Summary of Contents for Cata UBIND60MT
- Page 1 INDUCTION INDUCTION INDUCTION INDUCTION UBIND60MT UBINDE60MT WRECOIND60 PLUG & PLAY User Manual User Manual...
-
Page 2: Table Of Contents
Contents | Before you start | Safety | Technical data | Guarantee | What's required for installation | What's in the box | Installation | Electrical installation | Use | Troubleshooting | Care & Maintence... -
Page 3: Safety
Safety | Before you start | Safety • To avoid the risks that are always These instructions are for your present when you use an electrical safety. Please read the following appliance it is important that this instructions carefully before appliance is installed correctly and proceeding with the installation that you read the safety instructions... - Page 4 Safety • Risk of fire! Do not store • Do not use inappropriate child detergents or fl ammable safety shields or hob guards. materials beneath the hob. These can cause accidents. • This appliance is intended for • Do not use covers. These can domestic use only.
- Page 5 Safety • WARNING: Accessible parts • WARNING: Use only hob may become hot when used guards designed by the with cooking appliances. Young manufacturer of the cooking children should be kept appliance or indicated by the away. Care should be taken to manufacturer of the appliance avoid touching the appliance.
-
Page 6: Technical Data
560 x 490 mm UBIND60MT: 7000W Max. power consumption UBINDE60MT: 7000W (Preset 2800W) Symbol Value Unit Model identification UBIND60MT / UBINDE60MT Type of hob Built-in hob Number of cooking zones and/or 4 zones areas Heating technology (induction cooking zones and cooking... -
Page 7: Guarantee
Guarantee | Recycling & disposal DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. This appliance is labelled in compliance with European directive 2011/65/EU for Waste Electrical and Electronic Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possible damage to the environment and to human... -
Page 8: What's Required For Installation
Installation | What's required for installation | What's in the box [01] UBIND60MT x 1 [02] x 1 [01] UBINDE60MT x 1 [02] x 1 [03] x 1... -
Page 9: Installation
Installation | Cut out work surface Cut out the work surface according to the L (mm) sizes shown in the drawing. W (mm) For the purpose of installation and use, a H (mm) minimum of 50 mm space shall be preserved D (mm) around the hole. - Page 10 Installation | Before you install the hob Before locating the fixing brackets the • A suitable isolating switch providing full hob should be placed on a stable, smooth disconnection from the mains power surface (use the packaging). Do not apply supply is incorporated in the permanent force onto the controls protruding from wiring, mounted and positioned to comply...
- Page 11 Installation | Seal the work surface & hob IMPORTANT: Ensure that the product is fully cured as per the manufacturers instructions before you commence installation of the hob. The hob MUST NOT be sealed into the worktop. Cut out worktop to supplied dimensions shown in DIAGRAM 01 with suitable equipment.
-
Page 12: Electrical Installation
Permanently Wired Version (Professional Fit important that this appliance is installed Only - Maximum Input 7000 W) -Model correctly and that you read the safety UBIND60MT instructions carefully to avoid misuse and hazards. Please keep this instruction CAUTION: THE FOLLOWING SECTION IS... - Page 13 Installation | Electrical installation Conversion to permanent wiring THE FOLLOWING SECTION IS FOR PROFESSIONAL QUALIFIED ELECTRICAL INSTALLERS ONLY. When connected to a mains outlet using the factory fitted plug, the software will limit the hob maximum power to 2800W. Once configured as a permanent installation, the maximum power output is 7000W.
- Page 14 13Amp 3.3kW 15Amp 4.5kW 20Amp 5.7kW 25Amp 7.0kW 32Amp * On the first use, the power setting of UBIND60MT is factory set to 7.0kW. UBINDE60MT is the factory settingof 2.8kW. 6. Touch the " " key again to finish configuration.
-
Page 15: Use
| Induction Cooking Before using your Induction Hob • Read this guide, taking special note of the Safety section. • Remove any protective film that may still be on your Induction hob. Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. - Page 16 | Choosing the right cookware Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the packaging or on the bottom of the pan. • You can check whether your cookware is suitable by carrying out a magnet test.
-
Page 17: Functions And Settings
| Before you start People with a heart pacemaker should consult with their doctor before WARNING: Read the instructions using any induction hob. before using the appliance. Switch on the appliance at the plug socket or double pole isolation switch. The appliance is ready for use. - Page 18 General Use Child Lock Function • You can lock the controls to Boost Function prevent unintended use (for example children accidentally Actived the boost function turning the cooking zones on). 1. Select the heating zone by touching the zone select key " ". •...
- Page 19 Pause Function • When the "10" is still flashing, touch The hob has a handy restart function to the " "or " " keys once to increase pause and restart the cooking process if or decrease one minute at a time. you’re interrupted.
- Page 20 • To cancel the timer, select the cooking zone and press the Timer key " " then press the " " key until the display shows "00". Note: the cooking zone will not be switched off. However if the timer completes the programmed time, the cooking zone will be switched off.
- Page 21 General Use Over-Temperature Protection An internal temperature sensor will monitor the temperature inside the induction hob. When an excessive temperature is detected, the induction hob will stop operation automatically. Detection of Small Articles When an unsuitable size or non-magnetic pan (e.g.
-
Page 22: Using Your Induction Hob
| Using your Induction Hob If the display flashes alternatelywith – the heat setting This means that: • You have not placed a pan on the correct cooking zone, To start cooking the pan you’re using is not suitable 1. Touch and hold the ON/OFF control. for induction cooking, After power on, the buzzer beeps once, all displays show "... -
Page 23: Troubleshooting
Troubleshooting | Troubleshooting Problem Possible cause Solution The induction hob No power. Make sure the induction hob is cannot be turned on. connected to the power supply and that it is switched on. Check the consumer unit to ensure the RCD has not tripped. Check whether there is a power cut by trying other electric appliances. - Page 24 Troubleshooting | Troubleshooting If an abnormality occurs , the induction hob will enter the protective state automatically and display corresponding protective codes: Error Message Possible cause What to do – No pot or pot not suitable. Replace the pot. Water or pot on the glass over the Clean the user interface.
-
Page 25: Care & Maintence
Care & Maintenance | Looking after your appliance IMPORTANT: Always switch off the electricity supply before performing any maintenance work. The appliance should be cleaned after use, allow to cool first! Type of dirt Cleaning method Cleaning materials Apply white vinegar to the surface, Limescale Special induction hob cleaner then wipe it dry with soft cloth. -
Page 26: Customer Service
Note: For electrical connection see Technical and legal information section Customer Service If your product breaks down. To arrange an in guarantee service call, please contact customer services on the following numbers. UK and N.Ireland T: 0344 800 1128 E: uksupport@apelson.co.uk www.spareszone.co.uk Republic of Ireland (ROI) T: 014475261 E: uksupport@apelson.co.uk... - Page 27 Notes...
- Page 28 AAUK Ltd Good Hope Close Normanton Industrial Estate Normanton West Yorkshire WF6 1TR UBIND60MT UBINDE60MT IM 20240826 v1.4...
- Page 29 此页不印刷 This page will not be printed 版本号：20240826+V1.4 尺寸：A5，70克双胶纸， 单色印刷，骑马钉...
