Advanced User Guide
Eaton® 9PX PowerPass® Distribution Modules and Transformers
Copyright © 2025 EATON
All rights reserved.
Eaton 9PX G2
9PXTFMR5G2
9PXPPDM2G2
9PXTFMR11G2
9PXPPDM1G2
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the PowerPass 9PX G2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eaton PowerPass 9PX G2

  • Page 1 Eaton 9PX G2 Advanced User Guide Eaton® 9PX PowerPass® Distribution Modules and Transformers 9PXTFMR5G2 9PXPPDM2G2 9PXTFMR11G2 9PXPPDM1G2 Copyright © 2025 EATON All rights reserved. English...
  • Page 2: Table Of Contents

    Table of Content Safety instructions ....................... 4 Special symbols ........................5 Introduction ........................6 3.1 Environmental protection ....................6 3.2 Benefits ..........................7 3.3 Front panels ........................8 3.4 Rear panels .......................... 9 3.5 System Configuration Options ..................12 Mechanical Installation ..................... 12 4.1 Inspecting the equipment ....................
  • Page 4: Safety Instructions

    SAVE THESE INSTRUCTIONS. This manual contains important instructions that you should follow during installation and maintenance of the Eaton 9PX G2 PowerPass Distribution Modules (PPDMs), 9PX G2 Transformers, and 9PX G2 UPS. Please read all instructions before operating the equipment and save this manual for future reference.
  • Page 5: Special Symbols

    Safety Warnings The UPS contains LETHAL VOLTAGES. All repairs and service should be performed by AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS inside the UPS. To reduce the risk of fire or electric shock, install this UPS in a temperature and humidity controlled, indoor environment, free of conductive contaminants.
  • Page 6: Introduction

    Follow all local regulations for the disposal of packing materials. End of life Eaton will process products at the end of their service life in compliance with local regulations. Eaton works with companies in charge of collecting and eliminating our products at the end of their service life.
  • Page 7: Benefits

    Choice of plug-receptacle or terminal-block wired models • Variety of output outlets • Breaker protection • Bypass and voltage selection switches on selected models There are four Eaton 9PX PPDM and 9PX Transformer models: • 9PXTFMR5G2 • 9PXPPDM2G2 • 9PXTFMR11G2 •...
  • Page 8: Front Panels

    Front panels Front Cover with Center Cover Attached (all models): Front Cover with Center Cover Removed to Access Bypass Switch ( 9PX PPDMs G2 only): Front Cover with Center Cover Open to Access Voltage Selection Switch (all models except 9PXTFMR11G2, which uses terminal-block wiring for voltage selection): Front Cover with Center Cover Open of 9PXTFMR11G2, which uses terminal-block wiring for voltage selection:...
  • Page 9: Rear Panels

    Rear panels This section provides rear panel illustrations of the 9PX PPDM and 9PX Transformer models. 9PXTFMR5G2 (1) Main Circuit (18) 5-20R Output Breaker (One Receptacles 240V-30A) MAIN (2) Output Circuit Output (to UPS) (2) Output Circuit Breakers (Two Breakers (Two 120V-20A) 120V-20A)
  • Page 10 Hardwired UPS 9PXPPDM2G2 Connections (1) Main Circuit (Terminal Block) Breaker (One 240V-30A) Input (to UPS) TO UPS INTPU CIRCUT I 240V~A30 Output (to UPS) Hardwired Load Output Connections (Terminal Block) 9PXTFMR11G2 (2) Output Circuit Output Circuit Breaker (One Output (to UPS) L14-30R Output Receptacles Breakers (Two...
  • Page 11 9PXPPDM1G2...
  • Page 12: System Configuration Options

    System Configuration Options Several system configuration offerings combine the 9PX 5000/6000/8000/11000 VA G2 UPS models with other units in the 9PX G2 solution suite, including the 9PX PPDMs G2 and 9PX Transformers G2, the 9PX 240V Extended Battery Module (EBM G2), and the external Maintenance Bypass (MBP G2) accessories.
  • Page 13: Tower Setups

    Note: The order of a tower installation, from left to right, is the 9PX PPDM G2 or 9PX Transformer G2, 9PX EBM G2, and the 9PX UPS G2 2. Position the cabinet upright. Turn the Eaton logo to align with the top of the cabinet. Ensure additional cabinets are upright.
  • Page 14: Rackmount Setup

    Rackmount Setup Note: • The order of a rackmount installation, from top to bottom, is the 9PX UPS, 9PX EBM, and the 9PX PPDM or 9PX Transformer. • First, install the rails in the rack. Then, install the cabinet on the rails. Installing the Rails To install the rails in the rack: 1.
  • Page 15 Installing the Cabinet To install the cabinet on the rails: 1. Do this only if the UPS is already installed and operating: Shut down the UPS before installing a 9PX PPDM G2 or 9PX Transformer G2. Refer to shutdown instructions in the appropriate 9PX UPS G2 user's guide for your system configuration.
  • Page 16: Electrical Installation

    Electrical Installation This chapter provides electrical installation instructions for the Eaton 9PX PowerPass Distribution Modules (PPDMs) and 9PX Transformers. Risk of electrical shock. Only qualified service personnel (such as a licensed electrician) shall perform the electrical installation. • To reduce the risk of fire, unit input connect only to a circuit provided with branch circuit overcurrent protection (30A for 9PXPPDM1G2, 9PXPPDM2G2, and 9PXTFMR5G2;...
  • Page 17 9PXPPDM2G2 block diagram. The 9PXPPDM2G2 I/O terminal block is hardwired: Procedure To wire the I/O terminal block for the 9PXPPDM2G2: 1. Switch off utility power at the distribution point where the 9PXPPDM2G2 model will be connected. Be absolutely sure there is no power. 2.
  • Page 18 6. Punch out the pre-cut knock-out holes for the input and output conduit. 7. Pull the input and output wires through separate conduit, leaving approximately 0.5m (2 ft) of exposed wire. Attach a flexible metal fitting to the end of each conduit. 8.
  • Page 19: 9Pxppdm11G2 Electrical Installation

    9PXPPDM11G2 Electrical Installation This section provides terminal block wiring requirements and electrical installation procedures for the 9PXTFMR11G2 model. The 9PXPPDM2G2 model requires a dedicated branch circuit that meets the following requirements: • 80A circuit with short circuit and overcurrent protection •...
  • Page 20 6. On the UPS, insert each conduit through a wiring access entry. Strip 9 mm (0.35”) of insulation from the end of each incoming wire. 7. On the 9PXTFMR11G2 terminal block, wire the UPS connections 1-3 and attach the cable gland to the panel 8.
  • Page 21: 9Pxppdm1G2 And 9Pxtfmr5G2 Electrical Installation

    9PXPPDM1G2 and 9PXTFMR5G2 Electrical Installation This section provides terminal block wiring requirements and electrical installation procedures for the 9PXPPDM1G2 and 9PXTFMR5G2 model. The 9PXPPDM1G2 and 9PXTFMR5G2 models require a dedicated branch circuit that meets the following requirements: • 30A circuit with short circuit and overcurrent protection •...
  • Page 22 Procedure For the 9PXPPDM1G2 and 9PXTFMR5G2 plug-receptacle models: 1. Verify that the output circuit breaker is in the OFF position (see chapter “Rear Panels”). 2. 9PXTFMR5G2 only. Go to Step 5. 3. 9PXPPDM1G2 only. On the front cover, unsnap and remove the square center cover. 4.
  • Page 23: 9Pxppdm1G2 And 9Pxppdm2G2 Voltage Selection

    9PXPPDM1G2 and 9PXPPDM2G2 Voltage selection This section provides voltage settings and the voltage selection switching procedure for the 9PXPPDM1G2 and 9PXPPDM2G2 models. 9PXPPDM1G2 voltage settings 9PXPPDM1G2 Output Voltage Input Voltage 208V Switch Position Default 240V Switch Position (from UPS) L6-30R 5-20R L14-30R L6-30R...
  • Page 24: 9Pxtfmr5G2 Voltage Selection

    9PXTFMR5G2 Voltage selection This section provides voltage settings and the voltage selection switching procedure for the 9PXTFMR5G2 model. 9PXTFMR5G2 voltage settings 9PXTFMR5G2 Output Voltage Input Voltage 208V Switch Position 240V Switch Position (from UPS) 5-20R 5-20R Procedure To change the 9PXTFMR5G2 voltage switch position: 1.
  • Page 25: 9Pxtfmr11G2 Voltage Selection

    9PXTFMR11G2 Voltage selection This section provides voltage settings and the voltage selection terminal block wiring procedure for the 9PXTFMR11G2 model. 9PXTFMR11G2 I/O Voltage Settings for Voltage Selection Terminal Block 9PXTFMR11G2 Output Voltage Input Voltage 208V Setting 240V Setting (from UPS) 9PXTFMR11G2 I/O Voltage Settings for Plug Receptacles Input 9PXTFMR11G2 Output Voltage...
  • Page 26 3. Replace the voltage selection terminal block cover and secure it with the Phillips-head screw. 4. For startup with the UPS, go to Chapter 6 “Startup”.
  • Page 27: Startup

    Startup This chapter provides instructions for starting up Eaton 9PX PowerPass Distribution Modules G2 (PPDMs G2) or 9PX Transformers G2 with a 9PX 5000/6000/8000/11000 VA UPS G2. System configuration connection diagrams are also provided. Startup with the UPS To start up a 9PX PPDM G2 or 9PX Transformer G2 with the UPS.
  • Page 28: Plug-Receptacle Connections

    Plug-Receptacle Connections • DO NOT protect laser printers with the UPS because of the exceptionally high power requirements of the heating elements. • Do not overload the 9PX PPDM or 9PX Transformers . For 120V output voltage, the output of L1 or L2 can only be half-loaded 9PXTFMR5G2, 9PXTFMR11G2 (plug-receptacle/terminal-block wired option), and 9PXPPDM1G2 models only.
  • Page 29 9PXTFMR11G2 L2/L-2 Output Limits 9PXTFMR11G2 L2 Receptacle 9PXTFMR11 L-2 Terminal Group 9PXPPDM1G2 L1 Load Output Limits 9PXPPDM1G2 L1 Receptacle Group 9PXPPDM1G2 L2 Load Output Limits...
  • Page 30: System Configuration Connection

    9PXPPDM1G2 L2 Receptacle Group CIRCUI T BREAKER OUTPU T 120V~ 20 120V~ 20 FROM UPS OUTPU OUTPU T 240V~ 30 MAIN CIRCUI T BREAKER 240V~ 30 NORMA L AC SOURCE TO UPS INPU OUTPU T 120/240V~ 30 OUTPU T 120V~ 20 CIRCUI T BREAKER 120V~ System Configuration Connection...
  • Page 31 9PXPPDM2G2 with 9PX5000 or 9PX6000 UPS (Kits 9PX5KP2G2 and 9PX6KP2G2) 9PXTFMR5G2, 11k 240V EBM, and 11k MBP with 9PX8000 or 9PX11000 UPS (Kits 9PX8KTF5G2 and 9PX11KTF5G2) 9PXTFMR11G2 and 11k 240V EBM with 9PX11000 UPS (Kit 9PX11KTF11G2)
  • Page 33: Maintenance Bypass

    Maintenance Bypass This chapter provides maintenance bypass information for the Eaton 9PX PowerPass Distribution Modules (PPDMs).. Refer to the 9PX UPS/EBM user's guide for operation information. The Maintenance Bypass feature allows you to remove the UPS while providing power to your protected equipment. This feature is useful when replacing the UPS for maintenance or upgrades.
  • Page 34: Return To Normal Ups Protection

    Return to Normal UPS Protection To reinstall the UPS and transfer your equipment from Maintenance Bypass (AC Line operation) to the UPS. 1. If optional Extended Battery Modules (EBMs) are installed, switch the battery circuit breaker on the first EBM rear panel to the On ( | ) position.
  • Page 35: Specifications

    Specifications This chapter provides product specifications and rear panel diagrams for the Eaton 9PX PowerPass Distribution Modules (PPDMs) and 9PX Transformers. Mechanical and environmental 9PXTFMR5G2 9PXPPDM1G2 9PXPPDM2G2 9PXTFMR11G2 Operating Temperature 0°C to 40°C (32°F to 104°F) Storage Temperature -22°C to 55°C (-7°F to 131°F) Relative Humidity 0–95% noncondensing...
  • Page 36: Service And Support

    (8) 5-20 R Service and Support If you have any question or problem with the UPS, call Eaton or your local service representative in your country / region. Please have the following information ready when you call for service: • Model number •...
