Bypassing – Individual Zones
Bypassing is used to temporarily exclude one or more zones that would normally be protected.
For instance, a pet may need to be left in a part of the house that is usually protected.
If you wish to bypass one or more zones, this must be done while the system is in the
disarmed state. The following steps are used for bypassing zones. Once you have bypassed
the zone(s) you may arm the system via the On or Partial mode. When your security system
is disarmed, any zones that has been temporarily isolated or bypassed will be reset, and will
therefore be protected when the system is armed again.
To manually un-bypass zones, perform the bypassing procedure on a zone that is
already bypassed. The corresponding light for that zone will go off when un-bypassed.
Key Sequence
Group Bypass
By pressing the [Bypass] key, followed by the [0] [0] keys, then the [Bypass] key again, all
zones that are designated as group bypass zones will be bypassed. Now you can arm your
system in either the [On] or [Partial] mode. Once armed pressing the [Bypass] key again will
toggle the bypassed zones on and off.
Key Sequence
NX alarm system user's manual
Operation
This example shows a user
bypassing zones 4 and 5.
1. Press the [Bypass] key.
2. (Optional) Enter a user code.
(The bypass light flashes.)
3. Enter the 2-digit zone number/s
you wish to bypass.
(E.g. Press the [0] and the [4] keys for zone
4, [0] and the [5] keys for zone 5). The
corresponding light for that zone will turn on
when bypassed.
4. Press the [Bypass] key.
Operation
1. Press the [Bypass] key.
2. (Optional) Enter a user code.
(The Bypass light flashes.)
3. Press the [0]-[0] keys. The group
bypass zone lights will turn on
when bypassed.
4. Press the [Bypass] key again.
