- Page 1 T3 SMITH MACHINE ATTACHMENT 401972 - T3SMITH82 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
-
Page 2: Hardware Pack
HARDWARE PACK... - Page 3 ASSEMBLY INSTRUCTIONS Step 1 1. Assemble the Connection Plate (9) on the racks by using Flat Washer (24), Spring Washer (25), Flat Nut (26) and Hex Bolt (28). 2. Assemble the Safety Pin (12) on the racks by using Flat Washer (22), Spring Washer (23) and Hex Bolt (27).
- Page 4 Step 2 Assemble the Guide Rod Bracket (1) on the racks by using Flat Washer (24), Spring Washer (25), Flat Nut (26) and Hex Bolt (29).
- Page 5 Step 3 Insert Barbell Plate (4), Left Safety Hook (5), Right Safety Hook (6) and Large Cushion (17) into the guide rod. (Pay attention to the direction of the M10 thread hole on the guide rod).
- Page 6 Step 4 1. After installing the assembly in Step 3 into the hole of the Guide Rod Bracket(1), fix it with Flat Washer (22), Spring Washer (23) and Hex bolt (27)； 2. Insert two Guide Rod (11) into the hole of Upper Fixed Frame (8), then assemble Upper Fixed Frame (8) and Guide Rod (11) on the racks by using Flat Washer (24), Spring Washer (25), Hex bolt (26) and Hex Bolt (30).
- Page 7 PARTS DIAGRAM / EXPLODED VIEW...
- Page 8 DESCRIPTION DESCRIPTION GUIDE ROD BRACKET (17) LARGE CUSHION Φ55*Φ25*25 LEFT SLIDING FRAME (18) END CAP F50*3 RIGHT SLIDING FRAME (19) LINEAR BEARING BARBELL PLATE (20) BEARING 61806ZZ LEFT SAFETY HOOK (21) CIRCLIPS Φ40 RIGHT SAFETY HOOK (22) FLAT WASHER Φ10.5*Φ30*2.5 BARBELL ASSEMBLY WELDING (23) SPRING WASHER Φ10...
-
Page 9: Warranty
DISCLAIMER This equipment must be used with care by capable and competent individuals under supervision, if necessary. The use of any equipment, including this one, involves the potential risk of injury. You accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages, rights of action, or causes of action, present or future, whether the same be known or unknown, anticipated, or unanticipated,... - Page 10 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2025 Titan Brands...
