Figure 3-4 Upload coefficients
3.5.2 Checkerboard Test Pattern
The MCTRL700 Pro supports checkerboard test pattern through calibration software, allowing compatibility
with a broader range of calibration options, such as full-grayscale calibration and low-grayscale calibration.
Firmware Update
Step 1 On the menu bar, choose User > Advanced Synchronous System User Login. Enter the password and click
Login.
The default password is "admin".
Step 2 Click
, or type "admin" or "123456" to open the program loading interface.
www.novastar.tech
MCTRL700 Pro LED Display Controller
Quick Start Guide
8
