Eaton 9PX Lithium-Ion
Eaton 9PX Lithium-Ion Advanced Users Guide
9PX1000IRTANZ-L / 9PX1500IRTANZ-L / 9PX2000IRTAU-L /
9PX3000IRTANZ-L / 9PXEBM48RT1U-L / 9PXEBM72RT1U-L
p/n: P-164001006
Revision 01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9PX1000IRTANZ-L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton 9PX1000IRTANZ-L

Summary of Contents for Eaton 9PX1000IRTANZ-L

  • Page 1 Eaton 9PX Lithium-Ion Eaton 9PX Lithium-Ion Advanced Users Guide 9PX1000IRTANZ-L / 9PX1500IRTANZ-L / 9PX2000IRTAU-L / 9PX3000IRTANZ-L / 9PXEBM48RT1U-L / 9PXEBM72RT1U-L p/n: P-164001006 Revision 01...
  • Page 2 Eaton, Powerware, and BladeUPS are registered trademarks of Eaton Corporation or its subsidiaries and affiliates. ©Copyright 2020 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the Phillips and Pozidriv are registered trademarks of Phillips Screw Company.
  • Page 3 Safety of Persons • The system has its own power source (the battery). Consequently, the power outlets may be energized ven if the systems is disconnected from the AC power source. Dangerous voltage levels are resent within the system. It should be opened exclusively by qualified service personnel.
  • Page 4 During the replacement of the Battery Module, it is imperative to use the same type and number of element as the original Battery Module provided with the UPS to maintain an identical level of performance and safety. If there are any questions, don’t hesitate to contact your local EATON representative.

  • Page 5: Table Of Contents

    6 6 U U P P S S M M a a i i n n t t e e n n a a n n c c e e ....................................................... . 3 3 3 3 6.1 Storing the Equipment ..........................33 6.2 Replacing Batteries ........................... 33 Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 6 8 8 S S p p e e c c i i f f i i c c a a t t i i o o n n s s ......................................................... . 4 4 3 3 8.1 Model Specifications ..........................43 Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 7 Before installing your 9PX, please read the booklet presenting the safety instructions. Then follow the indications in this manual. To discover the entire range of EATON products and the options available for the 9PX range, invite you to visit our web site at Eaton.com...

  • Page 8: Environmental Protection

    With the Eaton 9PX, you can safely eliminate the effects of power disturbances and guard the integrity of your equipment. Providing outstanding performance and reliability, the Eaton 9PX’s unique benefits include: •...
  • Page 9 23.8 x 17.3 x 3.4 / 605 x 440 x 86.5 50.2 / 22.8 9PXEBM48RT1U-L 17.6 x 17.2 x 1.7 / 448 x 438 x 42.9 36.5 / 16.6 9PXEBM72RT1U-L 23.7 x 17.2 x 1.7 / 603 x 438 x 42.9 46.6 / 21.2 Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 10: Rear Panels

    Group 2: programmable outlets for connection of equipment Connector for automatic recognition of an additional battery module RS232 communication port USB communication port Connector for ROO (Remote On/Off) control and RPO (Remote Power Off) 9PX 3000IRTANZ-L Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 11: Accessories

    C C o o n n t t r r o o l l P P a a n n e e l l The UPS has a five-button graphical LCD. It provides useful information about the UPS itself, load status, events, measurements and settings. Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 12: Lcd Description

    L L C C D D D D e e s s c c r r i i p p t t i i o o n n Operation status Online mode 100% 100% 2.4kW 19min Load/equipment status Battery status 3.0kVA 1EBM Efficiency: 94% Ef ciency and load group information Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 13: Display Functions

    [Efficiency] % / [Battery] % min V n° EBM / [Battery remaining life] months / [Average power usage] Wh / [Cumulated power] Wh / BMS Information Control Go to Bypass Transfers the UPS on Bypass mode Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 14: User Settings

    IPv4], [Com card IPv6], [Com card MAC] Registration Links to Eaton registration website 2 2 . . 7 7 U U s s e e r r S S e e t t t t i i n n g g s s The following table displays the options that can be changed by the user.
  • Page 15 [Enabled] [Disabled] On/Off Settings [Timer] [10s] … [180s] [Enabled] When mains recover during a Forced reboot [10s] shutdown sequence: If set to Enabled, shutdown sequence will complete and wait 10 seconds prior to restart, If set Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 16 RS232. ROO port: - [Function]: [No] [ROO] [RPO] [Building [No] Com settings Input signals alarm] [Forced bypass] [On generator] [Remote shutdown] - [Delay]: [0s] … [999s] [0s] - [Active]: [Open] [Closed] [Closed] RPO port: Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 17 Sets events or fault that will actuate Output signal parameters through Shutdown external contact connector or RS232 commands port [Send CMD]: [Yes] [No] Send CMD: [No] [Output OFF]: [No] [UPS] [Group 1] Output OFF: [No] Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 18 [Bypass overload] [Current limit] [Short circuit] [Inverter overload] General alarm [Power overload] [Low battery] [On bypass] [UPS OK] [Load protected] [Load powered] [Ext. charger ON] Defines which event or fault generate a general alarm through Output signal screen. Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 19 C C h h e e c c k k i i n n g g t t h h e e A A c c c c e e s s s s o o r r y y K K i i t t Figure 3. 9PX1000IRTANZ-L / 9PX1500IRTANZ-L 21 22 23 •...
  • Page 20 Elements supplied depending on the version or optional Cable locking system NMC communication card (optional, standard on Software lea et Netpack versions) Safety instructions HotSwap MBP module (optional, standard on HotSwap versions) Connection cables between HotSwap MBP module and UPS Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 21: Checking The Accessory Kit

    If you ordered an optional Extended Battery Module (EBM), verify that the following additional items are included with the EBM: Battery power cable with attached battery detection cable Stabilizer bracket (4 screws included) Rack kit for 19-inch enclosures (optional) EBM Installation manual. Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 22 Always keep 6" or 150 mm of free space behind the UPS rear panel for ventilation. If installing additional cabinets, place them next to the UPS in their final location. • Adjustment of the orientation of the LCD panel and of the logo. Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 23: Rack Installation

    R R a a c c k k I I n n s s t t a a l l l l a a t t i i o o n n • Rack mounting of UPS, EBM, and accessory modules. Follow steps 1 to 4 for module mounting on the rails. Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 24: Connecting The Ebm(S)

    Connecting the EBM(s) The rails and necessary hardware are supplied by EATON. 3 3 . . 5 5 C C o o n n n n e e c c t t i i n n g g t t h h e e E E B B M M ( ( s s ) ) A small amount of arching may occur when connecting an EBM to the UPS.
  • Page 25 Battery Comm EBM 4 NOTE The EBM communication wiring connections are directional and must be connected in the correct sequence to ensure proper detection, regulation and lifecycle monitoring of the integrated battery management system (BMS). Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 26: Detecting Other Accessories

    D D e e t t e e c c t t i i n n g g o o t t h h e e r r A A c c c c e e s s s s o o r r i i e e s s Tip If you ordered other UPS accessories, refer to specific user manuals to check the connection to the UPS. Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 27: Ups Connection Without Hotswap Mbp Module

    Note. The UPS charges the battery as soon as it is connected to the AC-power source, even if the is not pressed. Once the UPS is connected to the AC-power source, eight hours of charging are required before the battery can supply the rated backup time. Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 28: Connection With A Hotswap Mbp Module ( Optional Accessory)

    3. Start the UPS by pressing the ON/OFF button on the UPS control panel. The load is supplied by the UPS. "UPS ON - OK to switch" on the HotSwap MBP module goes ON. Eaton 9PX Lithium-Ion P-164001006—Rev 01 HotSwap MBP module test 1. Set switch to Bypass position and check that the load is still supplied.

  • Page 29: Communication Ports

    USB or RS232 communication port on the UPS. The UPS can now communicate with EATON power management software. Installation of the communication cards It is not necessary to shutdown the UPS before installing a communication card.

  • Page 30: Ups Remote Control Functions

    To ensure the UPS stops supplying power to the load during any mode of operation, the input power must be disconnected from the UPS when the Remote Power Off function is activated. Leave the RPO connector installed in the RPO port on the UPS even if the RPO function is not needed. Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 31 UPS from the front panel. Normally Closed Plug the RPO connector into the back of the UPS and fix the screws. Connect and restart the UPS according to the previously described procedures. Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 32 INDGW-M2 card- has SNMP and HTTP capabilities and a Modbus to facilitate remote monitoring of the UPS system through any Building Management System. • Relay-MS card- has isolated dry contact (Form-C) relay outputs for UPS status: Utility failure, Battery Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 33 UPS or power information. If there is a power outage and the 9PX UPS battery power becomes low, Eaton Software suite can automatically shut down your computer system to protect your data before the UPS shutdown occurs.
  • Page 34 UPS Remote Control Functions Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 35 O O p p e e r r a a t t i i n n g g M M o o d d e e s s The Eaton 9PX front panel indicates the UPS status through the UPS indicators, see section 2.4 Control Panel...

  • Page 36: Ups Shutdown

    10 ms when utility fails. Transfers to High Efficiency mode will be active after 5 minutes of Bypass voltage monitoring: if Bypass quality is not in tolerance, then the UPS will remain in Online mode. Eaton recommends to use the HE mode only to protect IT equipment. To set the High Efficiency mode: Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 37: Configuring Bypass Settings

    R R e e t t r r i i e e v v i i n n g g t t h h e e E E v v e e n n t t L L o o g g To retrieve the Event log through the display: Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 38: Retrieving The Fault Log

    5 5 . . 1 1 0 0 R R e e t t r r i i e e v v i i n n g g t t h h e e F F a a u u l l t t L L o o g g To retrieve the Fault log through the display: Press any button to activate the menu options, then select Fault log. Scroll through the listed faults. Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 39 If you store the equipment for a long period, recharge the battery every 6 months by connecting the UPS to utility power. The internal batteries charge to 90% capacity in less than 3 hours. However, Eaton recommends that the batteries charge for 48 hours after long-term storage. Check the battery recharge date on the shipping carton label.

  • Page 40: Replacing Batteries

    11. If there are no EBM modules that need to be replaced continue to the 6.3 Battery Settings Reset section before restarting the unit. Replacing the EBM(s) The EBM is heavy. Lifting the cabinet into a rack requires a minimum of two people. To replace the EBM(s): Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 41: 6.3 Battery Settings Reset

    BMS auto setup to advance the menu Connectivity test Reset battery life Functions reset NMC card reset BMS auto setup Done Reset the battery life counter in the “Functions Reset” option of the control menu. Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 42 If optional EBMs are installed, verify that the EBM are connected to the UPS. See section . Verify that the UPS power cord is plugged in. The UPS front panel display illuminates and shows EATON logo. Verify that the UPS status screen shows Press the button on the UPS front panel for at least 2 seconds.

  • Page 43: Replacing The Ups Equipped With A Hotswap Mbp

    This symbol indicates that you should not discard waste electrical or electronic equipment (WEEE) in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center. Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 44: Recycling The Used Equipment

    Recycling The Used Equipment Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 45 T T y y p p i i c c a a l l A A l l a a r r m m s s a a n n d d F F a a u u l l t t s s The Eaton 9PX are designed for durable, automatic operation and also alert you whenever potential operating problems may occur.

  • Page 46: Silencing The Alarm

    UPS technical representative. Please have the following information ready when you call for service: • Model number • Serial number • Firmware version number • Date of failure or problem • Symptoms of failure or problem • Customer return address and contact information Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 47: Ce Compliance Contact

    C C E E C C o o m m p p l l i i a a n n c c e e C C o o n n t t a a c c t t • Eaton I.F. SAS - 110 Rue Blaise Pascal - 38330 Montbonnot St Martin – France. Eaton 9PX Lithium-Ion...
  • Page 48 CE Compliance Contact Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 49 23.8 x 17.3 x 3.4 / 605 x 440 x 86.5 50.2 / 22.8 9PXEBM48RT1U-L 17.6 x 17.2 x 1.7 / 448 x 438 x 42.9 36.5 / 16.6 9PXEBM72RT1U-L 23.7 x 17.2 x 1.7 / 603 x 438 x 42.9 46.6 / 21.2 Eaton 9PX Lithium-Ion P-164001006—Rev 01...

  • Page 50: Model Specifications

    Online mode: 102%~130% :12s 130%~150% :2s >150% :shutdown after 300ms Percent is based on nominal Watt/VA. Transfer behavior can change (see output mode setting) Battery mode: 102%~130% :12s >130% :2s >150% : shutdown after 300 ms Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 51 FCC part 15 Class B / ICES-003 EMC (Immunity)* IEC 61000-4-2, (ESD): 8 kV Contact Discharge / 15 kV Air Discharge IEC 61000-4-3, (Radiated field): 10 V/m IEC 61000-4-4, (EFT): Power (Coupling network) 4 kV / Ethernet (Coupling clamp) 2 kV Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 52 2000VA: 72Vdc 3000VA: 72Vdc Type Lithium Iron Phosphate (LFP) battery module Lithium-Ion float service life 8 years /25°C Monitoring Advanced monitoring for earlier failure detection and warning EBM Battery Cable Length 350 mm / 13.78 in Eaton 9PX Lithium-Ion P-164001006—Rev 01...
  • Page 53 Model Specifications Eaton 9PX Lithium-Ion P-164001006—Rev 01...
