INSTRUCTION MANUAL
24 " :EMPV-24GC4B67A EMPV-24GC4L67A
30 " :EMPV-30GC5B70C EMPV-30GC5L70A
34 " :EMPV-34GC5B90A EMPV-34GC5B90C EMPV-34GC5L90A
36" : EMPV-36GC5B90S EMPV-36GC5L90I
Distributed by:
Empava Appliances Inc.
15253 Don Julian Rd, City of Industry, CA 91745 USA
www.empava.com
The instructions shall be marked with directions to the installer to leave them with
the appliance and to the consumer to retain them for future reference.
GAS COOKTOP
Appliance Class: 3
Empava Item #:
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Empava EMPV-24GC4B67A
Summary of Contents for Empava EMPV-24GC4B67A
-
Page 1: Gas Cooktop
INSTRUCTION MANUAL GAS COOKTOP Appliance Class: 3 Empava Item #: 24 " :EMPV-24GC4B67A EMPV-24GC4L67A 30 " :EMPV-30GC5B70C EMPV-30GC5L70A 34 " :EMPV-34GC5B90A EMPV-34GC5B90C EMPV-34GC5L90A 36" : EMPV-36GC5B90S EMPV-36GC5L90I Distributed by: Empava Appliances Inc. 15253 Don Julian Rd, City of Industry, CA 91745 USA www.empava.com... - Page 2 WARNING: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
-
Page 3: Table Of Contents
Contents ◆ Cooktop Description ◆ Important Information ◆ Operation ◆ Maintenance and Cleaning ◆ Troubleshooting ◆ Instructions for the Installer ◆ Important safety requirements ◆ Installation This appliance shall be installed in accordance with the regulations in force and only used in a well- ventilated space. -
Page 4: Cooktop Description
Cooktop Description Operating Instructions: EMPV-24GC4B67A Knob 5 is for burner 4 Knob 6 is for burner 1 Knob 7 is for burner 3 Knob 8 is for burner 2 Figure 1 1.burner 1 — 3400Btu/hr in 1.77” 2.burner 2 — 12000Btu/hr in 5.20"... -
Page 5: Operating Instructions
EMPV-34GC5B90A Operating Instructions: Knob 1 is for burner 10 Knob 2 is for burner 9 Knob 3 is for burner 8 Knob 4 is for burner 7 Knob 5 is for burner 6 Figure 5 1.burner 6—6000Btu/hr in 2.56" 2.burner 7—10200Btu/hr in 3.74"... -
Page 6: Important Information
EMPV-36GC5L90I Operating Instructions: Knob 1 is for burner 10 Knob 2 is for burner 9 Knob 3 is for burner 8 Knob 4 is for burner 7 Figure 9 Knob 5 is for burner 6 1.burner 6—6000Btu/hr in 2.56" 2.burner 7—10200Btu/hr in 3.74"... - Page 7 For your Safety ➢ This gas cooktop is designed to be operated by adults. Do not allow children to play near or with the gas cooktop. ➢ The gas cooktop gets hot when it is in use. ➢ Children should be kept away until it has cooled. ➢...
-
Page 8: Operation
Operation Lighting ◆ Simply press the knob in, turn anticlockwise to ignition position(star icon) . ◆ Press the ignition device and hold the knob till the burner is ignited ◆ Before releasing knob, ensure a flame is established, ◆ If the burner fails to ignite, put into off position and try again. If in case of a power failure or failure of the ignition, a match or lighting devise can be used. -
Page 9: Maintenance And Cleaning
WARNING: All burner caps can’t be dislocated installation, otherwise it will lead to flash back on the upper aluminum seats and cause the upper aluminum seats to melt and deform, see below figures for correctly placing the burner caps Figure 11 Re-ignition: If the flame is out for certain reasons, the safety device will cut off the gas power automatically. -
Page 10: Troubleshooting
Thermocouple The thermocouple is very crucial for cutting gas supply in case of flame out during cooking, be sure to keep them in very clean condition. Maintenance instructions suggesting (We suggest to clean it every six months.): 1) Keeping appliance area clear and free from combustible materials, gasoline, and other flammable vapors and liquids. -
Page 11: Important Safety Requirements
Cut out dimensions For Model Width Depth 24GC4B67A, 24GC4L67A 21.85in 18.70in 30GC5B70C, 30GC5L70A 28.55in 18.70in 34GC5B90A, 34GC5B90C, 34GC5L90A, 36GC5L90I 32.88in 18.70in 36GC5B90S 34.06in 18.70in Technical Data Burner configuration Nozzles Dia. (mm) Btu/hr Nozzles Dia. (mm) Btu/hr Wok burner(Triple ring burner) 1.62 12000 1.06... - Page 12 Figure 12 WARNING: The use of a gas cooking appliance results in the production of heat and moisture in the room in which it is installed. Ensure that the kitchen is well ventilated especially when the appliance is in use. Keep natural ventilation holes open or install a mechanical ventilation device. Prolonged intensive use of the appliance may call for additional ventilation, for example opening of a window, or more effective ventilation, for example increasing the level of mechanical ventilation where present.
- Page 13 All cord connected appliances shall include instructions relative to location of the wall receptacle and a warning to the user to disconnect the electrical supply before servicing the appliance. Socket needs to be installed below the cooktop surface, and away from the fire source Gas Conversion Operating Instructions Figure 14 Gas type...
- Page 14 Test the outlet pressure, the pressure is required to be 10 ± 1in wc. If it cannot meet the scope of the requirements, need to unscrew the pressure regulator nut as Figure 18, rotate slightly to adjust the white plastic parts inside the pressure regulator. Ignition test requires that the burner can be lit in 5 seconds normally, after 1 minute the flame is stable, there should be no liftedflame and yellow fire.
-
Page 15: Figure
Please, ensure that, once the gas cooktop is installed, it is easily accessible for the engineer in the event of a breakdown. WHEN THE GAS COOKTOP IS FIRST INSTALLED Once the gas cooktop has been installed, it is important to remove any protective materials, which were put on in the factory. -
Page 16: Figure
For model: 34GC5B90A, 34GC5B90C, For model: 36GC5B90S 34GC5L90A, 36GC5L90I Figure 20 Figure 21 Electrical connections Any electrical work required to install this gas cooktop should be carried out by a qualified electrician or competent person. Check the last letter of your model to know the electrical supply type: A is for AC,D is for DC. See PAGE 1 to check the electrical supply of your model The GAS COOKTOP MUST BE EARTHED If the cooktops to be connected to a 120V, 60 Hz AC electrical supply. - Page 17 Figure 24(for the appliance with five burners) Use with D.C battery When your cooktop is the one fitted with D.C supply device only, you are suggested to use one 1.5V battery. Be sure that the battery is well fixed then you can follow the “Lighting” procedure. Take off the battery if you won’t use the cooktop for a long time.
- Page 18 Simply fill in the fields below and print form. Send Completed Form Customer Service:(888)-682-8882 Empava Appliances Inc. Warranty/ Registration Dept. 15253 Don Julian Rd City of Industry,CA,91745 WARRANTY CARD PLEASE READ AGREEMENT BEFORE SIGNING Click Here Keep this copy for yourself.
