INSTRUCTION MANUAL
MODEL 702
PRECISION CALIBRATOR
TELEDYNE ADVANCED POLLUTION INSTRUMENTATION
9970 CARROLL CANYON ROAD
SAN DIEGO, CA 92131-1106
TOLL-FREE: 800-324-5190
FAX: +1 858-657-9816
TEL: +1 858-657-9800
E-MAIL: api-sales@teledyne.com
WEB SITE: www.teledyne-api.com
01914 Rev. E
DCN 5274
Copyright 2006 Teledyne API
13 March 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 702 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teledyne 702

Summary of Contents for Teledyne 702

  • Page 1 INSTRUCTION MANUAL MODEL 702 PRECISION CALIBRATOR TELEDYNE ADVANCED POLLUTION INSTRUMENTATION 9970 CARROLL CANYON ROAD SAN DIEGO, CA 92131-1106 TOLL-FREE: 800-324-5190 FAX: +1 858-657-9816 TEL: +1 858-657-9800 E-MAIL: api-sales@teledyne.com WEB SITE: www.teledyne-api.com 01914 Rev. E DCN 5274 Copyright 2006 Teledyne API...
  • Page 2 THIS PAGE IS INTENTIONALLY LEFT BLANK...

  • Page 3: Safety Messages

    Teledyne API Model 702 Precision Calibrator Instruction Manual SAFETY MESSAGES Your safety and the safety of others is very important. We have provided many important safety messages in this manual. Please read these messages carefully. A safety message alerts you to potential hazards that could hurt you or others. Each safety message is associated with a safety alert symbol.
  • Page 4 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 06496A...

  • Page 5: Table Of Contents

    Teledyne API Model 702 Precision Calibrator Instruction Manual TABLE OF CONTENTS SAFETY MESSAGES ................... I TABLE OF CONTENTS ..................III LIST OF FIGURES ....................V LIST OF TABLES....................VI 1 INTRODUCTION .................... 1-1 2 WARRANTY....................2-1 3 SPECIFICATIONS..................3-1 4 DESCRIPTION ....................4-1 4.1 O...
  • Page 6 Teledyne API Model 702 Precision Calibrator Instruction Manual 8 STARTING FOR THE FIRST TIME..............8-1 8.1 F ......................8-1 IRST 8.2 C ....................8-1 YLINDER ONNECTION 8.3 L ......................8-3 HECKING 8.4 C M702 ............... 8-4 ONNECTING THE TO THE NALYZER 9 SETTING DILUTION FLOWS ................

  • Page 7: List Of Figures

    Teledyne API Model 702 Precision Calibrator Instruction Manual LIST OF FIGURES 4-1: A ........................... 4-2 IGURE SSEMBLY 4-2: P ......................4-3 IGURE NEUMATIC IAGRAM 5-1: F ........................5-2 IGURE RONT ANEL 6-1: R ........................6-3 IGURE ANEL 6-2: S ..................6-6...

  • Page 8: List Of Tables

    Teledyne API Model 702 Precision Calibrator Instruction Manual LIST OF TABLES 3-1: M702 S ......................3-1 ABLE PECIFICATIONS 12-1: M702 T ....................12-1 ABLE ROUBLESHOOTING 06496A...

  • Page 9: Introduction

    Teledyne API Model 702 Precision Calibrator Instruction Manual 1 INTRODUCTION The Teledyne API Model 702 Precision Calibrator is a low-cost, simple, light-weight calibrator and is intended to be used as a single- or dual-point transfer medium. The basic unit is a two-gas dilution system.
  • Page 10 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 06496A...

  • Page 11: Warranty

    Expendable parts are excluded. If a Product fails to conform to its specifications within the warranty period, Teledyne API shall correct such defect by, in Teledyne API's discretion, repairing or replacing such defective Product or refunding the purchase price of such Product.
  • Page 12 Teledyne API Model 702 Precision Calibrator Instruction Manual TERMS AND CONDITIONS All units or components returned to Teledyne API should be properly packed for handling and returned freight prepaid to the nearest designated Service Center. After the repair, the equipment will be returned, freight prepaid.

  • Page 13: Specifications

    Teledyne API Model 702 Precision Calibrator Instruction Manual 3 SPECIFICATIONS Table 3-1: M702 Specifications ± 1% FS Flow measurement accuracy ± 1% FS Flow control repeatability Flow stability (7 days) Diluent flow range 1 to 3 SLPM Diluent pressure required...
  • Page 14 Teledyne API Model 702 Precision Calibrator Instruction Manual Rear panel pneumatic GAS IN (2 1/8” stainless unions) connections DILUENT IN (1/4” brass union) CAL GAS OUT (1/4” stainless steel union) Tubing Use Stainless Steel Tubing and Fittings for NH Analyzers (Option for NH Analyzers)

  • Page 15: Description

    Teledyne API Model 702 Precision Calibrator Instruction Manual 4 DESCRIPTION See Figure 4-1 (assembly drawing) and Figure 4-2 (pneumatic diagram). Zero air, or diluent, enters the M702 at the rear panel union labeled ZERO AIR IN. The air is controlled (ON/OFF) by a normally closed solenoid valve which is actuated by the DILUENT push button on the front panel.

  • Page 16: Figure 4-1: Assembly

    Teledyne API Model 702 Precision Calibrator Instruction Manual Figure 4-1: Assembly 06496A...

  • Page 17: Figure 4-2: Pneumatic Diagram

    Teledyne API Model 702 Precision Calibrator Instruction Manual Figure 4-2: Pneumatic Diagram 06496A...
  • Page 18 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 06496A...

  • Page 19: Front Panel

    Teledyne API Model 702 Precision Calibrator Instruction Manual 5 FRONT PANEL The front panel contains all the controls needed to operate the M702 Calibrator. See Figure 5-1. 5.1 Power Combination power switch and circuit breaker controls power to all of the M702 functions and protects against current overload.

  • Page 20: Figure 5-1: Front Panel

    Teledyne API Model 702 Precision Calibrator Instruction Manual Figure 5-1: Front Panel 06496A...

  • Page 21: Diluent Pressure

    Teledyne API Model 702 Precision Calibrator Instruction Manual 5.5 Diluent Pressure The Diluent Pressure knob controls the diluent pressure regulator; clockwise to increase. The regulator secondary pressure is displayed on the adjacent pressure gauge. The pressure gauge will read zero when the DILUENT valve is off.

  • Page 22: Digital Display

    Teledyne API Model 702 Precision Calibrator Instruction Manual 5.9 Digital Display Displays the Ozone Generator current setting in percentage units from zero to 100. Will read zero if neither PRESET 1 nor PRESET 2 is selected. Serves as “power on” indicator.

  • Page 23: Rear Panel

    Teledyne API Model 702 Precision Calibrator Instruction Manual 6 REAR PANEL All connections, electrical and pneumatical are made at the M702 rear panel. See Figure 6-1. 6.1 Zero Air In (1/4” BRASS swage-type union) Use CLEAN ¼” OD PFA (or similar) tubing.

  • Page 24: Cal Gas Out

    Teledyne API Model 702 Precision Calibrator Instruction Manual 6.3 Cal Gas Out (1/4” STAINLESS STEEL swage-type union) Connect the CAL GAS OUT port of the M702 to the analyzer sample manifold with CLEAN ¼” OD PFA (or similar) tubing. CAUTION The sample manifold must be properly vented.

  • Page 25: Figure 6-1: Rear Panel

    Teledyne API Model 702 Precision Calibrator Instruction Manual Figure 6-1: Rear Panel 06496A...

  • Page 26: Remote Control

    Teledyne API Model 702 Precision Calibrator Instruction Manual 6.4 Remote Control Five functions may be remotely controlled through the CONTROL IN terminal strip. CONTACT PAIR FUNCTION DILUENT VALVE CYL 1 VALVE CYL 2 VALVE OZONE PRESET 1 OZONE PRESET 2 These require a contact closure.

  • Page 27: Power

    Teledyne API Model 702 Precision Calibrator Instruction Manual 6.6 Power Use an approved three-wire grounded power cord. At 115 VAC, 60 Hz, the M702 draws 2.0 Amps. At 230 VAC, 50 HZ, the M702 draws 1.0 Amp. CAUTION Be sure that the power cord is properly grounded.

  • Page 28: Remote Control/Status Out

    Teledyne API Model 702 Precision Calibrator Instruction Manual 6.7 Remote Control/Status Out Figure 6-2: Status Output Configuration 6.8 Cooling Fan The cooling fan draws air in and requires at least 3” (75 mm) of clearance for proper operation. 06496A...

  • Page 29: Getting Started

    7.1 Unpacking Verify that there is no shipping damage. If there are signs of damage, immediately contact the shipper, then Teledyne API. Remove the cover and check for damage inside, particularly the glass GPT reaction chamber. Check the line voltage decal on the rear panel. Verify that it matches your local power. (The M702 is not frequency-sensitive.)
  • Page 30 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 06496A...

  • Page 31: Starting For The First Time

    Teledyne API Model 702 Precision Calibrator Instruction Manual 8 STARTING FOR THE FIRST TIME 8.1 First Turn-On 1. Remove the M702 cover. 2. Remove the oven cover. 3. Turn on the front panel POWER SWITCH. a) The digital display should come on, displaying “API” and then carrying out a rapid self- check.
  • Page 32 Teledyne API Model 702 Precision Calibrator Instruction Manual CAUTION Do not use plastic tubing. It may burst. With nitric oxide cylinders, atmospheric oxygen can permeate plastic tubing and oxidize NO to NO 3. Close the regulator shut-off valve. 4. Open the cylinder valve.

  • Page 33: Leak Checking

    Teledyne API Model 702 Precision Calibrator Instruction Manual 8.3 Leak Checking 1. Open the cylinder valve and the regulator valve. 2. Check for leaks at the: a) M702 rear panel union, b) inlet valve manifold and c) inlet valves, using bubble solution.

  • Page 34: Connecting The M702 To The Analyzer

    Teledyne API Model 702 Precision Calibrator Instruction Manual "CE" NOTE When the M702 is operating, the cover must be in place and all cover screws must be tightened. Otherwise the M702 may exceed "CE" standards for electromagnetic radiation. 8.4 Connecting the M702 to the Analyzer When you connect the M702 SPAN GAS OUT port to the analyzer(s) to be calibrated, it is very important that the analyzer sample inlet pressure be the same as the normal sampling pressure.

  • Page 35: Figure 8-1: Sample Manifold Venting

    Teledyne API Model 702 Precision Calibrator Instruction Manual NOTE: For NH Analyzers, keep all external tubing and fittings as short as possible. Ensure that the tubing and fittings are stainless steel and must be conditioned for 24 hours prior to use for each gas.
  • Page 36 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 06496A...

  • Page 37: Setting Dilution Flows

    Teledyne API Model 702 Precision Calibrator Instruction Manual 9 SETTING DILUTION FLOWS CAUTION We recommend that the M702 be set and kept at one flow for GAS and one flow for DILUENT. 9.1 Recommendations While it is possible that the M702 can be used as a multi-point calibrator, WE DO NOT RECOMMEND IT.

  • Page 38: Verifying Flows

    9.2 Verifying Flows 9.2.1 Diluent Flow 1. Connect the Zero Air Generator (Teledyne API Model 701) to the ZERO AIR IN port. 2. Set the Zero Air Generator output pressure to 35-50 psig. 3. Connect an NIST-traceable flow measurement device (mass flow meter, soap-film flowmeter or dry piston flowmeter) to the rear panel CAL GAS OUT port.

  • Page 39: Corrections For Npt (Normal Temperature & Pressure)

    Teledyne API Model 702 Precision Calibrator Instruction Manual 7. Select a gas pressure by adjusting the GAS PRESSURE regulator knob. 8. Measure the corresponding flow. 9. Adjust the gas pressure until the desired flow is obtained. 10. Note the gas pressure and use as an indication of flow.

  • Page 40: Example

    Teledyne API Model 702 Precision Calibrator Instruction Manual 9.2.4 Example Say you want to set a span gas of 450 ppb and require at least 1000 ccm to support your analyzer. Start with the DILUENT flow at 2000 ccm and the cylinder flow at 20 ccm.

  • Page 41: With Ozone And Gpt

    Teledyne API Model 702 Precision Calibrator Instruction Manual b) This flushes CYL gas from the inlet manifold and replaces it with ZERO air. 3. When going from one CYL to the other. a) Unfortunately, this condition requires that both CYL ports are used and so a second port is not available for venting.
  • Page 42 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 06496A...

  • Page 43: Setting Up Ozone Generation

    Teledyne API Model 702 Precision Calibrator Instruction Manual 10 SETTING UP OZONE GENERATION The OZONE option adds an ozone generator, a glass reaction chamber and a second air flow control restrictor. NOTE When using NH gas, do not turn on the ozone at the same time the gas is flowing.

  • Page 44: T Oadjusta Preset Value

    Teledyne API Model 702 Precision Calibrator Instruction Manual 10.1 To Adjust A Preset Value 1. Press PRESET 1 button (or PRESET 2). 2. Press the UP or DOWN button until the desired concentration is shown in the display. 3. Wait 5 seconds for the new value to be stored.

  • Page 45: Setting Up Gpt

    Teledyne API Model 702 Precision Calibrator Instruction Manual 11 SETTING UP GPT This option includes the Ozone option (with glass reaction chamber). By setting the correct flows and concentrations of nitric oxide, ozone and diluent, the nitric oxide (NO) is stoichiometrically oxidized by ozone (O...
  • Page 46 [NO] = NO concentration in the reaction chamber [ppm] = [NO] cyl x (QNO / (QNO + QO )) ppm In the Model 702 Calibrator, the criteria are easy to maintain because the critical factors have been pre-calculated. 1. The reaction chamber volume is 136 cc.

  • Page 47: Set-Up

    Teledyne API Model 702 Precision Calibrator Instruction Manual 11.2 Set-Up GPT is generally used to calibrate NOx analyzers having a primary range of 500ppb (0.5 ppm). With this in mind, we suggest the following set-up. [NO] cyl = 50 ppm QNO = 20 ccm (CYL pressure approx.

  • Page 48: Converter Efficiency

    Teledyne API Model 702 Precision Calibrator Instruction Manual 11.3 Converter Efficiency These NO , NO and NO figures are predicated on a 100% efficient converter in the NO analyzer. Refer to the Teledyne API Model 200A NO ANALYZER instruction’s manual for determining converter efficiency.

  • Page 49: Troubleshooting

    Teledyne API Model 702 Precision Calibrator Instruction Manual 12 TROUBLESHOOTING Table 12-1: M702 Troubleshooting Problem Probable Cause Corrective Action Plug in power cord at both Unplugged power cord. ends. Refer to Table 3-1 for the Incorrect line voltage. Power light does not come correct line voltage.
  • Page 50 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 12-2 06496A...

  • Page 51: Maintenance

    Teledyne API Model 702 Precision Calibrator Instruction Manual 13 MAINTENANCE NOTE The operations outlined in this chapter are to be performed by qualified maintenance personnel only. CAUTION Do not loosen any tubing connection while pressure is applied to the M702.
  • Page 52 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 13-2 06496A...

  • Page 53: Expendables

    Teledyne API Model 702 Precision Calibrator Instruction Manual 14 EXPENDABLES The Model 702 does not require any expendables. 06496A 14-1...
  • Page 54 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 14-2 06496A...
  • Page 55 Teledyne API Model 702 Precision Calibrator Instruction Manual APPENDIX A Table A-1: Model 702 Check Out Sheet CHECK OUT SHEET MODEL 702 SERIAL NUMBER_________DATE______________BY_________________ LINE POWER? ___________________________( _____VAC/ ___ HZ) PROM # _______________________________________ APPEARANCE __________________________________ OK LEAK-CHECK __________________________________OK FANS RUNNING? _______________________________YES TEMPERATURES OVEN ______________________________________(48-50°C)
  • Page 56 Teledyne API Model 702 Precision Calibrator Instruction Manual Table A-2: Model 702 Electrical Schematics Part No. Name 01798 Assembly, keyboard/display PCA 01799 Diagram, keyboard/display PCA 02280 Assembly, Rear Panel 02281 Diagram, Rear Panel 0290100 M702 Standard Version-Interconnect Drawing 0290101 M702 03 Option Version-Interconnect Drawing...
  • Page 58 Error : LOGO.BMP File Not Found M702 KEYBOARD/DISPLAY A P P R O V A L S D A T E The information herein is the property of API and is submitted in strictest con- D R A W N ENG: ss fidence for reference only.
  • Page 60 AC_N A C _ L HTR_POWER POWER IN (SWPS) 2.49K C 4 4 T P 3 T P 2 T P 1 . 1 u F 4.7K 4.7K T P 7 T P 1 0 T P 1 1 VREF2.5 VREF5.0 U14B AC IN...
  • Page 61 NOTES: M702 STANDARD VERSION USE 100K FOR 220-240VAC USE 22AWG WIRE FOR 110VAC CYL 1, CYL 2, AND DIL ARE VALVES, PART NUMBER VA0000023 FRONT PANEL CABLE ASSY 01790 AC PWR SW/CB 11.5K 25W 1% RS0000152 SW0000025 CB/SW MOV PLUG 100K ASSY 02350 DUMMY LOAD...
  • Page 62 NOTES: M702 O3 OPTION VERSION ALUM BLOCK STANDARD VERSION USE 22AWG WIRE O3 OPTION VERSION USE 100K THERMISTOR O3 HEATER LAMP 00329 HE0000017 ASSY 00612-01 CYL 1, CYL 2, AND DIL ARE VALVES, PART NUMBER VA0000023 RED SHRINK TUBING HEATER ASSY 01996 (01) FRONT PANEL CABLE ASSY 01790 AC PWR SW/CB...
  • Page 63 Teledyne API Model 702 Precision Calibrator Instruction Manual APPENDIX B – M702 SPARE PARTS & EXPENDABLES NOTE Use of replacement parts other than those supplied by API may result in non-compliance with European standard EN 61010-1. • 02046 - List, Spare Parts, M702 •...
  • Page 64 Teledyne API Model 702 Precision Calibrator Instruction Manual THIS PAGE IS INTENTIONALLY LEFT BLANK 06496A...
  • Page 65 003290000 Thermistor Assembly (885-071600) 005940300 ASSY, OZONE GENERATOR, M702 006120200 ASSY, OZONE GEN LAMP w/PIGTAIL (BIR) 015090300 ASSY, O3 GEN LAMP POWER SUPPLY, M700/702 017980000 PCA, KEYBOARD/DISPLAY, M702 018490100 GAUGE, PRESSURE, 30 PSI, M702 018540000 Pressure Regulator, Zero Air, M702...
  • Page 66 005940300 ASSY, OZONE GENERATOR, M702 006120200 ASSY, OZONE GEN LAMP w/PIGTAIL (BIR) 015090300 ASSY, O3 GEN LAMP POWER SUPPLY, M700/702 019800301 ASSY, FLOW RESTRICTOR,1/4,B,3000CCM,M702 028240000 REACTION CHAMBER, GPT, M700, M702 (KB) Recommended Spare Parts List: With IZS, ZS Option Installed...
