Enerzone EB00053 Installation And Operation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Installation
and Operation
Manual
SOLUTION 3.5
(EB00053 model)
US Environmental Protection Agency
phase II certified wood stove compliant
with 2020 cord wood standard
Safety tested according to ULC S627,
UL 1482 and UL 737 standards by an
accredited laboratory.
MOBILE
HOME
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN
LOCAL AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD STOVE. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
46110A

Advertisement

loading
Need help?

Need help?

Do you have a question about the EB00053 and is the answer not in the manual?

Questions and answers

Related Manuals for Enerzone EB00053

Summary of Contents for Enerzone EB00053

  • Page 1 Installation and Operation Manual SOLUTION 3.5 (EB00053 model) US Environmental Protection Agency phase II certified wood stove compliant with 2020 cord wood standard Safety tested according to ULC S627, UL 1482 and UL 737 standards by an accredited laboratory. MOBILE...
  • Page 3 It is also highly recommended to register the warranty online at https://www.enerzone-intl.com/en/warranty/warranty-registration/ Registering the warranty will help to quickly find the information needed on the unit.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS PART A - OPERATION AND MAINTENANCE ................7 1. Safety Information ........................7 2. General Information ........................ 8 2.1 Performances ........................8 2.2 Specifications ........................9 2.3 Dimensions ........................10 2.4 EPA Certification Loading ....................12 2.5 Materials ...........................14 2.6 Zone Heating ........................14 2.7 Emissions and Efficiency ....................15 3.
  • Page 5 Appendix 7: Air Tubes and Baffle Installation ................50 Appendix 8: Removing the Decorative Panels ................. 52 Appendix 9: Log retainers installation ..................53 Appendix 10: Exploded Diagram and Parts List ..............54 ENERZONE Limited Lifetime Warranty ..................57 Dealer: Installer: Phone Number: Serial Number: Installation and Operation Manual - Solution 3.5...

  • Page 6: Certification Plate

    CERTIFICATION PLATE Page 6 Installation and Operation Manual - Solution 3.5...

  • Page 7: Part A - Operation And Maintenance

    PART A - OPERATION AND MAINTENANCE 1. Safety Information • This stove has been tested for use with an open door in conjunction with a fire screen, sold separately. The door may be opened, or fire screen removed only during lighting procedures or reloading.

  • Page 8: General Information

    2. General Information Performances Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output. Model SOLUTION 3.5 (EB00053) Fuel Type Dry Cordwood Combustion Technology Non-Catalytic Recommended heating area (sq. ft.

  • Page 9: Specifications

    Specifications Recommended log length 16 in (406 mm) east-west Maximum log length 22 in (560 mm) east-west Flue outlet diameter 6 in (150 mm) Recommended connector pipe diameter 6 in (150 mm) Type of chimney ULC S629, UL 103 HT (2100 °F) Minimum chimney height 12 feet Baffle material...

  • Page 10: Dimensions

    Dimensions 2.3.1 Dimensions with pedestal 28 1/8" 714mm 14 1/8" 357mm 6" Ø 153mm Figure 1: Top View 33 1/2" 852mm 24 1/8" 612mm 12 1/2" 318mm 18 3/4" 476mm 22 5/8" 21 5/8" 576mm 550mm Figure 2: Front View Figure 3: Side View Page 10 Installation and Operation Manual - Solution 3.5...

  • Page 11: Combustion Chamber Dimensions

    2.3.2 Combustion Chamber Dimensions 9 7/8" 249mm 19" 483mm Figure 4: Door Opening 3/16" 3/8" 10mm 12 7/8" 326mm 22 7/8" 581mm 20 1/8" 510mm Figure 5: Front View - Combustion Chamber Figure 6: Side View - Combustion Chamber Installation and Operation Manual - Solution 3.5 Page 11...

  • Page 12: Epa Certification Loading

    EPA Certification Loading For EPA Certification testing, wood logs were 16 ± 1 inches long and the specie used was beech. 2.4.1 Air control The air control is located underneath the ash shelf. To open the air control, push the air control handle completely to the left (High).
  • Page 13 2.4.4 Logs placement The images below show how to place the logs in the combustion chamber as described previously. SECTION E SECTION E-E Installation and Operation Manual - Solution 3.5 Page 13...

  • Page 14: Materials

    Materials The body of this stove, which is most of its weight, is carbon steel. Should it ever become necessary many years in the future, almost the entire stove can be recycled into new products, thus eliminating the need to mine new materials. The paint coating on the stove is very thin.

  • Page 15: Emissions And Efficiency

    Emissions and Efficiency The low smoke emissions produced by the special features inside this stove firebox mean that the household will release up to 90% less smoke into the outside environment than if an older conventional stove was used. But there is more to the emission control technologies than protecting the environment.

  • Page 16: Log Length

    Harder woods are best for colder winter weather when more heat and longer burn cycles are desirable. Hardwood trees like oak, maple, ash and beech are slower growing and longer lived than softer woods like poplar and birch. That makes hardwood trees more valuable. The advice that only hardwoods are good to burn is outdated.

  • Page 17: Operating The Stove

    Here are some facts to consider in estimating drying time: − Firewood bought from a dealer is rarely dry enough to burn, so it is advisable to buy the wood in spring and dry it yourself; − Drying happens faster in dry weather than in a damp climate;...

  • Page 18: The Use Of A Fire Screen

    The Use of a Fire Screen In the United States or in provinces with a particulate emission limit (eg. US EPA), the use of wood stoves with the door open with a rigid firescreen is prohibited. This stove has been tested for use with an open door in conjunction with a fire screen, sold separately.

  • Page 19: Burning Wood Efficiently

    5. Burning Wood Efficiently First Use Two things happen when burning the first few fires; the paint cures and the internal components are conditioned. As the paint cures, some of the chemicals vaporize. The vapors are not poisonous, but they smell bad. Fresh paint fumes can also trigger false alarms in smoke detectors. When lighting the heater for the first few times, it may be wise to open doors and windows to ventilate the house.

  • Page 20: Combustion Cycles

    is burning. The best is to wrap a sheet on itself, grab the ends of the roll and make a knot. Use four or five sheets of paper tied together and put them on top and around the kindling. Open the air intake control completely, ignite the paper and close the door.

  • Page 21: Rekindling A Fire

    Burning in cycles means the loading door does not need to be opened while the wood is flaming. This is an advantage since it is preventing smoke leaking from the heater when the door is opened as a full fire is burning. This is especially true if the chimney is on the outside wall of the house.

  • Page 22: Air Intake Control

    Ashes should be placed in a tightly covered metal container. The container must be placed on a non-combustible floor or on the ground well away from all combustible materials. Ashes almost always contain live embers that can stay hot for days and which release carbon monoxide gas.
  • Page 23 5.7.2 Long Lasting Fire For a fire that will last up to eight hours, use the following guidance. Make sure there is a good coal bed of 1.5 to 2 inches thick with dark red embers. For the loading, put 2 logs at the back, 2 in the center and 2 in the front. All of them in an East-West orientation.

  • Page 24: Maintenance

    A longer burning time is not necessarily an indication of efficient operation. It is preferable to build a smaller fire that will provide three or four hours of heating than to fully load the firebox for a much longer burn. Shorter burn cycles make it easier to match the heat output of the stove to heat demand for space.

  • Page 25: Glass Door

    Glass Door 6.3.1 Cleaning Under normal conditions, the door glass should stay relatively clear. If the firewood is dry enough and the operating instructions in this manual are followed, a whitish, dusty deposit will form on the inner surface of the glass after a week or so of use. This is normal and can be easily removed when the heater is cold by wiping with a damp cloth or paper towel and then drying.

  • Page 26: Door

    6.3.3 Gasket The glass gasket is flat, adhesive-backed, woven fibreglass. The gasket must be centred on the edge of the glass. Follow the steps of the previous section to remove the glass. Remove the old gasket and clean the glass thoroughly. Peel back a section of the paper covering the adhesive and place the gasket on a table with the adhesive side up.

  • Page 27: Exhaust System

    6.4.2 Gasket It is important to replace the gasket with another having the same diameter and density to maintain a good seal. Remove the door and place it face-down on something soft like a cushion of rags or a piece of carpet. Remove the old gasket from the door.
  • Page 28 Establish a routine for the fuel, wood burner and firing technique. Check daily for creosote build-up until experience shows how often you need to clean to be safe. Be aware that the hotter the fire the less creosote is deposited, and weekly cleaning may be necessary in mild weather even though monthly cleaning may be enough in the coldest months.

  • Page 29: Part B - Installation

    PART B - INSTALLATION 7. Safety Information and Standards • The information given on the certification label affixed to the appliance always overrides the information published, in any other media (owner’s manual, catalogues, flyers, magazines and web sites). • Mixing of appliance components from different sources or modifying components may result in hazardous conditions.

  • Page 30: Location Of The Certification Label

    Location of the Certification Label The information given on the certification label always overrides the information published in any other media (owner’s manual, catalogues, flyers, magazines and web sites). It is important to refer to it in order to have a safe and compliant installation. Important information about the stove can also be found (model, serial number, etc.).
  • Page 31 84" (L) 213 cm 48" 36" 122 cm 92 cm Figure 10: Clearances - Top Figure 9: Clearances - Side Figure 11: Clearances - Corner Installation and Operation Manual - Solution 3.5 Page 31...

  • Page 32: Clearances

    Clearances APPLIANCE CLEARANCES WITH SINGLE APPLIANCE CLEARANCES WITH DOUBLE WALL PIPE CONNECTOR WALL PIPE CONNECTOR Canada Canada 13 ¼" (337 mm) 13" (330 mm) 7" (178 mm) 7" (178 mm) 14" (356 mm) 14" (356 mm) 14" (356 mm) 14" (356 mm) 7 ¼"...
  • Page 33 8.1.2 With Airmate APPLIANCE CLEARANCES WITH DOUBLE DISTANCES FROM DOUBLE WALL PIPE WALL PIPE CONNECTOR CONNECTOR Canada Canada 6" (152 mm) 6" (152 mm) 10 ¾" (273 mm) 10 ¾" (273 mm) 14" (356 mm) 14" (356 mm) 24 ⅞" (632 mm) 24 ⅞"...

  • Page 34: Mobile Home

    8.1.5 Inside an Alcove APPLIANCE CLEARANCES WITH DOUBLE DISTANCES FROM PIPE CONNECTOR WALL PIPE CONNECTOR WITH DOUBLE WALL PIPE CONNECTOR Canada Canada 11" (279 mm) 11" (279 mm) 15 ¾" (400 mm) 15 ¾" (400 mm) 16" (406 mm) 16" (406 mm) 26 ⅞"...
  • Page 35 8.1.8 Mobile Home With Heat Shield AC02710 or AC02762 It is strictly forbidden to install a unit with a single wall pipe in a mobile home. APPLIANCE CLEARANCES WITH DOUBLE DISTANCES FROM PIPE CONNECTOR WALL PIPE CONNECTOR WITH DOUBLE WALL PIPE CONNECTOR Canada Canada 3"...

  • Page 36: Floor Protection

    Floor Protection This stove is designed to prevent the floor from overheating. However, it must be placed on a non-flammable surface to protect the floor from hot embers that may fall during loading. The floor protection must be a continuous, non combustible material, such as steel with a minimum thickness of 0.015"...

  • Page 37: Reducing Clearances Safely

    Reducing Clearances Safely It is often desired to use as little space as possible when installing a wood stove. To do this, it is possible to reduce the clearances safely and install the stove closer to the walls by permanently installing a heat shield between the stove and the flammable material.
  • Page 38 Page 38 Installation and Operation Manual - Solution 3.5...
  • Page 39 8.3.2 Type of shield CLEARANCES MAY BE REDUCED BY THESE PERCENTAGES SIDES, CORNER TOP (CEILING) TYPE OF SHIELD AND REAR CAN / CAN / USA (%) MIN. USA (%) MIN. Sheet metal, a minimum of 24 gauge (0.61 mm) in thickness , spaced out at least 1" (25 mm)* by non-combustible spacers 12"...

  • Page 40: The Venting System

    9. The Venting System The venting system, made of the chimney and the connecting pipe between the stove and the chimney, acts as the engine that drives the wood heating system. Even the best stove will not function safely and efficiently if it is not connected to a suitable chimney. The heat in the flue gases that pass from the stove and chimney connector into the chimney is not waste heat.
  • Page 41 9.1.2 Factory-Built Metal Chimney in Mobile Home For use in a mobile home, this stove is to be connected to a 6" (150 mm) double wall factory built chimney pipe conforming to ULC-S629 or UL 103 HT standards for 650°C Factory-built chimney. The total length of the flue system should be at least 12' (3,6 m)including elbows, from the top of the stove.

  • Page 42: Minimum Chimney Height

    Minimum Chimney Height The top of the chimney should be tall enough to be above the air turbulence caused when wind blows against the house and its roof. The chimney must extend at least 3 ft. (1 m) above the highest point of contact with the roof, and at least 2 ft.

  • Page 43: Supply Of Combustion Air

    Supply of Combustion Air 9.4.1 Mobile Home This stove is approved to be installed in a mobile home. It must therefore have a supply of combustion air from outdoors. The air intake must not draw air from the attic, from the basement, from a garage or any enclosed space.

  • Page 44: Chimney Connector

    To reduce the risks against smoke spillage due to house depressurization, a carbon monoxide (CO) and a smoke detector is required in the room where the stove is installed. The CO detector will provide warning if for any reason the wood stove fails to function correctly. Chimney Connector The chimney connector is the single or double wall pipe installed between the stove flue collar and the chimney breech.
  • Page 45 • Minimum clearance from combustible material: 18" (450 mm). The minimum clearance may be reduced by 50%, to 9" (225 mm) if proper heat shield is installed either on the pipe or on the combustible surface. • The assembly should be as short and direct as possible between the stove and chimney. The use of two 45o elbows is preferable to a single 90o elbow.

  • Page 46: Appendix 1: Blower Installation

    APPENDIx 1: BLOWER INSTALLATION Remove the backplate by cutting the knockouts with pliers. MICRO-JOINT KNOCK-OUT Screw the blower (A) in place using the screws (B) included in the installation manual. Ensure that the blower’s power cord is not in contact with any surface of the stove to prevent electrical shock or fire damage.

  • Page 47: Appendix 2: Thermodisc Installation

    APPENDIx 2: THERMODISC INSTALLATION It allows the fan to operate only when the stove is hot enough. See the instructions provided with the thermodisc for more details. Screw the thermodisc (C) with the screws (D) provided on the back of the stove. The electrical cord of the thermodisc should not touch any surface of the stove to avoid electric shock or fire.

  • Page 48: Appendix 3: Optional Airmate Installation

    APPENDIx 3: OPTIONAL AIRMATE INSTALLATION Remove the deflector (A) and keep the screws (B). Install and fix the black pipe connector. Install the airmate (C) with the screws kept from the previous step (B). Page 48 Installation and Operation Manual - Solution 3.5...

  • Page 49: Appendix 4: Optional Fresh Air Intake Kit Installation

    APPENDIx 4: OPTIONAL FRESH AIR INTAKE KIT INSTALLATION This mobile home approved stove requires the installation of a fresh air intake kit (A) and an insulated fresh air intake pipe (HVAC type, must meet ULC S110 or UL 181 class 0 or class 1) (B), sold separately.

  • Page 50: Appendix 5: Optional Fire Screen Installation

    APPENDIx 5: OPTIONAL FIRE SCREEN INSTALLATION In the United States or in provinces with a particulate emission limit (eg. US EPA), the use of wood stoves with the door open with a rigid firescreen is prohibited. Open the door. Hold the fire screen by the two handles and bring it close to the door opening.

  • Page 51: Appendix 6: Mobile Home Installation

    APPENDIx 6: MOBILE HOME INSTALLATION Screw the base on the floor with the proper hardware. Installation and Operation Manual - Solution 3.5 Page 51...

  • Page 52: Appendix 7: Air Tubes And Baffle Installation

    APPENDIx 7: AIR TUBES AND BAFFLE INSTALLATION Starting with the rear tube, lean and insert the right end of the secondary air tube into the rear right channel hole. Then lift and insert the left end of the tube into the rear left channel. Align the notch in the left end of the tube with the key of the left air channel hole.
  • Page 53 Note that secondary air tubes (A) can be replaced without removing the baffle board (B) and that all tubes are identical. Installation and Operation Manual - Solution 3.5 Page 53...

  • Page 54: Appendix 8: Removing The Decorative Panels

    APPENDIx 8: REMOVING THE DECORATIVE PANELS To remove the decorative panels (A), remove the screws (B) and push forward on the panel to unhook it from the support (C). Page 54 Installation and Operation Manual - Solution 3.5...

  • Page 55: Appendix 9: Log Retainers Installation

    APPENDIx 9: LOG RETAINERS INSTALLATION 2" 2" Installation and Operation Manual - Solution 3.5 Page 55...

  • Page 56: Appendix 10: Exploded Diagram And Parts List

    APPENDIx 10: ExPLODED DIAGRAM AND PARTS LIST Page 56 Installation and Operation Manual - Solution 3.5...
  • Page 57 IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your unit, please provide the model number and the serial number. We reserve the right to change parts due to technology upgrades or availability. Contact an authorized dealer to obtain any of these parts.
  • Page 58 Item Description PL36758 REFRACTORY BRICK 3 1/4" X 4 1/2" X 1 1/4" PL70864 SECONDARY AIR TUBE 21565 C-CAST 3.5 SERIE BAFFLE AC01234 AIRMATE AC02055 QUICK CONNECT THERMODISC KIT 44028 CERAMIC THERMODISC F110-20F PL05530-02 THERMODISC BOX (COVER) 60013 POWER CORD 96" X 18-3 type SJT (50 pcs per carton) SE53560 130 CFM BLOWER WITH VARIABLE SPEED CONTROL 44070...

  • Page 59: Enerzone Limited Lifetime Warranty

    Labour cost and repair work to the account of the manufacturer are based on a predetermined rate schedule and must not exceed the wholesale price of the replacement part. Shall your unit or a components be defective, contact immediately your ENERZONE dealer. To accelerate processing of your warranty claim, make sure to have on hand the following information when calling:...
  • Page 60 NOTES :...
  • Page 61 Resale is strictly prohibited. The manufacturer may update St-Augustin-de-Desmaures (Québec), Canada this document from time to time and cannot be responsible G3A 2H3 for problems, injuries, or damages arising out of the use 1-877-356-6663 of information contained in any document obtained from https://www.enerzone-intl.com/en/ unauthorized sources. tech@sbi-international.com...
