Installation Instructions
PowerFlex 700S Phase II Control Kit
Catalog Numbers: 20D-P2-CKSx, 20D-P2-CKEx, 20D-DL2-CKSx, 20D-DL2-CKEx
Tools That You Need
What You Need to Do
ATTENTION: To avoid an electric shock hazard, verify that the voltage on the bus
capacitors has discharged before performing any work on the drive. Measure the
DC bus voltage at the +DC & –DC terminals of the Power Terminal Block. The
voltage must be zero.
ATTENTION: HOT surfaces can cause severe burns. Do not touch the heatsink
surface during operation of the drive. After disconnecting power, allow time for
cooling.
ATTENTION: This drive contains ESD (Electrostatic Discharge) sensitive parts
and assemblies. Static control precautions are required when installing, testing,
servicing or repairing this assembly. Component damage may result if ESD
control procedures are not followed. If you are not familiar with static control
procedures, reference Allen-Bradley® publication 8000-4.5.2, "Guarding Against
Electrostatic Damage" or any other applicable ESD protection handbook.
• Wrench for M5 hex nuts
• Phillips screwdriver for M3 screws
• Standard (flat blade) screwdriver
To install the PowerFlex® 700S Phase II Control Kit:
• Step 1: Remove power from the drive
• Step 2: Remove covers from the Phase I control assembly
• Step 3: Remove the Phase I control assembly
• Step 4: Open the main cover
• Step 5: Remove the Phase I cassette
• Step 6: Install the Phase II cassette
• Step 7: Document the revision change
• Step 8: Reconnect I/O and Communications
Advertisement
Table of Contents
Related Manuals for Rockwell Automation Allen-Bradley PowerFlex 700S 20D-P2-CKS Series
Summary of Contents for Rockwell Automation Allen-Bradley PowerFlex 700S 20D-P2-CKS Series
- Page 1 Installation Instructions PowerFlex 700S Phase II Control Kit Catalog Numbers: 20D-P2-CKSx, 20D-P2-CKEx, 20D-DL2-CKSx, 20D-DL2-CKEx ATTENTION: To avoid an electric shock hazard, verify that the voltage on the bus capacitors has discharged before performing any work on the drive. Measure the DC bus voltage at the +DC &...
-
Page 2: Step 1: Removing Power From The Drive
• sending an erroneous signal to your system’s field devices, causing unintended machine motion • causing an explosion in a hazardous environment Electrical arcing causes excessive wear to contacts on both the module and its mating connector. Worn contacts may create electrical resistance. Rockwell Automation Publication 20D-IN014B-EN-P - April 2017... -
Page 3: Step 2: Removing The Covers
Lift side cover off control assembly DRIVE S.M.A.R.T. Exit Lang Auto / Man Remove ENABLE SYNCHLINK Param # The actual product image may differ slightly, depending on whether the drive is equipped with a slim or expanded cassette. Rockwell Automation Publication 20D-IN014B-EN-P - April 2017... - Page 4 Slide the locking tab up, loosen the right-hand cover screw and remove. Frame 6 Loosen two screws at bottom of drive cover. Carefully slide bottom cover down and out. Loosen the two screws at top of cover and remove. Rockwell Automation Publication 20D-IN014B-EN-P - April 2017...
-
Page 5: Step 5: Removing The Cassette
PowerFlex 700S Phase II Control Kit Step 5: Removing the Task Description Cassette Disconnect the two cable connectors Loosen the two screw latches Slide the cassette out Rockwell Automation Publication 20D-IN014B-EN-P - April 2017... - Page 6 Step 7: Documenting Document drive revisions on the “Field Installed Options” tag. Use the blank line. Revision Changes FIELD INSTALLED OPTIONS Firmware Date Date Firmware 20-HIM 28-IO- 20-COMM- COM Module 20B_-DB1- Internal Dynamic Brake Rockwell Automation Publication 20D-IN014B-EN-P - April 2017...
- Page 7 Phase I control are compatible with drives with Phase II control. If you are replacing Phase II to Phase II, reconnect the I/O wiring, and replace the DPI communication adapter, if applicable. Rockwell Automation Publication 20D-IN014B-EN-P - April 2017...
-
Page 8: Additional Resources
Rockwell Automation sales representative. Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, DPI, DriveLogix, PowerFlex, Rockwell Software, Rockwell Automation, and SynchLink are trademarks of Rockwell Automation, Inc. EtherNet/IP is a trademark of ODVA, Inc. Trademarks not belonging to Rockwell Automation are property of their respective companies.
