Attach mounting hardware

If your server requires special rails or other hardware to install the tape drive, mount them on the tape drive
now. If your server does not require special mounting hardware, proceed to
now.
CAUTION:
Static electricity can damage electronic components. Always wear an antistatic wriststrap if one is
available. If not, after you have disconnected power from the server and removed the cover, touch a bare
metal part of the chassis. Similarly, touch a bare metal part of the drive before installing it.

HP ProLiant servers

NOTE:
If mounting hardware is supplied with your tape drive, it may not be exactly the same as shown in
the illustrations.
Different models of server require different mounting methods. The server may also incorporate a locking
mechanism to hold the tape drive in place. See
Please check your HP ProLiant server documentation to ascertain the correct method of mounting, and
to check whether mounting hardware is provided with the server.

Mounting rails

Some HP ProLiant servers, such as ML530 and ML570, require mounting rails. These may be metal or
plastic rails attached to the filler panel of the server's drive bay.
Use a regular Phillips screwdriver to attach the appropriate rails. Use the M3 screws provided with the
tape drive, as shown in
Ensure you do use the M3 screws provided. The rails may be attached to the filler panel by screws of
a different thread/size type and these should not be used. If in doubt, refer to your HP ProLiant server
documentation.
Figure 5 Attaching mounting rails
Figure 5 on page 21.
"Secure the drive" on page 27.
"Install drive" on page 23
DAT USB Tape Drives 21
