NovaLCT Operations
The MCTRL700 Pro offers a comprehensive upgrade from the traditional MCTRL series controllers. This
document outlines the key differences when used with NovaLCT (version 5.7.0 or later). For more detailed
information on screen configuration, brightness adjustment, calibration, display control, monitoring, and
other functions, please refer to the
Manual
.
Free Layout
When configuring LED screens with the MCTRL700 Pro, there are no rectangle restrictions for irregularly
shaped screens. This means that any blank areas are not included in the load capacity calculation. The load
capacity used by Ethernet ports is determined by the total number of pixels from all connected cabinets.
Figure 3-1 Traditional load calculation / Free layout
IP Settings
The MCTRL700 Pro allows you to set its IP address using NovaLCT. You can also reset it to the factory
default IP by pressing the reset button.
Step 1 On the menu bar, choose User > Advanced Synchronous System User Login. Enter the password and click
Login.
The default password is "admin".
Step 2 Choose Tools > Device Communication.
