- Page 1 4-Port USB3.2 Gen 1 Micro Hub w/DIN RAIL Mounting Kit Model Number: CG-MIC4P31H-PCBA Installation Guide Coolgear, Inc. Version: 1.0 Date: 04/08/2024...
-
Page 2: Table Of Contents
First Release 1. Introduction Thank you for purchasing Coolgear’s 4-Port USB3.2 Gen 1 Micro Hub. It provides an ideal solution to expand 4 USB3.2 Gen 1 ports (USB-A connectors) from one single USB3.2 host port. It provides a self power input (5V DC from 2-pin Terminal Blocks) to provide enough power on USB3.2 Gen 1 downstream facing ports. -
Page 3: Hardware Installation
Since the USB hub is plug-and-play, you don’t have to turn off your host computer when installing the hub. Connect the USB devices to the downstream ports of this hub. Mount your hub on the wall (with the Multi-Orientation Bracket) or DIN Rail (with the DIN Rail Clip) if required. Need help? Visit: coolgear.com/support... -
Page 4: Checking The Hub Installation
Do not disassemble the product. Handling the product’s ● internal components can expose it to ESD (Electro-Static Discharge) hazards that can affect the function of the device. If this product is not functioning properly, email our support ● team at support@coolgear.com. Need help? Visit: coolgear.com/support... - Page 5 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
