Device connection
Hardware Connection
Connect the control computer with NovaLCT installed to the MCTRL 700 Pro with Ethernet cable, as shown
in the figure below.
Software Settings
Step 1 Ensure that the MCTRL700 Pro is properly connected to the control computer.
Step 2 On the computer with NovaLCT installed, open the Network and Sharing Center.
Step 3 Click Change adapter settings.
Step 4 On the displayed window, right click Local Area Connection and go to Properties > Internet Protocol
Version 4 (TCP/IPv4) to enter the properties page.
Step 5 Select Use the following IP address, and set the computer's IP to a range within 192.168.0.2 to
192.168.0.254. Click OK to confirm.
Figure 2-1 Configuring IP address
