  • Page 1 Operator’s Manual T3AWG6K Series Simple AFG Rev. 2.1.4 Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 2: Table Of Contents

    ERSION ELEASES ......................14 AFG A NSTALL IMPLE PPLICATION ........................14 INSTRUMENT OVERVIEW ..........................16 T3AWG6062 ..........................16 RONT ANEL T3AWG6064 ..........................17 RONT ANEL T3AWG6068 ..........................18 RONT ANEL Analog Outputs ............................... 19 Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 3 External Clock Input Connector ........................48 Sync Clock Output Connector ........................48 Digital Output connector ..........................48 Sync In / Sync Out Connectors ........................48 List and parameters of predefined waveforms ..................49 RUN MODE ................................ 52 Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 4 How to promote a waveform to a Predefined ..................78 How to edit a Waveform ..........................79 How to create a new Waveform ........................79 CHANNEL COUPLING ............................80 CALIBRATION AND DIAGNOSTIC ........................83 MULTI-INSTRUMENT SYSTEM ........................84 Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 5 OMPLIANCE HS C : ............................... 93 OMPLIANCE UKCA C ERTIFICATION ............................. 93 AUSTRALIA & NEW ZEALAND DECLARATION OF CONFORMITY – EMC ..........94 END-OF-LIFE HANDLING ........................... 94 CHINA R HS C ERTIFICATION ..........................95 Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 6: General Safety Summary

    This section contains information and warnings that must be observed to keep the instrument operating in a correct and safe condition. You are required to follow generally accepted safety procedures in addition to the safety precautions specified in this section. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 7: Safety Symbols

    The WARNING sign indicates a potential hazard. It calls attention to a procedure, practice or condition which, if not followed, could possibly cause bodily injury or death. If a WARNING is indicated, do not proceed until its conditions are fully understood and met. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 8: Package Contents

    Package Contents The standard T3AWG6K Series package includes the following: • T3AWG6062, T3AWG6064 or T3AWG6068 Arbitrary Waveform Generator equipment •...

  • Page 9: Recommended Options And Accessories T3Awg6068

    LVDS to SMA digital adapter cable T3AWG-RACKMOUNT-X Rack Mount Kit Mechanical Characteristics Model T3AWG6062-T3AWG6064-T3AWG6068 Net Weight 10.5 kg Net Weight with Package 11 kg Overall Dimensions Height: 135 mm Width: 445 mm Depth: 320 mm Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 10: Key Features

    The instrument is intended for indoor use and should be operated in a clean, dry, nonconductive environment. Occasionally a temporary conductivity that is caused by condensation must be expected. This location is a typical office/home environment. Temporary condensation occurs only when the product is out of service. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 11: Environmental Requirements

    Remove loose dust on the outside the instrument with a lint-free cloth. Use care to avoid scratching the front panel display. • Use a soft cloth dampened with water to clean the instrument. Use a 75% isopropyl alcohol solution as a cleaner. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 12: Calibration

    CAUTION. Do not short output pins or apply external voltages to Output connectors. The instrument may be damaged. CAUTION. Do not apply excessive inputs over ±15 Vpk to Trigger Input connector. The instrument may be damaged. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 13: Installing Your Instrument

    Protect Your Instrument from Misuse Check Input and Output Connectors When connecting a cable, be sure to distinguish the input connector from the output connectors to avoid making the wrong connection. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 14: Obtaining The Latest Version Releases

    If your instrument has already installed another version of the Simple AFG application, DO NOT uninstall it otherwise you will lose all the configurations and projects. 1. Download the Simple AFG setup package from Teledyne LeCroy website and decompress it to instrument’s local disk.
  • Page 15 2. Right click on the “Add-AppDevPackage” file and select Run with PowerShell to start the installation. 3. When the application has been installed, press the “Enter” button to continue. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 16: Instrument Overview

    Instrument Overview Front Panel T3AWG6062 Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 17: Front Panel T3Awg6064

    Front Panel T3AWG6064 Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 18: Front Panel T3Awg6068

    Front Panel T3AWG6068 The front panels of the T3AWG6K series models differ from that shown in the picture above because they have twice the SMA analog output connectors because each output channel has two complementary outputs (+ and -). The Touch screen functionalities and features are described in the Simple AFG Application paragraph.

  • Page 19: Analog Outputs

    Analog Outputs The T3AWG6K series instrument series has 2/4/8 analog output channels, each one is single-ended or differential (depending on the model) and the connector type is a standard SMA. Marker Outputs Each Marker Out is a digital output channel that can generate programmable digital patterns synchronous to the analog outputs.

  • Page 20: Soft Keyboard And Rotary Knob

    The → key will move the selected digit to the right and the  key will move the selected digit to left. You can keep pressed the rotating knob and rotate it on the right or on the left to change the Delta increment. Rotary Knob Rotary Push Button Digit Selection Arrows Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 21: Numeric Keypad

    After the sign and the numeric portion of the desired value have been entered, the pressing of the multiplier button applies the parameter. The Enter button closes the virtual keyboard and will apply the entered value. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 22 If both the two unit of measure of a Unit Measure Range button are available for the selected parameter (i.e. Mega and Micro), if you press the range button M/u, the range will switch accordingly between Mega and Micro. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 23: Rear Panel T3Awg6062

    1 Display 1.2 port • 1 PS/2 Mouse & Keyboard ports • 1 COM port 1 Digital Output Connector: Pod A • 4 USB 3.0 ports • 2 Gigabit LAN port • 3 Audio IN/OUT Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 24: Rear Panel T3Awg6064

    • 1 HDMI 1.4 port • 3 Audio IN/OUT • 1 VGA port • • 1 DVI-D port • 1 Display 1.2 port • 1 PS/2 Mouse & Keyboard ports • 1 COM port Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 25: Rear Panel T3Awg6068 The Callouts On This Image Gives The Description Of The Corresponding Connectors

    1 DVI-D port • 1 Sync Clock Output • 1 Display 1.2 port • 1 Sync OUT + 1 Sync IN Connectors • 1 PS/2 Mouse & • Keyboard ports • 1 COM port Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 26: External Modulation Input Connector

    External Modulation Input Connector The T3AWG6K series instrument has an input connector to receive an external analog signal that is used as modulating source. When the selected Run Mode is “Modulation” and the source is “External” the instrument will use this signal to modulate the carrier waveform.

  • Page 27: Introduction

    Simple AFG Software The T3AWG6K series instrument includes a 7” capacitive touch screen and an easy touch user interface based on a Microsoft Windows 10 platform. You can control instrument operations using one or all of the following entering methods: •...

  • Page 28: User Interface Description

    As mentioned, the display is 7” capacitive touch screen display and you can use the gestures like in a mobile phone: If you use the Swipe Up or Down gesture over the Command Bar Area you can switch between the adjacent channels. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 29: Waveform Parameters Area

    For example, if the Run Mode is Sweep the Secondary tab will take the title name “Sweep” and the tab page will show the Sweep parameters. The same will happen for Modulation and Burst modes. In Continuous Run Mode the Secondary tab is not active. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 30 2. Numeric Keypad: this area contains the keys to edit the number that will be displayed in the area 1. The [+/-] key will toggle the sign of the number being entered and can be pressed at the end of the number editing. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 31 7. The horizontal scrollbar allows to change quickly the selected value. The position specifies the value between the allowed minimum and the maximum. The increment/decrement value entered by the rotary knob or by the scrollbar are applied to the instrument on the fly. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 32: Graph Area

    Furthermore, you can decide to View only the channels that you want tapping on coloured buttons under the graph. Checking View Grid, you can view further horizontal e vertical line with other values of amplitude. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 33: Zoom Graph

    Zoom and will be show two buttons, “Reset” and “Back” in the command bar, these buttons permit you to come back the previous values or set the default value state of the waveform with zoom at 100%. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 34 Times Scale, but you must insert a time value. The range of the Samples Scale is 0 to 16384, while the Time Range depends of the values set on the Channel Data. 2. ALL CH: enable or disable the View All Channels. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 35 View Grid: if enabled, you can view further horizontal e vertical line with an others value of amplitude and Samples/Times. 4. Zoom Rect Area: if enabled, the multitouch and the translation left/right will be disabled, you can holding down and then release to select an area to Zoom. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 36 5. Cursor: enable this button if you want to see a cursor on the graph that visualize the values (Sample/Time and Amplitude) of the waveforms in the position set. 6. Info Buttons: tap to open a panel where they are indicated a lite description of the buttons just listed. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 37: Channel Information

    The command bar contains several touch buttons to control the instrument and its layout changes depending on the model (in the 4/8 channel models some buttons can be located in the More menu instead of in the Command Bar). Below a detailed description of this bar is provided. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 38 Numeric Keyboard Button – This button enables or disables the virtual numeric keyboard. Note: this button is in the More menu on the four/eight channel model. More Button –This button gives access to other instrument features. These buttons as explained in the following table. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 39 Waveform Editor – Use this button to open the Waveform Editor software. (For more information, please refer to the Waveform Editor User Manual). License button – Use this button to enter the License setup page. (For more information, please refer to the relative section). Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 40: Input / Output Channels

    Input / Output Channels The T3AWG6K series have 2/4/8 independent analog channels. Each channel is single-ended and it is available on a SMA connector located in the front instrument panel (CH1, Ch2, …, CHn output). The Marker Out is a digital output signal available on a SMA connector located in the front instrument panel (MARKER OUT 1, MARKER OUT 2, …, MARKER OUT n).
  • Page 41 Vmin is the minimum level of the waveform High Level [V] It defines the maximum level of the waveform expressed in Volts Low Level [V] It defines the minimum level of the waveform expressed in Volts Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 42 The amplitude and the offset can be represented in four different formats, as listed before, that can be selected by rotate the 3D cube as below: Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 43 This parameter defines the frequency or the period of the generated waveform. This parameter is available for all the functions except DC Level and Noise. In sweep run mode it is replaced by the Phase[deg] or Start Freq./Stop Freq. [Hz] parameters. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 44 Note: the values refer to the rise and fall time between the 10% and the 90% of the pulse amplitude. The 0% to 100% transitions will be longer than the set values anyway the graph represents the entered value as the 0% to 100% transition time. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 45 Note: Using the Pulse Waveform the following constraints must be met: ������������ �������� + �������������� �������� < ������������ ���������� ��������ℎ < ������������ Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 46: Auxiliary Channels

    Marker out (blue, top) synchronous with the analog signal (red, bottom) Trigger In The Trigger In 1 (SMA connector located on the front panel) allows to control the signal generation when a channel is in Burst Run Mode or in Sweep Run Mode. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 47: External Modulation Input Connector

    FSK, PSK: 0V÷3.3V with 1.65V fixed threshold Reference Clock Input Connector The T3AWG6K series instrument can use an external clock source to generate the sampling clock frequency. This feature allows to synchronize the generator with an external clock and the frequency range is 5 MHz to 500 Mhz.

  • Page 48: Reference Clock Output Connector

    Important Note: this connector is not used by AFG application. Sync In / Sync Out Connectors The purpose of those connectors is to connect and synchronize together multiple instruments: up to 4 instruments can be linked together. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 49: List And Parameters Of Predefined Waveforms

    The Continuous Run Mode has been omitted in the table because it is available for all waveforms. AM, FM, Waveform Parameters PM, PSK, Sweep Burst Sine Amplitude, Offset, √ √ √ Frequency, Phase Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 50 Sinc Amplitude, Offset, √ √ √ Frequency, Phase Noise Noise level (Amplitude), √ Offset DC Level Offset Gaussian Amplitude, Offset, √ √ √ Frequency, Phase Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 51 Note: Consult the instrument datasheet to find out the specifications of frequency range for each waveform. You can assign the “Arbitrary” waveform using the combo box highlighted in figure below (refer to “Waveform List” description paragraph): Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 52: Run Mode

    200ns. For example, in the picture below is represented the initial part of the generation of a sine wave with 50 deg of phase in continuous mode. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 53: Continuous

    Continuous In the Continuous mode when the Run/Stop button is pressed the waveform is reproduced continuously until the Run/Stop button is pressed again or Waveform / Run Mode is changed. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 54: Marker Out Behaviour In Continuous Run Mode

    Marker out frequency = Carrier frequency / 16 when: 770MHz < Carrier frequency <= 1GHz • Marker out frequency = Carrier frequency / 32 when: 1.54GHz < Carrier frequency <= 2 GHz. Marker out (blue, top) synchronous with the analog signal (red, bottom) in Automatic width mode Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 55: Modulation

    Touching the “Mod. Type” button the modulation type menu opens as shown in the picture below. With the button Hide Profile you can view and hide the waveform modulation profile on the graph The modulation types are: Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 56: Marker Out Behaviour In Modulation Run Mode

    If the modulating source is Internal, the Marker Out generates a square wave synchronous with the modulating waveform. The leading edge of this pulse is positioned at the beginning of the modulating waveform. If the modulating source is External, the Marker Out is disabled. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 57: Modulation General Parameter

    The parameter Freq. Deviation [Hz] defines the frequency deviation with respect to the carrier frequency. The Deviation is between 0 Hz and the maximum frequency that satisfies the following 2 relationships: �������������� ������������������ − ������������������ > 0 ���� Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 58 Where ε is a small margin to avoid that the duty cycle reaches the 0 % or the 100 % and the factor “0.8” takes into account that the edges are defined as 10-90%. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 59: Sweep

    Linear: the frequency increases and decreases linearly. • Logarithm: the frequency increases and decreases following a logarithmic function. • Upstair: the frequency varies step by step. The number of steps is selectable through the Step Number parameter. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 60: Parameters

    Rising Time, Holding Time and Falling time parameters. Marker out (blue, top) synchronous with the sweep (red, bottom) in Automatic width mode Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 61: Burst

    Burst Mode The burst mode allows to define the behaviour of the instrument after the Trigger reception. Touching the “Mode” button the following menu opens and it is possible to select the burst type. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 62 Note: if the Noise is selected as carrier and the channel is in 1-Cycle Burst or N-Cycles Burst mode, the Duration Burst [s] control will appear in Carrier Setting and the user can specify the duration of a single burst generation. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 63 In this case the user can set which voltage level will be generated between one burst and another: the carrier’s first or last sample. Exponential Rise Carrier, 1-Cycle Burst Mode, Wait Trigger On First Sample Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 64: Marker Out Behaviour In Burst Run Mode

    Burst Gated with Trigger from external Trigger In 1 Es.2: in the following picture the 1-Cycle Burst mode operation is shown. A sine wave carrier (frequency = 1Mhz) is generated using the internal timer (interval = 5 us). Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 65 Marker out (blue, top) synchronous with 1-Cycle Burst (red, bottom) Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 66: Channels And Device Setting

    This control allows you to invert the polarity of the output signal. High Limit [V] Sets the maximum voltage that the channel can generate. This limit is verified during the generation, but it doesn’t take into account the Baseline Offset or Vocm level. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 67: Settings Button

    Settings, Clock Settings, Trigger Settings and Marker Settings tab. Main Settings Tab Device Settings tab The Device settings page contains some parameters valid for the device. In this tab is present a UI setting: ON/OFF waiting time[s]. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 68 Channel button to turn the channel's output ON or OFF. The range of the ON/OFF Waiting Time is 0s to 2s. The default value is 200 ms. Usage Example: Turn ON the Channel 1 Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 69: Clock Settings Tab

    Trigger In to analog Out latency. When the Sync Clock Output is enabled the Sync Clock Out Freq control will appear, and the user can choose Sync Output clock frequency from a list of all the possible values. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 70: Trigger Settings Tab

    Timer: the Trigger is internally generated by a Timer. The Timer count interval is set by Interval [s] textbox. Trigger In 1: a Trigger event is generated by the signal applied externally to the Trigger In 1 SMA connector when it crosses the selected Threshold Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 71 Trigger Input signal. The Delay Adjust parameter specifies the delay applied to the Trigger Input signal. The range of the delay is 0ps to 2418ps. The resolution of the delay is 78ps. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 72: Marker Settings

    Allows the User to choose between Automatic Width mode (Marker out width is automatically adjusted by the AFG Software) and Manual Width mode (Marker Out width is fixed to User defined value). This parameter has effect only for not Triggered modes. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 73 Marker Out 2 can be linked to Channel 3 or Channel 4 • Marker Out 3 can be linked to Channel 5 or Channel 6 • Marker Out 4 can be linked to Channel 7 or Channel 8 Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 74: Main Command Button Description

    In the “Load From” page it is also possible to manage the configuration list: you can delete, import or lock a configuration. When a configuration is locked it can’t be deleted or overwrited. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 75 If you touch the Import Configuration button you can import the configuration file that comes from a different machine or from a different user. The imported configuration will be inserted in the “Load From” list. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 76: Remote Control

    SCPI server. It is enabled by default. Remote Desktop Connection The following credentials must be used when connecting to the instrument by a remote desktop connection: Computer Name: T3AWG6000 User Name: t3awg6000 Password: 1234 Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 77: Waveform List

    Waveform List page will open showing all the waveforms available in the current configuration. The T3AWG6K series contains by default a set of Factory Predefined Waveforms. The Predefined Waveforms are the ones in red color on the list, the imported waveforms are the ones in gray.

  • Page 78: How To Import A Waveform From A File

    Waveform list. Before saving a configuration it’s necessary to promote an imported waveform as Predefined if the user want to keep it in the Waveform List. • Select an imported waveform on the waveform list. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 79: How To Edit A Waveform

    Prerequisites: “Waveform Editor” software installed. • Press the button in the More… menu to launch the “Waveform Editor”. • Please refer to the “Waveform Editor” user manual for a complete explanation about editing and creating waveforms. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 80: Channel Coupling

    CH1 is a Sine waveform, because for this one the parameter doesn’t exist). The Channel Coupling section allows you to specify that Channel N parameter like frequency, amplitude, offset etc. is related to Channel 1 parameter by a ratio (multiplying) and an offset (adding). Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 81 Press the parameter checkbox to select/deselect the single coupling parameter. • When waveforms have different carrier shapes, only the common parameters will be available on this page. • Ratio or Offset auto limit their ranges in base of the linked parameter value set. Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 82 Channel 2 Carrier page will be disabled. On the contrary, the Channel 1 frequency parameter will be enabled and if the frequency is changed to 5 MHz then the channel 2 frequency will automatically change to 13.5MHz. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 83: Calibration And Diagnostic

    Load Factory button: touching this button will load the factory calibration parameters. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 84: Multi-Instrument System

    Then connect the Sync Out of the slave to the Sync In of the next slave device and so on up to the last slave device. Sync OUT and Sync IN connectors Master instrument Slave instrument Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 85 2. On the Master unit (the one with the Sync OUT port connected) will appear a new Master Multi-instrument bar: 3. On the Slave unit (the one with the Sync IN port connected) will appear a new Slave Multi- instrument bar: Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 86 7. Press Start on the Master device. Both the master and the slave instruments will start synchronously. A lock symbol on the start button of the captured instrument indicates that it is controlled by the master device: Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 87: Behavior Of A Multi-Instrument System

    After selecting the clock source and connecting the eventual external source on the master instrument, this will be propagated to all the other instruments in the • system to synchronize them with each other. • Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 88 Therefore it is necessary to connect the trigger source on the master (Trigger Inputs 1 SMA connectors) and set its • parameters (Threshold, Edge,…) on it. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 89: Master Multi-Instrument Bar

    It notifies that the master instrument has captured the slave devices, so it can control the execution of whole the instruments chain. By sliding the Release button, the master instrument will release the control of the connected slave devices. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 90: Slave Multi-Instrument Toolbar

    It notifies that another slave device has been found forward on the chain. It notifies that no other slave device have been found forward, so this instrument is the last one in the chain. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 91: License

    T3AWG6-16DIG: 16 channel digital license T3AWG6068 model: a. T3AWG6-8DIG: 8 channel digital license b. T3AWG6-16DIG: 16 channel digital license c. T3AWG6-32DIG: 32 channel digital license To get the licence key please contact your sales representative. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 92: Compliance Information

    EMC unprotected applications. This product is intended for use in nonresidential areas only. Use in residential areas may cause electromagnetic interference. To ensure compliance with all applicable EMC standards, use high- quality shielded interface cables. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 93: Rohs Compliance

    UK SI 2016 No. 1101 The Electrical Equipment (Safety) Regulations UK SI 2016 No. 1091 Electromagnetic Compatibility Regulations UK SI 2012 No. 3032 Restriction of the Use of Certain Hazardous and Substances in electrical and Electronic Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 94: Australia & New Zealand Declaration Of Conformity - Emc

    The instrument is subject to disposal and recycling regulations that vary by country and region. Many countries prohibit the disposal of waste electronic equipment in standard waste receptacles. For more information about proper disposal and recycling of your Teledyne LeCroy product, please visit teledynelecroy.com/recycle. Teledyne Confidential; Commercially Sensitive Business Data...

  • Page 95: China Rohs Certification

    多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr6+) (PBB) (PBDE) PCBAs 机械硬件 金属片 塑料部件 电缆组件 显示器 电源 风扇 电池 电源线 外部电源(如有) 探头(如有) 熔丝(如有) 产品外壳(如有) 适配器/模块(如有) 鼠标(如有) O: 表明该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11364-2014标准规定的限量要求之下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T11364-2014标准规定的限量要求。 EFUP (对环境友好的使用时间): 30年。 使用条件：参阅用户手册“环境条件”部分的规定。 探头EFUP: 10年。 Teledyne Confidential; Commercially Sensitive Business Data...
  • Page 96 SJ/T11364-2014. EFUP (Environmental Friendly Use Period): 30 years. Use Conditions: Refer to the environmental conditions stated in the User Manual. EFUP for Probes: 10 years. 936764 Rev2 Teledyne Confidential; Commercially Sensitive Business Data...
