- Page 1 OWNER’S MANUAL THRU-THE-WALL AIR CONDITIONER MODELS 6PATW8000, 6PATW10000, 6PATW10002, 6PATW12000, 6PATW12002, 4PATW14002...
- Page 2 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. CONSUMER PRODUCT INFORMATION For your own records, please attach a copy of your sales receipt to this manual and complete the following: Model Number: _____________________________________ Serial Number: _______________________________________ Purchase Date: ____________________________________...
-
Page 3: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ..............1 IMPORTANT SAFETY INSTRUCTIONS ...........9 INSTALLATION INSTRUCTIONS .............10 NORMAL SOUNDS ................24 AIR CONDITIONER FEATURES ............24 CARE AND CLEANING ..............27 TROUBLESHOOTING ...............28 This manual provides the information needed for proper use and maintenance of this air conditioner. Basic preventative care can help extend the life of this unit. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS READ SAFETY PRECAUTIONS BEFORE INSTALLATION To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. THIS SYMBOL INDICATES THAT IGNORING INSTRUCTIONS MAY CAUSE DEATH OR SERIOUS INJURY. THIS SYMBOL INDICATES THAT IGNORING INSTRUCTIONS MAY CAUSE MODERATE INJURY TO YOUR PERSON, OR DAMAGE TO YOUR UNIT OR OTHER PROPERTY. - Page 5 CAUTIONS When removing air filter, DO NOT touch metal parts of Doing so may cause an injury. the unit. DO NOT clean with water. Water may enter the unit and degrade the insulation causing an electric shock. Ensure proper ventilation especially in rooms with a Failure to do so may result in an oxygen shortage. ...
- Page 6 Electronic Work WARNING: BEFORE PERFORMING ANY ELECTRICAL OR WIRING WORK, TURN OFF THE MAIN POWER TO THE SYSTEM. NOTE: The cographs are for explanation purpose only. DISPLAY Your machine may be slightly different. The actual shape shall prevail. POWER MAIN SUPPLY CONTROL CORD...
- Page 7 WARNING - Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants. - DO NOT modify the length of the power cord or use an extension cord to power the unit.
- Page 8 WARNING 4)Checking for presence of refrigerant The area shall be checked with an appropriate refrigerating detector prior to and during work, to ensure the technician is aware of potentially flammable atmospheres. Ensure that the leak detection equipment being used is suitable for use with flammable refrigerants, i.e. non-sparking, adequately sealed or intrinsically safe.
- Page 9 WARNING 7.Sealed electrical components shall be replaced. 1)During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.
- Page 10 WARNING For appliances containing flammable refrigerants, refrigerants purging shall be achieved by breaking the vacuum in the system with oxygen-free nitrogen and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum (optional for A2L). This process shall be repeated until no refrigerant is within the system (optional for A2L).
- Page 11 WARNING 15.Recovery When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge is available.
-
Page 12: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING NOTE : FOR YOUR SAFETY: Do not store or use gasoline or other flammable The power supply cord with this air vapors and liquids in the vicinity of this or any other appliances. conditioner contains a current detection device designed to reduce the risk of fire. Please refer to the section WARNING - PREVENT ACCIDENTS “Operation of Current Device” (below) for details. In the event that the power To reduce the risk of fire, electrical shock, or injury to persons when using supply cord is damaged, it cannot be your air conditioner, follow basic precautions, including the following: repaired. -
Page 13: Installation Instructions
INSTALLATION INSTRUCTIONS DO THIS FIRST ITEMS IN KIT (FOR EXISTING SLEEVE) Note that the air conditioner dimensions are: You may not need all parts listed in this kit. DO NOT discard unused parts. 24.25 inches wide, 14.5 inches high, and 18.5 inches deep (without front). Install air conditioner according to these installation HARDWARE instructions to achieve the best performance. Save (Included - Packed with the Unit) these installation instructions for future reference. -
Page 14: How To Install
STEP 1: IDENTIFY WALL-SLEEVE BRAND Identify the wall-sleeve brand for your installation from the chart below. WALL SLEEVE DIMENSIONS BRAND WIDTH HEIGHT DEPTH PERFECT AIRE, Frigidaire, White- 25½" 15¼" 16", 17½", or 22" Westinghouse, Carrier (52F Series) NOTE: Please verify General Electric, Hotpoint 26"... - Page 15 STEP 4: PREPARE THE WALL SLEEVE Prepare the wall sleeve for installation of the new unit per the following brand instructions. BRAND DEPTH PAGE PERFECT AIRE, Frigidaire, White- 16" & 17½" Westinghouse, Carrier (52F Series) Fedders 19¾” Fedders or Friedrich 16¾” General Electric/Hotpoint 16⅞" Sears or Carrier (51S Series) 18⅝"...
- Page 16 WALL SLEEVE BRANDS: #1 PERFECT AIRE, WHITE WESTINGHOUSE, FRIGIDAIRE, CARRIER 52F SERIES REAR LOUVERS 16 IN. & 17½ IN. DEEP 4.5ʺ 4ʺ 1. Remove existing rear grille and replace with provided 80°80° 80° 30° 30° 80° louvered panel. Install as shown here.
- Page 17 WALL SLEEVE BRANDS: #2 FEDDERS 19¾ IN. DEEP 1. Remove existing rear grille and replace with provided REAR LOUVERS louvered panel. Install as shown here. 4.5ʺ 4ʺ NOTE: You may need to drill holes in flange of existing 80°80° 80° 30° 30° 80° sleeve to match new rear grille. 2. Attach (2) 4¼ʺ x 3½ʺ x 1½ʺ centering/support blocks, one on each side wall.
- Page 18 WALL SLEEVE BRANDS: #3 FEDDERS OR FRIEDRICH 16¾ IN. DEEP 1. Remove existing rear grille and replace with provided REAR LOUVERS louvered panel. Install as shown here. 4.5ʺ 4ʺ NOTE: You may need to drill holes in flange of existing 80°80° 80° 30° 30° 80° sleeve to match new rear grille. 2. Attach (2) 4¼ʺ...
- Page 19 WALL SLEEVE BRANDS: #4 GENERAL ELECTRIC OR HOTPOINT 16 7 /8 IN. DEEP REAR LOUVERS 1. Remove existing rear grille and replace with provided 4.5ʺ 4ʺ louvered panel. Install as shown here. 80°80° 80° 30° 30° 80° NOTE: You may need to drill holes in flange of existing sleeve to match new rear grille. 2. Cut the (2) 17ʺ Tapered Spacer Blocks as shown below into two pieces.
- Page 20 WALL SLEEVE BRANDS: #5 SEARS OR CARRIER 51S SERIES 18 5 /8 IN. DEEP 1. Remove existing rear grille and replace with provided REAR LOUVERS louvered panel. Install as shown here. 4.5ʺ 4ʺ NOTE: You may need to drill holes in flange of existing 80°80° 80° 30° 30° 80° sleeve to match new rear grille. 2. Install (2) Tapered Spacer Blocks to the floor of the sleeve as shown. DO NOT CUT THE BLOCKS. This helps induce a rearward slope on the unit.
- Page 21 WALL SLEEVE BRANDS: #6 WHIRLPOOL 17 1 /8 IN. DEEP 1. Remove existing rear grille and replace with provided REAR LOUVERS louvered panel. Install as shown here. 4.5ʺ 4ʺ NOTE: You may need to drill holes in flange of existing 80°80° 80° 30° 30° 80° sleeve to match new rear grille. 2. Cut (2) 17ʺ Tapered Spacer Blocks as shown below into two pieces.
- Page 22 WALL SLEEVE BRANDS: #7 WHIRLPOOL 23 IN. DEEP 1. Remove existing rear grille and replace with provided REAR LOUVERS louvered panel. Install as shown here. NOTE: You may need to drill holes in flange of existing 4.5ʺ 4ʺ 80°80° 80° 30° 30° 80° sleeve to match new rear grille. BECAUSE OF THE INCREASED UNIT DEPTH, FIRST TRY DRY FITTING USING METHODS DESCRIBED BELOW: 2. Place (2) 1ʺ...
- Page 23 WALL SLEEVE BRANDS: #8 EMERSON 15 IN. DEEP 1. Remove existing rear grille and replace with provided REAR LOUVERS louvered panel. Install as shown here. 4.5ʺ 4ʺ NOTE: You may need to drill holes in flange of existing 80°80° 80° 30° 30° 80° sleeve to match new rear grille. 2. Attach (1) 1ʺ x ⅜ʺ x 25ʺ long seal in the center at the top of the sleeve. Remove the backing paper and press into position.
- Page 24 WALL SLEEVE BRANDS: #9 WHITE WESTINGHOUSE, FRIGIDAIRE 22 IN. DEEP REAR LOUVERS 1. Remove existing rear grille as shown and replace with 4.5ʺ 4ʺ provided louvered panel. Install as shown here. 80°80° 80° 30° 30° 80° NOTE: You may need to drill holes in flange of existing sleeve to match new rear grille. BECAUSE OF THE INCREASED UNIT DEPTH, FIRST TRY DRY FITTING USING METHODS DESCRIBED BELOW: TOP VIEW...
-
Page 25: Direct Unit Mounting
DIRECT UNIT MOUNTING The previous directions are the preferable way to mount the new rear grille. The unit’s performance is slightly better and the possibility of drafts is reduced. As a last resort, direct mounting of the grille to the unit can be considered. NOTE: The grille must be installed prior to inserting the unit into the sleeve. - Page 26 1. Install the 1ʺ x 1½ʺ x 84ʺ long stuffer-seal between the wall sleeve and the unit. A flat bladed screwdriver or putty knife is recommended. 2. Assemble the trim frame by inserting top and bottom pieces into side pieces and snapping into place. 3. Pull cord through trim frame, then slide in unit until flush with wall.
-
Page 27: Normal Sounds
Auto Auto Cool Basse Frais TEMP/TIMER Moyenne Sécher TEMP/MINUTERIE High Haute Ventilateur Follow Me On/Marche O /Arrêt Suivez-Moi Mode Fan/Ventilateur Timer/Minuterie Sleep/Sommeil Check Filter Energy Saver Contrôle Du Filtre Économie D'énergie... - Page 28 SLEEP FEATURE: TO SELECT THE OPERATING MODE: Press the SLEEP button to initiate the SLEEP To choose operating mode, press the MODE mode. In this mode, the selected temperature will button. Each time you press the button, a mode is increase by 2°F (1°C) 30 minutes after the mode selected in a sequence that goes from AUTO, COOL, is selected.
- Page 29 DISPLAY: ADDITIONAL THINGS YOU SHOULD KNOW: Shows the set temperature in °F or °C and the Auto- timer settings. While on FAN only mode, it shows the ● The Cool circuit has an automatic 3 minute room temperature. time-delayed start if the unit is turned off and on quickly. After unit is turned off, leave the unit off Display for a minimum of 3 minutes before attempting to turn back on. This prevents overheating of the compressor and possible circuit breaker tripping.
-
Page 30: Care And Cleaning
CARE AND CLEANING CAUTION Clean air conditioner occasionally to keep it looking and operating like new. Be sure to unplug the unit before cleaning to prevent shock or fire hazards. AIR FILTER CLEANING The air filter should be cleaned at least every two weeks or as Left filter Right filter necessary. Trapped particles in the filter can build up and cause an accumulation of frost on the cooling coils. ● There are two filters on the front of the unit (Left and Right). Grasp each filter by the center and pull up and out. ● Wash the filters using liquid dishwashing detergent and warm water. Rinse filters thoroughly. -
Page 31: Troubleshooting
TROUBLESHOOTING BEFORE CALLING FOR SERVICE, PLEASE REVIEW THE CHART BELOW ISSUE POSSIBLE CAUSES • Be sure unit is not too large or too small for the area of the room. • Verify that all doors, windows, curtains and any other openings are closed. Verify nothing is obstructing the front grille of unit, such as curtains, etc. • Allow enough time for room to cool, especially if outside temp is very high. • Check that the filter is not dirty and louvers are open all the way and blowing in the desired direction. AIR CONDITIONER NOT • Check that unit is set to COOL mode and that temperature is down enough (but COOLING ROOM, OR NOT BLOWING not too low). - Page 32 LEAVE A REVIEW THANK YOU FOR YOUR PURCHASE! As a small business, reviews are everything! We’d love to hear how you are enjoying your Perfect Aire product! Please take a minute to tell us (and others) about your experience. Thanks (again!)
