gal [249 l] 72.65 gal [275 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 31 131.29 gal [497 36.19 gal [137 l] 46.23 gal [175 l] 55.48 gal [210 l] 26.41 gal [445 l] 123.37 gal [467 135.78 gal [514 continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 32 62.08 gal [235 l] 75.82 gal [287 l] 94.57 gal [358 l] - 63.40 gal [240 l] 77.14 gal [292 l] 96.69 gal [366 l] - (1) Economic Low Level (2) Economic High Level continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 33: Barrier Machines 16-66 Kg / 35-150 Lb / 160-663 L
71.85 gal [272 l] 26.41 gal [100 l] 31.44 gal [119 l] 32.49 gal [123 l] 49.66 gal [188 l] 75.55 gal [286 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 34 140.80 gal [533 l] 60.23 gal [228 l] 64.72 gal [245 l] 73.97 gal [280 l] 91.93 gal [348 l] 145.29 gal [550 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 35: Barrier Machines 70-180 Kg / 160-400 Lb / 700-1800 L
1102.76 gal [389 l] 61.55 gal [233 l] 71.06 gal [269 l] (4) 83.48 gal [316 l] 103.56 gal [392 l] (2) 106.99 gal [405 continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 36 250.44 gal [948 l] 143.45 gal [543 l] 168.28 gal [637 l] 201.83 gal [753 l] 239.34 gal [906 l] 255.98 gal [969 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 37 340.52 gal [1289 l] 361.92 gal [1370 l] 345.27 gal [1307 l] 367.20 gal [1390 l] 350.03 gal [1325 l] 372.48 gal [1410 l] continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 38 MB90, *B*0900 MB110, *B*1100 MB140, *B*1400 MB180, *B*1800 (1) Economic Low Level (2) Economic High Level (3) Normal Low Level (4) Normal High Level continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 39: Programmable Water Level
FS 1000, *YN230 FS 1200, *YN275 Barrier Washers MB 16 MB 26, *B*0265 MB 33, *B*0332 MB 44, *B*0442 MB 66, *B*0663 continues... Table 4 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 40: Speed Of Machines With Frequency Inverter
Cabinet Freestanding FS 6 351-449 FS 7 351-449 FS 10 351-449 FS 13 351-449 FS 16 351-449 FS 23/3 351-449 FS 23/4 351-449 continues... Table 5 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 41: Programming The Wash Speed
RS machines : Extraction 450 - 500 RPM (MFR) FS & MB machines : Extraction [300 - 350] – [450 – (850) 1000] RPM (MFS NN) © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 42: Programming The Motor On And Off Times For Reversing
37.4°F [3°C] for each minute. • Water supply Inlet 1 can function as water recycle inlet valve. (Replaces the hard water supply). © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 43: Initializing The Machine Initializing The Machine
The Advance function allows to Skip a Sequence or to extend & de- No / Yes crease the time of a sequence. (default MB-machines : No) continues... Table 6 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 44 In the tub cold and hot water gets mixed and if af- ter 30 seconds the programmed target temperature is not reached, the heating will be started again. continues... Table 6 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 45 The heating will switch on again and the wash process will continue as soon as the external signal is switched off. continues... Table 6 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 46: Configuration Menu
The configuration menu can only be accessed when the ma- • For the Configuration Menu a password is required. chine is in standby (the power is switched on, but no program © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 47: Passwords
Brightness Display The brightness of the display is changed by adjusting the contrast of 1 - 20 the optimal viewing angle. continues... Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 48 Steam heating machine option. NOTE: For machine with steam heating: If this option is not set to "YES", the laundry may be damaged. continues... Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 49: Display Message
Select Celsius or Fahrenheit, depending if you prefer that the tempera- Celsius / Fahren- ture is displayed in degrees Celsius or degrees Fahrenheit. heit continues... Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 50 NOTE: Look inside the tub through the door glass before unlocking the outer door, check that the inner door is posi- tioned correctly. continues... Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 51 NOTE: Some handheld computers have very poor light sig- nal Strength. It is possible that you have to point just next to the Irda window. continues... Table 7 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 52: Advanced Menu
: DAQ Memory Menu Display Message Information All Memory Segments On / Switched on when all Memo- ry segments are operational. continues... Table 8 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 53: Hygienic Cycle Menu
The access to the Program Mode can be locked by a password. It means that without password you can't have access to the Main Menu Screen. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 54: Program Lock Menu
It avoids that programs once created get changed by somebody else. 1 HOT 194°F [90°C] INTENS (Unlocked) 2 WARM 140°F [60°C] INTENS (Locked) EXIT continues... Table 11 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 55 To change the Password insert first the old Password, then you are in- vited to create a new Password. Exit Return to Advanced Menu continues... Table 11 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 56: Traceability Menu
When the weight value is shown, it can be presented in kg or in a per- cent value (capacity machine). • Main Units correspond with the biggest number size on the display. continues... Table 13 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 57: Special
This item activates communication with dispensing PLC system. No / Yes Show Customer ID Displays the customer ID at the start of a cycle No/Yes continues... Table 14 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 58 If the external wait signal is set for soap and the signal is high, the No/Yes communication will be stopped until the signal is low before transmit- ting again. Exit Return to Advanced Menu continues... Table 14 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 59: How To Create And Adjust A Wash Program
Initializing the Machine How to Create and Adjust a Wash Program Figure 15 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 60: Programming
Get into the Setup Mode . Program Functions Display Message Information Select Program Number: 1 Insert the desired program number. Program 1 to 99 can be selected. continues... Table 15 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 61: Step 3: Program Step Function
NSERT T TEP … … ELETE ELETE … … EDIT EDIT STEP STEP … … VIEW VIEW S S … … EXIT EXIT CHM1658R Figure 19 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 62 An existing Step in the program disappears when it's deleted. A confirmation is asked first before deleting the Old Step. Exit Return to Program Menu. continues... Table 16 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 63: Step 4: Programming The Wash Part
• Depending on the machine type, with top or front soap dis- grams can be programmed. Refer to section Basic Descrip- penser, you have more or less sequences available. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 64 • No wash • You can also use the ARROW DOWN button if you accept Washing Machines with Front Soap Dispenser the pre-programmed default value. • Wash © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 65: The Prewash Sequence
Wash Step. This allows the operator to add soap for the next step. A buzzer signal warns the operator that the cycle has been inter- rupted. continues... Table 17 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 66: The Wash Sequence
The wash action (motor "Off" Time). Gentle wash action : 12 sec- onds. (The suggested default values can be adjusted at the Initialization menu) continues... Table 18 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 67 Wash Step. This allows the operator to add soap for the next step. A buzzer signal warns the operator that the cycle has been inter- rupted. continues... Table 18 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 68: The Cooldown Sequence
The wash action (motor "Off" Time). Gentle wash action : 12 sec- onds. (The suggested default values can be adjusted at the Initialization menu) continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 69 Wash Step. This allows the operator to add soap for the next step. A buzzer signal warns the operator that the cycle has been inter- rupted. continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 70: The Rinse Sequence
0 - 99.5 minutes The Rinse Sequence Time. (for 0 Minutes the Rinse sequence will be skipped) (programmable in steps of 0.5 Minutes) continues... Table 19 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 71 Wash Step. This allows the operator to add soap for the next step. A buzzer signal warns the operator that the cycle has been inter- rupted. continues... Table 19 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 72: The Final Rinse Sequence
The Final Rinse Sequence Time. (for 0 Minutes the Final Rinse sequence will be skipped) (program- mable in steps of 0.5 Minutes) continues... Table 20 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 73 Wash Step. This allows the operator to add soap for the next step. A buzzer signal warns the operator that the cycle has been inter- rupted. continues... Table 20 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 74: The Soak Sequence
10 minutes 1 - 99 minutes The wash action (motor "Off" Time). (The suggested default values can be adjusted at the Initialization menu) continues... Table 21 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 75 Wash Step. This allows the operator to add soap for the next step. A buzzer signal warns the operator that the cycle has been inter- rupted. continues... Table 21 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 76: The Flush Sequence
Wash Step. This allows the operator to add soap for the next step. A buzzer signal warns the operator that the cycle has been inter- rupted. continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 77: The Spray Sequence
Depending on the machine type, you have more or less func- grammed step is skipped. Go to Step 5: Programming the tions. Drain Step . © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 78 • Press the ENTER button to confirm your selection. • You can also use the ARROW DOWN button if you accept CHM1661R the pre-programmed default value. Figure 22 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 79: The Drain Sequence
The Drain Sequence Time. (for 0 Minutes the Drain sequence will be skipped) (programmable in steps of 0.5 Minutes) Exit Return to Edit Program Menu. continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 80: The Extract Sequence
The Extract Sequence Time. (for 0 Minutes the Extract sequence will be skipped) (programmable in steps of 0.5 Minutes) Exit Return to Edit Program Menu. continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 81: The No Drain Sequence
The Drain/Extraction part of the programmed step is skipped. C050 The No Drain Sequence Display Message Default Information Limits Exit Return to Edit Program Menu. continues... Table 22 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 82: The Static Drain Sequence
When the spin sequence starts, the garments are a big imbalance and the imbalance (tilt) function will be activated. C051 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 83: The Reversing Drain Sequence
The Static Drain Sequence Time. (for 0 Minutes the Static Drain sequence will be skipped) (program- mable in steps of 0.5 Minutes) Exit Return to Edit Program Menu. continues... © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 84: Operation Menu Operation Menu
• Insert the program number. soiled and/or smaller volumes of garments. In other cases these reduced water levels will give poor washing quali- • Press the "START" button. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 85: The Active Program
1. The programmed time of the processes. program mode. 2. The extra time for taking water. C066 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 86: Program End
• After closing the doors, you can start a new wash cycle. ing will be required after the fill process to reach the pro- grammed hot water temperature. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 87: Heating Process
• It’s recommended to program a pause (signal) if you want to fill the same soap box twice while the program is running. Only for machines with a Top Soap Dispenser. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 88: Wait State
• By turning the key switch to Program, the Service State burns. Menu will not disappear after 1 minute. C069 • By pressing the ARROW DOWN button you will see all the menu items. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 89: Water Recycling
FOR MACHINES WHICH ARE NOT EQUIPPED WITH system, a signal from the water recycling tank can be con- AN AUTOMATIC WEIGHING SYSTEM nected to the washing machine computer. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 90 • If the door is open there is shown "0kg" as the linen load weight on the display. Enter the weight value. When you close the door, you will be able to select a wash cycle. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 91: Pre-Programmed Programs Pre-Programmed Programs
Water RPM) continues... • H : type FS/MB = High extraction speed (625 – 1000 RPM) (depending on the size of the machine) Table 23 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 92: Wash Programs
3 minutes W (normal) D=30 sec- onds Final spin/ 5.5 min- Spin utes Slowdown Tumble 30 seconds W (5 seconds / 5 seconds) continues... Table 25 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 93: Wash Program 2: Warm Wash 140°F 60°C
3 minutes W (normal) D=30 sec- onds Final spin/ 5.5 min- Spin utes Slowdown Tumble 30 seconds W (5 seconds / 5 seconds) continues... Table 26 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 94: Wash Program 3: Colored Wash 104°F 40°C
3 minutes W (normal) D=30 sec- onds Final spin/ 5.5 min- Spin utes Slowdown Tumble 30 seconds W (5 seconds / 5 seconds) continues... Table 27 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 95: Wash Program 4: Bright Colored Wash 86°F 30°C
W (gentle) B=30 sec- [15°C] onds Drain 30 seconds D Step 2 Rinse 1 2 - 5 - 6 2 minutes W (gentle) continues... Table 29 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 96 1 (+6) 1 (2) 3 minutes W (gentle) D=30 sec- onds Final spin/ 2.5 min- Spin utes Slowdown Tumble 30 seconds W (gentle) continues... Table 29 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 97: Wash Program 6: Eco Hot Wash 194°F 90°C
20 minutes W (normal) B=30 sec- [60°C] onds Drain 30 seconds D Step 2 Rinse 1 2 - 5 - 6 4 minutes W (normal) continues... Table 31 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 98 6 minute W (normal) D=30 sec- onds Final spin/ 5.5 min- Spin utes Slowdown Tumble 30 seconds W (5 seconds / 5 seconds) continues... Table 31 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 99: Wash Program 8: Eco Colored Wash 104°F 40°C
20 minutes W (normal) B=30 sec- [34°C] onds Drain 30 seconds D Step 2 Rinse 1 2 - 5 - 6 4 minutes W (normal) continues... Table 33 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 100 6 minutes W (normal) D=30 sec- onds Final spin/ 4 minutes Spin Slowdown Tumble 30 seconds W (5 seconds / 5 seconds) continues... Table 33 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 101: Wash Program 10: Super Eco Hot Wash 194°F 90°C
2 minutes W (normal) Spin 1 minute Step 3 Rinse 2 1 (+6) 1 (2) 3 minutes W (normal) D=30 sec- onds continues... Table 35 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 102 Steel S. Dis- Dis- penser penser Final spin/ 5.5 min- Spin utes Slowdown Tumble 30 seconds W (5 seconds / 5 seconds) continues... Table 35 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 103: Wash Program 12: Super Eco Color Wash 104°F 40°C
2 minutes W (normal) Spin 1 minute Step 3 Rinse 2 1 (+6) 1 (2) 3 minutes W (normal) D=30 sec- onds continues... Table 37 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 104 Soap Steel S. Dis- Dis- penser penser Final spin/ 4 minutes Spin Slowdown Tumble 30 seconds W (5 seconds / 5 seconds) continues... Table 37 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 105: Wash Program 14: Extraction - Low Speed
3 minutes W (normal) D=30 sec- onds Final spin/ 5.5 min- Spin utes Slowdown Tumble 30 seconds W (5 seconds / 5 seconds) continues... Table 39 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 106: Roubleshooting
• Pressing the STOP or ENTER button (key switch in program mode). • Switching the power off/on. • Opening the door (fault 4 and 41). © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 107 Continue ? will be displayed. CHM1666R Possible cause : Figure 30 • Water supply inlets closed. • Decreasing capacity of the heating elements. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 108: Failure Message Overview
At loading parameters Stall prev Stall prevention function active Continue At spin sequence Wrong Softw Wrong software version Don’t start New software version continues... Table 40 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 109 (MB70-90-110-140-180 only) No Free Run Deceleration end of spin while Full stop + safety time At spin sequence (only brake is closed. MB70-90-110-140-180) continues... Table 40 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 110 Abnormal Cycle Termination mination cle has to be repeated (MB only) No Store PC Communication failure with For Information only End cycle (MB only) continues... Table 40 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 111: Service Menu
Advanced Menu … • Pulley ratio. CHM1667R • An overview of the input states. Figure 31 • Switching On the Inverter for a technical intervention. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 112: Display Message
• Invert Alarm : E26 + E28 + E29 + E30 + E60 + E61 + E62 + E72 + E73 + E74 + E75 • Lock Active : E78 + E79 continues... Table 41 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 113: Toolbox Menu
"Service Interval" a warning is given at the end of each cycle until the Cycle Counter has been reset. Exit Return to Service Menu continues... Table 42 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 114: Diagnostic Program
The machine takes water by inlet 2 until the safety level for heating is reached Heating activated (only if Wait temp = on) continues... Table 43 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 115 High spin speed (the drum is turning away from the soap box) Motor Stop Free run or controlled deceleration Inlet I1 The machine takes water by inlet 1 continues... Table 44 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 116: Basic Diagnostic Wash Program
Front Front Front ture Step Wash Wash 3-4-5 104°F A=12 seconds 6 min- [40°C] R=3 seconds utes Drain Drain 30 sec- onds continues... Table 45 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 117: Troubleshooting
Flash Memory with software into the socket continues... Table 46 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 118: External Communication Problems
In the Configuration Menu you can select "RS485" communi- cation or "Irda". Only one of both communication channels is Error Message Descriptions operational at the same time depending your selection. So if © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 119: Failure 1: Drain Failure Cooldown Sequence
Failure 2 occurs when the electronic timer detects that the wa- ter is not drained after 3 minutes in a Drain or Spin Sequence. The failure message is displayed at the end of the cycle. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 120: Failure 3: Out Of Balance Before Spin
The "DOOR SWITCH" is a place the door switch. properly. NO normal open contact. continues... continues... Table 50 Table 52 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 121: Failure 7: Door Lock Solenoid Switch Failure
DOOR NOT LOCKING (blinking). By opening the door : you ready for use again. are invited to close the door and press the START button once more. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 122: Failure 10: Bimetal/Spring
Table 56 Table 57 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 123: Failure 12: Overfill Failure
If the heating elements are not pressing the Service Button on the keypad. ments are heating. heating: Repair the wiring or replace the defective heater elements. continues... Table 59 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 124: Failure 21: Overflow Failure
When the water level is raising above the hole of the overflow displayed. The temperature sensor is checked during wash cy- tube: message 21 will be displayed. cle only. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 125: Failure 26: Undefined Mitsubishi Frequency Inverter Error Code
Error 27 will occur if at the Configuration menu the wrong in- verter type and by this way also the wrong baud rate has been selected. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 126: Failure 28: Tht (Mitsubishi) / E.ol (Keb) Time Out
4. Check if the fault is persis- If the fault is persistent, con- Communication Fault Invert- tent. tact the manufacturer. er . continues... continues... Table 68 Table 70 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 127: Failure 33: Stall Prevention Function
All the custom settings will be erased in the wash computer by loading the factory settings. Table 74 C080 After reconfiguration of the Wash Computer, fault 35 can only © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 128: Failure 40: Fill Failure Empty Water Recycling Tank
(siphon) remove the water and fix the Voltage ranges are not allowed. hose so that it doesn’t work as a siphon. continues... Table 75 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 129: Failure 44: Wrong Inverter Model Type
MB70, MB90, MB110, MB140, MB180, *B*0700, *B*0900, continues... *B*1100, *B*1400, *B*1800 machine only. Table 80 Failure 47 occurs when the friction blocks of the brake are © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 130: Failure 48: Brake Stays Open
Table 83 Failure 49: Unbalance Switch at Wash MB70, MB90, MB110, MB140, MB180, *B*0700, *B*0900, *B*1100, *B*1400, *B*1800 machine only. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 131: Failure 52: Pcb-Eeprom Crc Failure
RS6 - RS7 - RS10 only. Failure 60 occurs when there is no feedback speed signal from the Motor Drive at the wash sequence. Probably this also © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 132: Failure 61: Continue Spin
If the motor is broken, replace the motor. 2. Check the communication If the communication cable is cable. broken, repair the communi- continues... cation cable. Table 90 continues... Table 88 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 133: Failure 69: Rs Unbalance
(installed new inverter with- continues... out loading the parameters ?) Table 92 continues... Table 95 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 134: Failure 74: Cfistuck
2. Check if the wiring of the If the wiring is damaged: re- input signal "On Hold" is not pair the wiring. continues... damaged. Table 97 continues... Table 99 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 135: Failure 81: No Reheat
(If Traceability is switched off, Err 86 will not occur anymore). Diagnosing Failure 83 Refer to Extra Error message that shows the cause of the fail- ure. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 136: Failure 95: Watch Dog
MB16-MB66 : load on each load cell must be in range Verify if the value "Expected Free Weight XXX" in the Weigh- © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 137: Failure 104: Weigh Overload
Table 107 ing machine. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 138: Failure 300-353: Mitsubishi Inverter Alarm Message
Err 316 in the error log. Err CPU CPU Fault Communication error of built in CPU. Replace inverter. continues... Table 108 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 139 Err ILF* Input phase failure 1 phase of the 3-ph input was lost for more than 1 second. Repair the 3-phase power supply. continues... Table 108 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 140 * This option or function is not used. If you have this error anyway do the following : 1. Reload the inverter parameters. 2. If the fault is persistent, contact Technical Support. continues... Table 108 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 141: Failure 300-301-302: Oc Errors (Overcurrent)
In such case the contactor must not be replaced. The In- mal high friction. verter must be reset by a longer power interruption. continues... Table 111 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 142: Failure 335: Fin-Error (Cooling Fin Inverter Overheat)
2. Check for contact faults in the wiring. Refer to electrical scheme. Errdri driver relay Internal relay output gate drivers defect. If the fault is persistent, replace the inverter. continues... Table 116 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 143 ErrPrF* prot.rot.for. The drive has driven onto the right limit switch. ErrPrr* prot.rot.rev. The drive has driven onto the left limit switch. continues... Table 116 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 144: Failure 401: Bus-Error (Communication Bus Error)
Potential) the inverter makes an auto retry and activates the speed search function to pick up the motor during extraction. If this takes more than 10s there will be E. EF. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 145: Failure 420: Oc-Error (Overcurrent)
3. Check if the heatsink or the Clean what is necessary. cooling fans are not clogged with dust/dirt so that fresh air can circulate freely. continues... Table 120 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 146: Failure 426: E. Op (Overvoltage)
Software errors must never occur. If a software error message ry is of importance. occurs inform the manufacturer. Failure 551: DAQ Write Error Failure 551 occurs when the wash computer fails to write data © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 147: Service Information Service Information
• Outputs : 21 relays • Serial interface : RS485 (2 wire) networking between wash computer and external device (PC Computer) • Display : LCD display © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 148: Instructions For Replacing The Electronic Board And Keypad
Software • All Custom Settings will be lost. 1. Switch the power Off/On. 1. Switch off the main power. © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...
Page 149 For a practical way of working for changing the eprom : take the electronic board out of the wash- ing machine by the front side of the facia panel. C087 © Copyright, Alliance Laundry Systems LLC - Part No. D1591ENR9 DO NOT COPY or TRANSMIT...

This manual is also suitable for:

Lby663w Sbh663w Hy90 micro Lm1100 graphitronic Sbh700w Hyn090w ... Show all

Alliance Laundry Systems HY125 MICRO Programming Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Alliance Laundry Systems HY125 MICRO

Summary of Contents for Alliance Laundry Systems HY125 MICRO

This manual is also suitable for:

Table of Contents
