NovaStar MCTRL700 Pro Quick Start Manual page 5

Note
The default IP address for the MCTRL700 Pro is 192.168.0.10. Make sure not to use this address when
configuring the computer's IP.
Step 6 Run NovaLCT and click View Details of Device to confirm that the MCTRL700 Pro is connected.
Figure 2-2 Viewing details of device
Cascading Multiple Controllers
To control multiple MCTRL700 Pro controllers simultaneously, follow the figure below to cascade them via
the ETHERNET ports. Up to 20 controllers can be cascaded. Additionally, ensure that the IP addresses of all
cascaded devices are set within the same network segment but are not identical. For detailed instructions,
please refer to 3.2
Figure 2-3 Cascading devices
www.novastar.tech
IP Settings.
MCTRL700 Pro LED Display Controller
Quick Start Guide
3
