14
Slide part A up to fit the screws protruding from piece K.
17
Finally, with the help of a screwdriver, tighten the screws so that the piece is well fixed.
STEP 4. ASSEMBLING THE BLADES
E
1
With the motor well posi-
tioned, we will begin the as-
sembly of the blades E.
16
ENGLISH
K
15
A
18
A
L
Includes a replace-
ment screw
2
E
Place the first blade E securing it with the washers and screws
L with the help of the screwdriver, without tightening them too
much, to be able to put the rest of the blades.
16
Once fitted, turn piece A to
the right.
19
+
3
L
