User's Manual
FLUOVIEW
FVMPE-RS
Multi Photon Laser Scanning Microscope
Notice
Optical Microscope and Accessory
Thank you for your purchase of Olympus microscope at this time.
Retain this manual in an easily accessible place near a system for future reference.
- Research use only -
AX8334

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLUOVIEW FVMPE-RS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Olympus FLUOVIEW FVMPE-RS

Summary of Contents for Olympus FLUOVIEW FVMPE-RS

  • Page 1 Multi Photon Laser Scanning Microscope Notice Optical Microscope and Accessory Thank you for your purchase of Olympus microscope at this time. Retain this manual in an easily accessible place near a system for future reference. - Research use only -...
  • Page 3 • Service “Service” means any adjustment or repair performed by Olympus service personnel or technical personnel who are provided the service training according to the service manual provided by Olympus. The performance has influence on the feature of this system, and there is a risk that unintended CLASS 4 laser light is emitted.

  • Page 4: Registered Trademarks

    Registered Trademarks Registered Trademarks Microsoft, Microsoft Windows, Excel for Windows are registered trademarks of Microsoft Corporation. Mai Tai ® , InSigh , and DeepSee are registered trademarks of Newport Corporation. Chameleon , OBIS , and Sapphire are registered trademarks of Cohelent Inc.. ProScan is registered trademark of Prior Scientific Ltd..

  • Page 5: Safety Manual

    Safety Manual On this volume This volume describes warnings and cautions for your safety use of this system. Before use, be sure to observe all the warnings and cautions. In case this system is used in other methods than those described in this manual, the safety cannot be insured and a system failure may occur.
  • Page 7 In accordance with European Directive on Waste Electrical and Electronic Equipment, this symbol indicates that the product must not be disposed of as unsorted municipal waste, but should be collected separately. Refer to your local Olympus distributor in EU for return and/or collection systems available in your country. Research Use Only This product does not conform to FCC Part15 Class A.

  • Page 8: Table Of Contents

    Contents 1 Safety caution ............................ 1-1 Transportation and modification of this system ................1 1-2 Waste of system ................................1 1-3 Handling precautions ..............................2 Mechanical (heat) precaution ..............................2 Electrical precaution ....................................3 Laser precaution .....................................4 1-4 Necessary Actions ..............................8 Appointing a laser safety officer ..............................8 Laser controlled areas (warning signs and off-limits) ....................9 Preparing and wearing preventive eye glasses and protective clothes ..........10 Ophthalmologic examination ..............................10...

  • Page 9: Safety Caution

    • The used mercury lamp in this system must be disposed of as industrial waste. If you cannot dispose CAUTION of it properly, please contact Olympus. • In order to replace the lithium coin battery built in the touch panel controller in this system, please contact our sales office in your local area.

  • Page 10: Handling Precautions

    1-3 Handling precautions CAUTION • Also, refer to the part related to safety in manuals of surrounding units. However, if the following units are used in this system, the manuals provided with those units are not effective. See this manual about usage of those units. •...

  • Page 11: Electrical Precaution

    EMC performance of the device can not be assured. • Always use the power cord provided by Olympus. If no power cord is provided, please select the proper power cord by referring to the section "PROPER SELECTION OF THE POWER CORD" at the end of the safety manual.

  • Page 12: Laser Precaution

    Laser precaution This system is specified as a laser product of the class as shown below, depending upon the laser to be combined. (1) Laser combination CLASS 4 (IEC60825-1:2007) This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No.50, dated June 24, 2007 Laser products of Class 4 are products that can only be used under control of laser safety officer.
  • Page 13 FVMPE-RS • Direct light, specular reflected light and diffused reflection light of laser are dangerous. CAUTION • The laser used in this system is dangerous because the wavelength of the laser is an invisible near- infrared light. • Total laser radiation emitted from this system are as follows: MPE (Maximum Permissible Exposure): 0.016 J/m (for a single pulse)
  • Page 14 • Do not bend or pull the optical fiber cable with an excessive force or step on it. If the optical fiber cable is damaged, the laser light may leak outside it and cause an extremely hazardous situation. Should such an event occur, immediately turn off the laser power and contact your local Olympus representative.
  • Page 15 FVMPE-RS Eye damage CAUTION • Invisible laser emitted from this system focuses on retina of the eyeball. • If the laser enters into your eyes, the retina may be damaged to result in blindness, etc. • Get the protective eyewear matching class and wavelength of the laser of this system. •...

  • Page 16: Necessary Actions

    1-4 Necessary Actions OLYMPUS would like to take this opportunity to ask the customer to establish a system to ensure laser safety in line with the customer’s facility. The items necessary for ensuring laser safety are listed below. Appointing a laser safety officer Please take actions to ensure laser safety with a laser safety officer at the center of such activities.

  • Page 17: Laser Controlled Areas (Warning Signs And Off-Limits)

    FVMPE-RS Laser controlled areas (warning signs and off-limits) The area where a laser beam of class 3B or above is emitted is defined as laser control area. Define the room where this system is set up as laser control area. Place a warning sign near to each of the laser controlled areas that includes the following information: ·...

  • Page 18: Preparing And Wearing Preventive Eye Glasses And Protective Clothes

    Preparing and wearing preventive eye glasses and protective clothes In Laser Hazard Area, it is essentially required to wear eye protector and protective clothing. For this reason, in case a microscope should be operated, or a specimen should be set, wear the eye protector. 1 Using protective glasses Get the protective glasses matching class and wavelength of the laser of this system.

  • Page 19: Safety Functions Of This System

    This system is provided with the safety measures corresponding to the specifications required for class 4 laser products. CAUTION These safety functions are ensured in the state in which OLYMPUS delivers the microscope. Do not attempt to disassemble the microscope or the laser unit.

  • Page 20: Warning Labels

    Warning labels Safety symbols The following symbols are found on this system. Study the meaning of the symbols, and always use this system in the safest possible manner. Symbol Explanation Indicates that the surface becomes hot, and should not be touched with bare hands.

  • Page 21: Laser Safety Warning Labels

    FVMPE-RS 2-1 Laser safety warning labels Warning labels Type of labels attached to a laser system may be different, depending upon laser combination in your possession. Location attached • FV30-HSUMP Hybrid scanning unit for MPE (FV30-HSUMP)

  • Page 22: Aperture Label

    Aperture label Laser emits from the place where the above label exists and the arrow indicates. • BX63LF Laser aperture External laser...
  • Page 23 FVMPE-RS • FV30GF Laser aperture External laser...

  • Page 24: Protective Housing Labels

    Protective housing labels } As labels are attached to many places, the label positions are shown per unit later in this section. Product unit name BX63LF FV30-COMB4 FV30-LCU FV30-LCUMP 405nm Laser FV30- ADP405 Non descan DM 458nm Laser FV30- ADP458 FV30-NDM690 LSM Mirror FV30-NDM760...
  • Page 25 FVMPE-RS FV30GF FV30-COMB4 FV30-LCU FV30-LCUMP 405nm Laser FV30- ADP405 458nm Laser FV30- ADP458 FV30- U-AW 588nm Laser FV30-LCUMP U-FFWADP ADP588 U-LLG300 U-HGLGPS Non descan DM FV30-NDM690 LSM Mirror FV30-FURBB FV30-NDM760 Fluorescence Cube DM for SIM scanner FV30-NDMVCOIR FV30-ADM800 U-IFCBL100 FV30-LASA FV30-LAUS FV30-SIMMP FV30-ADMOPT...
  • Page 26 One laser system IR Laser FV30-LASA FV30-LAUS FV30-LASB IR Laser FV30-LASA FV30-LAUS FV30-LASB...
  • Page 27 FVMPE-RS Twin laser system IR Laser IR Laser FV30-LAUT FV30-LATAA FV30-LATAB IR Laser IR Laser FV30-LATAA FV30-LATAB FV30-LAUT...
  • Page 28 Dual lines system IR Laser FV30-LADAB FV30-LAUT IR Laser FV30-LADAB FV30-LAUT...
  • Page 29 FVMPE-RS Microscope and scan unit BX63LF FV30-HSUMP FV30-ETTR FV30-TBSUB FV30-RFABXL U-LLG300 FV30-TXDBX FV30-LAUS BX63L-NPA40 BX63LF BX63L-SVLAD FV30-BPBXL FV30GF FV30-ETTR FV30-HSUMP FV30-TBSUG FV30-RFABXL U-LLG300 FV30-LAUS FV30GF...
  • Page 30 BX63LF FV30-SIMMP FV30-HSUMP FV30-ETTR FV30-TBSIMB FV30-FURBB FV30-RFABXL FV30-TBSUB U-LLG300 FV30-TXDBX FV30-LAUT BX63L-NPA40 BX63LF BX63L-SVLAD FV30-BPBXL FV30GF FV30-ETTR FV30-SIMMP FV30-HSUMP FV30-TBSIMG FV30-TBSUG FV30-RFABXL FV30-FURBB U-LLG300 FV30-LAUT FV30GF...
  • Page 31 FVMPE-RS Detector FV30-RXD FV30-TXDBX FV30-ARXD FV30-RXD FV30-TXDBX FV30-AGAPD FV30-RXD FV30-TXDBX...
  • Page 32 Detail view • FV30-HSUMP...
  • Page 33 FVMPE-RS • FV30-SIMMP...
  • Page 34 • FV30-LAUS One laser system • FV30-LASA FV30-LASB...
  • Page 35 FVMPE-RS • FV30-LATAA FV30-LATAB Twin laser system • FV30-LAUT Dual lines system • FV30-LADAB...
  • Page 36 • FV30-TBSUB FV30-TBSIMB...
  • Page 37 FVMPE-RS • FV30-TBSUG FV30-TBSIMG...
  • Page 38 • FV30-RFABXL BX63LF...
  • Page 39 FVMPE-RS • FV30-RFABXL FV30GF...
  • Page 40 • FV30-RXD Open...
  • Page 41 FVMPE-RS • FV30-ARXD Open...
  • Page 42 • FV30-AGAPD Open...
  • Page 43 FVMPE-RS • FV30-TXDBX...
  • Page 44 • FV30-TD...
  • Page 45 FVMPE-RS • FV30-COMB4 • FV30-ADP405 • FV30-ADP458 • FV30-ADP588...
  • Page 46 • FV30-FURBB...

  • Page 47: Heat Safety Warning Label

    FVMPE-RS 2-2 Heat safety warning label • U-LH100IR...
  • Page 48 • U-LH100...
  • Page 49 FVMPE-RS • U-AW...
  • Page 50 • U-HGLGPS...

  • Page 51: Finger Safety Warning Label

    FVMPE-RS 2-3 Finger safety warning label...
  • Page 52 • BX63LF Though protection bin labels are attached to other places than the places indicated in this manual, the said labels are intended for our service personnel. CAUTION In case the warning label is blurred or peeled off and, if it should be replaced or if you need help, contact our local sales office immediately.

  • Page 53: Specifications

    FVMPE-RS Specifications 3-1 Specifications of units · Dimensions and weights Unit Specifications FV30-COMB4 Dimensions (mm) 400 (Depth) X 402 (Width) X 200 (Height) Weight 12.4 kg BX63LF Dimensions (mm) Microscope frame: 294.4 (Depth) X 413.2 (Width) X 347.5 (Height) Touch panel controller: 211 (Depth) X 190 (Width) X 105 (Height) Weight Microscope frame: 11 kg Touch panel controller: 2.4 kg...
  • Page 54 Unit Specifications BX63L-SVLAD Dimensions (mm) Long pillar unit: Ø 16 X 200.4 (Height) Middle pillar unit: Ø 16 X 160.4( (Height) Short pillar unit: Ø 16 X 46 (Height) Weight Long pillar unit: 0.3 kg Middle pillar unit: 0.23 kg Short pillar unit: 0.04 kg XLPLN25XWMP2 Dimensions (mm)
  • Page 55 FVMPE-RS Unit Specifications FV30-TXDBX Dimensions (mm) 333 (Depth) X 288 (Width) X 133 (Height) Weight 5.2 kg FV30-LCU Dimensions (mm) 510 (Depth) X 426 (Width) X 194 (Height) Weight 14 kg FV30-FURBB Dimensions (mm) Coupling lens unit: Ø 24 X 63.5 (Length) Fiber unit: Ø...
  • Page 56 Unit Specifications FV30-LAUS Dimensions (mm) 580 (Depth) X 565 (Width) X 180 (Height) Weight 15.5 kg FV30-LAUT Dimensions (mm) 750 (Depth) X 635 (Width) X 180 (Height) Weight 30.5 kg FV30-LCUMP Dimensions (mm) 510 (Depth) X 426 (Width) X 195 (Height) Weight 13.6 kg FV30-LASA...
  • Page 57 FVMPE-RS · FVMPE-RS Power supply rating Item Name Rating FV30-PSU Power supply and electronic control unit AC 100-120 V/220-240 V 5.0 A/2.3 A 50/60 Hz FV30-LCU Laser control unit AC 100-120 V/220-240 V 1.2 A/0.63 A 50/60 Hz FV30-LCUMP MPE laser control unit AC 100-120 V/220-240 V 1.5 A/0.76 A 50/60 Hz...

  • Page 58: Specifications Of Compatible Lasers

    690-1040 nm Chameleon VisionII Olympus 680-1080 nm Chameleon Vision S Olympus 690-1050 nm } For detail specifications of the IR pulse laser, refer to the materials provided by COHERENT or Spectra-Physics. } There are items which must be confirmed before starting or exiting the IR pulse laser. For details, refer to "2-5...
  • Page 59 FVMPE-RS } The table below shows the tolerance of the laser entering each port. FV30-HSUMP FV30-SIMMP IR port IR port Vis port Applicable 700-1300 nm 700-1100 nm 400-650 nm wavelength Tolerable 764 W/cm 382 W/cm 6.4 W/cm power density Converted to average power Converted to average power ·...

  • Page 60: Proper Selection Of The Power Supply Cord

    If no power supply cord is provided, please select the proper power supply cord for the equipment by referring to “Specifications” and “Certified Cord” below; CAUTION: In case you use a non-approved power supply cord for Olympus products, Olympus can no longer warrant the electrical safety of the equipment.
  • Page 61 FVMPE-RS Table 2 HAR flexible cord Approval organizations and cordage harmonization marking methods Alternative Marking Utilizing Printed or Embossed Harmoniza- Black-Red-Yellow Thread tion Marking (May be located on (Length of color section in mm) Approval Organization jacket or insulation of internal wiring) Black Yellow...
  • Page 63 Operation / Maintenance Manual...
  • Page 65 FVMPE-RS Precautions and notes for glare prevention When excitation filter is removed from the fluorescence mirror unit When the excitation filter is removed from the fluorescence mirror unit and attached on the excitation filter slider or exci- tation filter wheel on the side of the white lamp, very glaring light (*1) may enter the eyepieces in the following cases. When the illumination light from the white light lamp (*2) is input without passing through an excitation filter.
  • Page 66 Opening and closing of the shutter to shield the light of the white light lamp By pushing the FL SHUTTER button on the attached controller, U-MCZ, you can switch between irradiation and blocking of the illumination light. FL SHUTTER Button* * The FL SHUTTER button opens/closes the reflected shutter only.
  • Page 67 Contents 1 System outline ..................................1 1-1 Features of FVMPE-RS ....................................1 1-2 Features of each system ..................................2 External NDD (Non-Descanned Detector) unit ..............................2 1-3 Allowable work area when attaching/removing units...................3 1-4 System configuration ....................................5 System diagram ..............................................5 1-5 Confirmation when working with FVMPE-RS .........................7 Key operation ................................................7 Checking the emission indicator .....................................7 2 Precautions for use ...............................8...
  • Page 68 4-2 Stages (Operation/Maintenance)..............................18 How to install the stage (Maintenance) ..................................18 Placing the specimen (Operation) ....................................21 Moving the specimen (Operation) ....................................22 Setting the grounding (Maintenance) ..................................23 Adjusting the X-axis/Y-axis knob rotation tension (Operation) ....................................... . 23 Using the light shielding sheet (Operation)...............................24 4-3 Microscope BX63LF (Operation/Maintenance) ......................25 Using the Filters (Maintenance) (BX63LF only) ..............................25...
  • Page 69 4-7 Mercury lamp (for U-HGLGPS) (Operation) ........................35 Turning on the lamp ............................................35 Turning off the lamp ............................................35 Adjustment of the brightness ......................................36 Counter display ..............................................36 Lighting display LED ............................................36 5 How to assemble each NDD unit ......................38 5-1 External NDD unit (reflected right) (Maintenance)....................39 Unit structures ................................................39 Attaching and removing the cover (FV30-RXD) ..............................41 Attaching and removing the fluorescence cube (FV30-RXD) .......................42...
  • Page 70 5-4 Fluorescent mirror unit and DM unit (Maintenance) ....................56 Fluorescence mirror unit (IX3-FFXL)....................................56 DM Unit for the SIM Scanner (FV30-ADMOPT) ...............................59 6 Visual observation / observation using a camera ..............60 6-1 Touch panel controller (Operation/Maintenance) ....................60 Basic operations of touch panel controller (Operation/Maintenance) ..................60 Starting the touch panel controller (Operation/Maintenance) .
  • Page 71 Differential interference contrast (DIC) observation (Operation/Maintenance) 72 Adjusting the polarizer position (Maintenance) ..............................72 Observation method (Operation).......................................75 7 LSM observation (Operation) ..........................76 8 Signal connection with external device ....................77 8-1 Features of FV30-ANALOG ..................................77 8-2 Specifications of FV30-ANALOG ..............................77 8-3 Setting procedure ......................................81 Setting analog input range from external devices .............................81 Connection ...................................................82 Acquiring analog voltage input signal ..................................82...

  • Page 73: System Outline

    FVMPE-RS System outline 1-1 Features of FVMPE-RS · It is possible to perform high-speed observation using the resonant scanner. · High definition can be achieved using the galvanometer scanner. · It is possible to generate automatically a beam most suitable to the objective lens and laser wavelength, providing high efficiency and resolution imaging.

  • Page 74: Features Of Each System
