Eaton 9PX G2

Advanced User Guide

MBP6K208G2

MBP6KIECG2

MBP11K208G2

English

Table of Contents

Need help?

Do you have a question about the 9PX G2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eaton 9PX G2

Page 2: Table Of Contents
Table of Content Special symbols ........................3 Introduction ........................4 2.1 Environmental protection ........................4 2.2 Benefits ..............................5 Presentation ........................5 3.1 Weights and dimensions ........................... 5 3.2 Rear Panel ..............................6 Installation .......................... 7 4.1 Inspecting the equipment: MBP package content..................7 4.2 MBP connection to UPS ..........................
Page 3: Special Symbols
1 Special symbols The following are examples of symbols used on the UPS or accessories to alert you to important information: DANGER: Dangerous voltage levels are present within the UPS. The UPS has its own internal power source (the battery). Consequently, the power outlets may be energized even if the UPS is disconnected from the AC power source.
Page 4: Introduction
Before installing your HotSwap MBP with your UPS, please read first the safety instructions. Then follow the indications in this manual, which completes the UPS Installation and User Manual. To discover the entire range of EATON products, we invite you to visit our web site at www.eaton.com/ powerquality or contact your EATON representative 2.1 Environmental protection...
Page 5: Benefits
2.2 Benefits The Eaton® HotSwap MBP module makes it possible to service or even replace the UPS without affecting the connected loads (HotSwap function). You can safely eliminate the effects of UPS maintenance and guard the integrity of your equipment.
Page 6: Rear Panel
3.2 Rear Panel MBP rear panels MBP6K208G2 ① Input/Output terminal blocks MBP6KIECG2 ② Input/Output/MBP-Detection connector to the UPS ③ Manual Bypass switch ④ MBP-Detection connector to the UPS ⑤ Normal AC source switch ⑥ Sockets: MBP6K208G2: 2 x L6-20P + 2 x L6-30P MBP6KIECG2: 1 x C39 + 1 gang of 2 x C39 &...
Page 7: Installation
4 Installation 4.1 Inspecting the equipment: MBP package content If any equipment has been damaged during shipment, keep the shipping cartons and packing materials for the carrier or place of purchase and file a claim for shipping damage. If you discover damage after acceptance, file a claim for concealed damage.
Page 8: Mbp Connection To Ups
4.2 MBP connection to UPS Note: In the configuration "UPS + EBM", the MBP must be mounted at the back of EBM. Mechanical installation in rack position For the MBP11K208G2 used with 8000VA and 11000VA UPS, depending on the configuration, there are two different assemblies, identified with letters (UPS only) and (UPS+EBM).
Page 9 Follow the steps below to install the MBP in rack position. 1. Screw the ears on each MBP side. MBP6K208G2 used with 3000VA, 5000VA and 6000VA UPS MBP11K208G2 used with 8000VA and 11000VA UPS 2. Mount the MBP with its ears on the UPS rack. MBP6K208G2 used with 3000VA, 5000VA and 6000VA UPS MBP11K208G2 used with 8000VA and 11000VA UPS...
Page 10 MBP6KIECG2: Final assembly position: MBP6KIECG2 used with 6000VA IEC UPS MBP6KIECG2 used with 6000VA IEC UPS and 180V EBM Follow the steps below to install the MBP in rack position. 1. Screw the ears on each MBP side. 2. Mount the MBP with its ears on the rack.
Page 11 Mechanical installation in tower position Depending on the configuration, there are four different assemblies, identified with letters A, B, C and D. The different ways to mount the MBP with the UPS or the "UPS+EBM" are identified by the A, B, C & D letters. MBP6K208G2 and MBP11K208G2: Final assembly position: MBP6K208G2 used with 3000VA, 5000VA and 6000VA UPS...
Page 12 Follow the steps below to install the MBP in tower position. Screw the ears on each MBP side. MBP6K208G2 used with 3000VA, 5000VA and 6000VA UPS MBP11K208G2 used with 8000VA and 11000VA UPS Mount the MBP with its ears on the UPS or EBM MBP6K208G2 used with 3000VA, 5000VA and 6000VA UPS.
Page 13 MBP6KIECG2: Final assembly position: MBP6KIECG2 used with 6000VA IEC UPS MBP6KIECG2 used with 6000VA IEC UPS and EBM Follow the steps below to install the MBP in tower position. Screw the ears on each MBP side. Mount the MBP with its ears on the UPS or EBM...
Page 14 MBP electrical connection Caution: switch off utility power to the distribution point where the MBP will be connected. Be absolutely sure there is no power. Access to the terminal block Detach the knockouts from the AC terminal wiring box and install the cable glands included in the MBP accessory kit.
Page 15 Insert the electrical cables. Follow below instructions for upstream protection and cable cross section. Use copper cable only, and not aluminum. Recommended upstream protection MBP rating at 208V Upstream circuit breaker (CB) MBP 6k 5400VA/4800W with 6kVA UPS D curve 2 poles – 30A MBP 11k 8000VA/8000W with 8KVA UPS D curve 2 poles –...
Page 16 Strip the copper supply cable keeping the Earth cable longer for safety purpose. Insert the cables MBP 6k MBP 11k Tighten well the cable glands MBP 6k MBP 11k Close the I/O box terminal MBP 6k MBP 11k...
Page 17 Connection between MPB and UPS For the electrical connection on the UPS side, refer to the UPS User Manual Connect the MBP cord set (For 6k MBP only) Connect the MBP detection cable to the UPS Power up your installation Switch on the input circuit breaker of your installation.
Page 18: Operation
5 Operation 5.1 UPS start-up with HotSwap MBP Verify that the total equipment ratings do not exceed the UPS capacity to prevent an overload alarm. 1. Check that the UPS is correctly connected to the HotSwap MBP. If the UPS if equipped with outlets, those outlets can no longer be used (loads can only be connected to the MBP outlets or the MBP Output terminal blocks 2.
Page 19: Ups Maintenance With Hotswap Mbp
6 UPS maintenance with HotSwap MBP 6.1 UPS replacement with HotSwap MBP UPS Removing (please follow the MANDATORY step below). MBP6K208G2 and MBP6KIECG2: UPS replacement must be performed by qualified person only. For the following steps, refer to the UPS User Manual : •...
Page 20 MBP11K208G2: UPS replacement must be performed by qualified person only. BYPASS For the following steps, refer to the UPS User Manual : • Put the UPS in “Bypass mode” (“Control -> Go to bypass”). • Verify that the UPS is on Bypass mode by checking UPS display panel Set the MBP manual Bypass switch to "Bypass"...
Page 21 Return to normal operation: Check that the new UPS is correctly connected to the MBP, as described below: MBP6K208 and MBP6KIECG2: • After opening the UPS I/O terminal blocks cover, connect to UPS the 2 power cables, and the MBP detection cable, of the MBP I/O cord Set •...
Page 22: Ups Maintenance With Hotswap Mbp
6.2 UPS maintenance with HotSwap MBP Go to maintenance Bypass operation (please follow the MANDATORY steps below): For the following steps, refer to the UPS User Manual • Put the UPS in " Bypass mode" BYPASS • Verify that the UPS is on Bypass mode by checking UPS display panel 2.
Page 23: Specification And Technical Characteristics
7 Specification and technical characteristics MBP6K208G2 MBP11K208G2 MBP6KIECG2 Input Terminal blocks Output 2 x L6-20P 4 x L6-30P 1 x C39 2 x L6-30P 2 x C39 & 2x C13 Overall dimensions D x W x H (inch / mm) 4.9x5.1x9.4 / 5.1x5.1x11.2/ 4.9x5.1x9.4 /...
