Page 1 Eaton 9PX Gen2 Advanced User Guide 9PX5KIRTNG2 9PX5KIRTNBPG2 9PX6KIRTNG2 9PX6KIRTNBPG2 9PX8KIRTNG2 9PX8KIRTNBPG2 9PX11KIRTNG2 9PX11KIRTNBPG2 9PXEBM180RT3UG2 9PXEBM240RT3UG2 MBP6KIG2 MBP11KIG2 Copyright © 2025 EATON All rights reserved. English 9PX Gen2_5-11kVA_EMEA_EN...
Page 2: Table Of Contents
Table of Content Table of Contents Special symbols Introduction 2.1 Environmental protection Substances Packaging End of life Product Battery 2.2 Benefits Presentation 3.1 Weights and dimensions 3.2 Rear panel 3.3 Optional accessories Installation 4.1 Inspecting the equipment UPS Package content EBM Package content 4.2 Unpacking the UPS 4.4 Recommended positions...
Page 3 5.5 Advanced Battery Management + 5.6 Communication ports 5.7 UPS remote control functions Programmable signal inputs Programmable signal outputs 5.8 Eaton Intelligent Power Software suite 5.9 Cybersecurity Operation 6.1 Start-up and normal operation 6.2 Starting the UPS on battery 6.3 UPS start-up with HotSwap MBP 6.4 UPS shutdown...
Page 4 7.6 Recycling the used equipment Troubleshooting 8.1 Typical alarms and faults 8.2 Silencing the alarm 8.3 Service and support Specification and technical characteristics 9.1 UPS model list 9.2 Extended Battery Module model list 9.3 Electrical input 9.4 Electrical input connections 9.5 Electrical output 9.6 Electrical output connection 9.7 Battery...
Page 5: Special Symbols
1 Special symbols The following are examples of symbols used on the UPS or accessories to alert you to important information: DANGER: Dangerous voltage levels are present within the UPS. The UPS has its own internal power source (the battery). Consequently, the power outlets may be energized even if the UPS is disconnected from the AC power source.
Page 6: Introduction
Thank you for selecting an Eaton 9PX Gen2 product to protect your electrical equipment. The Eaton 9PX Gen2 range has been designed with the utmost care. We recommend that you take the time to read this advanced user guide to take full advantage of the many features of your UPS (Uninterruptible Power System).
Page 7: End Of Life
With the Eaton 9PX Gen2, you can safely eliminate the effects of power disturbances and guard the integrity of your equipment. Providing outstanding performance and reliability, the Eaton 9PX Gen2’s unique benefits include: •...
Page 8: Presentation
3 Presentation 3.1 Weights and dimensions Dimensions and weight Description (UPS) Weights (kg / lb) Dimensions (mm / inch) D x W x H 9PX5KIRTNG2 43.1 / 95 684x440x130 / 26.9x17.3x5.1 9PX6KIRTNG2 9PX8KIRTNG2 78.8 / 173.7 724x440x174 / 28.5x17.3x6.9 9PX11KIRTNG2 Description (EBM) Weights (kg / lb) Dimensions (mm / inch) D x W x H...
Page 9: Rear Panel
Rear panel UPS Rear Panels 9PX5KIRTNG2; 9PX6KIRTNG2 (3U) ① Network Management Card ② Battery connector ③ USB communication port ④ RS232 communication port ⑤ Relay output contact ⑥ Connectors for ROO (Remote On/Off) and RPO (Remote Power Off) control ⑦ Connector for HotSwap MBP detection ⑧...
Page 10 MBP Rear Panels and description The HotSwap MBP has a manual Bypass rotary switch with two positions: • UPS => the load is supplied by the UPS • Bypass => the load is supplied directly by the AC power source 2 lights indicate the Hotswap MBP power status: •...
Page 11: Optional Accessories
Eaton Gigabit Network Card (SNMP v1/v3 and IP v4/v6 // Ethernet 10/100/1000BaseT) INDGW-M2 Eaton Industrial Gateway Card (Modbus TCP / RTU) Relay-MS Eaton Relay card (1 x RS232 or 5 x Relay output) INDRELAY-MS Eaton Industrial relay card (5x relay outputs with dry contacts for remote alarm information) EMPDT1H1C2...
Page 12: Installation
4 Installation 4.1 Inspecting the equipment If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for shipping damage. If you discover damage after acceptance, file a claim for concealed damage.
Page 13 MBP package content If you ordered an optional Maintenance ByPass (MBP), verify that the following additional items are included with the MBP: MBP6KiG2 ① MBP ② Quick start ③ MBP Cord set (Only for 6k MBP) ④ Cable glands MBP11KiG2 ⑤...
Page 14: Unpacking The Ups
4.2 Unpacking the UPS Unpacking without removing the batteries The UPS is wrapped in a paper tray lifting system. It is prevented from slipping by the cardboard (blue circles) pasted on the paper tray. The UPS can be lifted by two people using the 2 “handles” per side (red circles). Take care to carry the product horizontally.
Page 15: Recommended Positions
Follow steps bellow for module mounting on the rails. The rails and necessary hardware are supplied by Eaton. As UPS is heavy, the batteries can be removed before mounting the UPS on the rack. Refer to "Installation in rack position with batteries removed".
Page 16 5000VA and 6000VA UPS: Installation in rack position by removing the battery Follow steps 1 to 16. Steps 1 to 6: Remove the battery Steps 7 to 10: Install the Rack Kit and Fix the UPS cabinet (w/o battery) Steps 11 to 16: Replace the battery and the front panel English 9PX Gen2_5-11kVA_EMEA_EN...
Page 17 8000VA and 11000VA UPS: Installation in rack position by removing the battery Follow steps 1 to 16. Steps 1 to 7: Remove the battery Steps 8 to 11: Install the Rack Kit and Fix the UPS cabinet (w/o battery) Steps 12 to 18: Replace the battery and the front panel English 9PX Gen2_5-11kVA_EMEA_EN...
Page 18: Ebm Connection
4.5 EBM connection Extended runtime with up to twelve Extended Battery Modules (EBMs) per UPS When 11KVA UPS is used with more than 8 EBMs (between 8 and 12), additional ground PE wires (Min 10AWG or 10mm2 cross-sectional area identical to input) are required, see illustration below: English 9PX Gen2_5-11kVA_EMEA_EN...
Page 19 Tour installation A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and will not harm personnel. Insert the EBM cable into the UPS battery connector quickly and firmly. 1. Attach the UPS and the EBMs to each other using the supplied mounting plate. 2.
Page 20 Rack installation A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and will not harm personnel. Insert the EBM cable into the UPS battery connector quickly and firmly. To increase stability, it is preferable to place the EBM below the UPS. 1.
Page 21: Ups Connection Hardwired Connection
4.6 UPS connection Hardwired connection UPS connection without HotSwap MBP module Check that the indications on the name plate located on the back of the UPS correspond to the AC-power source and the true electrical consumption of the total load. Caution: switch off utility power to the distribution point where the UPS will be connected.
Page 22 High leakage current: Earth connection essential before connecting supply Recommended protective devices and cable cross-sections 5000VA and 6000VA 8000VA and 11000VA CAUTION, for 8000VA and 11000VA: there is a risk of voltage backfeed. Before working on this circuit, isolate the UPS, then check for Hazardous Voltage between all terminals including the protective earth.
Page 23 Screw the electric cables, starting by the earth wire Screw the I/O box and tighten the cable gland 5000VA and 6000VA 8000VA and 11000VA Connect the output cables, switch on the breaker and start the UPS English 9PX Gen2_5-11kVA_EMEA_EN...
Page 24 Installation depending on the system earthing arrangement (SEA) Change in SEA between upstream and downstream or galvanic isolation required For 5000VA and 6000VA Main Low Voltage Switchboard (MLVS) Main Low Voltage Switchboard (MLVS) English 9PX Gen2_5-11kVA_EMEA_EN...
Page 25 Because 8000VA and 11000VA have multiple sources of supply, below figure for 8000VA and 11000VA: English 9PX Gen2_5-11kVA_EMEA_EN...
Page 26 English 9PX Gen2_5-11kVA_EMEA_EN...
Page 27 English 9PX Gen2_5-11kVA_EMEA_EN...
Page 28: Register Warranty
4.7 Register warranty Register warranty at https://www.pqproductregistration.eaton.com English 9PX Gen2_5-11kVA_EMEA_EN...
Page 29: Connection With Mbp
4.8 Connection with MBP The Eaton® HotSwap MBP module makes it possible to service or even replace the UPS without affecting the connected loads (HotSwap function). You can safely eliminate the effects of UPS maintenance and guard the integrity of your equipment.
Page 30 Follow the steps below to install the MBP in rack position. 1. Screw the ears on each MBP side. MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS 2. Mount the MBP with its ears on the UPS rack. MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS English...
Page 31: Mechanical Installation In Tower Position
Mechanical installation in tower position Depending on the configuration, there are four different assemblies, identified with letters A, B, C and D. The different ways to mount the MBP with the UPS or the "UPS+EBM" are identified by the A, B, C & D letters. Final assembly position: MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS...
Page 32 Follow the steps below to install the MBP in tower position. Screw the ears on each MBP side. MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS Mount the MBP with its ears on the UPS or EBM MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS English...
Page 33: Mbp Electrical Connection
MBP electrical connection Caution: Manually trip the input circuit breaker of your installation before connecting the supply cables. Access to the terminal block, remove the circular covers and screw the cable glands. MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS English 9PX Gen2_5-11kVA_EMEA_EN...
Page 34: Recommended Cable Cross-Sections For Standard Installation
Insert the electrical cables. Follow below instructions for upstream protection and cable cross section. Use copper cable only, and not aluminum. Recommended upstream protection The upstream circuit breaker for Normal AC/Bypass AC must be easily accessible. The unit can be disconnected from AC power source by opening this circuit breaker.
Page 35 Strip the copper supply cable keeping the Earth cable longer for safety purpose. Insert the cables MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS Tighten well the cable glands MBP6KiG2 used with 5000VA and 6000VA UPS MBP11KiG2 used with 8000VA and 11000VA UPS Close the I/O box terminal MBP6KiG2 used with 5000VA and 6000VA UPS...
Page 36: Connection Between Mpb And Ups
Connection between MPB and UPS For the electrical connection on the UPS side, follow the steps described in the chapter "Hardwired connection" Connect the MBP cord set (For 6k MBP only) Connect the MBP detection cable to the UPS Power up your installation Switch on the input circuit breaker of your installation.
Page 37: Interfaces And Communication
5 Interfaces and communication 5.1 Control panel The screen provides useful information about the UPS itself, load status, events, measurements and settings. ① Power ON indicator (green) ② On battery indicator (orange) ③ On bypass indicator (orange) ④ Alarm indicator (red) ⑤...
Page 38: Lcd Description
5.2 LCD description ① Operation status ② Load/equipment status ③ Efficiency and load group information ④ Battery status By default, or after 5 minutes of inactivity, the LCD displays the screen saver. The backlight LCD automatically dims after 5 minutes of inactivity. Press any button to restore the screen. Note.
Page 39: Display Functions
Clears faults Type / Model / Part Number / Serial Number / UPS Firmware / NMC Firmware / Identification IPV4 Address / IPV6 Address / Com card MAC Address /Detected accessories Registration Links to Eaton registration website English 9PX Gen2_5-11kVA_EMEA_EN...
Page 40: User Settings
5.4 User settings The following table displays the options that can be changed by the user. Submenu Available settings Default settings Main Menu Language [English] [English] [Français] [Deutsch] [Español] Automatic message for user [Portugues] [Italiano] [Simplified Chinese] configuration when UPS is [Japanese] powered for the first time.
Page 41 Main Menu Submenu Available settings Default settings Load segments UPS:[No delay]; Group1:[3s]; [Auto start delay] Group2:[6s] UPS:[Disabled]; Group1: [Auto shutdown delay] [Disabled]; Group2: [Disabled] Overload prealarm [102%] [10%] … [102%] Load % when overload alarm occurs Power Limit [Disabled] [Enabled] [Disabled] Disabled/ Enabled UPS power limit mode on 5K/6K/ 8K/11K.
Page 42 Main Menu Submenu Available settings Default settings [Enabled] [Disabled] [Yes] Power Off alert If enabled, activates a confirmation screen that requires user confirmation after pressing the power button, before UPS shutdown occurs. Remote shutdown, ROO, RPO, Input signals will never request user confirmation, even if the setting is enabled [Enabled] [Disabled] [Enabled]...
Page 43 Main Menu Submenu Available settings Default settings [ROO] [RPO] [DB9-4] Sets Input signals parameters (function, delay, operation) through external contact connectors or RS232 port. ROO port: - [Function]: [No] [ROO] [RPO] [Building [No] alarm] [Forced bypass] [On generator] [0s] [Remote shutdown] [Closed] - [Delay]: [0s] …...
Page 44: Advanced Battery Management
5.5 Advanced Battery Management + Eaton ABM+ (Advanced Battery Management) implements a machine learning algorithm providing battery health status. When set to predictive mode, the UPS will be able to provide an accurate remaining service time prediction based on real UPS usage condition.
Page 45: Communication Ports
1. Connect the RS232 or USB communication cable to the serial or USB port on the computer equipment. 2. Connect the other end of the communication cable to the USB or RS232 communication port on the UPS The UPS can now communicate with Eaton power management software. Characteristics of the contact RS232 communication port...
Page 46 Connectivity cards allow the UPS to communicate in a variety of networking environments and with different types of devices. The 9PX Gen2 models have one available communication bay for the following connectivity cards: • Gigabit Network card ( Network-M3) : provides a Gigabit Ethernet connection and enables secure UPS monitoring over HTTPS web browser interface, SNMP v1/v3 protocol and email alarms.
Page 47: Ups Remote Control Functions
5.7 UPS remote control functions Programmable signal inputs The 9PX Gen2 incorporates several programmable signal inputs: one Remote Power Off (RPO) input terminal, one Remote On/Off (ROO) input terminal, one RS-232 input (pin-4). Signal inputs can be configured (see Settings > Comm settings > Signal Input) to have one of the following functions:...
Page 48: Programmable Signal Outputs
Programmable signal outputs The 9PX Gen2 incorporates several programmable signal outputs: Two relay outputs and two optocoupler outputs (DB9 pins 1, 7 and 8). Signal outputs can be configured (see Settings > Comm settings > Output Signals) to report the...
Page 49: Eaton Intelligent Power Software Suite
It also gives you a complete record of critical power events, and it notifies you of important UPS or power information. If there is a power outage and the 9PX Gen2 UPS battery power becomes low, Eaton Software suite can automatically shut down your computer system to protect your data before the UPS shutdown occurs.
Page 50: Operation
On the first startup of the UPS, you will need to configure the output voltage and time of the UPS. To start the UPS: 1. Verify that the UPS power cord is plugged in. 2. The UPS front panel display illuminates and shows Eaton logo. 3. Verify that the UPS status screen shows 4. Press the button on the UPS front panel for at least few seconds.
Page 51: Ups Start-Up With Hotswap Mbp
6.3 UPS start-up with HotSwap MBP Verify that the total equipment ratings do not exceed the UPS capacity to prevent an overload alarm. 1. Check that the UPS is correctly connected to the HotSwap MBP. If the UPS if equipped with outlets, those outlets can no longer be used (loads can only be connected to the MBP outlets or the MBP Output terminal blocks 2.
Page 52: Operating Modes
6.5 Operating modes The Eaton 9PX Gen2 front panel indicates the UPS status through the UPS indicators located above the LCD screen. LED indicator: Normal mode When the green symbol is illuminated, the UPS is providing protected AC power output. The LED bar is illuminated in static blue.
Page 53: Return Of Ac Input Power
Transfers to High Efficiency mode will be active after five minutes of Bypass voltage monitoring: if Bypass quality is not in tolerance, then the UPS will remain in Normal mode. Eaton recommends using the HE mode only to protect IT equipment. To set the High Efficiency mode: 1.
Page 54: Ups Maintenance
If you store the equipment for a long period, recharge the battery every 6 months by connecting the UPS to utility power. The internal batteries charge to 90% capacity in less than 3 hours. However, Eaton recommends that the batteries charge for 48 hours after long-term storage.
Page 55: Ups Replacement With Hotswap Mbp
7.4 UPS replacement with HotSwap MBP UPS Removing (please follow the MANDATORY step below). UPS replacement must be performed by qualified person only. MBP6KiG2 1. Put the UPS in "Bypass mode" BYPASS 2. Verify that the UPS is on Bypass mode by checking UPS display panel 3.
Page 56: Mbp11Kig2
MBP11KiG2: UPS replacement must be performed by qualified person only. 1. Put the UPS in "Bypass mode" BYPASS 2. Verify that the UPS is on Bypass mode by checking UPS display panel 3. Set the MBP manual Bypass switch to "Bypass" position. The "Bypass mode" red light of the MBP goes On, indicating that the load is supplied directly by AC source, or Bypass AC source 4.
Page 57: Return To Normal Operation
Return to normal operation: 1. Check that the new UPS is correctly connected to the MBP, as described below: MBP6KiG2: • After opening the UPS I/O terminal blocks cover, connect to UPS the 2 power cables, and the MBP detection cable. •...
Page 58: Ups Maintenance With Hotswap Mbp
Contact your local recycling or hazardous waste center for information on proper disposal of the used equipment. eaton.com/recycling Do not dispose the battery or batteries in a fire. Batteries may explode. Proper disposal of batteries is required. Refer to your local codes for disposal requirements.
Page 59: Troubleshooting
8 Troubleshooting The Eaton 9PX Gen2 is designed for reliable, autonomous operation while providing you with notifications and alerts whenever a potential operational or performance issue occurs. Usually the alarms shown by the control panel do not mean that the output power is affected. Instead, they are preventive alarms intended to alert the user.
Page 60: Silencing The Alarm
8.3 Service and support If you have any question or problem with the UPS, call Eaton or your local service representative in your country / region. Please have the following information ready when you call for service: • Model number •...
Page 61: Specification And Technical Characteristics
Power rating Configuration Eaton 9PX 5000i RT3U Netpack G2 9PX5KIRTNG2 5000W/5000VA Rack / Tower Eaton 9PX 5000i RT3U HotSwap Netpack G2 9PX5KIRTNBPG2 Eaton 9PX 6000i RT3U Netpack G2 9PX6KIRTNG2 6000W/6000VA Rack / Tower Eaton 9PX 6000i RT3U HotSwap Netpack G2...
Page 62: Electrical Input
9.3 Electrical input Default frequency 50Hz Nominal frequency 50/60Hz Frequency range 40-70Hz Protective class Protective class I Default input Catalog Number Input nominal voltages Input voltage window (Voltage/Current) 9PX5KIRTNG2 9PX5KIRTNBPG2 230V/23A 9SX5KIRT3UG2 9PX5KIRTNG2 9PX6KIRTNG2 9PX6KIRTNBPG2 230V/27.6A at 100% load: 176-276V 200V, 208V, 220V, 230V, 240V 9SX6KIRT3UG2 at ≤40% load: 100-276V...
Page 63: Electrical Output
9.5 Electrical output All models Normal mode High Efficiency mode Battery mode Voltage regulation ±1% ±1% 5000/6000 VA: Up to 96.7% 5000/6000 VA: Up to 95% 5000/6000 VA: Up to 98.9% Efficiency 8000/11000 VA: Up to 97.2% 8000/11000 VA: Up to 96.1% 8000/11000 VA: Up to 99.5% Sync with line ±5% of nominal line frequency ±0.5% of auto-selected...
Page 64: Battery
9.7 Battery Internal batteries 5000/6000VA: 180Vdc – 1x15x12V, 5Ah 9PXEBM180RT3UG2: 180Vdc - 2x15x12V, 2x5Ah=10Ah Specifications 8000/11000VA: 240Vdc - 1x20x12V, 9Ah 9PXEBM240RT3UG2: 240Vdc – 1x20x12V, 9Ah Sealed, maintenance-free, valve-regulated, lead-acid, with minimum 3-5 year float service life at 25°C Type (77°F). Monitoring Advanced Battery Management for earlier failure detection and warning (ABM+) 180V DC : 330mm...
Page 65: Environmental And Safety
9.8 Environmental and safety IEC/EN 62040-1 Safety Standards IEC/EN 62040-2 Electromagnetic Compatibility EMC IEC/EN 62040-3 Performance FCC part 15 Class A UL 1778 ENERGY STAR Program Requirements for uninterruptible Power Supplies (UPSs) Version 2.0 CISPR32 Class A FCC part 15 Class A IEC/EN 62040-2 C1 EMC (Emissions) IEC/EN 61000-3-2 or IEC/EN 61000-3-12 Harmonics...
Page 66: Glossary
10 Glossary Backup time Time during which the load can be supplied by the UPS operating on battery power. Low-battery warning This is a battery-voltage level indicating that battery power is low and that the user must take action before the UPS shuts down. Load Devices or equipment connected to the UPS output.
