- Page 1 Installation Instruction LH6500 Version: 1.0 Date: Jun. 2018...
-
Page 2: Before Installation
Before Installation Lock Diagram... -
Page 3: Packing List
Packing List... -
Page 4: Door Preparation
Door Preparation 1. Check door thickness; prepare proper screws and spindles. Door Thickness D Spindles G Spindle I Screws 40 - 50 mm 30 mm 75 mm 25 mm Note: If the door is thicker than 40-50 mm,this lock shall not be applicable. 2. - Page 5 Cautions 1. New lock is defined as always open mode until it is locked once by mifare card. 2. Please swipe authorised card, time sync card, room card at first for the new lock. 3. The lock is equipped with mechanical keys for manual unlocking. Remove the mechanical keys from the package and keep them in a safe place.
-
Page 6: Installation
Installation 1. Drill holes on the door 2. Remove the mortise latch plate (J) center line of the handle backset 62.5 mm Note 1: Align the template along the vertical center line of the mortise (H) at the desired handle height, and tape it to door. Note 2: Mark the holes first, then start drilling. - Page 7 3. Install mortise (H)
- Page 8 4. Install lock cylinder (C) 5.Install spindle (D) and stud (B) Note: Ensure the two triangles are in horizontal alignment.
- Page 9 6. Install outdoor unit (A) 7.Install spindle (G) and (D)
- Page 10 9. Install the battery (P) and 8.Install indoor unit (N) battery cover (Q)
- Page 11 10. Mark and drill holes for strike 25 mm...
- Page 12 11. Test Lock by mechanical key (S) Step1: Remove the cover on the key hole with a hook ( T ). Step2: Insert mechanical key (S) into the key hole and rotate it at 90°.
- Page 13 © Copyright 2018. ZKTECO CO., LTD. ZKTeco Logo is a registered trademark of ZKTeco or a related company. All other product and company names mentioned are used for identification purposes only and may be the trademarks of their respective owners. All specifications are subject to change without notice. All rights reserved.
