    FPI M FPI Mag 3000 Battery Powered Electromagnetic Flow Meter Quick Start Installation Guide 30127-07 Rev. 1.0 13SEP2024 About This Quick Start Guide This quick start guide is designed to provide installation instructions when the location of the sensor installation has been predetermined.
  • Page 3: Verify Contents Of Shipping Box

    FPI M 1. Verify Contents of Shipping Box 2. Verify Flow Meter Serial Numbers Upon receiving the meter, unpack the contents of the Verify the system serial numbers on both the sensor and shipping box and verify that the items in listed below are converter match to ensure a properly calibrated system.
  • Page 4: Sensor Installation Location

    FPI M 6. Install Pipe Valve 4. Sensor Installation Location WARNING! Pressurized pipes should only be hot This Quick Start Guide is designed to provide installation tapped, cut, or drilled by qualified personnel using high instructions when the location of the sensor installation has quality saddles, valves and stainless steel nipples.
  • Page 5: Connect Sensor On Pipe Valve

    FPI M 8. Connect Sensor on Pipe Valve The sensor assembly uses a compression seal, which keeps the sensor watertight when the pipe is under pressure. Care must be taken when installing the sensor to avoid leaks. Visually inspect all elements of the installation to ensure they are structurally sound and of high quality materials, including Bottom Plate...
  • Page 6: Inserting The Sensor

    FPI M 10. Inserting the Sensor Follow the steps below to insert the sensor probe into the pipe. If you disassembled and reassembled the compression seal, hand tighten the compression seal bolts and nuts. DO NOT FULLY TIGHTEN THE COMPRESSION SEAL BOLTS AND NUTS. If you did not disassemble the compression seal, proceed to step 2.
  • Page 7: Installing The Short Retaining Rods

    FPI M 10. Installing the Short Retaining Rods After the sensor has been inserted and the load adjusted, shorter retaining rods can be installed and the longer ones removed. This will make the sensor more compact. Protective Caps IMPORTANT: The long retaining rods are matched to each sensor and are Captive required for the removal of the sensor.
  • Page 8: Connect Sensor Outputs To Converter

    necessary, secure the cable so that it does not fall Cable Cover Secure rope or snake to this Carefully pull the rope or snake until the sensor cable Rip Wire back through the conduit. area of the cable cover end clears the conduit. Remove the cable cover by pulling the rip wire.
  • Page 9 LTRA INTERNAL WIRE CONNECTION FPI M Wiring Diagrams TERMINAL BLOCK ASSIGNMENTS TERMINAL BLOCK ASSIGNMENTS Coils Harness Terminal Port Wire Color YELLOW Black BLACK Electrodes Harness Terminal Port Wire Color GREEN BARE WIRE Green WHITE Bare wire White Pulse Output Harness Terminal Port Wire Color...
