Summary of Contents for Empava EMPV-30GC21-GX
- Page 1 INSTRUCTION MANUAL GAS COOKTOP EMPV-30GC21-GX Distributed by: Empava Appliances Inc. 15253 Don Julian Rd, City of Industry, CA 91745 USA www.empava.com Phone: +1(888)682 8882 Email: support@empava.com...
- Page 2 Read the instructions before installing or using this appliance. This appliance shall be installed in accordance with the regulations in force and only used in a well- ventilated space. The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 or, in Canada, the Natural Gas and Propane Installation Code, CSA B149.1.
-
Page 3: Table Of Contents
Contents Important Safety Information ........................1 Installation .................................3 Cooktop Description ............................4 Technical Date ..............................5 Operation Lighting a Surface Burner ............................5 Selecting a Flame Size ............................6 Cooktop Cookware ................................7 Cookware Size ...................................8 Maintenance and Cleaning Cleaning Knobs ................................9 Cleaning Cooktop Surface ............................ -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE If the information in these instructions is not followed exactly, a fire or explosion may result, causing property damage, personal injury or death. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. -
Page 5: General Safety Instructions
IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE GENERAL SAFETY INSTRUCTIONS ■ Use this appliance for its intended purpose as described in this owner’s manual. ■ It is dangerous to store stuff in cabinet areas above appliance. ■ Have your cooktop installed and properly grounded by a qualified installer in accordance with the provided installation instructions. -
Page 6: Installation
Installation ■ Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment of the appliance are compatible. ■ The adjustment conditions for this appliance are stated on the label (or data plate). ■... -
Page 7: Cooktop Description
Cooktop Description EMPV-30GC21-GX... -
Page 8: Technical Date
Technical Date NG: Manifold pressure Propane: Manifold pressure Gas type 4” W.C.P. 10” W.C.P. Injector diameter(mm) Btu/hr Injector diameter(mm) Btu/hr Wok burner 2.38 20000 1.30 20000 Rapid burner 1.55 10500 0.96 10500 Semi-Rapid burner 1.35 8000 0.85 8000 Auxiliary burner 0.97 4500 0.65... -
Page 9: Selecting A Flame Size
If in case of a power failure or failure of the ignition, a match or lighting devise can be used. Care must be taken when using this method. The device shall not be operated for more than 15s. If after 15s the burner has not lit, stop operating the device and open the compartment door and/ or wait at least 1 min before attempting a further ignition of the burner. -
Page 10: Cooktop Cookware
WARNING: Users could not use the cooking vessels on the hotplate that overlap its edges. WARNING: All burner caps can’t be dislocated installation, otherwise it will lead to flash back on the upper aluminum seats and cause the upper aluminum seats to melt and deform, see below figures for correctly placing the burner caps. -
Page 11: Cookware Size
Cookware Size ■ Set the cooktop to a high flame when using a large diameter cookware and low flame when using small diameter cookware. ■ Generally, wide/shallow cookware will heat quicker and cook more evenly than narrow/tall ones. ■ Using oversized cookware may cause the flames to spread out and damage the surrounding countertop or other countertop appliances. -
Page 12: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the gas cooktop from the electricity supply. The gas cooktop is best cleaned while it is still warm; as spillage can be removed more easily than if it is left to cool. -
Page 13: Cleaning Burner Grates
4. Use a paper towel or a non-scratch cleaning pad for ceramic cooktops to clean the entire cooktop surface. 5. Use a dry cloth or paper towel to remove all cleaning residue. No need to rinse. Cleaning Burner Grates Grates should be washed in hot, soapy water and rinsed with clean water. To soften burned-on food, place grates in a solution containing ¼-cup of household ammonia for several hours. -
Page 14: Installation Guide
Installation Guide The cooktops may be located in a kitchen, a kitchen/diner or bed sitting room, but not in a bathroom, shower room or garage. Before making the cut out in the worktop ensure that there is a minimum distance of 2-1/2" between the rear edge of the cooktops and the wall. - Page 15 Model A. Width B. Depth C. Height Width Case Depth EMPV-12GC29 305(12) 533(21) 61.5(2.42) 265(10.43) 483(19) EMPV-30GC5B70C-GX 762(30) 533(21) 48.5(1.90) 711(28) 483(19) EMPV-30GC21-GX 762(30) 533(21) 48.5(1.90) 711(28) 483(19) EMPV-30GC63-GX 762(30) 533(21) 48.5(1.90) 711(28) 483(19) EMPV-30GC26-GX 762(30) 533(21) 55(2.17) 711(28) 483(19)
-
Page 16: Gas Supply
GAS SUPPLY Explosion Hazard: Do not exceed 25 ft-lbs of torque when making gas line connections. Overtightening may crack the pressure regulator resulting in fire or explosion hazard. Gas Pressure Regulator You must use the gas pressure regulator supplied with this range. For proper operations the inlet pressure to the regulator should be as follows! Gas Type Manifold pressure: Natural gas pressure at 4"... -
Page 17: Electrical Connections
ELECTRICAL CONNECTIONS This appliance is equipped with a (three-prong) grounding plug for your protection against shock hazard and should be plugged directly into a properly grounded receptacle. Do not cut or remove the grounding prong from this plug. Electrical Requirements-120-volt, 60 Hertz, properly grounded circuit protected by a15-amp or 20-amp circuit breaker or time delay fuse. -
Page 18: Converting To Type Of Propane
Circuit diagram Figure 13 Figure 15 Converting To Type Of Propane This appliance can be used with Propane and Natural gas. lt is shipped from the factory adjusted for use with Natural gas: Conversion orifices are located in accessories package. Follow the instructions packaged with the orifices for gas conversion. - Page 19 Save the orifices removed from the appliance for future use. 1. Air supply valve and cooktop valve need to be closed, unplug the power plug for AC model. 2.When the gas pressure regulator is in NG state and need to be converted to Propane regulator, and then counter clock wise unscrew the marked NG threaded rod, reverse the threaded rod, turn the LP arrow upwards and tighten it to the screw cap, then install the cap back to the gas pressure regulator.
- Page 20 Figure 16 8.Similarly, when use in NG status, turn the marked NG arrow upwards and tighten it to the screw cap (see Figure 16). Repeat the above operation. The outlet pressure requires to be 4 ± 1in w.c. 9.After the conversion is completed, the conversion label in the accessory bag needs to be attached next to the original label.
-
Page 21: Converting To Type Of Ng
NG: Manifold pressure Propane: Manifold pressure Gas type 4” W.C.P. 10” W.C.P. Injector diameter(mm) Btu/hr Injector diameter(mm) Btu/hr Wok burner 2.38 20000 1.30 20000 Rapid burner 1.55 10500 0.96 10500 Semi-Rapid burner 1.35 8000 0.85 8000 Auxiliary burner 0.97 4500 0.65 4500 Converting To Type Of GN... -
Page 22: Adjusting Low Flame Setting On Cooktop Burners
Adjusting low flame setting on cooktop burners Low setting adjustments must be made with 4 other burners in operation on a medium setting. This procedure prevents the low flame from being set too low, resulting in the flame being extinguished when other burners are turned on. -
Page 23: Trouble Shooting
Trouble Shooting PROBLEM POSSIBLE CAUSES WHAT TO DO Control knobs will not To turn from the OFF position, push the Knob isn’t pushed down. turn knob down and then turn. Check plugged in and switched on. No power. Check mains circuit breaker. No spark when control Loose sparker cable. -
Page 24: Warranty Card
Simply fill in the fields below and print form. Send Completed Form to: Customer Service:(888)-682-8882 Empava Appliances Inc. Warranty/ Registration Dept. 15253 Don Julian Rd City of Indstry, CA, 91745 WARRANTY CARD PLEASE READ AGREEMENT BEFORE SIGNING Click Here Keep this copy for yourself.
