Understanding the Code Pad Lights
Armed Light
The Armed light is lit when the alarm system is armed. The Armed light is 'off' when it is
disarmed. The Armed light will flash when there has been an alarm during the previous arm
cycle.
Bypass Light
The Bypass light is 'lit' when any zone in this code pad's area is bypassed. The zone(s) that
is bypassed will also be illuminated. If the Bypass light is 'off', no zones are bypassed.
Chime Light
The Chime light is 'lit' when the chime feature is on; the light is 'off' otherwise.
Exit Light
The Exit light is 'lit' during the exit delay. The Exit light will flash during the last 10 seconds of
the exit delay as a warning that the time is running out. (The user may want to restart the exit
delay if the Exit light is flashing in order to prevent an alarm. The user may then press the
[Exit] key to restart the exit delay before the delay expires.)
Fire Light
A steady Fire light means a fire zone has been faulted. A rapidly flashing Fire light means
that a fire zone is in a trouble condition.
On Light
The On light is 'lit' when the system is armed. The On light is 'off' when it is disarmed.
Partial Light
The Partial light is 'lit' when the system is armed in the Partial mode. All non bypassed zones
will be delayed and follow the partial delay time. When armed in Partial mode, the Arm, On,
and Bypass lights will also be 'lit'.
Power Light
The Power light is lit if the primary power is on. The Power light will flash if the system
detects a low battery condition.
Ready Light
The Ready light is 'lit' when the system is ready to arm and 'flashes' if ready to force arm.
The Ready light is off when the system is not ready to arm because of a zone(s) being
faulted.
Zone Light
The zone lights are 'off' when everything is normal. A zone light will be 'lit' if the zone has
been bypassed. If a zone light is 'flashing', that zone is in alarm or has been faulted. If a zone
light is 'flashing' rapidly, it means that the zone is in a trouble condition. Trouble conditions
are: Hardwire Zone Tamper, Wireless Zone Tamper, Sensor Low Battery and Sensor Loss of
Supervision
(A combination of Alarm/Fault and Tamper/Trouble will produce a rapid 'flashing' light for a
short period of time, followed by a slow 'flashing' light.)
NX alarm system user's manual
Page 3
