Mounting screws
Other HP ProLiant server models, such as ML350 and ML370, only require the use of special locating
screws with no mounting rail.
Use a Torx screwdriver to attach the appropriate screws. You may need to purchase the M3 screws
separately. Position the screws, as shown in
• HP ProLiant ML350: Use M3 mounting screws. These have a thicker head than the standard
M3 screws.
HP ProLiant ML370: Use M3 offset mounting screws. These have a thick offset piece and a
•
thicker head than the standard M3 screws.
1. M3 mounting screws
2. M3 offset mounting screws
Figure 6 Attaching mounting screws

Other servers

Attach the appropriate mounting hardware. Refer to the manufacturer's documentation for instructions.
• If you are installing on a server that requires a tray, place the tape drive in the tray.
• If you are installing in a server that requires mounting rails, fasten the rails to the tape drive.
• Some servers have snap-on mounting rails attached to the filler panel. These can be removed
and attached to the tape drive with screws.
22
Installing an internal DAT tape drive
Figure 6 on page 22.
1
2
