Eaton 9PX Lithium-Ion
Advanced Users Guide
9PX1500IRT2U-L
9PX2200IRT2U-L
9PX3000IRT2U-L
9PXEBM48RT1U-L
9PXEBM72RT1U-L
p/n: P-164001006
Revision 02

Advertisement

Table of Contents
loading

Related Manuals for Eaton 9PX

Summary of Contents for Eaton 9PX

  • Page 1 Eaton 9PX Lithium-Ion Advanced Users Guide 9PX1500IRT2U-L 9PX2200IRT2U-L 9PX3000IRT2U-L 9PXEBM48RT1U-L 9PXEBM72RT1U-L p/n: P-164001006 Revision 02...
  • Page 2 (WEEE) in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center. ©Copyright 2023 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton.
  • Page 3 S S a a f f e e t t y y o o f f P P e e r r s s o o n n s s • The system has its own power source (the battery). Consequently, the power outlets may be energized ven if the systems is disconnected from the AC power source.
  • Page 4 During the replacement of the Battery Module, it is imperative to use the same type and number of element as the original Battery Module provided with the UPS to maintain an identical level of performance and safety. If there are any questions, don’t hesitate to contact your local EATON representative.

  • Page 5: Table Of Contents

    6 6 M M a a i i n n t t e e n n a a n n c c e e ..........................................................3 3 1 1 6.1 Storing the Equipment ..........................31 6.2 Replacing Batteries ........................... 31 Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 6 8 8 S S p p e e c c i i f f i i c c a a t t i i o o n n s s ......................................................... . 4 4 1 1 8.1 Model Specifications ..........................41 Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 7 Then follow the indications in this manual. To discover the entire range of Eaton Tripp Lite SmartOnline series products and the options available for the Eaton Tripp Lite SmartOnline series range, we invite you to visit our web site at Eaton Tripp Lite.com...

  • Page 8: Environmental Protection

    With the Eaton 9PX, you can safely eliminate the effects of power disturbances and guard the integrity of your equipment. Providing outstanding performance and reliability, the Eaton 9PX’s unique benefits include: •...
  • Page 9 22.8 / 50.2 9PXEBM48RT1U-L 448 x 438 x 42.9 / 17.6 x 17.2 x 1.7 16.6 / 36.5 9PXEBM72RT1U-L 603 x 438 x 42.9 / 23.7 x 17.2 x 1.7 21.2 / 46.6 Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 10: Rear Panels

    Connector for ROO (Remote On/Off) control and RPO (Remote Power Off) 9PXEBM48RT1U-L Connectors for battery modules (to the UPS or to the other battery modules) Connectors for automatic recognition of battery modules 9PXEBM72RT1U-L Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 11: Accessories

    Online mode Fault indicator (green) indicator (red) Battery mode Bypass mode indicator (orange) indicator (orange) Online mode 100% 100% 2.4k W 19min 3.0kVA 1EBM Efficiency: 94 % Escape Down Enter On/Off button Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 12: Lcd Description

    The UPS is Off, waiting for startup Standby mode Equipment is not powered until command from user. button is pressed. The UPS is operating normally. The UPS is powering and protecting the Online mode equipment. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 13: Display Functions

    Tests dry contact relay outputs and relay card contacts. Simulates line failure and battery low Function reset Clears active fault, power usage, battery remaining life, reset NMC, Restore factory settings. Settings Local settings Sets product general parameters Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 14: User Settings

    Output voltage [200V] [208V] [220V] [230V] [240V] [230V] Output frequency Mode: [Normal] [Converter] [Marine] Frequency [Normal] In/Out settings can be changed in Frequency [Converter] mode In [Marine] mode output frequency follows input frequency Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 15 [Timer] [1min] … [15min] [5min] [Level] [100W] … [1000W] [100W] Energy saving If Enabled, UPS will shut-down after defined duration. of back-up time, if load is less than set value. Sleep mode [Enabled] [Disabled] [Enabled] Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 16 - [Function]: [No] [ROO] [RPO] [Building alarm] [Forced bypass] [On generator] [Remote shutdown] - [Delay]: [0s] … [999s] [0s] - [Active]: [Open] [Closed] [Open] DB9-4 port: - [Function]: [No] [ROO] [RPO] [Building alarm] [Forced bypass] [On generator] [Remote shutdown] Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 17 Sets delay before noticing on battery information to software. [On battery] [Battery fault] [Internal fault] [Overload pre-alarm] [Internal fault] [Ambient temp.] [Fan lock] General alarm [Bypass overload] [Current limit] [Short circuit] [Inverter overload] [Power overload] [Low battery] Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 18 Table 6. User Settings (Continued) Submenu Available Settings Default Settings [On bypass] [UPS OK] [Load protected] [Load powered] [Ext. charger ON] Defines which event or fault generate a general alarm through Output signal screen. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 19 RS232 communication cable NMC communication card(optional,standard USB communication cable on Network Bundle options 3 cable locking systems HotSwap MBP module (optional) Software lea et Connection cables between Hotswap MBP Safety instructions module and UPS Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 20 Place the UPS on a flat, stable surface in its final location. Always keep 6" or 150 mm of free space behind the UPS rear panel for ventilation. If installing additional cabinets, place them next to the UPS in their final location. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 21 Tower Installation • Adjustment of the orientation of the LCD panel and of the logo. • Adjustment of the angle of vision of the LCD panel. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 22: Rack Installation

    Rack mounting of UPS, EBM, and accessory modules. Follow steps 1 to 4 for module mounting on the rails. The rails and necessary hardware are supplied by EATON. 3 3 . . 5 5 C C o o n n n n e e c c t t i i n n g g t t h h e e E E B B M M ( ( s s ) ) A small amount of arching may occur when connecting an EBM to the UPS.

  • Page 23: Connecting The Ebm(S)

    EBM 4 NOTE The EBM communication wiring connections are directional and must be connected in the correct sequence to ensure proper detection, regulation and lifecycle monitoring of the integrated battery management system (BMS). Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 24: Detecting Other Accessories

    D D e e t t e e c c t t i i n n g g o o t t h h e e r r A A c c c c e e s s s s o o r r i i e e s s Tip If you ordered other UPS accessories, refer to specific user manuals to check the connection to the UPS. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 25: Ups Connection Without Hotswap Mbp Module

    For the 9PX 2200I / 3000I models, connect any high-power devices to the 16 A outlet. To program shutdown of outlets during operation on battery...

  • Page 26: Connection With A Hotswap Mbp Module ( Optional Accessory)

    An additional cable kit is required to connect the UPS to the MBP . Follow the same procedure as for the 9PX 2200IRT / 9PX 3000IRT using the blue and red color markings. HotSwap MBP module operation The HotSwap MBP module has a rotary...

  • Page 27: Communication Ports

    Plug and Play UPS ON Output UPS ON BAT Mode Output Output Power supply for external signals or options Contact characteristics (optocoupler) • Voltage: 48 V DC max • Current: 25 mA max Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 28: Ups Remote Control Functions

    U U P P S S R R e e m m o o t t e e C C o o n n t t r r o o l l F F u u n n c c t t i i o o n n s s Programmable Signal Inputs The 9PX incorporates 3 programmable signal inputs: one Remote Power Off (RPO) input terminal, one Remote On/Off (ROO) input terminal, one RS-232 input (pin-4). Signal inputs can be configured see Settings > Com settings >...
  • Page 29 UPS from the front panel. Normally Closed Plug the RPO connector into the back of the UPS and fix the screws. Connect and restart the UPS according to the previously described procedures. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 30 Connectivity Cards Connectivity cards allow the UPS to communicate in a variety of networking environments and with different types of devices. The 9PX models have one available communication bay for the following connectivity cards: • Network-M2 /Network-M3 card — has SNMP and HTTP capabilities as well as monitoring through a Web browser interface;...
  • Page 31 UPS or power information. If there is a power outage and the 9PX UPS battery power becomes low, Eaton Software suite can automatically shut down your computer system to protect your data before the UPS shutdown occurs.
  • Page 32 UPS Remote Control Functions Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 33 O O p p e e r r a a t t i i n n g g M M o o d d e e s s The Eaton 9PX front panel indicates the UPS status through the UPS indicators, see section 2.4 Control Panel...

  • Page 34: Ups Shutdown

    10 ms when utility fails. Transfers to High Efficiency mode will be active after 5 minutes of Bypass voltage monitoring: if Bypass quality is not in tolerance, then the UPS will remain in Online mode. Eaton recommends to use the HE mode only to protect IT equipment. To set the High Efficiency mode:...

  • Page 35: Configuring Bypass Settings

    R R e e t t r r i i e e v v i i n n g g t t h h e e E E v v e e n n t t L L o o g g To retrieve the Event log through the display: Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 36: Retrieving The Fault Log

    5 5 . . 1 1 0 0 R R e e t t r r i i e e v v i i n n g g t t h h e e F F a a u u l l t t L L o o g g To retrieve the Fault log through the display: Press any button to activate the menu options, then select Fault log. Scroll through the listed faults. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 37 If you store the equipment for a long period, recharge the battery every 6 months by connecting the UPS to utility power. The internal batteries charge to 90% capacity in less than 3 hours. However, Eaton recommends that the batteries charge for 48 hours after long-term storage. Check the battery recharge date on the shipping carton label.

  • Page 38: Replacing Batteries

    12. If the UPS was shut down during the battery replacement process see . Replacing the EBM(s) The EBM is heavy. Lifting the cabinet into a rack requires a minimum of two people. To replace the EBM(s): Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 39: Battery Settings Reset

    BMS auto setup to advance the menu Connectivity test Reset battery life Functions reset NMC card reset BMS auto setup Done Reset the battery life counter in the “Functions Reset” option of the control menu. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 40 If optional EBMs are installed, verify that the EBM are connected to the UPS. See section . See section for powering the UPS back to normal operation. If the UPS has a MBP module attached see 3.6 Detecting other Accessories for the correct startup procedure. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 41: Replacing The Ups Equipped With A Hotswap Mbp

    This symbol indicates that you should not discard waste electrical or electronic equipment (WEEE) in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 42: Recycling The Used Equipment

    Recycling The Used Equipment Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 43 T T y y p p i i c c a a l l A A l l a a r r m m s s a a n n d d F F a a u u l l t t s s The Eaton 9PX are designed for durable, automatic operation and also alert you whenever potential operating problems may occur.

  • Page 44: Silencing The Alarm

    • Model number • Serial number • Firmware version number • Date of failure or problem • Symptoms of failure or problem • Customer return address and contact information Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 45: Ce Compliance Contact

    C C E E C C o o m m p p l l i i a a n n c c e e C C o o n n t t a a c c t t • Eaton I.F. SAS - 110 Rue Blaise Pascal - 38330 Montbonnot St Martin – France. Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 46 CE Compliance Contact Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 47 22.8 / 50.2 9PXEBM48RT1U-L 448 x 438 x 42.9 / 17.6 x 17.2 x 1.7 16.6 / 36.5 9PXEBM72RT1U-L 603 x 438 x 42.9 / 23.7 x 17.2 x 1.7 21.2 / 46.6 Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...

  • Page 48: Model Specifications

    50 or 60 Hz, autosensing or configurable as a frequency converter Output Overload Online mode: 102%~130% :12s 130%~150% :2s >150% :shutdown after 300ms Percent is based on nominal Watt/VA. Transfer behavior can change (see output mode setting) Battery mode: 102%~130% :12s Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 49 IEC 61000-4-3, (Radiated field): 10 V/m IEC 61000-4-4, (EFT): Power (Coupling network) 4 kV / Ethernet (Coupling clamp) 2 kV IEC 61000-4-5, (Surges): 2 kV Differentiel Mode / 4 kV Common Mode / Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 50 Lithium Iron Phosphate (LFP) battery module Lithium-Ion float service life 8 years /25°C Monitoring Integrated battery management system (BMS) for temperature regulation and life cycle monitoring. EBM Battery Cable Length 350 mm / 13.78 in Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
  • Page 51 Model Specifications Eaton 9PX Lithium-Ion User Guide P-164001006—Rev 02...
