- Page 1 7 Port USB 3.2 Gen 1 Hub PCBA w/ ESD Surge Protection Model Number: CG-7PU31HB-PCBA Installation Guide Coolgear, Inc. Version: 1.0 Date: 04/08/2024...
- Page 2 First Release 1. Introduction Thank you for purchasing Coolgear’s 7-Port USB3.2 Gen 1 Metal Hub. It provides an ideal solution to expand 7 USB3.2 Gen 1 ports from one single USB3.2 Gen 1 host port. It provides a DC Jack and 2-pin terminal blocks for self power source (+7~24V DC) to provide enough power on USB3.2 Gen 1 buses.
-
Page 3: Connector Layout
Remove possible static discharge potential from any objects that the hub may come in contact with before installation. This can be accomplished by touching a bare metal chassis rail after you have turned off the power. Need help? Visit: coolgear.com/support... -
Page 4: Environmental Specifications
Double click Generic USB Hub, the message will show that this device is working properly. 5. Environmental Specifications Operating temp.: 0 to 55°C (32 to 131°F) Operating humidity: 5 to 95% RH Dimensions (LxWxH): 7.12”(L)x2.34”(W)x1.03”(H) (181.00 x 59.40 x 26.30 mm Need help? Visit: coolgear.com/support... - Page 5 Technical Support When you reach out to Coolgear support, you’ll find yourself in the hands of a solution-oriented and knowledgeable expert ready to answer whatever question you throw at them. If you ever need help with your product, visit coolgear.com/support for support tickets, downloads, and other support resources.
- Page 6 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
